If you prioritize performance in what you drive, why not hold your audio system to the same standards? With the utmost care and commitment to premium sound, Focal designed, developed, and manufactured these Utopia TBM 1" tweeters at their workshop in Saint-Etienne, France. They stun with sonic accuracy and depth of sound on par with those in Focal's highly acclaimed home speakers. Incorporate these tweeters into a custom system with other Focal components and enhance your passion for driving with revealing highs and a sparkling soundstage.
What a Beryllium tweeter can do
Focal's unique 'M'-profile inverted dome tweeter employs Beryllium for its supremely smooth highs. Lighter and more rigid than both titanium and aluminum, this material brings the smoothness of a silk tweeter to your music, but with the accuracy and extended response usually associated with a high-quality metal tweeter. Brace yourself for a new level of detail from these tweeters.
A la carte
This component speaker was designed to be part of a Focal Utopia M system, incorporating these other high-performance speakers:
These components will deliver the ultimate in car audio performance, whether you install them in factory speaker locations or use them for a custom installation.
Installation Note: You'll need an active crossover for these tweeters, as Focal doesn't include passive crossovers.
- 1" tweeters
- Beryllium 'M'-profile inverted dome design
- tuned mass damper surround
- integrated grilles
- includes mounting brackets
- 4-ohm impedance
- handles up to 20 watts RMS (200 watts peak power)
- frequency response: 1,500-40,000 Hz
- sensitivity: 95 dB at 2.83 volts
- top-mount depth: 13/16"
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # UTOPIA TBM
What's in the box:
- Two inverted dome tweeters
- 2 Flush mount housings (with tweeters installed)
- 2 Magnet covers
- Beryllium precautions
- Focal brochure
Focal TBM reviews
Thanks for submitting your review
More details on the Focal TBM
Features & specs
|Tweeter Design||M-Profile Inverted Dome|
|Woofer Surround||Butyl Rubber|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||N/A|
|Sensitivity at 2.83 volts||95|
|Frequency Response||1500 - 50k Hz|
|Minimum RMS Wattage||---|
|Maximum RMS Wattage||20|
|Peak Power Handling (Watts)||200|
|Top-mount Depth (Inches)||0 13/16|
|Bottom-mount Depth (Inches)||N/A|
|Cutout Diameter or Length (inches)||0|
|Mounting Height (Inches)||0.152|
Magnet Cover: The included covers snap onto the tweeter magnets to create a "small volume" enclosure. The cover can be used with or without the flush mount housings. Without the magnet covers, the tweeters retain their IAL design (Infinite Acoustic Load).
Mounting: The tweeters are already installed in the flush mount housings when shipped. Each housing is mounted using the single screw hole in the rear. In the same way the tweeters are mounted in the housings using four screws, they can be mounted without the housing using the same screw holes. (Useful if your space won't accommodate the size of the housing.) The tweeter depth is 0.585" when mounted without the flush mount housing and with the magnet cover. Once installed the tweeters do not swivel.
Tweeter Mounting Dimensions:
|w/o Flush Mount Housing||With Flush Mount Housing|
Crossover: No crossovers are included with the tweeters, so an electronic (preferred) or passive crossover must be added.
