About the Yamaha AVENTAGE RX-A780
Bring movies and music to life
Bring movies and music to life
The Yamaha RX-A780 delivers thrilling home theater sound with tons of music choices. This 4K-compatible receiver has decoding for Dolby Atmos® and DTS:X™ for 360-degree surround sound with overhead effects. Upscaling for HDMI sources lets you enjoy more of your video content in stunning Ultra High Definition. You can expand your system with two HDMI outputs for watching the same video source on two different screens, plus wired and wireless options for playing music in different rooms.
Wireless surround sound? Yes, please
Want fewer wires in your life? Add MusicCast 20 or MusicCast 50 wireless streaming speakers. This receiver allows them to be connected as wireless surround speakers in a 5.1 home theater system with traditional wired front and center channel speakers.
The AVENTAGE difference
For their AVENTAGE-series receivers, Yamaha uses custom-designed parts with anti-resonance technology to reduce distortion caused by vibration. A rigid H-shaped frame adds stability to cut out chassis vibration almost completely. A specially designed fifth foot at the center of the receiver's base dampens internal and external vibrations, and an aluminum front panel further reduces resonance to maximize sound quality.
The RX-A780's meticulous construction, symmetrical amplifier layout, and low-jitter digital circuitry all work together to give you accurate sound with precise stereo imaging and a wide, natural soundstage.
For music lovers
This receiver can play a variety of high-resolution audio formats through its front-panel USB port or from a networked computer. And if you're a vinyl lover, a phono input provides an easy connection for your turntable.
Flexible speaker configurations for a custom sound system
The RX-A780 has connections for nine speakers, and it can power up to seven speakers at a time. You can set up a standard 7.2-channel surround sound system, or you can go with 5.2-channel surround sound and use the rear surround channels as height channels in a 5.1.2 Atmos system.
You can also use the rear surround channels to bi-amp your main front speakers for more powerful sound, or reassign them to set up a wired stereo system in a separate room. When Zone 2 is powered on, Yamaha's Intelligent Amp Assign feature automatically redirects the power for the two surround back channels to your stereo setup in Zone 2, giving you five-channel surround sound in the living room.
A world of wireless listening options
Built-in support for streaming services like Spotify®, TIDAL, and Pandora® lets you play and control your favorite music directly through the receiver. Apple® AirPlay® lets you stream from a compatible iOS® device, and Bluetooth adds even more streaming flexibility.
MusicCast lets you listen the way you want
Yamaha's MusicCast technology makes it easier than ever to set up a whole-home wireless music system. You can add audio playback in up to nine additional rooms with compatible Yamaha wireless speakers and sound bars.
MusicCast lets you stream music from your personal collection, internet radio, and streaming services. You can also play Bluetooth sources, sound from your TV, and even CDs and vinyl. The free MusicCast Controller app makes it easy to access your music and control what you have playing in different rooms.
"Alexa, turn up the volume"
Alexa voice control integration means you only have to ask when you want to play music, control volume, or turn the receiver on and off. Alexa can even help you link or unlink rooms in your multi-room MusicCast system.
Power and Processing:
- 7-channel amplifier
- 95 watts per channel into 8 ohms (20-20,000 Hz) at 0.06% THD, with 2 channels driven
- Dolby® and DTS® surround sound decoding
- Dolby Atmos and DTS:X for more enveloping home theater sound
- supports a 5.1.2 Atmos setup with multiple placement patterns for height channels
- upscales standard-definition video signals to HD and 4K Ultra HD (via HDMI inputs only)
- MusicCast Surround lets you add MusicCast 20 or MusicCast 50 speakers to create a 5.1-channel setup with wireless rear surrounds
- YPAO (Yamaha Parametric Room Acoustic Optimizer) automatic speaker calibration with Reflected Sound Control to deliver more accurate surround sound across different listening levels (microphone included)
- Cinema DSP modes add richness and depth to music and movie soundtracks
- Virtual Cinema Front simulates surround sound effects when five connected speakers are all placed in the front of the room
- Adaptive Dynamic Range Control limits the volume level on sound effects and commercials for more discreet late-night listening
- Dialogue Lift and Level Adjustment for clearer, louder dialogue while watching movies and shows
Digital and Streaming Music Options:
- built-in Wi-Fi for listening to music from a networked PC, free internet radio, and music services
- Spotify Connect lets you play Spotify's streaming music library through the receiver, controlled by your smartphone or tablet (requires Spotify app and a premium subscription)
- support for TIDAL and Deezer
- built-in Bluetooth for wireless music streaming from a compatible phone, tablet, or computer
- Apple® AirPlay® for streaming music from an iPhone®, iPad®, iPod touch® or computer running iTunes®
- MusicCast wirelessly connects compatible Yamaha components for whole-home audio
- plays high-resolution digital music files via USB storage device or a networked computer (PCM up to 24-bit/192kHz resolution; DSD up to 11.2 MHz)
- works with Amazon Alexa-compatible voice control assistants
- dual-room/dual-source output
- powered and line-level stereo audio output for 2nd room (using powered 2nd-room output allows 5.2 home theater in main room)
- Intelligent Amp Assign automatically redirects surround back channels in Main zone to Zone 2 speakers when Zone 2 is powered on
- HDMI audio sources and high-res DSD files cannot be output to Zone 2
Audio Performance Features:
- four 32-bit/384kHz Burr-Brown digital-to-analog converters
- surround back speaker channels re-assignable for bi-amping compatible front left and right speakers
- Pure Direct mode switches off front-panel display, tone controls, and DSP circuitry for cleaner sound with analog audio sources
- Compressed Music Enhancer improves sound quality of Bluetooth streams, MP3s, and other digital music files
- HDMI audio/video switching: 5 in, 2 out
- HDCP 2.2 technology ensures compatibility with 4K Ultra HD sources and TVs
- HDR-compatible for extended picture contrast and brightness with compatible 4K TVs and HDR-encoded content
- supports HDR10, Dolby Vision™, and HLG
- component video input
- composite video input
- digital audio inputs: 2 optical and 2 coaxial
- preamp outputs for 2 powered subwoofers
- 4 analog stereo audio inputs (including front-panel 3.5mm stereo input)
- phono input for use with a turntable
- Ethernet port for network connection
- front-panel USB port for audio playback from USB flash drives
- outputs for 9 speakers (Front L/R, Center, Surround L/R, Extra SP1 L/R, Extra SP2 L/R)
- receiver can power a maximum of 7 channels at once
- remote input/output (IR) and 12 volt-trigger output for use with external controllers
- 4K/60p and 3D video pass-through
- free Yamaha MusicCast Controller app lets you use your Apple or Android device as a Wi-Fi® remote
- four SCENE presets for one-touch power-up, source selection and DSP recall
- full-color on-screen display
- HDMI standby pass-through allows source switching without powering up receiver
- AM/FM tuner
- remote control
- full-size headphone jack
- detachable power cord
- 17-1/8"W x 6-3/4"H x 15"D (9-3/4"H with Wi-Fi antennas raised)
- weight: 24.3 lbs.
- warranty: 3 years
- Our 60-day money-back guarantee
- MFR # RX-A780BL
What's in the box:
- 7.2ch AV receiver
- 6.5' AC power cord
- Wireless remote control (RAV570)
- 2 "AAA" batteries
- YPAO microphone
- 2 WLAN/Bluetooth antennas (installed)
- AM loop antenna
- FM wire antenna
- Quick Start Guide
- Warranty Information
- "Yamaha Worldwide Representative Offices" note
- Spotify Connect brochure
Yamaha AVENTAGE RX-A780 reviews
I bought this receiver about a year ago. Worked fine but nothing special until it would not turn on after lightly using it for about a week before the year mark of having it. I called customer service and had to take the receiver an hour away to be fixed. After checking on the status of the repair, I was informed the parts from Yamaha are on backorder and the receiver will not be fixed for 2+ months. Buyer beware! Go with another company!
Cons: broke after a year
1 of 1 found this helpful
Fantastic receiver, with an amazing amount of control over how you want your system setup. I'm currently using it in 7.1 mode for Zone 1 powering my home theatre, then I'm using Zone 2 to power outdoor speakers on my deck. I love the fact that I can go in and tinker with settings like internal power amp assignment or speaker placement to get the best sound. Throw in that it has built in support for Spotify, Pandora, Air Play and other streaming inputs plus as well as the ability to control both zones from my phone makes this the coolest piece of A/V equipment I've ever owned!
0 of 0 found this helpful
Excellent sound and picture quality. I matched this with Polk Blackstone TL250 and Polk sub PSW111 and it has brought my speakers to life! I replaced a 10 year old Sony and was surprised at the difference in quality and responsiveness of the rear speakers. I'm also very happy with the quality of the video routing through the receiver. On my old receiver I found that intense action scenes with dynamic video and loud audio would be slightly suppressed, but this receiver can handle it all with no lag whatsoever. I was told by a Crutchfield agent that Yamaha was very proud of their processing chips used in their Aventage line. I have not used all the functions of this but it has been a great fit so far its been great. I would recommend this high quality and well built receiver.
Pros: Sounds, video and computer processor
Cons: Slight lag time with Bluetooth and App is just ok.
