Kenwood Excelon KFC-X3C Excelon Series 3-1/2" 2-way car speakers

Item # 113X3C

Find what Fits your vehicle

Remove

Checking fit...

14 questions - 20 answers

Item # 113X3C

Ships free

On backorder
Expected: 4/7/2024

Deeply discounted installation gear

$79.00 pair

Other options

About the Kenwood Excelon KFC-X3C

Alexander H.

The speaker for the spot

That blown dash speaker is driving you nuts, isn't it? Kenwood's Excelon KFC-X3C 3-1/2" speakers are the perfect replacement, incorporating silk dome tweeters  for an extended high range. You can count on Excelon quality sound from these carbon-fiber cones that can handle up to 50 watts RMS. Grilles are not included.

Product highlights:

  • 3-1/2" 2-way car speakers (pair)
  • polypropylene cone with silk dome tweeter
  • handles up to 50 watts RMS (120 watts peak power)
  • frequency range: 800-23,000 Hz
  • top-mount depth: 1-7/16"
  • sensitivity: 83 dB
  • impedance: 4 ohms
  • grilles not included
  • warranty: 2 years
  • MFR # KFC-X3C

What's in the box:

  • Two 2-way speakers
  • Two 12" Lengths of speaker wire with in-line crossovers (attached)
  • Adhesive backed foam gaskets
  • Installation instructions (English/ French/ Spanish)
  • Specifications printed on box

Customer reviews for Kenwood Excelon KFC-X3C

Loading reviews...

Average review:

5.0 out of 5 stars
219 reviews

Thanks for submitting your review

Filter by rating

Customer photos

Customer provided image, click to load a larger version.
Customer provided image, click to load a larger version.

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee review (What's this?)

Reviewed on Samsung.com

This review was collected as part of a promotion

Pros:

Cons:

Crutchfield response
Customer provided image, click to load a larger version.
<< >>

More details on the Kenwood Excelon KFC-X3C

Pat M.

Features & specs

General
Speaker Size 3 1/2
Design 2-way
Tweeter Design Balanced Dome
Impedance (Ohms) 4
Tweeter Composition Silk
Woofer Composition Polypropylene
Woofer Surround Rubber
Parts Warranty 2 Years
Labor Warranty 2 Years
Specifications
Sensitivity (1W at 1 meter) 83
Sensitivity at 2.83 volts N/A
Frequency Response 800 - 23k Hz
Minimum RMS Wattage ---
Maximum RMS Wattage 50
Peak Power Handling (Watts) 120
Top-mount Depth (Inches) 1 7/16
Bottom-mount Depth (Inches) N/A
Cutout Diameter or Length (inches) 2 15/16
Mounting Height (Inches) 0.315
Frame Width 3.429
Frame Length 3.429

Product Research

Features

Crossovers: A high-pass crossover is integrated into each included wire. The output end of the wire has quick slides that plug onto the speaker terminals. (The input end of the wire is not terminated.)

Warranty Note: Although the information included with these speakers indicates a 1-year warranty, they are actually covered by the Kenwood eXcelon 2-year warranty.

Loading accessories...

