Pioneer TS-SW2002D2

Shallow-mount 8" subwoofer with dual 2-ohm voice coils

Zoom
  • Pioneer TS-SW2002D2

    Front

  • Pioneer TS-SW2002D2

    Back

  • Pioneer TS-SW2002D2

Crutchfield OMC logo
We don't check this item for fit or compatibility.


Our take on the Pioneer TS-SW2002D2

by Bob Bihlmayer
Pioneer

What's a component sub and why would I want one?

A component sub is simply a speaker that's designed to reproduce bass once it's installed in a compatible enclosure. Think about the impact of a movie soundtrack in a big theater or even in your own home HDTV setup. A component sub can add the same kind of power to the music in your car. And a car sub is not all about the boom that you hear on a street corner (although that's cool too) - you can pair a component sub with your choice of enclosure to get bass just the way you like it, from tight and punchy to fat and loose. And once you experience music in your car with a well-tuned subwoofer, you'll never go back.

A shallow-mount sub that rocks

Pioneer's TS Series shallow-mount subs bring great bass to vehicles where conventional subs won't fit. Their low profile allows the use of slender enclosures that'll fit behind a truck seat or any tight space while delivering the bass performance you need. The TS-SW2002D2 8" shallow-mount sub handles up to 150 watts RMS with a mounting depth of just 2-5/8".

Mica-injected molded resin cone

The TS-SW2002D2 features an oversized cone made of mica-injected molded resin that moves more air and delivers accurate bass. The dual 2-ohm voice coils allow you to wire the sub for 1- or 4-ohm impedance. The sub works best in a small sealed enclosure, making it ideal for those tight spaces in today's smaller vehicles. Pioneer recommends their UD-SW200D downfiring shallow subwoofer enclosure for use with this sub.

See more info on this item

Highlights:

  • 8" shallow subwoofer with dual 2-ohm voice coils
  • mica-injected resin cone
  • handles up to 150 watts RMS (600 watts peak power)
  • works in free-air applications
  • frequency response: 20-200 Hz
  • sensitivity: 86 dB
  • mounting depth: 2-5/8"
  • box volume: 0.5 cubic feet
  • warranty: 1 year
  • Our 60-day money-back guarantee

Hands-on research from the Crutchfield Labs (what are the Labs?)

Features and Specs
Size
Loading...
8 -inch
Impedance
Loading...
2 ohms
Cone Material
Loading...
Mica-injected IMPP
Surround Material
Loading...
Elastic Polymer
Ideal Sealed Box Volume (cubic feet)
Loading...
0.5
Ideal Ported Box Volume (cubic feet)
Loading...
0.5
Port diameter (inches)
Loading...
3
Port length (inches)
Loading...
10
Free-Air
Loading...
Yes
Dual Voice Coil
Loading...
Yes
Sensitivity
Loading...
86 dB at 1 watt
Frequency Response
Loading...
20 - 200 Hz
RMS Power Range (Watts)
Loading...
50-150
Peak Power Handling (Watts)
Loading...
600
Top Mount Depth (inches)
Loading...
2 11/16
Bottom Mount Depth (inches)
Loading...
N/A
Cutout Diameter or Length (inches)
Loading...
7
Vas (liters)
Loading...
3.8
Fs (Hz)
Loading...
65
Qts
Loading...
0.98
Xmax (millimeters)
Loading...
2.8
Parts Warranty
Loading...
1 Year
Labor Warranty
Loading...
1 Year
Product Research
What's in the box?

Download owner's manual

  • One 8" Pioneer shallow mount subwoofer
  • Six 1-1/8" Self-tapping screws
  • Adhesive backed foam gasket
  • Manual (English/ French/ Spanish/ Portuguese)
  • Warranty information

Our Product Research Team

At Crutchfield, you'll get detailed, accurate information that's hard to find elsewhere. That's because we have our own in-house Product Research team — they open the box, verify contents, check the owner's manual, and record dimensions, features and specs. We stay on top of new products and technologies to help people make informed choices.

Features

Shallow Mount Woofer: Pioneer's Shallow-Mount subwoofers are designed to provide installation options for a broad range of vehicles. They can be mounted behind or under the seats of many vehicles. The TS-SW2002D2 has a Mica reinforced IMPP (Injection Molded Polypropylene) composite cone. The process of bonding reinforced pulp to the back of the cone improves its damping capability and eliminates excess vibration.

Dual 2-ohm Voice Coils: This woofer features two 2-ohm voice coils that offer wiring flexibility. When the voice coils are wired in parallel, the woofer presents a 1-ohm load. When the voice coils are wired in series, the woofer presents a 4-ohm load.

Terminals: The spring post terminals will accept pin connectors, single banana plugs, or bare wire up to 10 gauge.

Sealed Box Volume: Sealed is the preferred enclosure type for theTS-SW2002D2. The sealed box sizes recommended by Pioneer range from 0.15 ft³ to 0.5 ft³; with 0.5 ft³ being the ideal size.

Vented Box Volume: The vented box sizes recommended by Pioneer range from 0.25ft³ to 0.5 ft³; within this range the ideal size is 0.5 ft³ with a single 3" diameter x 10" long port.

Bandpass Box Volume: The bandpass box sizes recommended by Pioneer range from 0.25 ft³ per chamber to 0.4 ft³ per chamber; within this range the ideal size is 0.4 ft³ per chamber. One 3" diameter x 6.5" long port should be used in an enclosure with 0.4 ft³ chambers.

Infinite-Baffle Operation: The woofer is also optimized for infinite-baffle operation (free-air) so that it can be installed in a variety of locations, including factory woofer applications, without the need for a dedicated enclosure.


Review this product
Great Gear Giveaway rewards card

Submit a review and then enter to win a $500 rewards card

Pioneer TS-SW2002D2 Reviews

Average Customer Review:

1 people say:

Review this product:

Thanks for taking the time to share your experiences about this product. Please be sure to focus your comments on the product itself. Read our Review Guidelines for more information.

Your email won't be visible. Please use the email address that is associated with your order.
(e.g., JohnD) Your review will be signed using the display name and location
(e.g., Charlottesville, VA)

Click on a star to rate the overall product on a scale of 1-5
Rate the following specific attributes
  Value
 Sound Quality
 Ease of Use
 "Coolness Factor"
 Build Quality
1500 characters left
Attach a YouTube Review
Crutchfield Video Review Guidelines
  • Only submit videos that you made or are authorized to use.
  • Do not submit videos that contain music, video or visuals that are copyrighted and belong to someone else.
  • Please see our Review Guidelines for more information.
500 characters left
500 characters left
Filter by rating:
4 out of 5

Pioneer TS-SW2002D2

Written By gearboxrabbit, Philadelphia, PA on Monday, July 28, 2014
Crutchfield Customer Review (What's this?)

I put this sub in my 2007 Civic Si sedan. I used the free-air application and installed it in the rear deck. Boy was I disappointed. It was marginally better than the stock system with 50% of my music selections and worse the rest of the time. The rear deck rattled most of the time so I had to keep turning the sub down. I took a chance and ordered the enclosure made for this sub, the $59 Pioneer UD-SW200D. What a pleasant surprise - blown away by the performance of the sub now! I am very pleased with the overall sound. The enclosure isn't much larger than a shoe box but it puts out solid, clean bass. This setup is made for the listeners in the car - so it won't attract much attention from those outside the vehicle. I am using a Kicker 11DX600.5 amp.
Pros:
Compact and space saving. Excellent bass.
Cons:
None.
2 out of 2 people found this helpful