1 of 1 found this helpful
0 of 1 found this helpful
I needed a solid replacement for an older receiver, and in addition to multi-channel functionality was looking for wireless and/or bluetooth capabilities. This receiver is already rewarding me with great sound and flexible usage of several sound sources. Also, I want this receiver to last for many many years, and I trust Yamaha audio from previous experience for long lasting, enduring operation.
Pros: Very good sound; ease of set-up; phone input; quality all around.
Cons: Though the owner's manual (which is available online, not packaged with the unit) is chock full of information, I believe it could be somewhat better designed/written/organized.
1 of 1 found this helpful
Love this receiver, I replaced a older Harmon Kardon receiver with this new Yamaha. The power and sound quality is outstanding. The ARC integration worked right away and set up was pretty smooth. II still have figured out to configure with Amazon Alexa but I am working on that....
1 of 2 found this helpful
Excellent sound with all the inputs and outputs for a great system.
Pros: Many ways to connect to music, dual zone, has bi-amp capabilities. Has pre-outs for two sub woofers and pre-amp for external amps as well.
Cons: Owners manual must be printed off line 200 pages.
0 of 0 found this helpful
This receiver rocks, great sound through. Out the house and awesome for movies!
0 of 0 found this helpful
Unit works great but the directions on hooking it up and then setting it up are really poor... I had to look it up online...
1 of 1 found this helpful
Great mid price range receiver. Easy to use and set up. Easy to add components.
Pros: Excellent sound
0 of 0 found this helpful
After much research, I chose the Yamaha RX-A780. Glad I did. The unit has more usable sound features and a really good audio calibrator. I thought it would crossover my front speakers lower, but due to the sound reflections in our mobile home this R.S.C. feature made the sound wonderful. No peaks or dips in the bands! It is really nice for music too, Satellite and Blu-Ray sound are much improved. I upgraded from a Harman/Kardon, and while it has beautiful sound, this Yamaha is an improvement, I cannot really locate where the speakers are individualy, with the Harman I could tell when sound panned. One can custom label all inputs if one chooses, but due to CEC they are labeled automatically first. Nice. I use Klipsch Gallery speakers and the sound is not overly crisp. I was surprised. The Crutchfield advisor I spoke with was correct in telling me that the Denon I was considering might be too soft sounding, Above all, this Yamaha does not sound abundantly digital. The GUI has a very small learning curve, and I picked it up quickly. The build is nice and sturdy, metal or aluminum dials might be nice, but not needed. they feel accurate. It arrived fast and in perfect condition! A big thank you to Archer@Crutchfield for all the correspondence and comments! It's a win. Now I will let the break-in reveal it's attitude!
Pros: Quality feel, Sound, R.S.C., Soounds great with music, broadcast and movies.
Cons: Uh....I don't know.
2 of 2 found this helpful
This is truly a great receiver at this price point. I've owned many Yamaha receivers and upgraded a RXV-1800 that was 10 years old with this one. It is packed with useful features and new technology. The sound is excellent as well and it was easy to install and make all the connections.
Pros: Great sound and features. Easy to connect.
Cons: Remote is a little cluncky and has rather small buttons.
1 of 1 found this helpful
Difficult set up. Zone 2 function was not ideal for open concept homes; noticeable delay in adjacent rooms even when using "party mode" and manually adjusting delay settings. Also not ideal for Apple users as does not support AirPlay 2 devices. This limits your flexibility to set up wireless whole house system unless you utilize Yamaha's MusicCast line of products. Ultimately traded it in for Denon AVR - S90H which is a much better fit for my set up. Crutchfield support was amazing though.....
Cons: Difficult to set up; no AirPlay 2 support
1 of 2 found this helpful
This is a great A/V receiver. It's a "smart" device. It's connected to the internet wireless like mine is or you can use an ethernet cable. With the Yamaha Musiccast app, (free download, 23.5 mb, on your tablet or smart phone), you can connect the receiver and Musiccast surrounds to the internet and the surrounds to the amp. On the Musiccast app you can stream music direct from the internet to the Musiccast surrounds without the receiver being on. I connected my TiVo to the receiver and the display showed it is a TiVo without any input from me. The same for the DVD. It has about as much control as almost anyone would like. It took a little getting use to because of all the control possibilities. But once I did it's easy to adjust anything. The settings are shown on the TV screen in great detail including images of the speakers while the sound of the program stays on. I have 8 speakers connected to it. 2-front, 1-center, 1-subwoofer, 2 wireless Yamaha Musiccast rear-surrounds and 2- front-presence speakers. It's easy to adjust the level of each or you can use the YPAO microphone, (included), to set the levels automatically. I trust Yamaha. I already had an R-S700 receiver using it as a preamp to my Crown power amp for my stereo. Years of great service so far. I expect no less from this Aventage. Noise is nowhere to be found on either receiver. Ultra-clear highs and plenty of bass with good speakers.
Pros: Excellent sound with many preset sound possibilities. Great control of all aspects of sound. No "noise."
Cons: It may take some getting use to to easily use all the controls for some. But once that's done it's very easy.
2 of 2 found this helpful
I have a Yamaha receiver but it's old and outdated so I bought a new one and stayed with Yamaha because I'm very happy with their product. Thank you Crutchfield for helping me with all my audio purchases . ??
Pros: Sounds great, love Wi Fi and Bluetooth
0 of 0 found this helpful
My music tastes range from listening to music from the 40's on up including movie scores, easy listening, smooth jazz, country western, Italian and classic rock and my new Yamaha handles all of them to perfection especially with its ability to set your listening pleasure with its preset audio scenarios. The Receiver is easy to use and I am constantly switching from vinyl, disc, FM and Sirius. Set up was a breeze. This was a Crutchfield recommendation and it appears it was a perfect fit with my existing audio system setup. Could not be more pleased.
2 of 2 found this helpful
Absolutely amazed at how much Yamaha has advanced their AV tuner receivers. This unit replaced an existing RX-V663 so I could pass 4K ultra HD signals to my new 6" flatscreen. Setup was a breeze with the on-screen display. Glad I spent a little extra and went with the Aventage.
2 of 2 found this helpful
Control and power to spare, excellent unit .
0 of 1 found this helpful
The Yamaha A780 is the third Yamaha receiver I've had. They just keep making them better and better. The two system option is great. Bluetooth is also a very nice option, especially when you have a party and someone wants to hear a particular song. I'm still learning different things the Yamaha will do, but for right now, I am extremely happy with my purchase. River made this suggestion, she had been great to work with, we seem to have similar ideas when it comes to equipment.
1 of 1 found this helpful
Great unit. Runs the surround sound and connects to net radio easily. Links rapidly with the other Yamaha WXA and WXC units installed. Great for individual area control. Easy to install. Crutchfield has great support as well.
1 of 1 found this helpful
Great so far! Set up was easy and it didn't take long to connect all the devices to it. We haven't explored all the different aspects yet, but love the airplay and having the phono input for the record player.
1 of 1 found this helpful
The sound is tremendous. The setup was easy and I now have Pandora playing in surround sound and in a second room.
Pros: Easy speaker setup. Surround sound Pandora. Great sound in the second room.
Cons: No HDMI support for room 2 but my old Denon did not have it either.
1 of 1 found this helpful
The sound is dynamic and the video performance is superb.
3 of 5 found this helpful
Product came when promised in a blue package wrap so you could not see what it was. Good packaging. I was replacing a 9 year old 11 speaker set up with an Onkyo receiver. I had issues with HDMI syncing and the main amps went out. Awesome sound for that time frame. Due to cost trade offs I dropped back to 9 speakers. The sound and features of this system for the money is great. There are so many features-set up and configuration is not simple. Used the setup app on an iPad Pro and it really helped. The speaker configuration settings via the app worked well. Really liked being able to over ride voice settings on some of the sound fields. Also like controlling the receiver from an iPad or iphone. There are 8 quick menu keys which make it easy for family to select the right source configured with the sound field and your personal settings by knowing your button number for a source. As usual documentation could be clearer and more detailed-had to do trial and error with source and sound customization. Have not set up remote and music cast; however that is a key feature that influenced my purchase. Did I say sound from sources of satellite, tuner, blue ray an vinyl phono are awesome.
Pros: Great features and product for the price
Cons: Complex setup and configuration due to the many devices, speakers and features-probably needs some imbedded AI
5 of 6 found this helpful
This is an awesome audio device. The sound quality is incredible. Integrated apps make filling my home with rich music easy. MusicCast allows me to wirelessly sync both of my Aventage receivers with each other, as well as the MusicCast 20 speaker. The sound has ZERO sync/delay issues, making the rich sound seem like it all is a single unit. I could not be more pleased.
Pros: Amazing sound. Multi-zone. MusicCast wireless synchronization. Android app is great.
Cons: The remote is very cumbersome to work through. It is not intuitive and I found most of the hidden juicy features buried in menus.
