About the Chief VCTU Extra-large Universal Projector Mount
A high-capacity projector mount with tool-free adjustments
A high-capacity projector mount with tool-free adjustments
The durable Chief VCTU universal mount was made for larger projectors weighing between 50-150 lbs. The mount has independent knobs for making tool-free pitch, yaw, and roll adjustments, as well as cable management openings to keep your installation looking neat.
The VCTU attaches to your ceiling using a 1-1/2" threaded column and ceiling plate (both sold separately).
Product highlights:
- supports up to 150 lbs.
- attaches to your ceiling using a ceiling plate and 1-1/2" threaded column (both sold separately)
- independent knobs for tool-free micro-adjustments of pitch, roll, and yaw
- roll: 5°
- pitch: 20®
- yaw: 10° (micro) and 360° (macro)
- cable management openings for a tidy installation
- 27-1/8"W x 4-7/8"H x 27-1/8"D
- weight: 26.7 lbs.
- warranty: 10 years
- Our 60-day money-back guarantee
- MFR # VCTUW
What's in the box:
- Chief VCT:
- Mounting bracket
- Wrench-tool
- Hex-key
- Installation Instructions
- Chief HCU:
- Interface bracket
- 4 Long extension arms
- 4 Short extension arms
- 4 Fixed arms
- Eight M4x16mm screws
- Eight M5x20mm screws
- Eight M6x16mm screws
- Eight M6x25mm screws
- Eight M8x12mm Screws
- Eight M8x16mm screws
- Eight M10x20mm screws
- Eight M8 washers
- Eight M5 washers
- Twelve M8 nuts
- 8 Nested washers
- Pitch socket adapter
- Hex-key
- Installation Instructions
Reviews
Customer reviews
Loading reviews...
Thanks for submitting your review
Customer photos
This review was collected as part of a promotion
Pros:
Cons:
More details on the Chief VCTU Extra-large Universal Projector Mount
Product Research
Features
Extra-Large Universal Projector Mount: The Chief VCTUW ceiling projector mount provides the strong support you need for mounting extra-large projectors. The Chief VCTUW consists of a universal mounting bracket and interface bracket. All components of the Chief VCTUB are made of heavy-gauge steel for a secure and long-lasting mount. It is also UL certified.
Compatibility: The Chief VCTUW extra-large universal projector mount supports projectors weighing up to 150 lbs. It includes M4, M5, M6, M8, and M10 screws (along with other hardware) to secure to your projector. Its maximum width measures 27.125" and maximum depth measures 27.125".
Note: A combination of fixed, short, and long mounting legs are included. One mounting leg of the interface bracket should be attached to each available mounting hole on your projector.
Mounting Options: The Chief VCTUW attaches to your ceiling using a 1.5" NPT ceiling plate and 1.5" threaded NPT column (both sold separately - see Accessories Tab).
Note: It is recommended that the ceiling's structural members can support a redundant weight factor five times the weight of the equipment you intend to install. If the structure cannot support that amount of weight, the structure must be reinforced before you install the projector mount.
Micro Adjustments: The Chief VCTUW offers micro adjustments to set the appropriate height and angle, as well level the projector. The 20° pitch adjustment sets the height of the projected image, the 360° yaw adjustment sets the left/right position of the projected image, while the 5° roll adjustment levels the projected image.
