XS Power D3400

Deep cycle 12-volt battery

Item # 122D3400

Give your vehicle the necessary juice to perform at its best.

Read more from Crutchfield writer, Dominic D.

California customers:
Please click here for your Proposition 65 warning.

Ships free

Temporarily out of stock

Expected: 3/22/2019


About the XS Power D3400

Give your vehicle the necessary juice to perform at its best. XS Power deep cycle batteries can act as replacements for your car's standard battery, or you can use them as auxiliaries to power your high-performance sound system and hydraulics reliably. If you've got a boat or an RV, XS Power's got a solution for your electric needs, too.

Depending on your vehicle and the application, you'll need some accessories to connect your XS Power battery. To see what works with this battery, click on the "Accessories" tab above. If you have questions, our advisors are here to help.

Give your vehicle the necessary juice to perform at its best. XS Power deep cycle batteries can act as replacements for your car's standard battery, or you can use them as auxiliaries to power your high-performance sound system and hydraulics reliably. If you've got a boat or an RV, XS Power's got a solution for your electric needs, too.

AGM technology

XS Power deep cycle batteries feature a sealed absorbed glass mat (AGM) design that incorporates special glass fiber mats that contain the acid electrolyte between the lead plates, rather than a standard flooded (liquid) design. This leak-proof, non-hazardous configuration typically lasts longer than normal replacement batteries if properly charged. These batteries actually store energy, so you don't have to add a capacitor to your system to get a quick burst when you need it.

Leak-proof design

Since there are no external vents on an XS Power battery, you can mount it in a passenger compartment, below a seat, or inside a glove box without fear of leaks. No leaks mean no corrosion or damage to chrome or paint. XS Power guarantees their batteries will not leak, even if damaged. These batteries also resist extreme vibrations so they'll perform in the trunk or hatch area without skipping a beat.

XS Power D3400

The XS Power D3400 deep cycle 12-volt battery provides up to 3,300 maximum amps and has a capacity of 65 amp-hours. A reinforced plastic case protects it in your vehicle. Check "Accessories" for items that'll help you install and secure your new battery.

Need more help choosing the right battery for your vehicle?

XS Power offers a handy vehicle guide on their website. Simply enter the year, make, and model, and you'll instantly receive a list of batteries that should fit your vehicle. And they'll recommend installation accessories to help make things more convenient. Or just give us a call and talk to one of our advisors.

Important Note: You must charge this battery before installing it. We recommend XS Power's HF IntelliCharger (sold separately) to charge this battery properly. Improper charging can permanently damage the battery, and void your warranty.


Product highlights:

  • 12-volt deep cycle car battery
  • sealed absorbed glass mat (AGM) design
  • reinforced ABS plastic case
  • 1,000 cranking amps
  • maximum output: 3,300 amps
  • discharge capacity: 65 amp-hours
  • fits BCI Group 34 vehicles
  • 10-1/4"W x 7-1/4"H x 6-3/4"D (measure for fit)
  • weight: 46.0 lbs.
  • warranty: 3 years
  • Our 60-day money-back guarantee
  • MFR # D3400

What's in the box:

  • D3400 AGM Deep cycle 12 volt battery
  • 2 M6 bolts
  • 2 Split lock washers
  • D Series Instruction Sheet

Customer reviews

Loading reviews...

XS Power D3400 Reviews

Average Customer Review(s):

Verified customer (What's this?)
Verified employee purchase (What's this?)



Crutchfield response

More details on the XS Power D3400

Product Research


Overview: The XS Power D3400 is a 12-volt battery that is designed to be used as a supplemental power source in your vehicle, or it can replace your vehicle's OEM battery. It can supply the power needed to run your high-powered audio system, better than a standard battery.