5 of 5 found this helpful
As a long time Yamaha owner I can say with confidence, "Real Cinema surround sound in the home is ONLY delivered by Yamaha!" That's my quote based upon years of owning many other surround sound AVR's and decoders as well. Moreover, Yamaha is the only Brand to use pro electronics even in their entry level equipment. Example: Back in the day, Burr-Brown DAC's (Digital to Analog Converters) were "the" must have. Well, Yamaha uses them even in their entry level aka cheapest surround sound AVR's. This means you'll have "Audiophile" quality sound no matter the Yamaha AV you choose. Also, Yamaha AV receivers can drive even the heftiest ohm loads as they're ohm switchable. This plays out as you being able to drive the stingiest speakers without your Yamaha AVR even getting hot. Heat build up is #1 enemy to any amp or AVR. Other brands like Onkyo, Denon etc. are known to run HOT when driving 6 0hm loads are greater. If your speakers are 6 or 4 ohm load then Yamaha is the only receiver you should consider. All the facts I've laid out for you is proof positive why Yamaha is superior in longevity. While Burr-Brown DAC's are the "real deal" Yamaha also offers Sabre Pro DACs in their top shelf AVR's. Knowing that, throw in their commercial strength surround sound decoder chips. Yup, commercial strength as in Cinema grade Dolby Digital decoding. No BS! The Yamaha line delivers surround sound in the home that's as convincing as any
Pros: Unrivaled surround sound and channel separation. Hard locked left to right, ceiling to floor, front to back, sound separation that provides dizzying surround sound! True audio ventriloquism from speakers to the ears. Cinema grade Dolby surround sound!
9 of 11 found this helpful
Great so far!
4 of 13 found this helpful
2 stars because my technician says I need an indoor antenna and for that money it should have been able to perform efficiently and smoothly! In all my life my life never had to have indoor antennas for previous receivers
0 of 44 found this helpful
Excellent receiver. Returned to Yamaha after several years with a Poineer and am happy I did.
Pros: Great sound, dual zones
Cons: No HDMI to zone 2 unless in "party" mode.
3 of 6 found this helpful
I love this receiver. It has all the features I wanted and plenty of power for my speakers. I'm using it as a 5.1 system in my master bedroom and 2.0 system in my master bathroom. It was very easy to install, connect, and use. The only thing I'm having trouble with is using the Zone B speakers only but I'm sure I can figure that out with a little more research.
Pros: Easy to use, does it all.
3 of 6 found this helpful
Bought the Aventage RX-A780 to replace a Denon AVR-1913. Much improved menu and GUI on the Yamaha vs the Denon!!! Setup was also easier on the Yamaha. Pleased with the sound and customization, and the remote app is straight forward. Spotify functionality w/ remote app is responsive and a breeze. Expected it to run hotter than the Denon, but to my surprise, there is little to no difference.
Pros: Sound, Setup, Remote App, User Menu/GUI
5 of 5 found this helpful
Working great so far. My setup so far is Martin Logan 35xt speakers (2.0 system) with this receiver. I have setup in my small office but eventually want to move it to my basement. The main reason I was drawn towards this receiver is the ability to use wireless surround speakers. Eventually I plan to setup a 5.1 system with 2 ML 35xt, Martin logan center 50xt(or Martin logan 30), Martin logan 1000W sub (or ML 700W or SVS 2000SB) and 2 Yamaha MusicCast 20 rears. I connected the speakers using banana plugs on the receiver end, while using a spade plug at ML 35xt end. It has lot of juice to power the ML 35xts. I love the different programs such as Chambers, Movies etc. I mainly listen to music and it sounds awesome. In certain Queen songs I hear certain drums and bass that I never heard in any previous systems. Make sure you run the YPAO as I noticed the sound changed considerably after I ran it. One feature I really love is that even when the system is turned off (but plugged in - in standby mode), you can still get display output in your TV / monitor. It works really well because I have my computer connected to the receiver. So when I am working on computer and do not need the music system on, I can turn off the receiver but still get the output on the monitor. It prevents me from switching the hdmi input on my computer. I still need to setup the FM and AM radio. This receiver does not have multipoint YPAO which is disappointing for a receiver at this price point.
Pros: - Standby passthrough when receiver is off - Lot of power - Very good YPAO RSC - Lot of programs for different music and movie setting - Music and Movies sound great
Cons: Does not have multipoint YPAO. This means that you can only configure the settings based on one point in the room.
8 of 8 found this helpful
An excellent receiver that allowed me to expand my system to include presence speakers and support for my new 4K HD television. Sound quality is very good, and overall features are great for a receiver in this price range.
Pros: Very good sound quality. Phono input, which is missing from many other modern receivers. High level of customization via the on-screen display.
Cons: User interface for scene setup is confusing. Some remote control functions are not very intuitive - especially for family members who are only occasional users. It would benefit from an LCD display - like my old Sony had!
5 of 5 found this helpful
Very nice. As mentioned before; great picture quality. Great sound. YPAO worked well. Tech Casey helped set up Zone 2. One must set the A780 volume for Zone 2 quite high (I'm at +5.0), but it defaults to -40, so this must also be addressed in Multizone setup menu. I'm feeding Zone 2 out to a 45 year old HarmonKardon 75+ that feeds two other areas/rooms. Total system includes Dish, DVD, VHS, 2 Sony Jukeboxes, another CD player, a Cassette player, and phono. It rocks! The only thing I miss is that this unit does not have a remote that will control the off/on of the various sources, like my old one did. Must use a universal remote. (Replaced a 12 year old Yamaha RX-V559 ) Been a Crutchfield customer for many decades!
Pros: Great video and sound! Plenty of capability.
Cons: Needs a universal remote to control auxiliaries.
3 of 3 found this helpful
Very impressed with the HDMI pass thru for TV it provides a much cleaner picture than Onkyo, also the sound clarity was improved. Very happy so far with my new receiver.
Pros: Great video pass-thru
Cons: the HDMI connections are close together
3 of 4 found this helpful
More details on the Yamaha AVENTAGE RX-A780
Features & specs
Aventage Series: The Aventage line of Yamaha AV receivers is based on the audio design concept of providing a massive, full-bodied sound for movie sound effects and the accurate reproduction of music sources. By expertly harmonizing traditional and advanced technologies, every factor that affects sound quality, from materials & parts construction to circuitry layout, vibration damping, and "fine-tuning" the sound, is handled with no other thought than to achieve the best possible audio quality. As a result, every Aventage receiver has the ability to reproduce the most subtle details of high-definition sound, so that listeners can enjoy a truly high-class sound studio experience at home.
- High Drive Amp Technology: A fully discrete power amplifier helps maximize sound and minimize distortion of the receiver. The Yamaha RX-A780 AV Receiver is equipped with a 7-channel amplifier rated at 95 watts (into 8-ohms, at 20-20kHz, with 0.06% THD, driving 2 channels) which provides high dynamic power with low-impedance drive capability.
- High Purity Pre-Amplification: The Yamaha RX-A780 uses four high quality, audio-grade Burr-Brown 384kHz/32-bit digital-to-analog converters to maximize sound quality. The AV receiver also utilizes low-jitter PLL circuitry to help optimize sound imaging. The result is a more dynamic sound with greater detail and less distortion.
- Independent Power Supplies: Independent power supplies are used for the receiver's analog and digital circuitry to prevent digital noise from affecting analog circuitry. These power supplies are highly efficient and result in less power consumption in standby mode.
- Aluminum Front-Panel: The aluminum front-panel is used to effectively shield sensitive circuitry from external noise and electronic energy generated by dimmer switches, fluorescent lighting, video monitors and so on. This ensures optimum sonic performance in the widest range of installation environments.
- Advanced Design Feet: The feet of the receiver feature a newly designed, high-density structure which utilizes two different kinds of interior ribs (straight and curved) to enhance strength and damping performance. Installation stability is improved and chassis resonance is dispersed, effectively eliminating external vibration. The low-range response is enhanced, while resonance peaks in the mid- and high-range are reduced, providing dynamic sound and accurate reproduction.
- Anti-Resonance Technology: The Anti-Resonance Technology (A.R.T) Wedge is a fifth foot in the center of the unit. It dampens vibrations from the power transformer, power transistors and heat sinks, as well as vibrations that might be caused by the sound from the speakers.
Intelligent Amplifier Assignment: Intelligent Amp Assignment automatically assigns amplifier channels of the Yamaha AV receiver to certain speakers depending on what speaker layout has been selected and what content is being played back. You can connect up to nine speakers to the AV receiver and it will determine which seven speakers need amplification. You can choose from a variety of amplifier speaker layout configurations.
- 7.1ch or 5.1.2ch Surround: In this configuration, up to nine speakers (Front L/R, Front Presence L/R, Center, Surround L/R, & Surround Back L/R) can be connected to the AV receiver. When Cinema DSP 3D is on or a Dolby Atmos soundtrack is being played, the two Front Presence or Dolby Atmos speakers will be powered and not the two Surround Back speakers. When Cinema DSP 3D is off or Dolby Atmos is not playing, this situation is reversed and the Front Presence or Dolby Atmos speakers turn off while the Surround Back speakers are powered. Bi-amp and Zone 2 speakers are not available in this mode.
- Dolby Atmos (5.1.2ch) + Zone 2: In this setup, you can hook up a 5.1.2ch Dolby Atmos speaker system in the main room and a pair of speakers in Zone 2 to the receiver. When Zone 2 is off, all seven channels of your Dolby Atmos speaker system will be powered. However, when Zone 2 is turned on, power to the Front Height, Overhead, or Dolby Atmos speakers will be cut off and directed to the pair of speakers in Zone; limiting you to only 5.1ch surround in the main room. Bi-amp & Surround Back speakers are not available in this setup.
