Name: JL Audio ACS110LG-TW1
Brand: JL Audio
SKU: 13693334
Price: 629.99 USD
Availability: InStock
Rating: 4.5 (114 reviews)

Overview

by Crutchfield's

Engineered for performance

JL Audio's ACS110LG-TW1 PowerWedge+ powered subwoofer delivers the impressive bass you expect from JL Audio without taking up a lot of space. The compact PowerWedge+ enclosure houses a built-in Class D amplifier that safely sends 400 watts RMS to the specially engineered, ultra-low-impedance TW1 10" subwoofer.

KEEP READING

Engineered for performance

Made in USA

JL Audio uses state-of-the-art automated woodworking equipment to fabricate the high-quality MDF enclosure with rugged automotive carpeting, a steel-mesh grille, 5-way binding posts, and solid internal wiring. The enclosure and subwoofer are constructed at the manufacturing facility in Florida to ensure that you get the bass that you expect from JL Audio.

Small enclosure, big sound

The specially designed, sealed enclosure measures just over 5 inches thick, so it'll fit just about anywhere. You'll enjoy thick low-frequency response from all of your music with this capable enclosure in your vehicle. And you can easily remove the power connector from this sub, so you can pull it out of your vehicle when you need a little extra space.

READ LESS

Product highlights:

Featured in our article: Best car powered subwoofers for 2023
10" TW1 subwoofer in sealed enclosure
built-in Class D amp delivers 400 watts RMS
woofer impedance: 0.25 ohms
low-pass filter (50-200 Hz, 12 dB slope)
8-gauge amp wiring kit required (sold separately)
fuse rating: 30 A
dimensions: 18.5"W x 11.125"H x 5.875"D
weight: 20.1 lb.
warranty: 2 years
Our 60-day money-back guarantee
MFR # 93334

What's in the box:

JL Audio ACS110LG-TW1 owner's manual

PowerWedge+ enclosure (loaded with one 10TW1-0.25 subwoofer and built-in amplifier)
Black metal grille (installed)
Power connection plug (installed)
30-amp ATO fuse (installed)
12" Speaker level input harness
Owner's manual
Specification card
Warranty information

Reviews

Loading reviews...

JL Audio ACS110LG-TW1 reviews

Average review:

114 reviews

Thanks for submitting your review

Most reviews are processed and published within 5 business days. You will receive a confirmation email once your review has been published.

Filter by rating

Customer photos

Customer provided image, click to load a larger version.

Verified customer

Verified employee review

Reviewed on Samsung.com

This review was collected as part of a promotion

Pros:

Cons:

Have questions for

Crutchfield response

Helpful?

Yes

<< >>

Details

Researched by Crutchfield's Pat M.

Features & specs

General
Enclosure Type	Sealed
Finish Material	Carpet
Grille	Steel
Connector Type	RCA/Set screw
Quick-disconnect Plug	Yes
Bi-amp Inputs	No
Woofer Size (inches)	10
Woofer Material	Mica-filled Poly
Passive Radiator	---
Width	18-1/2"
Height	11-1/8"
Depth	5-7/8"
Parts Warranty	2 Years
Labor Warranty	2 Years
Specifications
Frequency Response	N/A
Amplifier Power (RMS)	400 watts
Maximum Wattage	N/A
Sensitivity	N/A
Impedance	0.25 ohms
Second Voice Coil Impedance	N/A
Crossover Point	50-200

Product Research

Features

Overview: The ACS110LG-TW1 PowerWedge+ is a compact powered subwoofer, useful in vehicles with limited space. The sealed enclosure is loaded with one 10TW1-0.25 10" low impedance subwoofer (0.25Ω) and a 400 watt RMS class-D amplifier. The amp uses JL Audio's exclusive DCD amplifier technology, combining direct power conversion (no conventional switching power supply) with an ultra-high current output section. The result is an efficient design (91-94%) with very little heat generated.

Enclosure Design: The enclosure features MDF (medium-density fiberboard), constructed using CNC woodworking equipment, and covered with high-grade automotive carpeting. The driver is protected by a black steel-mesh grille.

Power/Ground Plug: The power, ground, and remote turn-on wires attach to a removable terminal block; easily unplugged so the subwoofer can be removed when you need more storage space. Each terminal is a screw clamp that will accept up to 8 gauge wire (minimum 8 gauge power and ground recommend).

