About the Pioneer TS-D65F
The pleasure of Pioneer
The pleasure of Pioneer
It's the right time to step up to new speakers — these D Series car speakers deliver superior Pioneer quality at a competitive price. Designed to provide a smooth and open sound that's miles above your factory speakers, the TS-D65F 6-1/2" 2-way car speakers give you low distortion and unfailing performance, even under the harsh conditions of life in your car doors.
Sweet highs and hearty lows
Pioneer infuses the D Series polypropylene woofer cone with strong aramid fibers, making it both durable and incredibly responsive for the best bass experience possible. A coated textile dome tweeter ensures the excellent high-frequency perfomance you've been craving. Prepare for crisp, musical detail and a new, impactful soundstage across your dash that will take enjoyment of your music to the next level — especially if you power these speakers with an aftermarket amplifier.
Grilles are not included; the factory grilles should be suitable for most applications.
- 2-way car speakers (pair)
- 6-1/2" injection-molded polypropylene woofer cone interlaced with aramid fibers
- 1" polyester soft dome tweeter
- handles up to 90 watts RMS (270 watts peak power)
- frequency range: 32-49,000 Hz
- sensitivity: 85 dB
- top-mount depth: 2-5/8"
- impedance: 4 ohms
- grilles not included
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # TS-D65F
What's in the box:
- Two 2-way speakers
- Eight 3/4" Screws
- Warranty information
Pioneer TS-D65F reviews
Thanks for submitting your review
More details on the Pioneer TS-D65F
Features & specs
|Speaker Size||6 1/2|
|Tweeter Design||1" Dome|
|Woofer Composition||IMPP with Aramid Fibers|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||85|
|Sensitivity at 2.83 volts||N/A|
|Frequency Response||32 - 49k Hz|
|Minimum RMS Wattage||---|
|Maximum RMS Wattage||90|
|Peak Power Handling (Watts)||270|
|Top-mount Depth (Inches)||2 5/8|
|Bottom-mount Depth (Inches)||N/A|
|Cutout Diameter or Length (inches)||5 9/16|
|Mounting Height (Inches)||0.861|
Woofers: Each speaker uses an aramid fiber interlaced injection-molded polypropylene (IMPP) woofer. This process of cone molding assures a uniform thickness and the addition of aramid fibers adds rigidity to the cones.
Tweeters: The tweeters pivot within their housings, so they can be angled to optimize imaging.
Size Classification Note: Some manufacturers, including Pioneer, call this size speaker a 6-1/2". Because it requires a larger cutout than a standard 6-1/2" speaker, Crutchfield has traditionally referred to this size as a 6-3/4". Please refer to the Crutchfield Vehicle Selector to confirm fit in your vehicle.
The Pioneer TS-D65F replaces these items
- Aramid/basalt fiber composite woofer with rubber surround
- 1-1/8" soft dome tweeter
- recommended power range: 2-60 watts RMS