- 7.1ch + Zone 2: In this configuration, up to nine speakers (Front L/R, Center, Surround L/R, Surround Back L/R, and Zone 2) can be connected to the AV receiver. When Zone 2 is off, all seven channels will be used in the Main Zone. However, when Zone 2 is on, power to the two surround back channels will be directed to the two speakers in Zone 2 and the Main Zone will receive five channels of power. The same or different analog input sources/volume settings can be applied to both zones. Bi-amp, Front Presence, & Dolby Atmos speakers are not available in this mode.
- 5.1ch Bi-Amp: Up to five speakers (Front L/R, Center, & Surround L/R) can be connected to the AV receiver. The Surround Back amplifier channels of the AV receiver are reassigned to bi-amp the front speakers. A bi-amplification connection uses two amplifiers for one speaker. One amplifier is connected to the woofer section of a loudspeaker while the other is connected to the combined midrange and tweeter section. With this arrangement each amplifier operates over a limited frequency range, making its job easier. Zone 2, Front Presence, & Dolby Atmos speakers are not available in this mode.
Wireless Surround: You can combine this AV receiver with the upcoming MusicCast 50 or MusicCast 20 wireless streaming speakers, as well as the MusicCast Sub100 wireless powered subwoofer (all sold separately) and enjoy the convenience of creating a home theater with wireless rear speakers in a 5.1-channel system. What's more, you get stunningly realistic sound with a clean, clutter-free setup.
Note: Wireless Surround requires that the AV receiver and compatible MusicCast speakers (sold separately) be on the same wireless network. You will need to download the MusicCast Controller app onto your Apple iOS 9.0+ or Android OS 4.1+ device for setup.
YPAO Sound Optimization: This unit employs the YPAO (Yamaha Parametric Acoustic Optimizer), which automatically adjusts the output of the speakers based on placement, performance, and the room's acoustic characteristics. Yamaha's YPAO system uses a small microphone and sophisticated equalization to automatically set the best sound for any room, no matter where the speakers are. First it checks the speaker connections and phase of each speaker. Then it sends out tones which are captured by the microphone to analyze the room acoustics and sets a variety of parameters; such as the speaker size, the distance of the speakers, and even the volume level; until it achieves the best sound conditions for your room.
- R.S.C. (Reflected Sound Control) Multipoint: The receiver employs R.S.C. (Reflected Sound Control) to correct early reflections for studio-quality surround sound.
- EQ: Choose between 3 YPAO EQ modes - Natural (adjusts all speakers to a natural sound; useful when the flat setting sounds too bright), Flat (use when all the speakers in the system have similar sound characteristics), or Front (EQs the center and rear speakers to sound like the front; useful when your front speakers are better than the others in the system)
- DSP Effect Normalization: In addition, the receiver's YPAO Sound Optimization provides DSP Effect Normalization, which varies the Cinema DSP parameters according to the reflected sounds in the room.
- YPAO Volume: Human ears have less sensitivity to high and low frequencies, especially at lower volumes. YPAO Volume applies loudness EQ correction to automatically adjust high and low frequency levels as volume changes. Using the YPAO measurement results, EQ correction is optimized to your system settings and listening environment.
Note: You can also choose to manually adjust the AV receiver's speaker, crossover, & EQ settings.
Compatible Digital Audio Formats: The AV receiver supports the following stereo & multichannel digital audio formats through its HDMI jacks and optical/coax digital inputs.
|Digital Audio Connector||Audio Signal Type||Audio Signal Format|
|HDMI (5 Inputs/2 Outputs)||High Definition Audio Bitstream|| Dolby Atmos, Dolby Digital Plus, Dolby TrueHD |
DTS:X, DTS-HD Master Audio, DTS-HD High Resolution, DTS Express
|Bitstream||Dolby Digital, DTS, DTS-ES, DTS 96/24|
|PCM||2ch to 8ch (32-192kHz, 16/20/24-bit)|
|DSD||2ch to 6ch (2.8MHz, 1-bit)|
|Optical/Coaxial (2 Optical Inputs/2 Coaxial Inputs)||Bitstream||Dolby Digital, DTS, DTS ES, DTS 96/24|
|PCM||2ch to 6ch, (32-96kHz, 16/20/24-bit)|
Immersive Surround Sound: The Yamaha RX-A780 AV receiver goes beyond regular surround with the latest immersive surround sound formats, including Dolby Atmos & DTS:X.
- Dolby Atmos: The Yamaha AV receiver will enhance properly designed systems with Dolby Atmos where sound comes alive from all directions, including overhead, to fill the home theater with astonishing clarity, power, detail and depth. The RX-A780 has the processing power to run a more enveloping 5.1.2ch Dolby Atmos layout utilizing front-height, ceiling mounted, or Dolby Atmos-enabled speakers (sold separately). A 5.1.2 speaker configuration is based upon a traditional 5.1 speaker layout complemented by two Front Height, Overhead, or Dolby Atmos-enabled speakers.
- DTS:X: DTS:X is the next generation object-based, multi-dimensional audio technology from DTS. Unbound from channels, DTS:X conveys the fluid movement of sound to create an incredibly rich, realistic and immersive soundscape - in front of, behind, beside and above the audience - more accurately than ever before. DTS:X offers the ability to automatically adapt the audio to the speaker layout that best fits your space.
Post Decoding Formats: The Yamaha AV receiver supports Dolby Surround, Neural:X, and DTS Neo:6 (Music/Cinema) to enhance 2-channel and multichannel decoding formats.
- Dolby Surround: Dolby Surround offers an enhanced cinema experience to your 2ch and multichannel movie soundtracks using your existing 5.1ch, 7.1ch or Dolby Atmos speaker setup. Dolby Surround enhances audio definition by improving the spatial dimension and overall audio definition of movie soundtracks. It does this by using four distinct surround zones that provide greater control over the exact placement of each detail in a movie sound track, so audio can be matched more accurately to the video on screen; this means more depth and greater realism for your movies. As a result, individual sounds are clearer and more distinct. It also improves the surround sound experience across the entire theater by widening the listening "sweet spot".
- Neural:X: DTS:X incorporates Neural:X, the latest spatial remapping technology from DTS, which provides a fully immersive output for all types of source content; this includes DTS bitstreams and non-encoded (PCM) data. Neural:X delivers a thrilling sense of immersive sound to your speaker layout regardless of the original source format.
- DTS Neo:6: DTS Neo:6 is an advanced matrix decoder that takes any two-channel source (including television broadcasts, CDs and DVDs) and expands it into five or six channels. It also provides separate, optimized modes for stereo music materials and matrix surround motion picture soundtracks. DTS Neo:6 brings you a more revealing sound from ordinary stereo and a more expansive home cinema experience.
Cinema DSP Soundfields: This Yamaha proprietary soundfield creation technology was created by combining measured soundfield data with digital signal processing. Yamaha collected soundfield data from famous concert halls and music clubs around the world, utilizing its wealth of experience in the fields of concert hall design, public address, and mixing. Conventional multichannel audio reproduction systems base their sound on Dolby Digital and DTS decoding, using matrix and steering technologies to create surround sound effects. Yamaha Cinema DSP is much more advanced, creating immersive independent soundfields that envelop you in an unmatched surround sound experience. With dialog, music and effects ideally located in these separate soundfields, you will hear sound with accurate placement, smooth movement, exceptional clarity and richness, and realistic presence. It will seem as if the walls of your room have disappeared and you are in the middle of your own immense theater. The AV receiver offers a wide variety Cinema DSP programs for movies, music, and games (you can adjust the Cinema DSP effect levels).
- DSP Soundfields: Movie soundfields include Standard, Spectacle, Sci-Fi, Adventure, Drama, Mono Movie, Sports, Action Game, Role Playing Game. Music soundfields include Hall Munich, Hall in Vienna, Chamber, Cellar Club, The Roxy Theater, The Bottom Line, Music Video, 7ch Stereo\.
- DSP Parameters: You can change the receiver's CINEMA DSP effect level (level of the soundfield effect to be added). You can adjust the level of the soundfield effect from -6 dB to +3 dB. You can also adjust the delay between the direct sound and the presence soundfield (1-99ms), surround soundfield (1-49ms), and surround back soundfield (1-49ms). In addition, you can adjust the broadening effect (0.1-2.0) of the presence soundfield, surround soundfield, and the surround back sound field. You can even adjust the loss (0-10) of the presence soundfield, surround back soundfield, and surround back soundfield. Finally, you can adjust the delay time of the rear reverberant sound (1.0-5.0s), the delay between the direct sound and rear reverberant sound (0-250ms), and the volume of the reverberant sound (0-100%).
Cinema DSP 3D: The actually measured soundfield data in recorded soundtracks contain the information of the height of the sound images. Cinema DSP 3D mode achieves the reproduction of the accurate height of these sound images so that it can create the accurate and intensive stereoscopic soundfield in your listening room. Yamaha Cinema DSP 3D lets you enjoy your movies and music even more in your home; regardless if you are using 5.1 speaker setup, only have a two-channel speaker system, or listening through headphones.
- Virtual Presence Speaker (VPS): With the power of Cinema DSP 3D technology and the Virtual Presence Speaker (VPS) mode, the receiver virtually reproduces the height of the 3D soundfield without actually having front presence speakers. The Virtual Presence Speaker function makes full use of center and surround speakers to create audible information from where presence (height) speakers are normally installed.
- Virtual Surround Back Speaker (VSBS): This receiver also features a Virtual Surround Back Speaker function. Even without using surround back speakers, you can experience more natural, lifelike sound from behind you without physical speakers being installed in the surround back area of the listening environment.
