About the Rockford Fosgate R1T-S
Put Rockford Fosgate sound in your car without breaking the bank. Whether you're customizing your existing system or replacing some burned-out tweeters, Prime tweeters offer clean, crisp performance that'll keep you and your friends entertained as you drive.
The Prime R1T-S tweeters feature Mylar balanced dome construction that ensures wide dispersion and clear soundstage details. Install a set in your vehicle, and you'll enjoy vibrant highs that add excitement to your music without grating on your ears. Built-in high-pass filters ensure a smooth audio response, so these tweeters will reproduce your highs faithfully.
Installation note: You'll need a pair of our universal backstraps to install these tweeters in the factory locations.
Priced per pair
- 1" Mylar balanced dome tweeters (pair)
- flush- and surface-mount hardware included
- 4.5kHz, 6 dB/oct passive crossovers built-in
- power handling: 2-40 watts RMS (80 watts peak power)
- frequency response: 2,500-22,000 Hz
- sensitivity: 72.5 dB
- top-mount depth: 13/16"
- grilles included
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # R1T-S
What's in the box:
- Two 1" tweeters (with attached 6' speaker wire terminated by quick-slide connectors)
- 2 Flush mounting brackets (installed)
- 2 Flush mount retaining rings
- 2 Surface mounting brackets
- Four 5/8" Flat head screws
- Installation and Operation instructions (English/ French/ Spanish/ German/ Italian)
Rockford Fosgate R1T-S reviews
Thanks for submitting your review
More details on the Rockford Fosgate R1T-S
Features & specs
|Tweeter Design||Balanced dome|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
|Sensitivity (1W at 1 meter)||72.5|
|Sensitivity at 2.83 volts||75.5|
|Frequency Response||2500 - 22k Hz|
|Minimum RMS Wattage||2|
|Maximum RMS Wattage||40|
|Peak Power Handling (Watts)||80|
|Top-mount Depth (Inches)||0 11/16|
|Bottom-mount Depth (Inches)||0 3/4|
|Cutout Diameter or Length (inches)||1 7/8|
|Mounting Height (Inches)||1.095|
Overview: The Rockford Fosgate Prime R1T-S is a dedicated tweeter system featuring a lightweight Mylar dome. Multiple tweeter mounting configurations allow flush, surface, and angle configurations.
Mylar Dome Tweeter: The Prime R1T-S features a lightweight 1.0" Mylar dome tweeter for high sensitivity and smooth extended frequency response. This low distortion material allows accurate reproduction of high frequencies for an open sound stage.
Crossover: The R1T-S tweeter has an integrated 6 dB/octave high-pass crossover fixed at 4,500 Hz.
Mounting: The Rockford Fosgate R1T-S provides multiple mounting configurations. You can choose a flush mount, surface mount, or angle mount installation. You can further angle the tweeter once installed in any of the included mounts.
|Tweeter Mounting Dimensions||Flush||Surface||Angle|
|Mounting Depth||0.75"||0.6875" (screw depth)||0.625" (screw depth)|
