About the Kicker 46CST204
Titanium!
Experience the powefully crisp detail of Kicker's 46CST204 titanium dome tweeters. Kiss your old muddy factory sound good-bye and boost your favorite jams with a fresh, live-performance feel. Included external crossovers feature three-level attenuation so you can control the brightness. And three mounting possibilities, including adjustable tweeter pods, give you the flexibility you need to get these tweeters closer to your ears for an improved soundscape.
Product highlights:
- 3/4" titanium dome tweeters
- hardware for flush-, surface-, pod-, and angle-mounting
- handles up to 50 watts RMS (150 watts RMS peak power)
- frequency range: 4,500-21,000 Hz
- in-line crossovers (4,500 Hz at 6 dB/octave)
- features neodymium magnets
- sensitivity: 92 dB
- top-mount depth: 9/16"
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # 46CST204
What's in the box:
Kicker 46CST204 owner's manual
- Two 3/4" Tweeters (each with 8" Wire attached)
- Two 3.5' Lengths of speaker wire with in-line crossovers (quick-slides on one end and tinned bare wire on the other)
- 2 Flush mount tweeter rings
- 2 Short tweeter mounting nuts
- 2 Long tweeter mounting nuts
- 2 Back angled tweeter rings
- 2 Front angled tweeter rings
- 2 Angled surface mount tweeter housings
- Four 5/8" Screws
- 4 Red plastic wire caps
- Owner's manual (English/ Spanish/ German/ French)
Customer Q&A
Q
Can I use these tweeters with Kicker coaxial speakers?
A
Yes I put them in the dash of my Jeep Wrangler unlimited.And thy sound great
12 reasons to shop with us
#9
Articles, DIY tips, and videos
Our experts help you shop smart.
REVIEWS
Customer reviews
Loading reviews...
Kicker 46CST204 reviews
Average review:
Thanks for submitting your review
Customer photos
More details on the Kicker 46CST204
Features & specs
| General | ||
|---|---|---|
| Speaker Size | 3/4 | |
| Design | 1-way | |
| Tweeter Design | 3/4" Dome | |
| Impedance (Ohms) | 4 | |
| Tweeter Composition | Titanium | |
| Woofer Composition | --- | |
| Woofer Surround | --- | |
| Parts Warranty | 1 Year | |
| Labor Warranty | 1 Year | |
| Specifications | ||
| Sensitivity (1W at 1 meter) | 92 | |
| Sensitivity at 2.83 volts | N/A | |
| Frequency Response | 4500 - 21k Hz | |
| Minimum RMS Wattage | 10 | |
| Maximum RMS Wattage | 50 | |
| Peak Power Handling (Watts) | 150 | |
| Top-mount Depth (Inches) | 0 9/16 | |
| Bottom-mount Depth (Inches) | N/A | |
| Cutout Diameter or Length (inches) | 1 5/8 | |
| Mounting Height (Inches) | 0.275 | |
Product Research
Features
Mounting Options: The tweeters come with brackets to allow multiple mounting configurations: flush-mounted, angled flush-mounted (approximately 10°), and angled surface-mounted (approximately 45°).
Tweeter Dimensions:
| Flush Mount | Angled Flush Mount | Angled Surface Mount | |
| Mounting Height | 0.275" | 0.662" | 1.928" |
| Depth | 0.548" | 0.705" | 0.491" (screw depth) |
| Frame Diameter | 1.975" | 1.975" | N/A |
| Cutout Diameter | 1.570" | 1.685" | N/A |
| Frame Width | N/A | N/A | 1.887" |
| Frame Length | N/A | N/A | 2.110" |
Crossovers: The passive crossovers are in-line with the included speaker wire. The slope is 6 dB/octave and the crossover point is 4,500 Hz. The crossover measures approximately ¾" at its thickest point.
The Kicker 46CST204 replaces these items
- flush-, surface-, and angled-mounting hardware included
- external passive high-pass crossover included (6 dB per octave at 4,500Hz)
- power handling: 2-50 watts RMS (100 watts peak power)
