About the Onkyo TX-NR686
Next-level home entertainment
Next-level home entertainment
Onkyo's TX-NR686 lets you step up your home theater with stunning 4K picture quality and immersive, three-dimensional surround sound. It's THX® certified so you get spot-on, distortion-free reproduction of movie soundtracks with intricately detailed effects, even at lower volume levels. Convenient wireless music options, multi-room music, and easy app control make this receiver a winner for movie nights, parties, and everyday entertainment.
Geared toward great sound
Outstanding audio performance is an integral part of the 'NR686's design. A premium 32-bit/384kHz digital-to-analog converter gives you crystal-clear reproduction of music, TV, and movie soundtracks. Dynamic Audio Amplification delivers massive power with low distortion for thrilling movie sound effects. Specialized Vector Linear Shaping Circuitry (VLSC) filters out noise across the two front channels for faithful reproduction of the original audio signal.
Plenty of wireless music choices
The 'NR686 gives you all kinds of options for wireless listening. Built-in Wi-Fi gives you access to popular streaming services like Spotify® and Pandora®, along with tracks you have stored on your networked computer. Apple® AirPlay® lets you stream from compatible iOS® devices, and Bluetooth adds even more streaming music options.
Use the Onkyo Controller app to control streaming from your Apple or Android™ device.
Chromecast built-in and Google Home voice control
Chromecast built-in lets you use your phone, tablet, or computer to stream music to the receiver from over 100 audio apps. With a Google Home voice assistant or the Google Home app, you can use your voice to control playback and connect with other Chromecast built-in devices for wireless music throughout your home.
Works with Sonos
The 'NR686 also works great as a component in your Sonos wireless multi-room music system. Just add a Sonos Connect and you can send any music or audio source from the Sonos app to the receiver. It'll even automatically turn on and switch to the correct input when you fire it up in the Sonos app.
DTS Play-Fi for a flexible wireless multi-room music system
DTS Play-Fi gives you the freedom to mix and match Play-Fi devices from different brands. Use the Play-Fi app to queue up songs, play and pause music, and control multiple Play-Fi speakers and components throughout your home.
Customizable speaker connections
The 'NR686 has outputs for nine speakers, allowing for different home theater and wired multi-room music configurations (just remember, its seven amplifier channels can't power more than seven speakers at once). You can set up a traditional 7.2-channel system, or you can reassign the Surround Back channels to power overhead speakers in a 5.1.2-channel Dolby Atmos® or DTS:X™ system.
If you're happy with 5.2-channel surround sound in your living room, you can use the receiver's surround back outputs to bi-amp your front left and right speakers for more powerful sound. Or you can connect a pair of speakers for stereo sound in another room. You can also connect a stereo receiver or amplifier through line-level Zone 2 connections and use the 'NR686 as a preamp, so you can use all seven channels for surround sound in your home theater and still get stereo sound in a second room.
Power and Processing:
- 7-channel amplifier
- 100 watts per channel into 8 ohms (20-20,000 Hz) at .08% THD, with 2 channels driven
- Dolby® and DTS® surround sound decoding
- Dolby Atmos® processing for use with in-ceiling or "height" speakers for more enveloping surround sound
- DTS:X™ for an immersive, 3-dimensional soundstage
- THX® Certified Select™ theater reference sound
- AccuEQ automatic speaker calibration optimizes your system's sound for your room (microphone included)
- new AccuReflex technology aligns phase of up-firing "height" speakers with the sound coming directly from your other speakers
Digital and Streaming Music Options:
- built-in Wi-Fi for listening to music from a networked PC, free internet radio, and music services
- includes support for Pandora®, Spotify®, TIDAL, Deezer, and TuneIn (subscription required for some services)