- Virtual Cinema DSP: Virtual Cinema DSP is an algorithm that allows you to enjoy DSP soundfield surround effects while using a minimal two-speaker system. Virtual Cinema DSP lets you enjoy the effects of Cinema DSP surround sound without using surround speakers (handy for use in custom installations where some rooms don't have surround speakers). It can be used with the front/center speakers or even with just the two front left and right speakers. This unit will switch to virtual Cinema DSP mode automatically when surround speakers are unavailable.
- Virtual Cinema Front: With Virtual Cinema Front, you will enjoy virtual 5-channel surround sound with higher quality and resolution by installing surround speakers at the front. You get more flexibility to arrange your speakers inside the room, along with easy enjoyment of high quality surround sound.
- Silent Cinema: Silent Cinema makes it possible to hear large-scale surround sound through ordinary headphones. This is a variation of Cinema DSP technology that Yamaha developed to let you listen in private to movies and other multi-channel sources for hours without listening fatigue.
HiFi Sound Modes: The Yamaha RX-A780 offers two HiFi audio modes which bypass the receiver's tone & DSP processing for higher sound quality performance. These HiFi sound modes let you play back input sources without any soundfield effect processing. When either of these modes are enabled, each speaker produces its own channel audio signal (without soundfield processing). When playing back 2-channel sources, such as a CD player, stereo sound is heard from the front speakers. When playing back multichannel sources, the receiver produces unprocessed multichannel surround sound.
- Straight: 2-channel stereo sources are output from only the front left and right speakers, while multi-channel sources are decoded straight into the appropriate channels without any additional tone or DSP processing.
- Pure Direct: Turns off the surround and tone circuitry, and dims the front-panel display, allowing sources to bypass the decoders and DSP processors of this unit so you can enjoy pure hi-fi sound from 2-channel or multi-channel sources. During Pure Direct playback no sound is output from the subwoofer.
ARC + eARC (via available Firmware Update): The ARC (Audio Return Channel) of the RX-A780's HDMI main monitor output allows the audio to be sent from your compatible HDTV to the RX-A780 through the same HDMI cable already being used to send audio and video to your HDTV. This eliminates the need for extra cables connected to your television. The Yamaha RX-A780 will even support eARC (Enhanced Audio Return Channel) via an available firmware update. eARC will offer support for uncomprerssed audio formats like Dolby TrueHD, Dolby Atmos, DTS:X, & DTS HD Master Audio - where standard ARC was limited to Dolby Digital, Dolby Digital Plus, DTS, DTS HD, and PCM.
Compressed Music Enhancer: Yamaha employs sophisticated digital signal processing with exclusive algorithms to enable playback that improves the performance of compressed music formats, including MP3, WMA, AAC, & Bluetooth (SBC/AAC). The Yamaha receiver's Compressed Music Enhancer feature is even optimized for Bluetooth wireless audio streaming. With the Compressed Music Enhancer, highs and especially lows are richer and smoother, bringing music back to life to be as close to the original as possible.
Dialogue Level & Lift: Dialogue Level Adjustment lets you control the volume of the vocal sound, so you hear movie dialog and music vocals at the ideal level for clear, comfortable listening. Dialogue Lift adjust the perceived height of dialogue sounds. If the dialogue sounds as if it in coming from below the TV screen, you can raise its perceived height by increasing this setting.
Dynamic Range Control: The Yamaha RX-A780 employs two Dynamic Range Control functions.
- Adaptive DRC: Adaptive DRC automatically adjusts the dynamic range of the sound according to the volume level. This ensures that you hear clear dialog, vocals, and all sound effects at comfortable levels. There is no need to adjust the volume level as you listen; everything from whispers to big explosions will be heard clearly and comfortably at the same volume setting. It also tones down loud TV commercials and is ideal for low-volume, late-night listening when you do not want to disturb others.
- Dynamic Range: The amount of dynamic range compression applied to bitstream signals is adjustable; Min/Auto is suitable for low volume listening, Standard is typical for home use, and Max doesn't compress the dynamic range at all.
Bass Management: The Yamaha RX-A780 AV receiver provides the following Bass Management settings.
- Bass & Treble: You can adjust the balance of the high-frequency range (Treble) and low-frequency range (Bass) of sounds output from the receiver' front left and right speakers to obtain a desired tone. You can independently adjust the bass (50Hz) and treble (20kHz) from -6dB to +6dB in 0.5 dB increments. The tone control of the main Zone, Zone 2, and headphone connection can be set separately.
- Extra Bass: You can select whether to play front channel low-frequencies through either the front speaker or the subwoofer, or through both the subwoofer and front speakers. Use the Extra Bass feature to amplify bass tones, not just in your main room but also on systems in Zone 2. Even with compact or in-wall speakers which typically lack bass, you'll hear all your sources with powerful bass sound.
- Subwoofer Trim: The Subwoofer Trim control enhances the low frequencies by avoiding overlap with the front speaker output. This will result in a cleaner, more focused sound stage while providing a seamless frequency response. When subwoofer frequency overlap occurs in conventional systems, the overall sound is "pushed" toward the subwoofer. Subwoofer Trim takes care of this by separating the low subwoofer frequencies cleanly, thus stabilizing the front stage while providing a well-balanced enhanced bass sound.
Volume Setup: The Yamaha RX-A780 allows you to customize the receiver's volume levels.
- Volume Scale: You can choose to display the "Relative" volume scale (-80 to +16dB) or an "Absolute" volume scale (0 to 97).
- Max Volume Adjustment: Use this feature to set the receiver's maximum volume level (the main Zone and Zone 2 can be set independently). This feature is useful to avoid turning the volume too loud by mistake. You can set the Max Volume from -30dB to +15dB in 5dB steps, or to +16.5dB (full volume range is -80dB to +16.5 dB).
- Initial Volume Setting: Use this feature to set the volume level when the receiver's power is turned on (the main Zone and Zone 2 can be set independently). You can choose between Off (same as the volume when the unit was turned off), Mute, and -80dB to + 16.5dB in increments of 0.5dB.
- Volume Trim: Use this feature to adjust the volume level of each input. This is useful to balance the level of each input to avoid sudden changes in volume when switching between input sources. The range is from -6dB to +6dB in 0.5dB increments.
Audio Outputs: The Yamaha AV receiver is fitted with binding-post speaker terminals, dual mono-sub/LFE outputs, a set of front pre-outs, and a front-panel headphone jack.
- Speaker Terminals: The receiver has binding post terminals for all speaker outputs. The binding posts can accept bare wire, pin connectors, and single banana plugs. These terminals are spaced too far apart for dual banana plugs and a collar surrounding them prevents the use of spade connectors. You can select 8 ohms or 6 ohms in the menu depending on your speaker application. The amplifier supports 4- to 8-ohm Front speakers, and 6- to 8-ohm Center and Surround speakers.
- Dual Sub Outputs: The Yamaha AV receiver includes dual LFE (mono-subwoofer) outputs for connecting up to two powered subs (parallel outputs; not discrete).
- Front Pre-Outs: The set of stereo Front Pre-Outs let you connect an external power amplifier to power your front speakers.
- Headphone Jack: The Yamaha RX-A780 is equipped with a front-panel 1/4" headphone jack for connecting a set of headphones, so you can listen to your music privately. Connecting a set of headphones automatically mutes the receiver's speaker outputs. Sound effects applied during playback can also be heard through the headphones.
Phono Input: The Yamaha RX-A780 AV receiver features a dedicated Phono (MM) input for connecting your turntable and listening to your vinyl records.
Front-Panel Aux Input: The RX-A780 features a front-panel Aux input (3.5mm) for connecting your portable audio player with a headphone output.
HDMI 2.0b: The Yamaha RX-A780 AV receiver is fitted with five HDMI 2.0b inputs and two HDMI 2.0b outputs that support the latest HDMI standards; such as 4K/60Hz, HDCP 2.2, 4:4:4 color subsampling, HDR (High Dynamic Range), and Wide Color Gamut (BT.2020) for full support of today's 4K content from Ultra HD Blu-ray, online video services (like Amazon & Netflix), and future TV broadcast services.
- 4K/60Hz: The RX-A780 supports up to 4K (3840x2160 pixels) video @ 60 frames per second on all of its HDMI inputs and output. It also supports a 480i, 480p, 720p, 1080i, or 1080p video signal.
- HDCP 2.2: All of the receiver's HDMI jacks support HDCP 2.2, which fully complies with the latest copyright protection standard for 4K video transmission.
- 4:4:4 Color Subsampling: The receiver also supports RGB, YCbCr 4:4:4, YCbCr 4:2:2, and YCbCr 4:2:0 color subsampling (@ 60Hz or 50Hz). With 4:4:4 color subsampling, luminance (brightness) and chroma (color) are sampled at the same rate; resulting in an RGB color palette as big as the video sampling rate for a video image with more colors, plus greater color accuracy and detail.
- Wide Color Gamut (BT.2020): The BT.2020 color standard delivers a much wider color gamut and represents about 75% of the total visual color spectrum, while the current Rec. 709 color standard selected as the color space for HDTVs and early generation 4K Ultra HDTVs covers only 35% of the total visual color spectrum.
Note: Use a premium high-speed 18Gbps HDMI cable for the best 4K/HDR performance.