Terminals Needed: This D-series battery does not come with battery terminals, so you will need to purchase the proper terminal adapters for your application before installation can take place:

  • Car Stereo Installation: You will need terminal adapters that fit the inner diameter of your power ring terminals. Recommended terminal adapters include: Two 5/16" brass stud adapters (#589), Two 3/8" brass stud adapters (#590), Two 5/16" + Two 3/8" brass stud adapters (#588), or Two 3/8" zinc-plated steel stud adapters (#587). For dual-battery installations, a second battery install kit, such as the XS Power AK3500, can be used to connect the D3400 in parallel (+ to + and - to -) with the main battery.
  • OEM Battery Replacement: The D3400 fits the BCI Group 34 vehicle applications and will fit GM vehicles applications. For vehicles with side-post terminals, an i-Bar (#551, #555, #556) can convert the top terminal into a side terminal, and provide terminals on the top for connecting your amplifier power. If you are installing the battery under the hood or replacing your vehicle's OEM battery, you will need either the Short Brass Post Adapters (#580) or the Long Brass Post Adapters (#586) to connect your battery cables. The 3400 Billet Aluminum Hold Down (#573) can also be used to install the battery under the hood.

Absorbent Glass Mat (AGM): XS Power's AGM (Absorbent Glass Mat) batteries use a fibrous material to suspend the liquid electrolyte against the lead plates. Because the electrolyte is absorbed in the material, there is little chance of an acid leak, even in the event the case is ruptured. AGM batteries contain more lead compared to traditional "flooded" batteries, thus producing more power.

Charging the Battery: It is very important to properly charge an Absorbent Glass Mat (AGM) battery before using. Improper charging can permanently damage the battery, and will void the warranty. The XS Power HF IntelliCharger for AGM Batteries (sold separately) has a microprocessor that monitors the charging process to avoid overcharging, and is recommended for this battery.

Specifications: The D3400 has the following specifications:

  • MAX Amps: 3300 amps
  • Cranking Amps (at 32°F): 1000 amps
  • Reserve Capacity: 135 minutes
  • Discharge Capacity: 65 Ah (amp hours)
  • Dimensions: Length=10.24", Height=7.2", Width=6.75"
  • Weight: 46 pounds

Loading accessories...

Customer Q&A

Crutchfield asked: Why did you buy this?
Needed a reliable battery. [ Robert Thomas  Feb 18, 2019 ]
For the POWER! [ Jessie  Jan 18, 2019 ]
it is just a little bigger than stock and will fit great. [ ronald  Jan 16, 2019 ]
I needed big power [ Andre  Aug 10, 2018 ]
Love this battery tons of power, always positive reviews and perfect for some car audio goods. [ R  Jun 25, 2018 ]
had one before. loved it so i bought two more [ Aaron  Feb 08, 2017 ]
Reveiws [ STEVE  Mar 04, 2016 ]

