Pioneer TS-A300TW

A-Series 3/4" tweeters

Item # 130TSA300T

Find what Fits your vehicle

Item # 130TSA300T

Since 1974

Years of experience making people happy.

Hands-on research

We double check the details on each item.

Audition speakers online

Compare different models with just a pair of headphones.

About the Pioneer TS-A300TW

Alexander H.

Enjoy new details

Fight mushy sound with Pioneer's A-Series TS-A300TW 3/4" tweeters. The polyimide hard dome design ensures impressive detail and minimal distortion at high volume so you can finally enjoy your tunes the way they're meant to be heard. Inline crossovers channel the appropriate frequencies to these tweeters, and Pioneer includes versatile flush- and surface-mounting hardware so you can get them in the right spot to maximize the soundstage in your car.

Product highlights:

  • 3/4" polyimide hard dome tweeters (pair)
  • flush- and surface-mount hardware included
  • inline crossovers included
  • handles up to 100 watts RMS (450 watts peak power)
  • frequency response: 1,400-69,000 Hz
  • sensitivity: 88 dB
  • top-mount depth: 1/2"
  • warranty: 1 year
  • Our 60-day money-back guarantee
  • MFR # TS-A300TW

What's in the box:

  • Two tweeters (with attached 10" speaker leads terminated with quick-connects)
  • Two 40" Lengths of speaker wire with in-line crossovers (each has quick slides to connect to the tweeter on one end and bare wire on the other)
  • 2 Angled surface mount housings
  • 2 Flush mount rings
  • 2 Factory mount brackets
  • Six 1/2" Screws
  • 2 Speed clips
  • 2 Adhesive backed foam discs
  • Specs on box

Customer reviews

Loading reviews...

Pioneer TS-A300TW reviews

Average review:

60 reviews

Thanks for submitting your review

Filter by rating

Customer photos

Customer provided image, click to load a larger version.
Customer provided image, click to load a larger version.

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee review (What's this?)

Reviewed on

This review was collected as part of a promotion



Crutchfield response
Customer provided image, click to load a larger version.

<< >>

More details on the Pioneer TS-A300TW

Pat M.

Features & specs

Speaker Size 3/4
Design 1-way
Tweeter Design Dome
Impedance (Ohms) 6
Tweeter Composition Polyimide
Woofer Composition ---
Woofer Surround ---
Parts Warranty 1 Year
Labor Warranty 1 Year
Sensitivity (1W at 1 meter) 88
Sensitivity at 2.83 volts N/A
Frequency Response 1400 - 69k Hz
Minimum RMS Wattage ---
Maximum RMS Wattage 100
Peak Power Handling (Watts) 450
Top-mount Depth (Inches) 0 9/16
Bottom-mount Depth (Inches) N/A
Cutout Diameter or Length (inches) 1 11/16
Mounting Height (Inches) 0.233

Product Research


Tweeter Mounting: The system includes flush mount rings and angled surface mount housings for the tweeters. The angled surface mount housing positions the tweeters at approximately a 45° angle. Bendable brackets are also included for mounting the tweeters in factory locations. Once installed the tweeters do not swivel.

Tweeter Mounting Dimensions:

  Angled Surface Mount Flush Mount
Mounting Height 1.47" 0.233"
Mounting Depth screw depth 0.552"
Frame Diameter N/A 1.955"
Frame Depth 1.785" N/A
Frame Width 1.5" N/A
Cutout Diameter N/A 1.641"

Crossovers: The high pass crossovers are integrated into the included speaker wire. The slope is 6 dB/octave and the crossover point is 3.8 kHz. The capacitors (crossovers) are approximately ½" diameter x ¾" long. The quick slide terminals on the output end of the wire connect to the terminals on the wire attached to the tweeters. One of the terminals is male and the other female, so they only attach to the tweeter wires one way. The black wire with a white stripe is the positive lead.

Loading accessories...

Customer Q&A

6 questions already asked

These are a 6ohm rated tweeter how would the ohm impedance drop when wired in with a 100 watt rms 4 ohm single voice coil coaxial speaker? My amp is rated 116 watts rms at 4 ohm and 225 rms at 2 ohm
[ JORDAN CARL  Apr 19, 2022 ]
1 answer
You'll be at about 2.4 ohms if you wire them in parallel with your 4-ohm speakers. These tweeters are rated for up to 100 watts RMS.
[ Jenny  Apr 26, 2022 ]  Staff
OEM tweeters have 4 wires (LF: Blue, Blue, Green, Pink; RF: Blue, Purple, Green, Pink) to the built-in tweeter connector. These Pioneer Dome Tweeters I just bought only have 2 wires with a crossover to 2 -/+ wires. Am I missing something? Do I need an extra harness or something?
[ JAMES  Dec 15, 2020 ]
1 answer
If you purchased the product from Crutchfield, feel free to contact our Tech Support team. Our toll-free Tech Support number is printed on your invoice, and is also available under the "My Orders" tab in the "My Account" section of our website. If you did not purchase the unit from Crutchfield, then you may want to contact the manufacturer.
[ KRISTINA  Dec 29, 2020 ]  Staff
Well these speakers handle the power of being hooked up in parallel with 6x9's powered by a pbr 300x2?
[ Ed  Oct 17, 2020 ]
1 answer
We have not received any answers from other customers on your question. I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They should be able to help answer your question.
[ Thomas  Nov 10, 2020 ]  Staff
You can't hook up a cross overs with a mono block amp right ?? Not sure but I don't know ?? If not how would that work ?
[ Daniel  May 16, 2019 ]
1 answer
Well I can't answer that for you let the crutchfield experts answer that it's what they are paid to do????????
[ STEVEN  May 28, 2019 ]
