Crux SOCGM-17C Wiring Interface

Install an aftermarket radio and retain safety chimes in select 2000-13 GM vehicles

Item # 249GM17C

Find what Fits your car

Ships free

In Stock
$56.99

About the Crux SOCGM-17C Wiring Interface

Add a new radio

Installing a new car stereo can often mean losing your GM vehicle's factory warning chimes. Crux's SOCGM-17C wiring interface solves this problem, allowing you to install a new receiver while retaining the safety chimes and your Retained Accessory Power feature. This interface does not retain OnStar® or steering wheel audio controls.

Product highlights:

KEEP READINGREAD LESS

What's in the box:

  • Radio replacement interface
  • Wiring harness
  • Installation Instructions

Customer reviews

Loading reviews...

Crux SOCGM-17C Wiring Interface Reviews

Average Customer Review(s):

Verified customer (What's this?)
Verified employee purchase (What's this?)

Pros:

Cons:

Crutchfield response

More details on the Crux SOCGM-17C Wiring Interface

Product Research

Features

Radio Replacement Interface: The CRUX SOCGM-17C radio replacement interface retains select factory features in General Motors Class II vehicles when replacing your factory radio with an aftermarket head unit. The CRUX SOCGM-17C retains the following factory feature set.

  • Supports Bose, Monsoon, & Y-91 factory amplified systems (fader is not retained in Y-91 system); also works with non-amplified factory audio systems
  • 12 Volt Accessory output (3A max)
  • RAP (Retained Accessory Power) - keeps the radio powered after the key is off, until the driver door is opened or the OEM timer ends; whichever happens first
  • Illumination Output (250mA max)
  • Retains safety & warning chimes (adjustable level); safety & warning chimes include seat belt, check engine, key in ignition, low fuel, low oil, and lights on
Note: This interface does not support steering wheel control or OnStar.

Vehicle Compatibility: The CRUX SOCGM-17C radio replacement interface works with the following 2000-2013 GM vehicles with Class II system.

Make Model Year
Buick Century 2004-2005
Lacrosse 2005-2007
Rainer 2004-2007
Rendezvous 2003-2005
Terraza 2005-2007
Cadillac Escalade 2003-2006
Chevrolet Avalanche 2003-2006
Cavalier 2000-2005
Colorado 2004-2013
Corvette 2005-2013
Express 2004-2007
Impala 2000-2005
Monte Carlo 2000-2005
S-10 2003-2004
Silverado 2003-2007
SSR 2003-2006
Suburban 2003-2006
Tahoe 2002-2006
Trailblazer 2002-2009
Uplander 2005-2008
Venture 2003-2005
Hummer H2 2003-2007
H3 2005-2009
GMC Canyon 2004-2011
Envoy 2002-2009
Savana 2003-2007
Sierra 2003-2007
Suburban 2003-2006
Yukon 2003-2006
Isuzu Ascender 2003-2008
Oldsmobile Alero 2001-2004
Bravada 2002-2004
Silhouette 2000-2004
Pontiac Aztek 2001-2005
Grand Am 2001-2005
Grand Prix 2004-2008
Montana 2000-2006
Sunfire 200-2005
Saturn Relay 2005-2007
Saab 9-7X 2005-2008

GM Class II Harness: The included GM Class II wiring harness features a 24-pin connector which plugs into your vehicle's factory radio harness and a 16-pin connector which plugs into the SOCGM-17C interface module. The GM Class II wiring harness also provides the following bare-wire leads which will need to be soldered or crimped to your aftermarket head unit's wiring harness:

Wire Color Function
Black Chassis Ground
Red +12 Volt Accessory
Yellow +12 Volt Constant
Orange Illumination
Blue/White Amp Turn-On
White Left Front Speaker +
White/Black Left Front Speaker -
Gray Right Front Speaker +
Gray/Black Right Front Speaker -
Green Left Rear Speaker +
Green/Black Left Rear Speaker -
Purple Right Rear Speaker +
Purple/Black Right Rear Speaker -
Red/White Reverse Gear

Loading accessories...