10 questions already asked

Will this battery fit under the hood of a 2013 mustang gt California special 5.0?
[ Jeffery  Mar 01, 2017 ]
1 answer
For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Kenny  Mar 01, 2017 ]  Staff
Can this battery fit inside a 2014 tundra?
[ Antoniyo  Feb 23, 2017 ]
5 answers
yes it will fit. The battery comes with Top posts. So if you need side post extensions you will have to order them extra.
[ K  Mar 02, 2017 ]
Are you talking about under the hood, or in the cab? Either way you should use a tape measure to find lenghtxWidthxHeight
[ SHANE  Feb 23, 2017 ]
yes it is a normal siize batt. with top p-ost . it will fit your factory battery7 box just fine
[ chris  Feb 23, 2017 ]
[ RODNEY  Feb 23, 2017 ]
Yes. You'll Reach the truck's weight capacity before you run out of room.
[ Paul  Feb 23, 2017 ]
Does this battery fit 2017 Hyundai elantra se?
[ David  Feb 04, 2017 ]
2 answers
not positive but this is not an oversized battery
[ chris  Feb 23, 2017 ]
For additional details on fit please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Kenny  Feb 07, 2017 ]  Staff
will this battery work on a 1997 Honda accord?
[ eli  Dec 05, 2016 ]
2 answers
Your Honda is battery group 24 so the d3400 may not work in your vehicle. Try the d2400 as that should be a direct fit.
[ NATHAN  Dec 06, 2016 ]
Best place to check is the xs power website
[ Joseph  Dec 06, 2016 ]
Will this work as a high powered battery for starting as well as audio electronics? I have a 2004 Pontiac Grand Prix GT1 with 2 10' kickers (500 watts peak) and a 600W Max kicker amp.
[ Cullen  Jul 22, 2016 ]
12 answers
[ Daniel  Aug 03, 2016 ]
I am using that right now with two sundown audio sa-12 rev.3 probably pushing close to 1500 watts rms with a kicker kx 2400.1 amp in a 2005 avalanche custom set up self done. Im pretty sure you'll be fine. The only thing I have extra is a big 3 upgrade crutchfield has some great info how to do it on their site. I had an upgraded alternator too but I'm back to stock
[ Lelunde  Jul 26, 2016 ]
Yes with no problems I have the d3400 running Rockford Fosgate prime D 500 mono pushing Sundown 8 500 watts and Rockford Fosgate prime D 400 4ch
[ ceon  Jul 23, 2016 ]
It should. I was running this batt to push 2 15' RF T1 on a 1000rms RF T1 amp in a 2009 impala. I still had voltage drops to the mid 12v range at night. My original battery would drop in the 10v range
[ Joseph  Jul 23, 2016 ]
It should be more then enough with the amount of power you are runing from your amp, also doing a big 3 upgrade helps alot with your charging system.
[ MICHAEL A  Jul 22, 2016 ]
Easily. I have one in my 2010 F150 that I run old school, power hungry amps in with no issues even at night! Ran my stereo through two whole movies at the drive in sitting in the bed and truck didn't even hesitate to start!
[ Samantha  Jul 22, 2016 ]
This will more than do the job. No worries. I'm running a Memphis mojo 2500.1 and 2 arc audio 300.4 in a Cadillac. STS. It handles it fine. I was going to run 2 batteries but this one does the job. Best upgrade I've made, besides adding processor
[ Jo-nathan  Jul 22, 2016 ]
if that car fits a group 34 I would defiantly do it. I ran this on my old 01 accord wit big 4 upgrade two type s 12s at 1ohm to 1000 watt Cerwin Vega Mono block volt meters to the back and front so know this thing would never drop below 13.6 even on the deepest longest notes... Great product with lots of room to upgrade system
[ ANDREW  Jul 22, 2016 ]
Yes, this battery will have more than enough power. Cars only use the battery on initial start up and when a lot of power is being drawn. When a car is running the alternator should take over for the most part. The beauty of this battery is that you can play your stereo all night long with your car off and still have enough power to start up your car in the morning. (My 1600 watt system has pulled many all nighters blasting music) This battery has not let me down once.
[ BRIAN J  Jul 22, 2016 ]
I had this battery in a v8 f150 and a v6 mustang running a mrx-m110 mono amp and a mrx-f65 4 channel just fine. Make sure this battery will fit in your car, as a good number of GM products require side post batteries. If it fits, it's more than enough for what you need.
[ Courtney  Jul 22, 2016 ]
Yes it will work. I have 2 of these batteries in my 1997 Chevrolet Silverado with 4 12' Alpine type R subs and a MA Audio 4000W amp.
[ NATHAN  Jul 22, 2016 ]
