Kenwood Excelon KFC-XP184C

7" component speaker system

Save $50 when you purchase
a select $139+ Kenwood stereo along with a select $139+ Kenwood stereo along with two pairs of select Kenwood speakers two pairs of select Kenwood speakers
Zoom
  • Kenwood Excelon KFC-XP184C

    Front

  • Kenwood Excelon KFC-XP184C

    Back

  • Kenwood Excelon KFC-XP184C

  • Kenwood Excelon KFC-XP184C

  • Kenwood Excelon KFC-XP184C

  • Kenwood Excelon KFC-XP184C

  • Kenwood Excelon KFC-XP184C

    Right



Our take on the Kenwood Excelon KFC-XP184C

by John Pollard
Kenwood

Why install component speakers?

A component speaker system gives you the best possible performance from your car audio system. A system consists of separate woofers, tweeters, and crossovers, each designed to cover one specific range of frequencies. As separate components, the woofer can move freely to deliver more powerful performance, while the tweeter can be custom-mounted in a better spot up closer to your ears, revealing a whole new world of detail. Separate crossovers are far superior to the simple filters wired into full-range speakers, so the components work together for smoother, more focused sound.

Big, big woofers
The Kenwood Excelon KFC-X184C component speaker system features a huge 7" woofer, packed into a frame that will still fit into the factory openings of many Dodge, GM, and Toyota vehicles (some cars may require slight modifications). A bigger cone moves more air, so your music can have the fullness and punch you miss with most factory speakers. A diamond-array pattern etched into the cone increases its strength for improved dynamic response and lower distortion. The rubber surround resists weathering, providing reliable support that keeps your music playing, no matter what.

Sweet sound from silk tweeters
The separate 1" silk dome tweeters deliver all the high-frequency details smoothly, while special-design circuitry and powerful, lightweight magnets make these tweeters extremely accurate without sounding harsh. Kenwood includes multi-purpose adapter brackets that help the oversized woofers to fit in some Dodge, GM, or Toyota vehicles. Grilles are not included; factory grilles are appropriate for most installations.

See more info on this item

Highlights:

  • component speaker system includes 2 woofers and 2 tweeters with inline crossovers
  • brackets included for 6-3/4" and 6"x9" locations
  • Diamond Array Pattern carbon-polypropylene woofer
  • butyl rubber surround
  • 1" silk dome tweeter with neodymium magnet
  • power range: 6-80 watts RMS (280 watts peak power)
  • frequency response: 63-18,000 Hz
  • sensitivity: 86 dB
  • depth: 2-3/8"
  • warranty: 2 years
  • Our 60-day money-back guarantee

Hands-on research from the Crutchfield Labs (what are the Labs?)

Features and Specs
General
Speaker Size
Loading...
7
Design
Loading...
2-way
Tweeter Design
Loading...
1" Dome
Tweeter Composition
Loading...
Silk
Woofer Composition
Loading...
Carbon/Polypropylene
Woofer Surround
Loading...
Rubber
Parts Warranty
Loading...
2 Years
Labor Warranty
Loading...
2 Years
Specifications
Sensitivity
Loading...
86 dB
Frequency Response
Loading...
63 - 18k Hz
RMS Power Range (Watts)
Loading...
6-80
Peak Power Handling (Watts)
Loading...
280
Impedance (Ohms)
Loading...
4
Top-mount Depth (Inches)
Loading...
2 3/8
Bottom-mount Depth (Inches)
Loading...
N/A
Cutout Diameter or Length (inches)
Loading...
6
Product Research
What's in the box?

Download owner's manual

  • Two Woofers
  • 2 Tweeters (each has a 5" Length of wire attached)
  • 2 Flush-mount tweeter housings (installed on tweeters)
  • 2 Flush-mount retaining clips
  • 2 OEM tweeter mounting brackets
  • Two 6x9 Adapter brackets (Dodge)
  • 2 Multi-purpose adapter brackets (include GM and Toyota applications)
  • Two 29" Tweeter wires with integrated crossovers
  • Two 11" Woofer wires (each has quick-slides on one end and bare wire on the other)
  • Eight 3/4" Self-tapping screws
  • Eight 3/8" Self-tapping screws
  • Four 5/8" Self-tapping screws
  • 2 Wing nuts
  • 4 Speed clips
  • Adhesive backed foam gaskets
  • Instructions (English/ French/ Spanish/ Portuguese)
  • Warranty information
  • Tweeter templates on box

Our Product Research Team

At Crutchfield, you'll get detailed, accurate information that's hard to find elsewhere. That's because we have our own in-house Product Research team — they open the box, verify contents, check the owner's manual, and record dimensions, features and specs. We stay on top of new products and technologies to help people make informed choices.

Features

Woofers: The woofers are oversized for a fuller sound quality than typical factory speakers. The Carbon/Polypropylene cones and rubber surrounds are durable, designed to withstand the harsh automotive environment.

Custom Brackets: The KFC-XP184C woofer is designed as a factory replacement speaker and includes adapters compatible with many GM, Toyota, and Dodge vehicles (one bracket adapts to a 6x9 opening, the other is a multi-purpose bracket and is scored for trimming to fit several applications). Please refer to the Crutchfield Car Selector to confirm fit for your vehicle.

Tweeter Mounting Options: The tweeters can be flush mounted using the supplied housings and metal retaining-clips. Once installed the tweeters can pivot in the housing, so their angle can be adjusted to obtain a better soundstage. The tweeters can also be top or bottom mounted in a factory tweeter location using the included OEM brackets. The tweeters cannot pivot when installed in the OEM brackets. Once mounted in the appropriate housing, the tweeters have these dimensions:

  Flush Mount Factory Top Mount (remove bottom mount flanges) Factory Bottom Mount (remove top mount flanges)
Mounting Depth 1.25" 0.58" (screw depth) 1.125"
Mounting Height 0.721" 0.893" 0"
Cutout Diameter 1.76" N/A N/A
Frame Diameter 2.084" 1.691" 1.691"
Frame Width (w/flange) N/A 2.675" 2.675"

Crossover Network: The system features low-pass crossovers wired to the woofer terminals and attached to the speaker baskets. A high-pass crossover is integrated into each included tweeter wire. The input end of the tweeter wire (female quick slides) attaches the the woofer terminal in parallel with its input. The output end of the tweeter wire (one male and one female quick slide) mates to the wire attached to the tweeter.

Warranty Note: Although the information included with these speakers indicates a 1-year warranty, they are actually covered by the Kenwood eXcelon 2-year warranty.
