About the Dual XR4120
Dump the discs with Dual
Dump the discs with Dual
If you're just not listening to CDs anymore, Dual's XR4120 digital media receiver gives you a wallet-friendly way to enjoy your music collection on the road. You can listen to your favorite AM/FM stations, plug a thumb drive full of music into the USB port, jack your music player into the front minijack aux input, or fold down the faceplate to insert an SD card. It all sounds great on this Dual receiver, thanks to the healthy output of the built-in MOSFET amplifier. (Need Bluetooth? Check out the Axxera AM118BT digital media receiver.)
A smart start to a new system
The detachable faceplate features a 10-character black-on-white display that's easy to read day or night. The included wireless remote adds convenience and control, while a set of rear preamp outputs will come in handy when you decide to expand your system.
- digital media receiver with AM/FM tuner (does not play CDs)
- built-in MOSFET amplifier (16 watts RMS CEA-2006/60 peak x 4 channels)
- plays MP3 and WMA music files
- detachable face with single-line display and blue button illumination
- wireless remote control
- bass and treble controls with 4 presets curves (1 user-adjustable curve)
- inputs: front USB port (no iPod® control), front auxiliary input, SD card slot
- outputs: 2-channel preamp outputs (2-volt rear)
Other Features and Specs:
What's in the box:
- Digital media receiver
- Face (attached)
- Sleeve (installed)
- Trim ring (installed)
- Remote control (CR2025 battery installed)
- Wiring harness
- Four M5 x 6mm screws
- Four M4 x 6mm screws
- Rear-support bolt
- Hex nut
- 2 Radio removal tools
- Quick Start Guide
Dual XR4120 reviews
Thanks for submitting your review
More details on the Dual XR4120
Features & specs
|Backup Camera Input||No|
|Second Camera Input||No|
|Alexa Voice Control|
|Memory Card Slot||USB, SD|
|Satellite Radio Ready||No|
|RMS Power (CTA-2006)||16 watts|
|RMS Power (Manufacturer)||---|
|Peak Output||60 watts|
|RMS Power Bandwidth||20-20kHz|
|Sub Preamp Outputs||No|
|Switchable Rear Preamp Outputs||No|
|Navigation App Compatible (iOS)|
|Navigation App Compatible (Android)|
|Preamp Voltage||2 volts|
|Key Button Color||Blue|
|Steering Wheel Control Compatible||No|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|FM Sensitivity||10 dBf|
|Radio Data System||No|
|Music File Playback||MP3, WMA|
USB Port: The Dual XR4120 digital media receiver is equipped with front-panel full-speed USB (type-A) port for playback of MP3/WMA files stored on a compatible USB mass storage device - like a USB thumbdrive or portable digital audio player. The unit will recognize USB mass storage device with internal memory up to 64GB. The unit's USB port (max. 500mA) will also charge your USB device during connection.
Note: The USB port does not support connection of Apple iOS or Android devices.
SD Card Slot: The Dual XR4120 digital media receiver is fitted with a front-panel SD-card slot that is hidden behind the head unit's detachable face-plate. The SD card slot supports playback of MP3/WMA files stored on SD and SDHC memory cards (up to 32GB).
Supported Media Files: The MP3/WMA music files stored on your USB mass storage device or SD/SDHC memory card must meet the following requirements for proper playback on the XR4120.
|Compatible Files||MP3, WMA|
|Sampling Frequency||MP3: 8-48khz, WMA: 8-48kHz|
|Bit Rate||MP3: 8-320kbps, WMA: 8-384kbps|
|ID3 Tag Support||MP3 Tags: version 1.0-2.0, WMA Tags|
|File Folder Limit||Maximum Files: 1,024; Maximum Folders: 512; Maximum Folder Levels: 8|
Playback & Search Functions: When a USB memory device or SD/SDHC memory card is first connected, playback will begin automatically. The XR4120 also offers the following playback & search features for MP3/WMA music files stored on your USB memory device or SD/SDHC memory card.
- Play/Pause: Play or pause tracks.
- Folder Access: Selects previous or next folder.
- Intro: Plays the first 10 seconds of each track in a folder.
- Track Select: Skip to the beginning of the next rack or return to the beginning of the previous track.
- Fast Forward/Reverse: Fast forward or reverse through a selected track.
- Repeat: Continuously repeat the current track or device.
- Random: Plays all tracks on the device or in the current folder in random order.
Auxiliary Input: The XR4120 features a front-panel 3.5mm auxiliary input for temporary connection of an external portable audio device, such as your iPod/iPhone, Android smartphone/tablet, or Blackberry.
MOSFET Amplifier: The Dual XR4120 is equipped with a MOSFET amplifier. Compared to conventional power supplies, the MOSFET amplification circuit is smaller and more efficient, and it delivers increased power with less distortion and absolutely zero on/off switching noise. More power means louder and cleaner music at higher volumes because you're not pushing the limits of the amplification circuit. The power output specs for the XR4120 are as follows:
- CEA2006 Specs: 16 watts RMS x 4 channels (at 4 ohms, 20Hz-20kHz, 1% THD-N)
- Maximum Power Output: 60 watts x 4 channels (240 watts total)
Note: The power specifications for the XR4120 are compliant with the CEA2006 Mobile Amplifier Power Testing and Measurement standards from the Consumer Electronics Association (CEA). These standards were developed as a way to equitably compare power specs from model to model and between manufacturers.
2V/2Ch Preamp Outputs: The Dual XRA4120 features a pair of 2-volt preamp outputs to connect an external amplifier. The preamp outputs are fading and cannot be set to non-fading.
Equalizer: The Dual digital media receiver features the following preset EQ curves (Flat, Pop, Jazz, Rock, & Off/User) to customize your music listening. The Bass & Treble can be independently adjusted from +/-7 when in Off/User EQ mode. Activating the Loudness feature will enhance the bass and treble frequencies when listening to music at low volumes.
Key Beep: When this function is enabled, every button press will output a beep tone.
AM/FM Tuner: The Dual XR4120 features a built-in AM/FM tuner with manual, seek, & preset tuning. The built-in AM/FM tuner allows you to store up to 18 FM station presets and 12 AM station presets. You can tune your presets manually or have the head unit do it automatically.
- Preset Scan: The Preset Scan feature automatically scans your saved preset stations in the selected AM/FM band for five seconds each.
- Local: The Local function allows only strong radio stations to be received, blocking stations with weaker signals.
- Mono Mode: Selecting the Mono mode can improve reception in areas with weak FM signals.
Note: You can switch the tuner between USA or European tuning.
Detachable Face: The Dual digital media receiver features a detachable faceplate to deter theft (no face case is supplied). An optional soft face case (142DFC1X, sold separately) can be purchased for this unit.
10-Character LCD: The XR4120 features a 10 character LCD with white text & black background for easy viewing during the day or nighttime; plus blue button illumination.
12/24 Hour Clock: The unit's built-in clock will display 12-hour AM/PM time in USA frequency spacing mode. In European frequency spacing mode, the clock will display 24-hour time.
Wireless Remote Control: The XR4120 comes supplied with an 17-button IR remote control which provides wireless control over the Dual digital media receiver.
