About the Infinity Kappa 50.5cs
Catapult your system into the upper echelons of mobile audio with a Kappa component speaker system from Infinity! Ceramic Metal Matrix Diaphragm (C.M.M.D.) cones were first developed for Infinity's award-winning Prelude MTS home speaker system. They are constructed by bonding an aluminum cone to layers of ceramic, forming a driver that is lightweight, rugged, and extremely responsive.
Unlike other speakers, the high-roll rubber surround on the 50.5cs woofer is attached to the bottom of the Ceramic Metal Matrix Diaphragm (C.M.M.D.) cone. The result is more cone area for incredible depth and fullness in the low frequency spectrum. The cone is lighter than previous models too, for greater midrange sensitivity.
Angle the highly-acclaimed C.M.M.D. tweeter in flush-mount mode for superb stereo imaging. The 3,500 Hz crossover network (18 dB/octave high-pass, 18 dB/octave low-pass) channels signals to the appropriate drivers for seamless output.
Product Highlights:
- Ceramic Metal Matrix Diaphragm Plus One woofer cone
- 1" C.M.M.D. dome tweeter can be flush-, surface-, or angle-mounted
- hi-roll rubber surround
- 2-way crossovers (high-pass/low-pass at 3500 Hz, 18 dB/octave)
- frequency response 55-21,000 Hz
- power range 2-85 watts RMS
- peak power handling 255 watts
- sensitivity 90 dB
- top-mount depth 2-1/16"
- 3-year warranty
- MFR # KAPPA50.5CS
What's in the box:
Infinity Kappa 50.5cs owner's manual
- 2 Woofers
- 2 Grilles
- 2 Grille rings
- 2 Crossovers
- 2 Tweeters (each tweeter has attached 10" speaker leads)
- 2 Flush-mount cups
- 2 Threaded flush-mount adapters
- 2 Plastic locking nuts
- 2 Surface-mount cups
- Two 0.205" female quick-slides
- Two 0.110" female quick-slides
- Eight 1" self-tapping screws
- Four 5/8" self-tapping screws
- Four 7/16" self-tapping screws
- 2 Nuts
- 4 Clip washers
- 8 Speed clips
- Instructions
- Warranty/registration card
Reviews
Customer reviews
Loading reviews...
Infinity Kappa 50.5cs reviews
Average review:
Thanks for submitting your review
Customer photos
This review was collected as part of a promotion
Pros:
Cons:
More details on the Infinity Kappa 50.5cs
Features & specs
| General | ||
|---|---|---|
| Speaker Size | ||
| Design | 2-way | |
| Tweeter Design | 1" Dome | |
| Impedance (Ohms) | 4 | |
| Tweeter Composition | C.M.M.D. | |
| Woofer Composition | C.M.M.D. | |
| Woofer Surround | Hi-roll rubber | |
| Parts Warranty | 3 Years | |
| Labor Warranty | 3 Years | |
| Specifications | ||
| Sensitivity (1W at 1 meter) | N/A | |
| Sensitivity at 2.83 volts | 90 | |
| Frequency Response | 55 - 21k Hz | |
| Minimum RMS Wattage | 2 | |
| Maximum RMS Wattage | 85 | |
| Peak Power Handling (Watts) | 255 | |
| Top-mount Depth (Inches) | 2 1/16 | |
| Bottom-mount Depth (Inches) | N/A | |
| Cutout Diameter or Length (inches) | 4 3/4 | |
| Mounting Height (Inches) | 0.4 | |
Product Research
C.M.M.D. Plus One Woofer Cones: These speakers use cones approximately 30% larger than other speakers of the same size. This is accomplished by using a new basket design and hi-roll surround. The Plus One design offers greater bass output and a significant increase in efficiency. In addition, the C.M.M.D. cones virtually eliminate coloration due to cone flexing, resulting in less distortion and superior accuracy.
Surrounds: The hi-roll rubber surrounds allow the woofers a greater range of movement, resulting in longer X-max and more bass output.
Tweeter Materials: Each tweeter features a 1" C.M.M.D. dome that offers superior stiffness and damping compared to traditional metal domes. Each tweeter is driven by a powerful neodymium magnet, resulting in higher power handling and superior detail.
"I-Mount" Tweeter Mounting System: Surface mounting involves mounting the surface mount cup (using the supplied screws), then snapping the tweeter into the cup. Flush mounting is made easy through the use of the threaded flush mount adapter and plastic locking nut. For flush mounting, the tweeter is snapped into the flush mount cup. Then, the cup is secured to the flush mount adapter with a nut and clip washer. Once a cutout is made, the flush mount adapter (with the tweeter installed) is inserted into the hole. The large plastic locking nut is threaded onto the adapter (from behind the mounting surface) to hold the complete assembly securely in place. When flush mounted, the tweeters may be angled for optimum response and imaging. There are no provisions for angled surface mounting of the tweeters.
Tweeter Mounting Dimensions:
| Surface Mount | Flush Mount | |
| Mounting Height | 0.996" | 0.588" |
| Depth | (0.315" screw depth) | 1.164" |
| Frame Diameter | 1.646" | 2.003" |
| Cutout Diameter | NA | 1.781" |
2-Way Crossovers: These speakers include computer-optimized, voice-matched crossovers. Each crossover features an 18dB/octave, 3.5kHz high-pass network for the tweeter and an 18dB/octave, 3.5kHz low-pass network for the woofer.
Custom Contour: Custom Contour, if enabled, will reduce the midrange output from the system, resulting in more perceived bass and high frequency response. In each crossover, this feature is enabled using the jumper, which is connected directly to the circuit board.
Crossover Connections: The crossover inputs and outputs are gold-plated screw terminals.
Mounting: There are two mounting holes in the base of each crossover.
Crossover Dimensions: L=4.251", W=3.008", H=1.437"
The Infinity Kappa 50.5cs replaces these items
- Plus One 5-1/4" C.M.M.D. woofers with rubber surrounds
- 1" C.M.M.D. dome tweeter
- high-quality 2-way crossovers