It should be able to handle it. Be advised, that your alternator will be handling majority of your electrical load while the car is running. The battery starts car. The alternator runs the car and charges the battery once the engine is running. A larger battery would allow you to run your sound system longer with the engine off. The amount of power your running shouldn't be too much of a drain on your alternator. I'm currently running a dual battery setup with a custom high output alternator. The d3400 is my primary and I have a smaller one just for my bass amplifier. I haven't had any issues with this battery, but I spent a significant amount of time and money upgrading my electrical system. Consider upgrading your entire electrical system(higher amperage alternator,bigger battey/dual battery, and a larger gauge amp wire kit) if you go up to a system that is pushing over 500 watts RMS so you can optimize your audio system. Any more questions?
[ Anthony  Jul 22, 2016 ]
Will this fit my 1997 Jeep Grand Cherokee limited?
[ Blaze  Apr 21, 2016 ]
3 answers
Yes, it is the correct BCI group so it is supposed to be a direct replacement.
[ Courtney  Apr 22, 2016 ]
Not sure. Check out xs power webstie to confirm fitment.
[ Anthony  Apr 22, 2016 ]
I do not know, but there are reference guides available by car make/model/year showing what fits.
[ Donald  Apr 22, 2016 ]
Will this work as a starting battery for a 06 jeep commander 5.7?
[ Jesse N Stephanie  Apr 04, 2016 ]
1 answer
For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.
[ Kenny  Apr 05, 2016 ]  Staff
Hello, i have a 1998 pontiac transport minivan, can i use an xs power battery as a starting battery & if so, which battery can i use & would i be required to have any modifications done including accessories for a proper fit? Thank you.
[ Dennis  Mar 08, 2015 ]
2 answers
Thank you very much krissy, have a wonderful blessed day.
[ Dennis  Mar 11, 2015 ]
I forwarded your question to an Advisor and they responded with the following: That battery will work in the vehicle. If it has side battery posts then they will need the XS Power 555 i-Bar kit, or f it has regular posts then they will need the XS Power Short Brass Posts. I hope this information helps. If you would like to discuss further you can contact an Advisor directly by phone (1-800-324-9695) or online chat.
[ Krissy  Mar 11, 2015 ]  Staff
Do these batteries ship charged? Or do I need to plan on purchasing a charger? I've read both yes and no reviews from different sites.
[ Ryan  Oct 23, 2014 ]
10 answers
They come charged. ??????????
[ Luciano  Oct 28, 2014 ]
When I received my xs power batteries they where 12.8 Volts, but I put it on the charger over night before i put them in my car and it was 12.9 volts resting.
[ STEVE  Oct 24, 2014 ]
Yes, you have to charge it. I purchased mine about a year ago. It recommends that you charge it over night with a battery charger.
[ PAUL A  Oct 24, 2014 ]
Mine came charged, went from box to under the hood read 13.4 i believe before i fired car no problems. I imagine it couldn't hurt to charge before initial use if you have easy access to the correct type of charger
[ GREGORY M  Oct 24, 2014 ]
Mine came resting at 11.9 I believe I could have hooked it straight up to my truck but I always sit a new battery on a charger before an install, your local auto parts store will do it for free too so you don't have to buy a charger
[ KALEB  Oct 24, 2014 ]
Mine shipped charged (not fully charged but almost), but I would purchase a charger anyway.. Make sure you purchase the correct charger, or you will mess up the battery..
[ MARC C  Oct 24, 2014 ]
Mine came charged, I checked it with a voltage meter before installing it (forgot voltage exactly). But once installed I let my engine run for a good while so the alternator could charge it up fully.
[ KEAMMY  Oct 24, 2014 ]
I received mine from Crutchfield with a PARTIAL charge. You will need a charger though to get the initial charge that the battery needs to see for like 24 hours prior to use. It needs the full 14.4v from a charger, not the 13.8 from your car system for it to be 100% effective as an audio system battery.
[ MICK  Oct 24, 2014 ]
Honestly it's best to charge before use because your alternator will not charge it to its full potential.. I just took mine to autozonr and let th charge mines for free
[ LAVONTE  Oct 24, 2014 ]
The battery comes with a good charge, but you need to charge before use so you don't lower the overall resting charge of the battery.
[ MATHIS  Oct 24, 2014 ]
i have a yukon xl 2004 im running 0 awg amp kit 10 awg speaker wire and 2500w sundown audio amp and two 15 ' sundown audio x15 total 2500rms i got a 240 amp alternator and i was wondering would this battery be fine the d3400?
[ tammy  Jan 23, 2014 ]
1 answer
Thanks for your question. I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help you make the best choice for your system.
[ Krissy  Jan 24, 2014 ]  Staff