HDR (High Dynamic Range): The Yamaha RX-A780 supports HDR (high dynamic range) Video - including HDR 10, Dolby Vision, and Hybrid Log-Gamma. HDR (High Dynamic Range Video) provides enhanced picture quality by simultaneously enabling greater detail for both the dark and bright parts of an image. HDR reproduces a greater dynamic range of luminosity or brightness levels, creating greater contrast. This increased contrast reveals the subtle nuances of the image, from detailed blacks and shadows to the brightest whites and colors, plus greater depth.
- HDR 10: HDR 10 is an open standard and currently the most popular HDR format on the market. It uses static metadata at the start of a movie to tell the receiver and your TV that the video content is encoded using HDR.
- Hybrid-Log Gamma: HLG (Hybrid-Log Gamma) is primarily designed for live video feed and over-the-air broadcasts. It uses no pre-encoded metadata and is backwards compatible with SDR. HLG's native compatibility allows much of today's existing SDR infrastructure to be re-used for HDR in the future.
- Dolby Vision: Unlike HDR 10 which contains static metadata and HLG which uses no metadata, Dolby Vision uses dynamic metadata technology which sets individual color and brightness levels for each and every scene. Dolby works directly with filmmakers at major Hollywood studios to create superior HDR video masters of blockbuster movies.
4K Video Upconversion & Upscaling: The Yamaha RX-A780 is capable of outstanding video upconversion and upscaling. This AV Receiver will upscale video signals from analog (480i only)-to-HDMI and HDMI-to-HDMI, up to 4K. This means a much better picture with HDTVs capable of 720p, 1080i, 1080p, or 4K resolution. Only the receiver's main HDMI output is capable of video upconversion & upscaling; the sub HDMI output does not support video upconversion or upscaling.
Dual HDMI Outputs: The receiver's two HDMI outputs are parallel, so the same HDMI audio/video signal is output through both and can be used simultaneously (video is output at the resolution supported by both TVs).
Other HDMI Features: The Yamaha RX-A780 AV receiver's HDMI connectivity also offers 3D video pass-through, Deep Color & x.v.Color support, as well as an auto LipSync function.
- 3D Ready: The Yamaha RX-A780 AV receiver supports 3D video pass-through (720p/1080p only) from connected 3D-compatible Blu-ray, games and broadcast devices to 3D-compatible HDTVs (all 3D components must be connected via HDMI). Special eyewear will be required for viewing 3D content.
- Deep Color & x.v.Color Support: The AV receiver supports Deep Color and x.v.Color content, which can display a larger color range than standard-definition schemes. The result is a more lifelike, vibrant picture
- LipSync: This function adjusts the delay between audio and video output. You can do this manually or have the receiver set the LipSync function automatically. When connected to a TV via HDMI the receiver automatically adjusts audio output timing (0-500ms) if the TV supports an automatic LipSync function. You can also manually delay the sound output up to 500ms to synchronize it with the video image.
- Standby Through Mode: When the RX-A780 is in standby mode (power off), the Standby Through feature allows HDMI source signals to pass through the receiver to the TV. The HDMI input can be changed using the remote control. So, there's no need to turn on the AV receiver in order to switch HDMI sources.
Analog Video Inputs: The RX-A780 AV receiver is outfitted with one composite video and one component video input. Both the composite and component video inputs only support 480i. These analog video inputs are upscaled (up to 4k) and upconverted to HDMI out to your TV (the receiver has no analog video outputs).
Background Audio/Video: The Background Video feature allows you to watch a video source while listening to a different audio source. With the RX-A780, you can select any video input (HDMI or analog) and listen to audio from any of the receiver's audio sources (including AM/FM tuner, Aux, Phono, USB, Network, or Bluetooth).
Wired or Wireless Network Connection: The Yamaha RX-A780 offers a wired (Ethernet) or wireless (WiFi) network connection to your home's network router. Either network connection gives the receiver access to DLNA music servers, AirPlay, MusicCast, and various online music services. The receiver also supports WiFi Direct for wireless connectivity between WiFi enabled devices without a router.
- Ethernet Jack: The Yamaha AV receiver is fitted with a RJ-45 Ethernet (LAN) port to connect the receiver to your home network. The Ethernet port provides the most reliable connection.
- Built-in WiFi: The AV receivers offers built-in dual-band (2.4 + 5GHz) WiFi (IEEE 802.11 a/b/g/n/ac) for a wireless network connection; WPS, WEP, WPA-PSK (TKIP), WPA-PSK (AES), WPA2-PSK (AES) security protection is supported. Wireless network setup can be done via WPS button, Access Point Scan, Manual Setting, PIN Code, or even through your Apple iOS device (7.0+).
- WiFi Direct: When using WiFi Direct, you can connect directly with other WiFi-enabled devices without using a wireless router. You'll be able to wirelessly stream a variety of music files to the Yamaha receiver without connecting to your home network. WiFi Direct completely bypasses your WiFi access point/router, so it's easy to set up. You'll continue to navigate your music and view song/artist information from your mobile device.
Note: Network setup requires that the receiver be connected to your TV via HDMI for display of the on-screen menu. The receiver's network setup cannot be accessed through its front-panel display.
Online Music Services: The Yamaha RX-A780 offers access to Internet Radio through built-in Airable by TuneIn; your Spotify Premium account through Spotify Connect on your Apple iOS or Android device; and your Pandora, TIDAL, SiriusXM, Qobuz, Napster, or Deezer music account through Yamaha's MusicCast Controller app.
- Airable by TuneIn: You can listen to Internet radio stations using Airable by TuneIn. Search worldwide internet radio content by Genre, Language, Location, Quality, Popularity, or do a keyword search.
- Spotify Connect: With the Spotify app on your Apple iOS or Android smartphone, you've got instant access to millions of songs. And now you can stream those same songs from your smartphone to the RX-A780 by using Spotify Connect; simply hit play on the app to start streaming music. What's more, when you've been listening to Spotify on your smartphone outside and come inside, the song immediately begins to stream to the unit for uninterrupted music enjoyment. You can also personalize playlists and receive phone calls while listening to music.
- Pandora: Pandora is accessible through the Yamaha MusicCast Controller app for Apple iOS & Android. Pandora is personalized radio that plays music and comedy you'll love. Just start with the name of one of your favorite artists, songs, comedians or composers and Pandora will create a custom station that plays similar tracks. You can also rate (thumbs up/thumbs down) songs as they play, and Pandora will adapt stations to your feedback. You can even bookmark stations and easily switch between favorites.
- TIDAL: Tidal is accessible through the Yamaha MusicCast Controller app for Apple iOS & Android. TIDAL is a global streaming service that offers over 30 million songs in high-fidelity CD sound quality. TIDAL has two pricing tiers; either $9.99 or $19.99 a month. Both pricing levels allow you to access TIDAL's entire music library. The $19.99 tier has the added benefit of high-fidelity sound at CD-level quality.
- SiriusXM: SiriusXM Internet Radio is accessible through the Yamaha MusicCast Controller app and lets you listen to over 120 channels of commercial-free music, talk radio, news, sports, entertainment, and more. Subscription fees will apply.
- Qobuz: Qobuz offers the biggest catalog of Hi-Fi and Hi-Res albums in the world, both for new releases and specialized genres. For hundreds of thousands of albums, Qobuz includes all the information you need to recreate the appeal of a real CD - the names of musicians, producers, lyrics (everything you need to know to appreciate your favorite albums). Qobuz offers MP3, CD, and Hi-Res quality subscriptions.
- Napster: Napster is also accessible through the Yamaha MusicCast Controller app. This streaming music subscription service (starting a $10 per month) allows you to play the full-length songs you choose on demand from a collection of over 10 million songs, without ads and without having to purchase or download the music.
- Deezer: Deezer is an online music service offering over 43 million tracks starting at $9.99 a month and is accessible through the Yamaha MusicCast Controller app. Discover the perfect playlist or make your own, as well as browse curated collections by genre.
DLNA Certified: The RX-A780 is DLNA (Digital Living Network Alliance) 1.5 and Windows 7/8/10 compliant for audio networking. This means it's easier for you to access and enjoy digital music stored on your PC over your home network. You can use your PC to play high-bit rate music content through your audio system, or use the RX-A780 to browse and play music files on your hard drive. You can control playback of your streamed audio files from the AV receiver's remote control. The receiver also supports ID3-Tag and META tag information so song title, artist name, and album name can be displayed from the unit's on-screen menu (via HDMI).
- The AV receiver supports the following DLNA music servers - (1) PC with Windows Media Player 11 or later installed, (2) PC with DLNA/UPnP Certificate server software installed, (3) NAS with DLNA/UPnP certification.
- Supported music files include - WAV/FLAC/AIFF (up to 192kHz/24-bit), ALAC (up to 96kHz/24-bit), MP3/WMA/AAC (up to 48kHz/320kbps), and DSD (2.8/5.6MHz).
AM/FM Tuner: The Yamaha RX-A780 AV receiver features a built-in AM/FM tuner with manual, seek, and preset tuning. The RX-A780 lets you store up to 40 AM/FM station presets. This can be done manually or automatically (auto-preset tuning). You can set this receiver to automatically match FM broadcast frequencies in stereo, or convert the frequency to monaural for weaker stations. An indoor FM wire antenna and AM loop antenna are included with the receiver.