- Chromecast built-in for wireless music streaming from compatible devices
- allows voice control through Google Home
- compatible with Sonos Connect — receiver turns on automatically and sets the right input when selected in the app
- DTS Play-Fi lets you stream music and create a multi-room music system with other Play-Fi speakers and components
- built-in Bluetooth for wireless music streaming from a compatible phone, tablet, or computer
- Apple® AirPlay® for streaming music from an iPhone®, iPad®, iPod touch®, or computer running iTunes®
- plays high-resolution digital music files via USB storage device or a networked computer (PCM-based files up to 24-bit/192kHz resolution)
- plays DSD files (up to 5.6 MHz) from network and USB storage devices
- DTS Play-Fi® available via future firmware update
- dual-room/dual-source output
- powered stereo audio output for 2nd room
- using powered 2nd-room output allows 5.2-channel home theater in main room
- line-level 2nd-room output for use with a separate amplifier or powered speakers
Audio Performance Features:
- high-current amplifier design
- 32-bit/384kHz Asahi Kasei AK4458 digital-to-analog converter for clear sound from digital sources
- Music Optimizer function enhances the sound quality of compressed music files and Bluetooth streams
- bi-amp capability with compatible front speakers by reassigning surround back channels
- VLSC (Vector Linear Shaping Circuitry) minimizes noise across front left and right channels
- HDMI audio/video switching: 7 in, 2 out (includes front-panel input)
- HDCP 2.2 technology ensures compatibility with 4K Ultra HD sources and TVs
- HDR-compatible for extended picture contrast and brightness with compatible 4K TVs and HDR-encoded content
- supports HDR10, Dolby Vision™, and HLG
- 2 component video inputs
- 2 composite video inputs
- digital audio inputs: 2 optical and 1 coaxial
- 6 analog stereo audio inputs
- MM (moving magnet) phono input for connecting a turntable
- preamp outputs for 2 powered subwoofers
- rear-panel USB port for audio playback from USB storage devices
- Ethernet port for network connection
- outputs for 9 speakers (Front L/R, Center, Surround L/R, Surround Back L/R, Zone 2 L/R)
- receiver can power a maximum of seven channels at once
- free Onkyo Controller app lets you use your Apple or Android™ device as a Wi-Fi remote
- 4K/60p and 3D video pass-through
- HDMI standby pass-through allows access to all HDMI connected devices without having to power on the receiver
- Phase-Matching Bass Boost optimizes low frequencies to preserve clarity with vocals and movie dialogue
- 40 AM/FM presets
- remote control
- 17-3/16"W x 6-13/16"H x 15-9/16"D
- weight: 22 lbs.
- warranty: 2 years
- Our 60-day money-back guarantee
- MFR # TXNR686
What's in the box:
- 7.2ch AV receiver
- Remote control (RC-911R)
- 2 "AAA" batteries
- Setup microphone
- AM loop antenna
- FM wire antenna
- Initial Setup Guide
- Safety Information
- Chromecast built-in instructions
- Onkyo Next Generation Audio brochure
- Onkyo Music brochure
- Product Registration/Warranty Information
Onkyo TX-NR686 reviews
I put this in with klipsch speakers I have cable Xbox plays everything flawless if you're worried about the price you don't want to be blown away. I know to many poeple who try to home theatre in a box it's not the same you pay to play
2 of 2 found this helpful
Great sound, loaded with features, easy to operate, attractive, and a great price. Add to this the great customer service provided by Crutchfield, and you end up with the best receiver for the dollar.
Pros: See review
0 of 0 found this helpful
Wow, has the technology changed since I last purchased any components. The ease of use and the capabilities of this receiver are excellent.
2 of 2 found this helpful
I know the brand for a such long time
2 of 5 found this helpful
Simple to set up, simple to operate. I have a small living room (24 x 17), and the sound is excellent. This is my third Onkyo, but not my last.
Pros: Simple to understand setup, use
2 of 2 found this helpful
Operating this unit is not very intuitive. My old Marantz was more user friendly.
Cons: Set up instructions
0 of 5 found this helpful
This is a excellent Receiver. I recommend this because it is a really good Receive.
