About the Jensen BUCAM300AJ
Reverse that rig
Reverse that rig
Got a big vehicle like an RV? Wouldn't it be great to hear your co-pilot's instructions loud and clear over speakers when you're reversing into a campsite? Jensen builds a microphone into their BUCAM300AJ rear-view camera so you can hear what's behind you as well as see it. The camera delivers a wide 170-degree horizontal view that's an invaluable aid when you're reversing into a tricky spot.
The camera's composite video connection makes it a great match for any video receiver with an RCA rear-view camera input.
- waterproof CMOS color rear-view camera
- built-in microphone
- universal fit
- composite video connection
- 170-degree wide angle
- parking guidelines
- minimum illumination: 0.5 Lux
- IP rating: IP67
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # BUCAM300AJ
What's in the box:
- Rear-view camera w/ bracket (attached 18" power/audio/video cable)
- 7' Power/ground cable
- 19.75' Composite video/mono audio cable
- 2 Screws
- Self-adhesive tape
- Installation Manual
More details on the Jensen BUCAM300AJ
Features & specs
|Features and Specs|
|Lux Rating||0.5 lux (min)|
|Horizontal Viewing Angle||170 deg|
|Vertical Viewing Angle||N/A|
|Plug type||Composite video, Mono-RCA|
Backup Camera: This rear-view camera can be installed on a variety of vehicles with an in-dash aftermarket video monitor. Your aftermarket in-dash monitor must feature a composite video camera input. The camera allows you to view what's behind your vehicle on your in-dash monitor's screen when you put your vehicle in reverse.
Note: This rear-view camera is meant as a back-up aid only; never solely rely on the rear-view camera when backing-up. In addition to using the rear-view camera, always look behind you to make sure everything is clear when backing up your vehicle.
CMOS Image Sensor + Wide View Lens: The rear-view camera employs a CMOS image sensor with a resolution of 640 x 480 (effective pixels). The image sensor also incorporates auto white balance. The rear-view camera features a 170-degree wide view lens to help you see better behind your vehicle. The rear-view camera provides low-light visibility down to 0.5 lux.
Built-In Microphone: The rear-view camera even features a built-in omni-directional microphone to pick up sound behind your vehicle.
Parking Guidelines: The rear-view camera provides parking guidelines on the screen of your vehicle's in-dash monitor to help you back into a parking space. The parking guidelines cannot be turned off.
Audio/Video Connection: The rear-view camera comes with a 19.75' composite video/mono-RCA audio cable to run from the camera to the camera input (consisting of a composite video & mono-RCA jack) of your vehicle's in-dash monitor. An RCA-to-3.5mm audio adapter may be required for some receivers.
Weather Resistant Housing: The rear-view camera utilizes a weather resistant zinc alloy housing with a IP67 rating.
Mounting Bracket: The rear-view camera comes with a bracket that allows you to mount the camera under a flat surface on the back of your vehicle. Two screws and self-adhesive tape are supplied. The mounting bracket allows you to adjust the angle of the camera up or down.
Power Requirements: In addition to connecting the rear-view camera to your in-dash monitor's composite video camera input, you will also need to connect the camera's power wire to your vehicle's positive reverse lamp circuit and the camera's ground wire to your vehicle's metal chassis.
