Rockford Fosgate R2S-1X12

Sealed truck-style enclosure with with one 12" Prime subwoofer

Zoom
  • Rockford Fosgate R2S-1X12

    Front

  • Rockford Fosgate R2S-1X12

    Back

  • Rockford Fosgate R2S-1X12

  • Rockford Fosgate R2S-1X12



Our take on the Rockford Fosgate R2S-1X12

by John Pollard
Rockford Fosgate

Enclosed Subwoofers 101

An enclosed subwoofer is a box with a subwoofer already installed. The advantage to buying an enclosed sub is that the manufacturer made the sub, then designed and built the box as a perfect match, so you'll get the best possible performance. Every enclosed sub has a maximum RMS power handling rating, so pair it with an amp with a similar RMS power rating to get the best performance.

Big bass in a tight space
Rockford Fosgate's Prime Series R2S-1X12 shallow sub enclosure lets you have big bass in your vehicle without taking up too much space. Coming in at 5-1/4" deep, this box was made with the regular cab truck owner in mind. Rockford Fosgate built each enclosure with 5/8" thick medium-density fiberboard protected by rugged black carpeting so they're tough too.

Prime Series R2S-1X12

Powerful woofer
The enclosure comes loaded with one Prime R2SD4 sub that handles up to 250 watts RMS, wired for 2-ohm impedance. The sub features a mica-injected polypropylene cone with a poly-foam surround for accurate bass that you can feel.

See more info on this item

Highlights:

  • sealed truck-style enclosure with one 12" Prime subwoofer
  • 5/8" medium density fiberboard construction covered with heavy-duty carpet
  • 2-ohm total impedance
  • power handling: 100-250 watts RMS (500 watts peak power)
  • frequency response: 29-250 Hz
  • sensitivity: 85 dB
  • 27-1/4"W x 13-1/2"H x 5-1/4"D1 x 3-3/8"D2
  • warranty: 1 year
  • Our 60-day money-back guarantee

Hands-on research from the Crutchfield Labs (what are the Labs?)

Features and Specs
General
Woofer Size (inches)
Loading...
12
Woofer Material
Loading...
Mica injected poly
Enclosure Type
Loading...
Sealed
Color
Loading...
Black
Pieces in System
Loading...
1
Width (inches)
Loading...
27-1/4
Height (inches)
Loading...
13-1/2
Depth (inches)
Loading...
5-1/4
Second Depth (inches)
Loading...
3-3/8
Connector Type
Loading...
Spring post
Frequency Response
Loading...
29-250 Hz
Power Range (Watts RMS)
Loading...
100-250
Maximum Wattage
Loading...
500
Sensitivity
Loading...
85 dB
Impedance
Loading...
2 ohms
Parts Warranty
Loading...
1 Year
Labor Warranty
Loading...
1 Year
Product Research
What's in the box?

Download owner's manual

  • Sealed enclosure loaded with one 12" woofer
  • 2 Mounting brackets
  • Four 3/4" Self tapping screws
  • Installation and operation instructions

Our Product Research Team

At Crutchfield, you'll get detailed, accurate information that's hard to find elsewhere. That's because we have our own in-house Product Research team — they open the box, verify contents, check the owner's manual, and record dimensions, features and specs. We stay on top of new products and technologies to help people make informed choices.

Features

Enclosure: The Rockford Fosgate Prime R2S-1X12 houses a single R2SD4 12" subwoofer. The sealed enclosure is constructed of 5/8" Medium Density Fiberboard (MDF) and covered with black high density carpet. There is a pair of high current spring posts on the right side (when facing the subwoofer); the terminal will accommodate pin connectors, single or dual banana plugs, or bare wire up to 10 gauge. The subwoofer's dual voice coils are wired in parallel and present a 2-ohm load to your amplifier.

Voice Coil Former: The R2SD4-12's voice coil former is made of anodized aluminum to provide superior heat dissipation. Unlike traditional plastic, aluminum acts as a heat-sink to quickly dissipate thermal build-up on the voice coil. This keeps the subwoofer cool and improves durability.

