EFX PA10BX Wiring Kit

10-gauge amplifier wiring kit — includes 2-channel patch cable

Item # 142PA10BX

The PA10BX wiring kit from EFX will supply your car amplifier with the wiring necessary for receiving its signal...

The PA10BX wiring kit from EFX will supply your car amplifier with the wiring necessary for receiving its signal...

California customers:
Please click here for your Proposition 65 warning.

Item # 142PA10BX

In stock
$34.99

About the EFX PA10BX Wiring Kit

Get the right wire for your amp

The PA10BX wiring kit from EFX will supply your car amplifier with the wiring necessary for receiving its signal and powering up. The 10-gauge power and ground cables ensure that your amp gets all the power it needs to play music at its full potential. The ground cable features EFX's Ultimate Ground Terminal, which attaches to your vehicle's chassis by way of 2 self-tapping screws (included) to make sure you get a tight and secure ground connection.

Get the right wire for your amp

The PA10BX wiring kit from EFX will supply your car amplifier with the wiring necessary for receiving its signal and powering up. The 10-gauge power and ground cables ensure that your amp gets all the power it needs to play music at its full potential. The ground cable features EFX's Ultimate Ground Terminal, which attaches to your vehicle's chassis by way of 2 self-tapping screws (included) to make sure you get a tight and secure ground connection.

This wiring kit works with smaller amplifiers, with less than about 250 watts RMS of total output power. Please check your amplifier's installation instructions to confirm the proper size wire to use. The kit includes a stereo RCA patch cable, remote turn-on lead, in-line fuseholder, fuse, and an assortment of connectors and hardware to help with your amp's installation.

This wiring kit does not include speaker wires. You will need to purchase those separately, in order to complete your amplifier installation. This kit includes patch cables for a 2-channel or mono amp — you'll need to add cables for multi-channel amps.

READ LESS

Product highlights:

  • amplifier wiring kit with power, ground, and audio connections
  • 17-foot blue 10-gauge power cable
  • 2-foot black 10-gauge ground cable with Ultimate Ground Terminal
  • 17-foot blue remote turn-on lead
  • 17-foot twisted pair RCA patch cable
  • 30-amp fuse and in-line fuse holder
  • 6 feet of flex loom
  • assorted mounting screws, crimp-on connectors, and wire ties
  • warranty: 90 days (no warranty on fuses)
  • Our 60-day money-back guarantee
  • MFR # EFXPA10BX

What's in the box:

  • 17' Length of 10 AWG blue power wire with in-line waterproof fuse holder and ring terminal (30A ATC fuse installed)
  • 2' Length of 10 AWG black ground wire with Ultimate Ground Terminal
  • 17' Length of blue turn-on wire
  • 17' Length of Core-Twisted RCA interconnect cable (2 male RCAs on each end)
  • 6' Length of black 3/8" split loom tubing
  • Spare 30A ATC fuse
  • Firewall grommet
  • 2 Spade terminals for 10 AWG wire (1 red/1 black)
  • 1 Spade terminal for turn-on lead
  • 1 Butt connector for turn-on lead
  • 2 Sself-tapping screws (for Ultimate Ground Terminal)
  • 6 Plastic cable ties (length=8")
  • Instructions

Customer reviews

Loading reviews...

EFX PA10BX Wiring Kit reviews

Average review:

167 reviews

Thanks for submitting your review

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

<< >>

More details on the EFX PA10BX Wiring Kit

Mark G.
The EFX PA10BX Wiring Kit replaces these items:

Product Research

Features

Compatibility: The PA10BX kit is designed for amplifiers with fuse ratings up to 30 amps.

Kit Contents: This amp wiring kit includes the following:

  • Power/Ground/Remote wire: The power/ground wires use OFC (oxygen-free copper) for high-current delivery. The wires use fine strands of copper and soft-touch insulation for maximum flexibility.
    • 17' length 10 AWG blue power wire with in-line waterproof fuse holder (30A ATC fuse installed) and a ring terminal (0.336" inside diameter, 0.55" outside diameter)
    • 2' length 10 AWG black ground wire with patent-pending Ultimate Ground Terminal for reliable ground connections.
    • 17' length of 18 AWG blue turn-on lead
  • RCA Patch Cable: 17' Core-twisted stereo RCA interconnect cable with split-top center pin and segmented shield for maximum contact and connection reliability. Twisted pair construction gives you maximum noise rejection and better sound quality. The RCA plugs have a micro barrel design and integrated strain relief.
  • Connectors: The kit includes the following crimp-on terminals:
    • Two 10-gauge crimp-on spade connectors (with 1 red and 1 black rubber insulator boot)
    • One 18-gauge crimp-on spade connector with red plastic boot (for remote turn-on lead)
    • One 18-gauge crimp-on butt connector (for remote turn-on lead)
  • Mounting Accessories:
    • 6' length of 3/8" diameter split loom to protect cables
    • 2 Phillips-head self-tapping screws (for securing the Ultimate Ground Terminal)
    • Plastic firewall grommet (0.25" inside diameter, 0.371" outside diameter)
    • Six 8" plastic wire ties
    • Spare 30A ATC fuse
    • Instructions

Loading accessories...

Customer Q&A

2 questions already asked

Q
will this wiring set up work on my B-8PTD sub/amp combo?
[ charles  Jan 04, 2017 ]
5 answers
A
yes this kit will work.
[ SEAN  Jan 07, 2017 ]  Staff
A
That kit should work nicely. 8 or 10 gauge is what is required for power, so this fits the bill.
[ JEFF  Jan 05, 2017 ]  Staff
A
Yes, this kit will work absolutely fine. As with any installation of an amp or powered sub-woofer, be sure to route your wiring to the sub-woofer so that it crosses (as minimally as possible), not parallels power wires in the vehicle so as to prevent alternator noise interference. You should be good to go!
[ Ron  Jan 05, 2017 ]  Staff
A
That looks like all the wires you will need, though I am not certain which one in the picture is for the ground - maybe the black wire, since I don't know what else it would be for. The picture appears to include a power wire (thick blue), a trigger wire (thin blue), and the RCA cables for the sound, plus an assortment of connectors, which you may or may not use. If the black wire is not for the ground, you can use any extra you have from the power wire, with appropriate connectors as needed, for the ground.
[ waterdog  Jan 05, 2017 ]  Staff
A
Yes it will. Would not recommend this sub/amp though for loud rock or heavy metal music. Have blown two of them.
[ RANDALL  Jan 04, 2017 ]  Staff