Audio Inputs: The amplifier section will accept either a line level (RCA) or speaker level signal. A 12" speaker level input harness is included.

Remote Level Control: An optional RBC-1 wired Remote Bass Control (item number 136RBC1, sold separately) allows bass level adjustment from the front of your vehicle.

Controls:

Input Sensitivity: rotary control; variable from 70 mV to 1.4 V for the RCA inputs and 280 mV to 5.4 V for the speaker level inputs
Turn-On Mode: three position switch:
- REM: amp turns on when +12 volts DC is applied to the remote terminal
- DC: the amp turns on when a DC offset voltage is detected on the speaker level inputs
- Signal: the amp turns on when an audio signal is detected on the speaker level inputs, turns off after 30 seconds without an input signal
Crossover: rotary control; the crossover point is continuously variable from 50 Hz to 200 Hz; the slope is 12 dB/octave and the low-pass crossover is always engaged
Polarity: two position switch; allows you to reverse the phase of the subwoofer (0°, 180°)

Protection Circuit: The amp is equipped with thermal protection circuit; it will shut down if it overheats.

Dimensions:

Width: 18-1/2" (18-3/4" including wiring)
Height: 11-1/8"
Depth: 5-1/8" (5-7/8" including grille)

Accessories

Loading accessories...

Q&A

19 questions already asked

Frequency Response - what is the frequency response of this subwoofer?

[ Jasona97 Mar 03, 2023 ]

1 answer

This specification is not listed by JL sadly, Jason. We will not be able to nail down an exact number, but we can take a look at the JL 10TW3-D4 speaker in the link below for some guidance. This speaker is extremely similar to the one used in the TW1 enclosure and does play 24hz-200hz. The small, sealed box will of course affect the low-end extension, but those numbers should be a good ballpark for your tuning. I hope this helps! https://www.crutchfield.com/p_13610TW3/JL-Audio-10TW3-D4.html

[ Bo Mar 08, 2023 ] Staff

If I screw brackets to mount this in my truck and keep it secured will it void the warranty and do you sell a kit for that purpose?

[ CONRAD Sep 21, 2022 ]

1 answer

Greetings Conrad, and thank you for your question. You will not void the warranty by screwing in mounting screws. If purchased from Crutchfield, we will make sure of that. we no longer have the box mounting hardware. It was basically black L- brackets and screws.

[ THOMAS Sep 21, 2022 ] Staff

If using with an "LC1i" line out converter can I expect similar review expectations as these folks running aftermarket head units connecting rca directly? That little converter is pretty rad but if this box is tuned for a pure signal.??? - I have a 17 GMC Sierra Elevation and the touch screen system is great. No way I'm altering the dash look. I'm just a 40's dad that still likes the 808's to hit when it's time. Not interested in "quaking" as we said in the 90's ?? - I'm also going to upgrade to 6x9 JL audio in the front doors at the same time as installing this powered box. - thanks for any experience shared. Jp

[ JONATHAN Jan 09, 2022 ]

3 answers

I havent gotten alot of bass out of this set up but for a truck its about right. I hooked mine up to the high input side instead of rcas

[ Anthony Jan 15, 2022 ]

Hi Jonathan, I'm pretty sure you will be happy with this particular JL amplified sub. I have one installed in a 2021 Ridgeline black edition with factory premium sound system ( factory head unit) and a epicenter bass restoration unit. This Subwoofer really puts out, I use it mainly for sound quality but it will rattle your mirrors if you turn it up to that level. Also I had the opportunity to try all of the micro-sub units in my vehicle including the ported/sealed 10" 12" and duel 8 inch but this one was to me the best all around.

[ ANDRE Jan 10, 2022 ]

I'm using this sub in a BMW M4. It is mounted in the trunk using a line out converter. I don't remember which one, but I think it is the LC1i. At subwoofer levels that give accurate frequency response it doesn't hit as well as I might hope. But I think that may be simply because it is in the trunk. If I turn the sub level up, it hits then and doesn't localize the bass to coming from the trunk. It still sounds as though it is coming from the main speakers. Hope this helps.

[ RICHARD Jan 09, 2022 ]

Does this sub with built-in amp sound better than the version without an amp? I'd probably get a 300/1 or something to power it.

