Name: Kicker 46CST204
Brand: Kicker
SKU: 20646CT204
Price: 69.99 USD
Availability: InStock
Rating: 4.5 (77 reviews)

Overview

Titanium!

Experience the powefully crisp detail of Kicker's 46CST204 titanium dome tweeters. Kiss your old muddy factory sound good-bye and boost your favorite jams with a fresh, live-performance feel. Included external crossovers feature three-level attenuation so you can control the brightness. And three mounting possibilities, including adjustable tweeter pods, give you the flexibility you need to get these tweeters closer to your ears for an improved soundscape.

Product highlights:

Featured in our article: Best car speakers for 2023
3/4" titanium dome tweeters
hardware for flush-, surface-, pod-, and angle-mounting
handles up to 50 watts RMS (150 watts RMS peak power)
frequency range: 4,500-21,000 Hz
in-line crossovers (4,500 Hz at 6 dB/octave)
features neodymium magnets
sensitivity: 92 dB
top-mount depth: 9/16"
warranty: 2 years
Our 60-day money-back guarantee
MFR # 46CST204

What's in the box:

Kicker 46CST204 owner's manual

Two 3/4" Tweeters (each with 8" Wire attached)
Two 3.5' Lengths of speaker wire with in-line crossovers (quick-slides on one end and tinned bare wire on the other)
2 Flush mount tweeter rings
2 Short tweeter mounting nuts
2 Long tweeter mounting nuts
2 Back angled tweeter rings
2 Front angled tweeter rings
2 Angled surface mount tweeter housings
Four 5/8" Screws
4 Red plastic wire caps
Owner's manual (English/ Spanish/ German/ French)

Reviews

Loading reviews...

Kicker 46CST204 reviews

Average review:

77 reviews

Thanks for submitting your review

Most reviews are processed and published within 5 business days. You will receive a confirmation email once your review has been published.

Filter by rating

Customer photos

Verified customer

Verified employee review

Pros:

Cons:

Have questions for

Crutchfield response

Helpful?

Yes

<< >>

Details

Researched by Crutchfield's Pat M.

Features & specs

General
Speaker Size	3/4
Design	1-way
Tweeter Design	Dome
Impedance (Ohms)	4
Tweeter Composition	Titanium
Woofer Composition	---
Woofer Surround	---
Parts Warranty	2 Years
Labor Warranty	2 Years
Specifications
Sensitivity (1W at 1 meter)	92
Sensitivity at 2.83 volts	N/A
Frequency Response	4500 - 21k Hz
Minimum RMS Wattage	10
Maximum RMS Wattage	50
Peak Power Handling (Watts)	150
Top-mount Depth (Inches)	0 9/16
Bottom-mount Depth (Inches)	N/A
Cutout Diameter or Length (inches)	1 5/8
Mounting Height (Inches)	0.275

The Kicker 46CST204 replaces these items:

Kicker 43CST20

Product Research

Features

Mounting Options: The tweeters come with brackets to allow multiple mounting configurations: flush-mounted, angled flush-mounted (approximately 10°), and angled surface-mounted (approximately 45°).

Tweeter Dimensions:

	Flush Mount	Angled Flush Mount	Angled Surface Mount
Mounting Height	0.275"	0.662"	1.928"
Depth	0.548"	0.705"	0.491" (screw depth)
Frame Diameter	1.975"	1.975"	N/A
Cutout Diameter	1.570"	1.685"	N/A
Frame Width	N/A	N/A	1.887"
Frame Length	N/A	N/A	2.110"

Crossovers: The passive crossovers are in-line with the included speaker wire. The slope is 6 dB/octave and the crossover point is 4,500 Hz. The crossover measures approximately ¾" at its thickest point.

The Kicker 46CST204 replaces these items

Kicker 43CST20

3/4" dome tweeters

59 reviews

flush-, surface-, and angled-mounting hardware included
external passive high-pass crossover included (6 dB per octave at 4,500Hz)
power handling: 2-50 watts RMS (100 watts peak power)

Accessories

Loading accessories...

Q&A

7 questions already asked

What diameter hole saw is needed to drill the custom brackets?

[ KC in VA Jun 20, 2022 ]

1 answer

If you need to get your tools in line before install, we got you covered K C! I show on these Kicker 46CST204 CS series tweets you will need a cutout of 1.570" if you use the flush mount cup. You will need a cutout of 1.685" if you use the angled flush mount. Surface mount of course, no hole saw needed.

[ Bo Jun 20, 2022 ] Staff

Hello, can you tell me that "50w rms" is per pair, or each? Tks

[ Mr Aug 02, 2021 ]

1 answer

That is the watts RMS for each tweeter.

[ Paul Aug 07, 2021 ] Staff

Can I use the harness from the old speakers and just plug it into the new speakers I bought?

[ Dylan Jul 09, 2021 ]

3 answers

Yes you can.

[ RICHARD Jul 09, 2021 ]

Yes you can, I bought these for my 95 Dodge Ram 1500.

[ john Jul 09, 2021 ]

Yes you can, they are (the prongs) on the tweeters slightly different in overall dimensions but the existing 'plugs' ie harness from Subaru stabs right on.

[ DONALD Jul 09, 2021 ]

Can I use these tweeters with Kicker coaxial speakers?

[ Zach Aug 02, 2020 ]

4 answers

Yes I put them in the dash of my Jeep Wrangler unlimited.And thy sound great

[ DEAN E Aug 03, 2020 ]

Yes I got the same ones in my truck with 12inch solo barics subwoofer and 8-1/2 inch coaxial speakers in the doors

[ DEREK Aug 03, 2020 ]

I'd say you can, why the heck not!

[ Bryant C. Aug 02, 2020 ]

Yes, you may need a passive x over like a bass blocker

[ JACOB Aug 02, 2020 ]

Do they come with the bass blocker 4500hrtz?

[ Brian Jun 13, 2020 ]

2 answers

Nope, had to buy the wire connector,(forgot number) after hooking up the new wire it sure made a big difference, it only cost, I think about $10.00. Good luck

[ LEE Jun 13, 2020 ]

Yes I think they did

[ DEAN E Jun 13, 2020 ]

Will this fit my 2011 honda civic?

[ Jimmy Dec 03, 2019 ]

1 answer

Depending on where you put it, yes

[ Yashida Dec 03, 2019 ]

How do you adjust the passive crossover? I see it is covered in a rubber protective tubing. Is it a switch or a knob? What is the ideal adjustment? Thanks.

[ brisky86 Aug 05, 2019 ]

2 answers

There is no adjustment. They are purchased at a frequency and everything below that frequency is cut off from going to speaker

[ JACOB Aug 02, 2020 ]

If you purchased the product from Crutchfield, feel free to contact our Tech Support team. They can walk you through the settings on the product and see if there may be a fix. Our toll-free Tech Support number is printed on your invoice, and is also available under the "My Orders" tab in the "My Account" section of our website. If you did not purchase the unit from Crutchfield, then you may want to contact the manufacturer.

[ Krissy Aug 12, 2019 ] Staff