Customer Q&A

14 questions already asked

Q
I want to upgrade the dash speakers in my 2022 RAV4 with a factory head unit. Should I install the crossover? Thanks
mark  Sep 23, 2023
1 answer
A
The Kenwood Excelon KFC-X3C would be an excellent choice there (pun intended LOL), Mark! You would need to install the crossover as you can damage your speakers without it, and the crossover also would provide the best possible sound quality from the Kenwood speakers.
bo  Sep 23, 2023 (Staff)
Q
Are these 50 watts per speaker or 50 watts for the pair(meaning 25 watts each)?
eliseo  Mar 04, 2023
1 answer
A
Greetings Eliseo, and thank you for your question. The rating is per speaker, not total for the pair.
hogan  Mar 08, 2023 (Staff)
Q
I'm planning to change out my dash speakers for my 2022 Venza xle. Will it work for the factory JBL HU?
kalun  Feb 02, 2023
1 answer
A
This would be compatible with the factory JBL system. These speakers have a similar impedance to the factory speakers, which we measured at 3.4-ohm. The safest option would be to replace with a 4-ohm speaker like the KFC-X3C.
zachary  Feb 02, 2023 (Staff)
Q
I need 3 speakers, 2x dash corner plus one on center. Do you sell single speakers?
hannu  Oct 22, 2020
1 answer
A
Most of our speakers do come in pairs. Depending on the car the speakers are going in we might have a speaker that is sold individually. We would want to check fitment of the speaker to make sure it works in your car. If you need help give us a call at 1-800-324-9695 and we'll be glad to help you find a solution!
allison  Nov 13, 2020 (Staff)
Q
I am installing these in a 2020 gladiator. the speakers came with a inline crossover. do I connect the Metra plug after the crossover or do I remove the crossover?
luis  Jul 16, 2020
1 answer
A
I recommend installing the inline crossover. It may not be needed depending on the stock system in the Gladiator, but it doesn't hurt anything to be installed.
jason  Aug 03, 2020 (Staff)
Q
Do they come with bass blockers if so can I remove them?
jennifer  May 13, 2020
3 answers
A
They come with two 12" Lengths of speaker wire with in-line crossovers (attached).
casey  Jun 01, 2020 (Staff)
A
Mine came with a bass blocking capacitor which I was easily able to remove. I unsoldered the wires from my factory speaker and soldered them to the new Kenwood speakers and just plugged them in. I'm in a unique situation where my car has the JBL Greenedge system which is supposed to be ultra efficient and the amplifier only puts out a few watts per channel. I was VERY surprised to hear the Kenwood speakers play rich and full on the factory amplifier. I can literally go to "Max" on the dial and they play clean. Yes, they would be happy with more power but could not be more pleased with the sweet, balanced sound they are providing. The factory JBL upgrades system really wakes up when speakers are replaced with ones capable of true fidelity. I'm sure the Toyota JBL Greenedge system has factory crossover settings in place, not sure if you'd want to blast these little speakers with 150 watts of full range bass?? That being said, Crutchfield was out of stock on these speakers and as soon as they were available again, I purchased another pair for the rear corners on the Camry JBL system. I previously had FOCAL Toyota Specific speakers in the rear corners but they were VERY shrill and harsh, the Kenwoods are much richer and more pleasing. Sorry for the long answer of..... YES, they are in the wiring harness and are designed to be removed, they simply unplug out of the line.
randall  May 28, 2020
A
They do not.
michael  May 28, 2020
Q
Hello, I am looking for a pair of speakers to replace my tweeters speakers in my 2016 Jeep roll bar. Will these speakers need a bass blocker ?
james  Mar 24, 2020
1 answer
A
If you are sending a full-range signal to them a bass blocker would definitely be a good idea.
casey  Apr 14, 2020 (Staff)
Q
Does this fit an extended cab door for a 2002 Chevrolet Silverado?
emilianov1  Jan 13, 2020
3 answers
A
I put them in a jeep renegade not sure
allen  Jan 18, 2020
A
Works great with my 1993 Ford Mustang. Matter of fact, I love the way it sounds and handles the power from my old school Kenwood deck.
gerald  Jan 14, 2020
A
You can either call crutchfield or go to their website, input your truck information, and find out if they do for your truck.
carlos  Jan 13, 2020
Q
Does this fit in a extended cab door for a 2002 Chevrolet Silverado?
emilianov1  Jan 13, 2020
1 answer
A
You can check to see if this will fit your vehicle by using our Outfit My Car tool: http://www.crutchfield.com/car/carselector.aspx For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
kristina  Jan 28, 2020 (Staff)
Q
I want to install this in The dash corners of a Subaru Legacy 2017. Sadly there's no wiring harness for them, so how do I connect them? Does it include some wires or do I have to purchased a harness myself?
michael  Sep 24, 2019
1 answer
A
These speakers come with two 12" lengths of wire that you can splice into the stock wiring using tap connectors like these: www.crutchfield.com/p_669PP605/item.html Then you can connect the other end to the speakers
jason  Oct 09, 2019 (Staff)
Q
I want to run these active with some illusion audio 6.5's off a 4 channel amp. The pioneer headunit will provide the crossover set point adjustments for me, my question: how do I set the high pass for the tweeters themselves or is there a capacitor inline already to do that? Where should I start the crossover points for these on my head unit? Just confused as to whether to set low pass at xx and high pass around xx what that will do to the tweeters?
robert  Aug 21, 2019
2 answers
A
Inline capacitors built into leads for speakers
allen  Sep 11, 2019
A
If you purchased the product from Crutchfield, feel free to contact our Tech Support team. Our toll-free Tech Support number is printed on your invoice, and is also available under the "My Orders" tab in the "My Account" section of our website. If you did not purchase the unit from Crutchfield, then you may want to contact the manufacturer.
kristina  Sep 11, 2019 (Staff)
