About the Polaris/MTX Lock & Ride Audio Roof
A rockin' roof
A rockin' roof
Polaris partnered with MTX Audio to create the rugged, rockin' Lock & Ride® Pro Fit Premium Audio Roof for the Polaris Ranger. You'll get great sound, outstanding protection from the elements, and the security of knowing that you're getting an aftermarket-style upgrade from a factory-designed piece.
The four MTX 6"x9" speakers deliver plenty of sound.
It's what's underneath that counts
The most important thing a roof can do is keep rain, snow, and sunlight away from you. This rugged roof does a fine job of that, but it's what's under the roof that makes it special. The four MTX 6"x9" speakers produce plenty of sound, and the sealed enclosures ensure that you'll get plenty of bottom-end thump from up top.
This clever system centers around a digital media receiver with built-in Bluetooth® connectivity, so you can play your music and control your apps from the phone in your pocket. When your device's battery gets low, just plug into the charging USB port. And, because Polaris knows what you need in UTV gear, there's also an LED floodlight and a sealed overhead storage bin.
- factory-designed to fit the Polaris Ranger
- digital media receiver with built-in 4-channel amp
- built-in Bluetooth for music streaming (no phone calls)
- four 6"x9" MTX speakers
- inputs: minijack aux input, USB charging port
- overhead storage bin
- LED floodlight
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # 2880538
What's in the box:
- Audio roof
- Digital media receiver (pre-installed)
- Four 6x9 speakers (pre-installed)
- 18" Wiring harness
- 7' Power wire (terminated w/ ring-terminals on each end)
- 7' Ground wire (terminated w/ ring-terminals on each end)
- Front liner
- Rear liner
- Rubber stripping
- Rubber connector cover
- Four "L" brackets
- 2 Square plates
- Rectangular plate
- 7 Bolts
- 2 Washers
- 2 Nuts
- 6 Clips
- 5 Wire-ties
- Operating Instructions
- Installation Instructions
More details on the Polaris/MTX Lock & Ride Audio Roof
Premium Roof Audio Kit: The MTX Premium Roof Audio Kit (2880538) replaces the factory installed roof on your Polaris Ranger 900 XP or 800 EFI. The Premium Roof Audio Kit consists of a replacement roof, integrated digital media receiver with built-in amplifier & AM/FM tuner, and four pre-installed 6x9 speakers. All cables, wires, and mounting hardware are included for installation (see Installation Instruction for what tools will be need).
Vehicle Compatibility: The MTX Premium Roof Audio Kit (2880538) is designed specifically for the Polaris Ranger 900 XP and 800 EFI.
Durable Marine-Grade Roof: A durable marine-grade, precision engineered roof shields you from the elements in virtually any off-road condition.
Bluetooth Audio Streaming: Built-in Bluetooth allows you to stream stored music and music apps wirelessly from your smartphone or tablet device to the roof audio kit system. You can even control basic playback functions (like Play/Pause & Previous/Next Track) from the digital media receiver's front-panel buttons. Advanced music browsing and song/artist/album information are still handled by your Bluetooth source device.
Note: This system does not support Bluetooth hands-free phone communication.
Aux Input: The Aux input consists of a right-angle male 3.5 connector attached to a 20" cable inside the roof audio kit's storage compartment. Simply plug this Aux input cable into the headphone jack of your smartphone or digital audio player.
AM/FM Radio: The digital media receiver is equipped with a built-in AM/FM tuning for manual, seek, and preset tuning. You can store up to 15 AM and 15 FM preset stations (30 total presets).
USB Charging Port: While you have your smartphone playing through the system's Bluetooth or Aux input, you can charge it with the integrated USB (type-A) port. The USB port features a 9" cable and is hidden inside the roof's storage compartment.
Note: The USB port does not support audio playback.
Built-In Amplifier & Speakers: The Roof Audio Kit features two pair of two-way 6x9 speakers mounted in sealed enclosures for superior low-end reproduction. The speakers are powered by the digital media receiver's 4-channel amplifier.
Tone Controls: You can adjust the audio system's Bass, Treble, & Balance (there is no fader).
LCD Screen: The digital media receiver's LCD screen indicates Source, Station, & Volume. It does not provide song/artist/album information. You can adjust the LCD screen's contrast & brightness levels.
Overhead Lights: The MTX Premium Roof Audio Kit (2880538) also features overhead LED lighting.
Storage Compartment: An overhead storage compartment allows you to store your smartphone, goggles, gloves, and other valuables.
