High thump-to-dollar ratio

MTX's 55 Series subs give you huge boom for the buck, and the 5515-22 15” subwoofer epitomizes that mindset. MTX worked hard to build a high-performance sub that adds tons of bass to your system without emptying out your bank account. And MTX protects this sub with a 2-year warranty.

KEEP READING

High thump-to-dollar ratio

Solid engineering makes great subs

MTX squeezes an oversized cone into the standard 15" frame, so the sub moves more air and gives you more bass. The woofer's movement cools the sub as it plays, so it doesn't overheat when you're rocking out. The special suspension exerts extra control when you're pushing the sub hard, so it'll handle up to 400 watts RMS. Its dual 2-ohm voice coils give you more wiring options when setting up your system.

READ LESS

Product highlights:

15" subwoofer with dual 2-ohm voice coils
polypropylene cone with rubber surround
power handling: 200-400 watts RMS (200 watts per coil)
peak power handling: 800 watts
frequency response: 20-130 Hz
sensitivity: 85.5 dB
top-mount depth: 8"
sealed box volume: 1.5 cu. ft.
ported box volume: 2.48 cu. ft.
grille not included
warranty: 2 years
Our 60-day money-back guarantee
MFR # 5515-22

What's in the box:

MTX 5515-22 owner's manual

One 15" Dual 2-ohm voice coil subwoofer
Specifications

Reviews

Loading reviews...

MTX 5515-22 reviews

Average review:

3 reviews

Thanks for submitting your review

Most reviews are processed and published within 5 business days. You will receive a confirmation email once your review has been published.

Filter by rating

Customer photos

Verified customer

Verified employee review

Pros:

Cons:

Have questions for

Crutchfield response

Helpful?

Yes

<< >>

Details

Researched by Crutchfield's Pat M.

Features & specs


Size	15 -inch
Impedance (Ohms)	1, 4
Cone Material	Polypropylene
Surround Material	Rubber
Ideal Sealed Box Volume (cubic feet)	1.5
Ideal Ported Box Volume (cubic feet)	2.48
Port diameter (inches)	N/A
Port length (inches)	N/A
Free-Air	No
Dual Voice Coil	Yes
Sensitivity	95 dB at 2.83 volts 85.5 dB at 1 watt
Frequency Response	20 - 130 Hz
Max RMS Power Handling	400
Peak Power Handling (Watts)	800
Top Mount Depth (inches)	8
Bottom Mount Depth (inches)	---
Cutout Diameter or Length (inches)	13 13/16
Vas (liters)	161.2
Fs (Hz)	25
Qts	0.81
Xmax (millimeters)	15.24
Parts Warranty	2 Years
Labor Warranty	2 Years

Product Research

Features
Enclosure Compatibility

Features

Dual 2-ohm Voice Coils: This woofer features dual 2-ohm voice coils, offering wiring flexibility. When the voice coils are wired in parallel the woofer presents a 1-ohm load. When the voice coils are wired in series the woofer presents a 4-ohm load.

Terminals: The woofer features two pair of heavy-duty spring post terminals which can accept single or dual (standard 3/4" width) banana plugs, pin connectors, or bare wire up to 10-gauge.

Inverted Apex Surround: The new Inverted Apex surround allows increased cone surface area, creating more air movement and higher SPL.

Progressive Suspension: The progressive suspension controls excursion at high power, thus reducing distortion and improving sound quality.

Spider Plateau Venting: Heat from the voice coil is vented through vents that surround the back of the spider. As the woofer travels back and forth, cool air is pulled in and heated air is pushed out.

Enclosure Compatibility

Sealed Box: For the best possible sound quality where space is a premium MTX recommends a sealed enclosure with an internal volume of 1.5 ft³. Sealed enclosures provide the most control over a woofer, will handle a lot of power, and provide accurate sonic reproduction, making them suitable to all types of music.

Vented Box: The recommended vented box has a net internal volume of 2.48 ft³ with a slot port 14-1/2" x 2" x 20". Vented (or ported) enclosures typically provide better overall efficiency than sealed so they are suitable for use with smaller amplifiers, giving you more bass output from less power.
