Morel Maximus 602

6-1/2" component speaker system

Item # 210MMAX602

I dream of having Morel speakers in my car, and this component system comes at a price tag that could make that...

Read more from Crutchfield writer, Alexander H.

Find what Fits your car

Ships free today

In Stock
$289.99

About the Morel Maximus 602

Discover Morel components for yourself

I dream of having Morel speakers in my car, and this component system comes at a price tag that could make that dream come true. Every bit of Morel's passion for sound is present in this tough speaker system.

Discover Morel components for yourself

I dream of having Morel speakers in my car, and this component system comes at a price tag that could make that dream come true. Every bit of Morel's passion for sound is present in this tough speaker system.

Maximus sound

Morel makes amazing sound simple with the Maximus 602 6-1/2" component speaker system. This system uses a treated paper composite woofer cone and soft dome tweeter to deliver impressive full-range sound. This efficient system will respond well even when driven by a factory radio, but it'll handle up to 60 watts RMS, so you'll get better performance powering these speakers with an aftermarket amplifier. An in-line crossover sends the proper frequencies to the tweeter, and makes for an easier installation. Morel also includes mounting solutions for ideal tweeter placement.

Grilles are not included; the factory grilles should be suitable for most applications.

READ LESS

Product highlights:

  • 6-1/2" component speaker system
  • treated paper composite woofer cone with butyl rubber surround
  • steel woofer basket
  • soft dome textile tweeter
  • in-line crossover to protect tweeter
  • handles up to 60 watts RMS (120 watts peak power)
  • frequency response: 60-20,000 Hz
  • sensitivity: 94 dB at 2.83 V
  • woofer mounting depth: 2-1/2"
  • tweeter mounting solutions included
  • grilles not included
  • warranty: 1 year
  • Our 60-day money-back guarantee
KEEP READINGREAD LESS

What's in the box:

  • Two Woofers
  • Two Tweeters (with attached 10" length of speaker wire)
  • Two 78" Lengths of tweeter wire with in-line crossovers
  • 2 Mesh tweeter grilles (installed)
  • 2 Oval flush mount tweeter housings (with tweeters installed)
  • 2 Flush mount brackets
  • 2 Large angled surface mount tweeter housings
  • 2 Small angled surface mount tweeter housings
  • Twelve 1" Screws
  • 8 Speed clips
  • Two 0.187" Crimp-on female quick slides
  • Two 0.110" Crimp-on female quick slides
  • Two 0.187" Quick slide insulating covers
  • Two 0.110" Quick slide insulating covers
  • Installation guide
  • Morel window sticker

Customer reviews

Loading reviews...

Morel Maximus 602 Reviews

Average Customer Review(s):

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

More details on the Morel Maximus 602

Features & specs

General
Speaker Size 6 1/2
Design 2-way
Tweeter Design 25mm Dome
Impedance (Ohms) 4
Tweeter Composition Textile
Woofer Composition Treated Paper
Woofer Surround Rubber
Parts Warranty 1 Year
Labor Warranty 1 Year
Specifications
Sensitivity (1W at 1 meter) N/A
Sensitivity at 2.83 volts 94
Frequency Response 60 - 20k Hz
Minimum RMS Wattage ---
Maximum RMS Wattage 60
Peak Power Handling (Watts) 120
Top-mount Depth (Inches) 2 1/2
Bottom-mount Depth (Inches) 2 3/4
Cutout Diameter or Length (inches) 5 11/16

Product Research

Features

Woofer Size Classification Note: Some manufacturers, including Morel, call this size woofer a 6-1/2". Because it requires a larger cutout than a standard 6-1/2" speaker, Crutchfield has traditionally referred to this size woofer as a 6-3/4". Please enter your vehicle information to confirm fit.

Tweeter Mounting Options: The tweeter can be surface or flush mounted using the included adapters. The large surface mount housing also uses the oval flush mount housing and angles the tweeters at approximately 45°. The small surface mounting housing angles the tweeters at approximately 20°.

Tweeter Dimensions:

  Oval Flush Mount Large Surface Mount Small Surface Mount
Mounting Height 0.53" 1.945" 1.362"
Mounting Depth 0.788" screw depth screw depth
Cutout Diameter 1.942" N/A N/A
Frame Width 2.207" 2.332" 1.920"
Frame Depth 2.695" 2.645" 1.950"

Crossover: The low pass crossovers are mounted to the woofers' baskets and the high pass crossovers are wired in-line with the included tweeter wire.

Loading accessories...

Customer Q&A

Q
Crutchfield asked: Why did you buy this?
A
recommended by Advisor [ vincent  Apr 03, 2018 ]

2 questions already asked

Q
can you connect this to a dsp without going full active?
[ Jose  May 31, 2018 ]
1 answer
A
The processed signal will need to be amplified in order to power the speakers. The woofers have the attached low pass crossovers and the tweeters come with high pass crossovers wired in-line on their connection leads. For additional assistance and personalized recommendations, feel free to contact us directly by phone or through our online chat service: https://www.crutchfield.com/support/ContactUs.aspx
[ Ryan  Jun 09, 2018 ]  Staff
Q
Are there grilles available for this speaker?
[ Brian T.  Jul 07, 2017 ]
1 answer
A
I cannot find a grill for these speakers anywhere, not even on Morel's site. It appears they do not make a grill for them anymore. My Bio: http://www.crutchfield.com/Support/Bio.aspx?bio=101
[ Paul  Jul 10, 2017 ]  Staff