Stitched Tinsel Leads: The multipoint, periodic stitched technique of attaching the tinsel lead wires to the spider spreads stress and strain over a greater area, reducing fatigue and the possibility of shorting. This significantly improves the reliability and performance of the subwoofer.

Stamped Steel Basket: The R2SD4-12 subwoofer features a stamped steel basket for added rigidity.

CEA-2031 Compliant: The power handling specifications for the R2SD4-12 subwoofer conform to CEA-2031 industry standards. This means the subwoofer has the capacity to handle power under continuous demand, not instantaneous power handling, that over time, can damage voice coils.


Review this product
Great Gear Giveaway rewards card

Submit a review and then enter to win a $500 rewards card

Rockford Fosgate R2S-1X12 Reviews

Average Customer Review:

3 people say:

Review this product:

Thanks for taking the time to share your experiences about this product. Please be sure to focus your comments on the product itself. Read our Review Guidelines for more information.

Your email won't be visible. Please use the email address that is associated with your order.
(e.g., JohnD) Your review will be signed using the display name and location
(e.g., Charlottesville, VA)

Click on a star to rate the overall product on a scale of 1-5
Rate the following specific attributes
  Value
 Sound Quality
 Ease of Use
 "Coolness Factor"
 Build Quality
1500 characters left
Attach a YouTube Review
Crutchfield Video Review Guidelines
  • Only submit videos that you made or are authorized to use.
  • Do not submit videos that contain music, video or visuals that are copyrighted and belong to someone else.
  • Please see our Review Guidelines for more information.
500 characters left
500 characters left
Filter by rating:
4 out of 5

Quality

Written By Zack, Merced California on Saturday, January 25, 2014
Crutchfield Customer Review (What's this?)

Very reasonable priced already enclosed subwoofer. No, it's not the hardest hitting bass available, but it definitely puts a nice clean sound throughout my single cab f150
Pros:
Thin profile box, already enclosed, very clean sound especially when the volume is higher than normal listening level.
Cons:
Could hit harder if I had to choose a con.
1 out of 1 people found this helpful
Was this review helpful?    Yes | No
"Coolness Factor"
Build Quality
Ease of Use
Sound Quality
Value

4 out of 5

satisfied

Written By CraigM, Hartford, Michigan on Saturday, July 13, 2013
Crutchfield Customer Review (What's this?)

Pretty good unit for the price. Sounds good using a Kenwood 600 watt amp. I don't like it quite as well as the Kenwood that I replaced due to size limitations in a new vehicle, but it will do. Sound is very "tight" and I like that but maybe a little too tight.
Was this review helpful?    Yes | No
"Coolness Factor"
Build Quality
Ease of Use
Sound Quality
Value

5 out of 5

Works for me

Written By N, Denver, CO on Saturday, May 11, 2013

It took a bit of cutting and hacking to remove the jack mounts from behind the seats (I used a hacksaw to cut it to roughly 1/6 inch then a grinder to grind it down to be level with the truck, I used a crowbar to pull out the riveted mounts), along with pulling out the back carpet (just pull out both plastic pegs and bend it in the middle to get it out), but once I did this box fit in my '96 Single-cab Ranger. It's quite a tight fit, but it sounds good. It did lower the available space in the cab a bit, but not significantly.

I'm quite happy with the audio quality of the subwoofer, and the fact that it's a 12" that fits in a tiny truck cab.

Just to note, there is literally no space between the seat and the sub box. The sub box holds the seats in roughly a straight up position and the seats have to be pushed to latch upright. In hindsight I wish I would've gone with the 10" for my truck, but this one did fit and it does sound awesome.
Pros:
Fits in my truck
Cons:
Still a little big, wish I would've gone with a 10".
1 out of 3 people found this helpful
Was this review helpful?    Yes | No
"Coolness Factor"
Build Quality
Ease of Use
Sound Quality
Value