[ JAMES Aug 18, 2021 ]

1 answer

I don't know what the version with out the amp sounds like but this one sounds awesome

[ CHEDDIE Aug 18, 2021 ]

can i install 2?

[ Jon Apr 30, 2021 ]

Does this fit behind the second row back seat driver side of a double cab Tacoma 3rd gen?

[ Vanmannnn Feb 06, 2021 ]

1 answer

Yes, but you'll have to do some extensive trimming of the plastic storage bin behind the rear seatbacks. I also did some minor trimming to the plastic cladding on the rear seatback. Fits great in my opinion, but it's not for everyone.

[ MAX Feb 06, 2021 ]

Does this need to be broken in?

[ George Dec 11, 2020 ]

2 answers

No, this hits hard right out of the box.

[ SCOTT Dec 15, 2020 ]

I think it sounded good out of the box. It may be a little bit better after a few hundred hours now. I'm not certain. I made adjustments to the crossover and level that probably made more of a difference than break-in.

[ RICHARD Dec 15, 2020 ]

What's going to hit harder under the seat of a 2020 Chevy crew cab with Bose, the JL powered 10" box or the dual JL powered 8" box?

[ Mike Weaver Nov 16, 2020 ]

1 answer

Depends on the type of music that you'll be listening to. Ported 10 will be louder for R&B. The sealed 10 will be great with rock n roll or anything with the kick drums.

[ Daniel Nov 16, 2020 ]

Will it fit underneath a front seat of a 2012 5 speed 2.7L Tacoma Base/Access Cab?

[ Dale Jul 23, 2020 ]

1 answer

We have not received any answers from other customers on your question. I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They should be able to help answer your question.

[ Thomas Aug 07, 2020 ] Staff

What hardware is best to secure this box under the seat?

[ MARCUS May 04, 2020 ]

2 answers

I have a Ford Raptor and placed this under the rear with nothing to anchor in place. It has not moved from its original placement.

[ TOM May 04, 2020 ]

I screwed it to the back of the rear seat. It works perfect

[ SEAN May 04, 2020 ]

Does this have good bass?

[ Big Rick Jun 12, 2019 ]

5 answers

Yes definitely! It fills our Equinox nicely.

[ JASON Jun 13, 2019 ]

It is okay. I am deciding if it was work the money. I am not technical, so I will tell you what I was told. Do not install where it receives a signal. You have to wire to remote. You may know what that means. Mine would no longer receive a signal, so we had to go back later and install this way. I guess it is according to what your looking for. If you want big bass I would buy a sub amp and sub separately. JL Audio is good stuff. I am not sure it is worth the money.

[ CHRIS Jun 12, 2019 ]

Yes. It's more of a tighter bass. I listen to rock and heavy metal and I actually has it turned down to reduce some of the bass. I give it a 10/10.

[ KELLEY Jun 12, 2019 ]

Runs me out of my Tacoma. I like it a lot.

[ David Jun 12, 2019 ]

Go with a soar audio shallow 10 at 850 watts rms and 79.00 you can't beat it

[ CLOVIS Jun 12, 2019 ]

What modifications must be made to install this behind rear seat of a 2006 f250 crew cab?

[ WILLIAM May 05, 2017 ]

1 answer

For additional details on fit or installation please contact an Advisor by phone (1-800-324-9695) or online chat. They will be able to pull up your vehicle and give you the details on if this will fit and what you will need for an installation in your vehicle.

[ KENNETH May 06, 2017 ] Staff

Is there a big difference between the 8 inch and 10 inch? I just purchased the 8 inch one and it sounds great but it really doesn't have much of a low end bass. plus I noticed there's not a huge difference in price.

[ Paul May 15, 2016 ]

1 answer

Thanks for your question. For information on comparing two or more models I would recommend reaching out to an Advisor by phone (1-800-324-9695) or online chat. They will be able to help determine the differences and help you make the best choice for your system and your budget.

[ KRISTINA May 16, 2016 ] Staff

Will this fit behind or under the seat of a 2016 Toyota Tacoma?

[ Superman Mar 04, 2016 ]

4 answers

It fits my 2019 tacoma perfect without cutting any of the plastic storage bin. Just make sure you get the sealed box not the ported.

