About the SPL Boxes SB6X9-BL
When you can't install your 6x9" speakers in your vehicle's factory openings, SPL Boxes' SB6X9-BL enclosures give you an alternative that's built to last. These heavy-duty wedge-shaped enclosures can take the punishment of the car, truck, marine, or off-road environment. They feature rugged 1/2" MDF construction and a tough bedliner finish that protects the boxes from the elements. Gold-tipped spring terminals hold your speaker wires securely. These SB110V boxes each hold one 6x9" speaker in a sealed enclosure. Sold as pairs.
- sealed enclosures for 6x9" subwoofers
- 1/2" MDF construction
- bedliner finish
- sold in pairs
- dimensions: 12"W x 8.375"H x 7.125"D1 x 5"D2
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # SB6X9-BL
What's in the box:
- 2 Wedge-style enclosures (each holds a single 6x9 speaker)
SPL Boxes SB6X9-BL reviews
Thanks for submitting your review
This review was collected as part of a promotion
More details on the SPL Boxes SB6X9-BL
Features & specs
|Number of Boxes||2|
|Number of Speakers Per Box||1|
|Cutout Diameter or Length (inches)||0|
|Maximum Speaker Depth (inches)||4-13/16|
|Box Volume (cubic feet)||0.24|
|Second Depth (inches)||5|
|Wood Thickness (inches)||1/2|
|Speaker Wire Connectors||Spring terminal|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
Design: The SB6X9BL is a pair of unloaded, sealed enclosures for 6x9 speakers. They are covered with a bedliner type material. Each enclosure has a volume of approximately 0.24 ft³.
Terminals: Each enclosure has a pair of spring terminals mounted in the rear panel. The spring terminals will accept bare wire up to 12 gauge or pin connectors. Inside the enclosure, each terminal has a 0.205" male quick-slide (will accept 0.205" female quick slides) for both the positive and negative terminals.
Note: Speaker wire is needed to connect the terminals to the speakers.
Brackets: Brackets for securing the enclosures in your vehicle are recommended.
The SPL Boxes SB6X9-BL replaces these items
- 3/8" MDF (medium-density fiberboard) with black carpet covering
- internal volume: 0.29 cubic feet each
- dimensions: 12-13/16"W x 7-7/8"H1 x 6-5/16"H2 x 7-7/8"D
4 questions already asked
As described. Well built. Solid. No resonance when rapping with knuckles. I didn't have quite enough room in the corners of my cab for these. I could not use them so do not know how the speakers would have sounded.
David from Palestine, TX