Customer Q&A

Q
Crutchfield asked: Why did you buy this?
A
To hook up radio [ J  Dec 28, 2018 ]
A
Buying the cheapest one from another retailer does not include the interface module. Save your money (...and your patience) and buy it here first. [ not a hack  Dec 26, 2018 ]
A
Need it for I stall [ Tom  Dec 19, 2018 ]
A
To keep the stock features of my vehicle. [ denis  Oct 02, 2018 ]
A
part of my kit [ Joel  Sep 27, 2018 ]
A
needed install parts [ Stanley  Sep 08, 2018 ]
A
This was part of the suggested equipment to install in my van. [ William R.  Jun 05, 2018 ]
A
its a needed item for the install. [ adrian  Feb 17, 2018 ]
A
I didn't, it was added as part of a parts needed package [ Amy  Dec 28, 2017 ]
A
Needed [ Mark  Dec 20, 2017 ]
A
To simplify installation [ Ronald  Dec 18, 2017 ]
A
Buzz, the online tech knew exactly what was needed in my 05 c6 corvette when replacing the factory head unit. [ Tim  Dec 11, 2017 ]
A
was suggested for installation component. [ Ian  Dec 10, 2017 ]
A
was just what i needed [ patrick  Nov 28, 2017 ]
A
Compatible with car for aftermarket unit [ William  Oct 24, 2017 ]
A
need harness to fit 2004 gmc 2500hd serria pickup truck [ kim  Jul 28, 2017 ]
A
Crutchfield recommended it. [ Craig  Jun 23, 2017 ]
A
to be able to install aftermarket radio with factory bose system [ Sean  Jun 20, 2017 ]
A
Price for what is does. [ Jonathan  May 29, 2017 ]
A
i need it for my car [ Eric  May 03, 2017 ]
A
because I needed it...... [ David  Apr 10, 2017 ]
A
Update radio [ Elliott  Mar 29, 2017 ]
SHOW MORESHOW LESS

4 questions already asked

Q
I have a KD-X340BTS deck that is satellite ready. With this harness, will my xm still work?
[ Bill  Feb 12, 2019 ]
1 answer
A
Sorry, no. It does not retain factory satellite radio. For additional assistance and personalized recommendations, feel free to contact us directly by phone or through our online chat service: https://www.crutchfield.com/support/ContactUs.aspx
[ Ryan  Feb 18, 2019 ]  Staff
Q
I have a satellite ready deck KD-X340BTS to install. Will xm still work if I use this adapter?
[ Bill  Feb 12, 2019 ]
1 answer
A
This is the wiring harness and chime I needed for my make/model of vehicle. These are vehicle specific. I believe you have a separate adapter for enabling the satellite radio, that may be universal but not sure. My stereo has a separate spot for plugging in a satellite radio adapter for reception. Hope that helps.
[ David  Feb 12, 2019 ]
Q
Is the chime sound heard through the speakers or through this unit?
[ Daniel  Aug 06, 2018 ]
2 answers
A
Unit
[ David  Aug 07, 2018 ]
A
With this particular model, the chime sound is heard through the internal speaker on the unit, not through the car stereo speakers.
[ Anthony  Aug 06, 2018 ]
Q
in my corvette (2008) before the replacement radio and this thing chimed about three times. now I get a whole lot like 15 chimes, very irritating. any fix for this?
[ JimDod  Aug 02, 2018 ]
1 answer
A
If you purchased the product from Crutchfield, feel free to contact our Tech Support team. They can walk you through the settings on the product and see if there may be a fix. Our toll-free Tech Support number is printed on your invoice, and is also available under the "My Orders" tab in the "My Account" section of our website. If you did not purchase the unit from Crutchfield, then you may want to contact the manufacturer.
[ Krissy  Aug 06, 2018 ]  Staff