Web Control: When connected to your network (with Internet connection), you can control the Yamaha AV receiver with the web control screen displayed in your PC's web browser. You'll be able to control functions such as, Power On/Off & Volume. Internet Explorer 9.x, 10.x, 11.x, or Safari 7.x is recommended for web browser.
Firmware Updates: New firmware will be released for the purpose of additional features or product improvements. Firmware updates can be downloaded from the Yamaha website. If this unit is connected to the Internet, the receiver will indicate when a new firmware version is available and you can download the firmware via the network connection. Firmware updates normally take approximately 20 minutes or longer. Check Yamaha's Support Download Site for the most recent firmware updates.
AirPlay 2 (via available firmware update): Through an available firmware update, the Yamaha RX-A780 will support AirPlay 2. AirPlay 2 is an advanced and easy-to-use wireless multiroom audio platform for iTunes, Apple Music, and other compatible Apple iOS apps. With AirPlay 2 you can play any sound from your Apple iOS device (running iOS 11.4 or later) or Mac computer (running OS X 10.13.2) on the RX-A780 and other compatible AirPlay 2 speakers throughout your home. You will also be able to ask Siri-enabled devices (like your Apple iPhone, iPad, or Watch) to control playback of your Apple Music on the Yamaha RX-A780. With AirPlay 2, also get to see song/artist information and album art via the unit's on-screen menu (via HDMI). You can choose to play audio in one room, play the same audio in grouped rooms, or play the same audio in every room (you can control and group directly from Apple's Music App and Home app on your Apple iOS device). You can even watch videos and movies from YouTube and Netflix on your compatible Apple iOS device or Mac computer with perfectly synced audio on the Yamaha RX-A780.
Built-in Bluetooth: The Yamaha AV receiver is equipped with built-in Bluetooth (version 2.1+EDR) for wireless communication between Bluetooth-enabled audio source devices, headphones, and speakers. The AV receiver can act as a Bluetooth receiver in order to wirelessly stream music from an audio device, or a Bluetooth transmitter (available firmware update) in order to wirelessly stream music to a set of BT-enabled headphones/speakers.
- Bluetooth Receiver: The Yamaha AV receiver incorporates Bluetooth A2DP & AVRCP, so you can wirelessly stream stored music & music apps from a Bluetooth-enabled device; like your Apple iPod/iPhone/iPad, Android smartphone/tablet, Windows Phone/PC, or Mac computer/laptop to the AV receiver. In addition to support for the standard SBC Bluetooth audio codec, the receiver offers support of AAC. By supporting AAC, the receiver offers better audio performance of music streamed from your Apple iPod/Phone/iPad. Song/artist information will be displayed on your HDMI connected TV's screen and the front-panel of the receiver. You'll you be able to control basic playback functions, like Play/Pause & Previous/Next Track from the receiver's remote; advance music browsing still has to be done from your Bluetooth source device.
- Bluetooth Transmitter (via available firmware update): The AV receiver can also act as a Bluetooth transmitter and stream its non-Bluetooth audio sources (HDMI, Network, USB/iPod, Analog, Optical/Coax Digital, & AM/FM tuner) out to most any Bluetooth headphone or speaker. You can only pair and stream audio to one Bluetooth headphone or speaker at a time. You can even have the same source playing from the main speakers and a Bluetooth speaker/headphone simultaneously (there is a slight audio delay). Volume control of the Bluetooth speaker/headphone will be controlled via the Bluetooth device and not the receiver.
Note: Due to the differences in Bluetooth technology, some Bluetooth enabled devices may be incompatible, function improperly, or may not support all features when used with the Yamaha AV receiver.
USB Port: This AV receiver is equipped with a front-panel USB (type-A) port that allows you to enjoy a variety of music files stored on a USB mass storage class memory device, such as a USB thumbdrive or portable digital audio player (not compatible with USB HDDs). Your USB mass storage class device must be formatted in FAT 16 or FAT32. You can use the receiver's on-screen menu (via HDMI) and remote control to navigate your stored music files on your connected USB memory device. USB portable audio devices that can be charged via USB will be charged when plugged into the AV receiver's USB port (5V/1A); even in standby mode. Compatible music files include:
- DSD (2.8/5.6/11.2 MHz)
- AIFF/FLAC/WAV (up to 192kHz/24-bit)
- ALAC (up to 96kHz/24-bit)
- MP3/WMA/AAC (up to 48kHz/320kpbs)
Note: The receiver's USB port does not support Apple iOS and Android OS devices.
Zone 2 (Line & Speaker Outputs): The Zone 2 feature allows you to set this receiver to reproduce separate input sources in the main zone and the second zone (Zone 2). The receiver has dedicated stereo RCA outputs for Zone 2, or the built-in amplifier can be configured to power speakers in the second zone connected to the Extra Speaker terminals.
- Line-Level Outputs: By using the Zone 2 line-level (RCA) outputs on the AV receiver you can connect an external receiver or integrated amplifier in a second room, allowing you to listen to 7.1ch surround in the main room and play a different stereo audio source in another room of your home. In this setup, the volume of Zone 2 can be controlled by the receiver or an optional integrated amp.
- Speaker-Level Outputs: By using the Zone 2 speaker-level outputs on the AV receiver you can directly connect a secondary pair of speakers in another room of your home, allowing you to listen to 5.1 surround sound in your main room and play a different stereo audio source in the other room. When the receiver is powering speakers in Zone 2, the surround back speakers in the main room are turned off (limiting you to 5.1ch in the main room). In this configuration, the volume of Zone 2 is controlled by the AV receiver
Zone 2 Sources: Digital (including optical/coaxial) and analog audio sources (including AM/FM radio); plus Bluetooth, USB, and Network sources can be output to Zone 2. You can have different sources playing in each zone or have the same source playing in both zones.
- Compatibility: Compatible Zone 2 sources include - Analog & Optical/Coaxial digital audio source inputs (2ch only), USB audio, Bluetooth audio, AirPlay, AM/FM tuner, Internet radio, DLNA music files, & MusicCast music apps.
- Incompatibility: Incompatible Zone 2 sources include - HDMI audio/video source inputs, Analog video source inputs, & DSD music files.
Note: You cannot select Bluetooth, USB and Network (MusicCast/Internet Radio/DLNA/AirPlay) sources exclusively for each zone. For example, if you select "NET" for Zone 2 when "USB" is selected for the main zone, the input source for the main zone also switches to "NET".
Party Mode (Main Zone Sync): The Party Mode (or Main Zone Sync) allows you to enjoy the AV receiver's Main Zone audio source in Zone 2 at the same time, regardless of input audio signal types (analog, digital or wireless). During the Party Mode, stereo playback is automatically selected for all zones (multichannel sources are mixed down to 2 channels). The Main Zone & Zone 2's volume can be adjusted independently. Utilize this function when you want to play back the same audio source in two rooms of your home.
HDMI Zone B: The receiver's second HDMI monitor output lets you send the same HDMI audio/video input signal that is being played in the main zone to a second zone (video is output at the resolution supported by both TVs). The HDMI Zone B does not support analog upconversion or video upscaling.
MusicCast Wireless Multiroom Audio Streaming: This AV receiver supports Yamaha's MusicCast multiroom audio eco-system, which allows you to wirelessly play back a wide variety of audio sources and content in multiple rooms of your home (additional MusicCast products sold separately). MusicCast works with your home's existing WiFi router and Yamaha's free MusicCast Controller app for Apple iOS 9.0+ and Android OS 4.1+. You'll be able to stream the receiver's tuner, inputs, Bluetooth, and network sources to other MusicCast products installed in your home. In addition, you'll be able to stream your MusicCast products' sources to the AV receiver. MusicCast supports the following source content.
- Analog & Digital Sources: The receiver's HDMI, optical/coaxial digital, and analog input sources can be played back over the MusicCast eco-system. Multi-channel content (5.1ch/7.1ch) is down-mixed to 2-channel sound for playback in other rooms without affecting the master room.
- Hi-Res Audio (via USB or DLNA): MusicCast supports Hi-Res audio via USB or DLNA. The MusicCast system is compatible with Apple Lossless (ALAC) up to 96kHz/24-bit, as well as FLAC and WAV music files up to 192kHz/24-bit. It also supports lower resolution music files like MP3, WMA, and AAC up to 48kHz. When multiple MusicCast devices are "linked" for multiroom audio playback, the Master room device's playback is at the native sampling rate (up to 192kHz/24-bit), while the other rooms and MusicCast devices down-converted to 48kHz.
- Online Music Services & Tuner: MusicCast offers support for Pandora, Spotify Connect, Tidal, Deezer, SiriusXM, Napster & Airable. In addition the receiver's AM/FM tuner can be distributed across multiple MusicCast speakers.
- Bluetooth: The receiver's Bluetooth source (SBC codec only) can be streamed to multiple MusicCast devices, so Bluetooth audio can be played in multiple rooms simultaneously.
- Up to 10 MusicCast devices can be connected to your home's wireless network (802.11 b/g/n/ac; 2.4 or 5GHz).
- If you want to install a MusicCast device to a location that is out of range of your wireless router, connect another MusicCast device to the router with a network cable to extend the range ("Extend Mode").
