About the Focal Integration ISS 165
You can use this angled tweeter mount to improve high-frequency dispersion in problem vehicles.
Focal applies the same technology they use in their studio and audiophile-grade home systems to their Integration line of car speakers. The Integration ISS 165 component system includes 6-3/4" woofers with cones made from Polyglass, a material that combines the warm sound of cellulose with the strength of glass, so they'll play accurately with no added resonances.
Each separate Integration processed aluminum inverted dome tweeter features a built-in phase plug and wave guide, which act together to increase the power of high-frequency notes and improve the stereo soundstage. Focal includes a low-profile surface mount and an angled mount so you can set up the tweeter for the best possible imaging in your vehicle.
Built-in crossover networks
The crossover networks are built-in, so you don't have those extra boxes to install. Low-profile Integration speakers allow you to put Focal sound quality and construction into your vehicle, so you can enjoy a dramatic jump in performance over your old speakers. Grilles are not included; factory grilles are appropriate for most installations.
Note: Focal describes this model as a 6-1/2" speaker. Most manufacturers designate this same frame size as a 6-3/4" speaker. For simplicity's sake we list it as a 6-3/4" speaker.
Installation note: You'll need a pair of our universal backstraps to install the tweeters in the factory locations
Woofer grilles are not included; the factory grilles should be suitable for most applications..
- component speaker system includes two 6-3/4" woofers and two tweeters
- Polyglass woofer with butyl rubber surround
- processed aluminum inverted dome tweeter
- built-in crossovers
- 4-ohm impedance
- 5-70 watts RMS power range (140 watts peak)
- frequency response: 60-20,000 Hz
- sensitivity: 92.6 dB
- woofer top-mount depth: 2"
- woofer grilles not included
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # ISS 165
What's in the box:
- Two woofers
- Two inverted dome tweeters (with 5" length of speaker wire attached)
- 2 Surface mount tweeter housings (with tweeters installed)
- 2 Angled surface mount tweeter housings
- Two 19" Lengths of speaker wire with in-line tweeter crossovers
- Two 7" Lengths of speaker wire with in-line woofer crossovers
- 2 Woofer mounting gaskets
- 8 Speed clips
- Four 7/8" Flathead screws
- Eight 1" Self-tapping screws
- Owner's manual (English/ French)
- Focal window sticker
More details on the Focal Integration ISS 165
Features & specs
|Speaker Size||6 1/2|
|Tweeter Design||Inverted Dome|
|Woofer Surround||Butyl Rubber|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||88.5|
|Sensitivity at 2.83 volts||92.6|
|Frequency Response||60 - 20k Hz|
|Minimum RMS Wattage||5|
|Maximum RMS Wattage||70|
|Peak Power Handling (Watts)||140|
|Top-mount Depth (Inches)||2|
|Bottom-mount Depth (Inches)||N/A|
|Cutout Diameter or Length (inches)||5 5/8|
Polyglass Cone: The woofer cone has a cellulose pulp base and is coated with a uniform deposit of hollow glass microballs. The addition of the Polyglass layer significantly increases the cone's rigidity without adding much weight. This combination takes advantage of the accuracy and neutrality of the hard outer surface, but maintains the superior damping characteristics of the cellulose pulp.
Surround: The butyl rubber surround is resistant to ultraviolet rays, temperature extremes, and humidity to add to the speaker's reliability and longevity.
Phase Plug: The bullet-shaped phase plug in the center of the woofer ensures a smooth, flat off-axis frequency response by preventing the high frequency sound waves emanating from one side of the cone from interfering with sound waves from the other side of the cone.
Voice Coil: The voice coil is wound around a 1" diameter low-mass Kapton former, ensuring no coil deformation.
Size Classification Note: Crutchfield has traditionally referred to this size woofer as a 6-3/4", while some manufacturers, including Focal, call it a 6-1/2". Please refer to the Crutchfield Vehicle Selector to confirm fit in your vehicle.
Crossovers: The included 7" woofer wires have integrated crossovers. The woofer ends of the wires have female quick-slides that easily connect to the woofer terminals.
Inverted Dome Tweeter: The tweeter is an inverted aluminum dome, producing a broad sound stage. The tweeter has a Neodymium magnet to provide a powerful magnetic field for the voice coil, while still maintaining the tweeter's compact dimensions.
Mounting Options: The tweeters include two types of surface mount housings, one low profile and one angled:
|Flush Mount||Low Profile Surface Mount||Angled Surface Mount|
|Mounting Depth||0.55"||0.875" (screw depth)||0.875" (screw depth)|
Crossovers: The included 19" tweeter wires have integrated crossovers. The tweeter ends of the wires have quick-slide terminals that easily connect to the wires soldered to the tweeters. The input end of each wire has three leads, a negative and two positives. The positive leads are labeled Car and Display, with a lower output level from the Car lead (useful because the placement of the woofer in a typical car installation requires the tweeter output be lowered to maintain a balanced sound).