[ DANIEL May 13, 2021 ]

I don't know...I don't have a Tacoma. I will say that I love the speaker but I highly recommend buying the separate bass remote control, which really should come with the speaker.

[ ELLIOTT Mar 05, 2016 ]

It fits under the seat in my f-150, I really couldn't tell you anything about a toyota.

[ Kevin Mar 04, 2016 ]

My suggestion is to make a mock-up of the speaker box from cardboard. Get the dimensions from Crutchfield and make a replica. I used this for my Mazda CX5 and it was incredibly helpful for testing the fit for installation. The real speaker box fit perfectly when I purchased it.

[ bryan Mar 04, 2016 ]

Has anyone installed the PowerWedge+ 10" or 12" Behind the back seat (Not Under the seat) in a 2016 or 2015 Ford F-150 XLT SuperCrew? For those who don't know, Both Rear Seats fold down to provide some Hidden Storage Space. I see 1 Review of an ACS110LG-TW1 10" PowerWedge in a 2016 F-150 from (Mark S. from Wayzata) He said the 10" fit under the seat without taking up any space. I'm hoping he meant behind the seat. Because if it's under the seat, it is taking up storage space. And I need all the space that I can get. I folded my seats down on my 2016 F-150 and it looks like it just might work. But it's hard to tell with the way the back panel bumps in and out. Really Hoping I could fit the 12" Wedge back there Thanks for any input. KZ

[ Ken Feb 15, 2016 ]

2 answers

I tried to fit it behind the seat of my 2017 F-150 (same body as the 15 and 16's) and it won't quite fit. If you removed some of the rear cab insulation and carpeting, you might get it to fit. If you don't you will smash the metal speaker grille. I have it under the small rear seat (passenger side) and it fits perfectly there laying flat.

[ DEREK Nov 01, 2018 ]

While we do not have the available space researched in that location, we can provide the dimensions of the JL Audio enclosure which you can use to cross-reference against the space you find available there: 21"W x 13.5"H x 6.625"D I hope that helps! My Bio: http://www.crutchfield.com/Support/Bio.aspx?bio=5

[ Ryan Feb 17, 2016 ] Staff

My powered sub did not come with installation instructions. Will you please send the installation instructions to me asap? I want to make sure I am pulling the dash properly, and don't want to break anything!

[ Ryan Nov 12, 2015 ]

1 answer

If you purchased the product from Crutchfield, feel free to contact our Tech Support team. They can walk you through the settings on the product and see if there may be a fix. Our toll-free Tech Support number is printed on your invoice, and is also available under the "My Orders" tab in the "My Account" section of our website. If you did not purchase the unit from Crutchfield, then you may want to contact the manufacturer. You can also post your question in our forums: http://community.crutchfield.com. Or try our online support center: http://crutchfield.custhelp.com/app/answers/list/kw/.

[ KRISTINA Nov 13, 2015 ] Staff

Is this box size really smaller than the JL Audio 8" version? How? This box with grill on is thinner than the JL Audio 6.5"? I'm looking for a sub box to fit under the passenger seat on a Dodge Ram Club Cab. Wanting to clear up my back seat where my huge JL 12" box is.

[ MAX Nov 12, 2015 ]

2 answers

I have the 10" version and it fits perfectly behind the single fold down seat in my 2005 Silverado crew cab.

[ Ryan Nov 12, 2015 ]

The dimensions listed are exactly what I received. It is a thin sub with very low impedance and an amp that works with that low impedance. In my truck this delivers good performance, particularly considering the small amount of space it takes up. It won't outperform a properly powered JL12W3, for example, but it is no slouch.

[ Dennis Nov 12, 2015 ]

Which sub speaker is used? W3 or?

[ Joe Oct 12, 2015 ]

1 answer

It seems like a variant of the TW1.

[ Dennis Oct 13, 2015 ]

Does this come with the bass knob and wire?

[ Ozzie Jul 09, 2015 ]

1 answer

I forwarded your question to an Advisor and they responded with the following: It does not, you would need to purchase the JL RBC 1, and an amp wiring kit. If you would like to discuss further you can contact an Advisor directly by phone (1-800-324-9695) or online chat.

[ KRISTINA Jul 13, 2015 ] Staff