MusicCast Controller App: The free MusicCast Controller app (for Apple iOS 9.0+ and Android OS 4.1+) puts control of your whole home listening experience in the palm of your hand from your compatible Apple iOS or Android device. You'll be able to quickly select the room or rooms you want to listen to music in, select the source or sources you want to listen to, browse music content from your music library and online music services or Internet Radio, plus control music playback functions.
- Rooms: Choose which room or rooms you want to listen to music in. You can select a different source for each room, group certain rooms together for playback of the same source, or link all rooms together so the same source is played back throughout the house.
- Source Selection: From the app you can select which source or sources you want to listen to; choose from network-connected devices, select online music services, Internet Radio, Bluetooth; as well as analog & digital inputs - including HDMI & USB.
- Music Browsing: You can browse music libraries from your network-connected devices; like your smartphone, tablet, computer, or laptop. You can also browse music content from select online music services and search Internet Radio stations from the MusicCast Controller app. You can also browse music files on your USB-connected thumbdrive.
- Playback & Song/Artist Info: From the MusicCast Controller app on your compatible Apple iOS or Android device you get Volume Up/Down, Play/Pause, and Previous/Next Track; as well as song/artist information and album art.
- Favorites: Internet radio stations, content from select online music services, plus playlists and songs from your network-connected device's music library can be saved as "Favorites" for quick recall within the MusicCast Controller app.
- Personalization & Customization: With the app's unique personalization features, you can choose from preloaded room images or change the color of buttons to represent each room in the home, or even take pictures of their own home and assign the images to each button. The content source buttons can also be customized to rename, remove or reorder selections for easier operation.
Alexa & Google Voice Control: Alexa and Google Home enabled devices (sold separately - see Accessories Tab) are able to control key functions of Yamaha's MusicCast system using voice commands. With Alexa & Google Home voice control integration, all you have to do is ask. The RX-A780 offers full compatibility with Amazon's and Google's range of voice control devices. Yamaha offers two Skill platforms that work hand-in-hand to give you a wide range of voice command possibilities, allowing you to control either a single MusicCast product or a whole MusicCast system. The Yamaha RX-A780, other MusicCast components, and Alexa/Google-enabled devices must be on the same WiFi network.
- MusicCast Smart Home Skill: The MusicCast Smart Home skill supports the most common, everyday voice commands you would use to control a single MusicCast component. These basic commands include power on/off, volume control, play/pause/skip/previous, mute/unmute and input selection. This skill supports simple, Alexa and Google standardized commands such as "Alexa" or "Ok Google", "volume up in the Kitchen."
- MusicCast Skill: The MusicCast skill goes beyond the basics, giving you enhanced control of unique MusicCast functions such as room linking, multiple room control, playback of MusicCast Favorites/Playlists and more. The commands are customized for MusicCast, for example "Alexa" or "Ok Google", "ask MusicCast to link the Kitchen with the Living Room."
- Echo Source Input: In addition or alternatively, an Echo device can be used as a music/audio source for a MusicCast system. All MusicCast devices offer a Bluetooth input. Just pair your Echo device with any MusicCast component and the sound will play from the MusicCast device. Many MusicCast products also offer inputs which can be connected to Echo Dot via its line output, if a wired connection is preferred over Bluetooth. Using the MusicCast Controller app, you can select the Bluetooth or wired input and link multiple MusicCast devices for playback, allowing you to hear sound from Echo Dot throughout your home.
Josh.ai Smart Home Voice Automation: An elevated voice agent for the high-end smart home, Josh.ai offers flexible voice control for nearly any aspect of your day-to-day experience and entertainment environment. Use voice commands to control the Yamaha AV receiver, thermostat, lights, home appliances, powered speakers, and more. Josh.ai is installed by custom integrators and accessed through the Josh - Home Automation app on your Apple iOS 11.1+ or Android OS 4.4+ device.
AV Controller App: Download Yamaha's free AV Controller App (for Apple iOS 9.0+ and Android OS 4.1+) onto your compatible smartphone or tablet and turn your mobile device into a WiFi enabled remote control for the Yamaha AV receiver. Your Apple iOS or Android device must be connected to the same home network as the Yamaha AV receiver.
- Basic Remote Functions: The AV Controller App provides the flexibility to control input, volume, mute and power commands from your compatible Apple iOS or Android device.
- DSP Controller: You can use the AV Controller App to adjust DSP soundfields & parameters to your preference to match the type of music/movie or the mood you want to achieve. There are two modes - (1) Basic, which lets you adjust the sound space by simply pinching the screen in-and-out; and (2) Advanced, which allows detailed adjustment of various parameters such as reverb, initial delay, and liveness.
- Internal Content Browsing: Using this app on your Apple iOS or Android device, you can browse and listen to content from all internally available sources; such as Internet Radio, Pandora, Spotify, USB devices, and the AM/FM tuner.
- Wireless Music Streaming: From the app, you can browse music stored on your Apple iOS or Android device and wirelessly transfer the content to the Yamaha A/V receiver for playback.
- Blu-Ray Player: This App not only controls the Yamaha AV receiver, it also controls Yamaha Blu-ray Disc Players, supporting various functions including Play/Pause, Stop, Fast Forward/Rewind, and Previous/Next Track.
AV Setup Guide App: Download Yamaha's AV Setup Guide App (for Apple iOS 6.0+ and Android OS 4.0.3+) onto your compatible Apple iOS or Android device for assistance with connecting cables between the Yamaha AV receiver and your source devices as well as AV receiver setup. This app guides you through various settings including speaker connections, TV and source device connections, plus assigning the power amplifier. Once you have completed the setup guide, settings from this app will automatically be copied to your network-connected AV receiver for quick and easy setup.
Remote Control: The receiver comes with an IR remote control for wireless operation of this receiver and other HDMI-connected sources (via HDMI CEC). This newly designed remote control features large buttons for enhanced ease of use.
HDMI-CEC (Consumer Electronics Control): The Yamaha AV receiver supports HDMI-CEC, which synchronizes the operation of this unit with other HDMI-CEC devices when connected via HDMI. When the AV receiver is connected to a HDMI-CEC compatible TV, they will turn ON/OFF together and you can use the TV remote to control the volume of the receiver. HDMI-CEC also provides playback functionality with other components, such as your Blu-ray player. For example, you can use the receiver's remote control to operate player functions like Play/Pause, Fast Forward/Rewind, Previous/Next Track, or Stop.
Note: Not all HDMI-CEC compatible components and functions are guaranteed to work.
Remote Jacks: The receiver has remote input and remote output minijack terminals (3.5mm) for use with external IR receivers and compatible Yamaha components.
12V Trigger Output: The RX-A780 has a programmable minijack output to send a 12-Volt DC turn-on signal to another component that accepts a 12V trigger, such as a power amplifier or motorized projection screen. The trigger is programmed either to work with a specific zone (main room or Zone2) or a specific source.
Advanced On-Screen Menu: The RX-A780 offers an on-screen (GUI) menu system through its HDMI output. The simple on-screen display combines text and graphics that make setup and other operations extremely easy. If your TV is connected to the composite video or component video monitor output, you will need to use the AV receiver's front-panel display when changing settings. You can set the receiver's on-screen menu language to English, French, Spanish, German, Russian, or Chinese. The front-panel display only offers English.
Note: Initial setup requires that the receiver be connected to your TV via HDMI for display of the on-screen menu. Many of the receiver's setup functions can only be found via the on-screen menu and not the front-panel display.
Scene (for One-Touch Start): The RX-A780 features four Scene buttons on the front-panel and and eight Scene buttons on the remote to make operating the receiver easier. Pressing a Scene button will automatically launch a number of operations that initiate play of the source controlled by that button; such as powering on the receiver, switching to the appropriate source input, and recalling the selected DSP surround mode.
Gapless Playback: Many live and classical albums have no gaps in the music. Gapless playback ensures that there are no pauses between audio files. This provides playback with no interruptions, the way it was meant to be heard. Compatible with WAV, FLAC, AIFF, and ALAC music files via USB or DLNA.
Favorites (Shortcuts): You can register up to 40 favorite USB music files, internet radio stations, and/or other network music content as shortcuts ("Favorites") and access them directly. Only the input source will be registered for Bluetooth and AirPlay.
Input Rename & Skip: The receiver automatically creates an input source name that is displayed on the front-panel screen for connected HDMI-compatible sources. You can also manually rename each input so the display reflects the actual source. If an input isn't being used, you can hide it from the display so you don't have to scroll past it when you change sources.
Display Dimmer: You can set the brightness of the front-panel display from -4 to 0.
ECO Mode: When the ECO Mode is enabled, you can reduce the receiver' power consumption by keeping the maximum volume, maximum output power, and front display's brightness low. ECO mode reduces power consumption by approximately 20%.
Timers: The receiver offers a programmable Sleep Timer and Auto Power Down function.
- Sleep Timer: The receiver's Sleep Timer function can be set turn the unit automatically off after 30, 60, 90, or 120 minutes.
- Auto Power Down: If you don't operate the receiver or use the remote for an extended period of time, the unit will automatically go into standby mode (Auto Power Down function). The Auto Power Down feature is selectable from 2, 4, 8 or 12 hours. The unit can also be set to power down if it does not detected an input signal for 20 minutes.
Memory Guard: This feature is used to prevent accidental changes to the DSP program parameter values and other system settings.
Q Crutchfield asked: Why did you buy this?
8 questions already asked