4 of 8 found this helpful
Exactly as described. Plenty of inputs. Room to grow if I upgrade speakers from 5.1 to 7.1. The assignable front panel display allows you to customize what inputs actually display, which helps idiot-proof it for the rest of the family to figure out how to use it when the inputs are logically matched in English to what we actually have. (i.e." Xfinity Box" instead of "DTV/Cable/Sat")
2 of 2 found this helpful
Replaced an older Onkyo TX-sr805 with this. Wow,..even though has less power I'm very happy with this baby,it has all the hdmi inputs you'll need and decent power to create a home theater experience through out my 7.1 system. Set up was a breeze and the auto calibration is very accurately. Dialog is crisp and clear, bass from my sub is clean, punchy and powerful.
Pros: Lots of hdmi inputs, decent power,up to date with new technology, 4k video switching etc
Cons: None yet
9 of 9 found this helpful
I put together a complete home system from Crutchfield. I have an Onkyo TX-NR686 powering Polk Audio RTi A1 bookshelf mains, Polk Audio TSi100 bookshelf for surrounds, and a Polk Audio CSi A4 center channel. All five are setup on the bookshelf around the TV and the low end is handled by a MartinLogan DynamoT 700W in a room about 14 feet by 22 feet. Also added a phono Audio-Technica LP-60XBT. The receiver delivers clear sound; the phono connection is great and the bluetooth pairing with multiple phones is easy. The range on bluetooth is really only 20' or so but it works very well. Haven't been able to utilize ARC yet but my TV is an older VIZIO so I'm not prepared to blame that on the receiver. Wired up easily with banana plugs and I'm very happy with value for money.
4 of 5 found this helpful
Lots of power to use with as many options as you can think of for an entry level reciever. I attached a pair of ELAC Debut F6.2 floor speakers, ELAC C6 center speaker and ELAC S10.2 subwoofer, Sony smart TV, U Turn phono, Dish TV and Panasonic BluRay DVD player and I am a happy little duck. I should say that I have this entry level system in a small room but for the size of my listening space, everything works just fine.
Pros: Lots of power and lots of connections for just about everything you can think of.
Cons: Entry level DAC that comes with entry level device.
2 of 4 found this helpful
The Onkyo TR-NR686 has been the perfect addition to the home theater. I have a 5.1 in-ceiling speaker system with a Velodyne sub. It sounds great! I downloaded the manual from the web. The manual is extremely easy to understand and made setting up a breeze which isn't always the case for electronics. This is my first Onkyo product but won't be my last. I've had a couple of Denon receivers over the years. The last one which was very expensive turned out to be a lemon and has soured me on the brand.
7 of 7 found this helpful
This was my first new receiver I had purchased in 20 years. I have some older Infinity RS3B speakers which demand a high current amplifier and this Onkyo came to play and loud at that. The setup was straight forward and even though I only use my 2 speakers for movies I used the auto tuning system for surround sound. This actually worked very well. I have had these speaker for decades and had them reworked and tested at the Infinity repair location in Chats worth about 10 years ago. They never sounded so good as the first movie I put on. The dynamics and stage was accurate and full. Even watching the Blues Brothers streamed had depth and width like I never had heard before. My wife seems to think the picture even improved as well. The receiver functions as a switch for all the video stuff but I still like my music from a CD clear and strong. I don't think anyone could stand to be in the room if you had the volume set to the THX reference level of 82. 69 was about as loud as I could take and the house was literally shaking at that point. Apartment dwellers this amp is not for you.
Pros: Great HDMI switching options and a very powerful amp with a huge dynamic range. The remote is fairly easy to work with.
Cons: The amp and it's WIFi app are intermittent and the built in Chromecast only seems to work from that app. I have several music Chromecast devices throughout my house and this amp does not want to join my Google home. I have not given up, but I am frustrated that this was a major selling point for me and has been problematic to set up.
4 of 8 found this helpful
This replaced my venerable old Yamaha receiver. Used the included microphone to calibrate the 5 speakers and subwoofer and it sounds amazing!
7 of 7 found this helpful
Overall an OK receiver for the money. Sound is good with some sources but not very good with Cable/Satellite as the source. Worked with settings and unable to improve it. Input from streaming source gives OK sound. Also do not under stand why volume has to start at 50 to have any sound. Why not start at 0 and work up from there? Not sure that I will keep this yet.
Cons: Sound quality from some sources Volume starting at 50 vs zero
2 of 9 found this helpful
This is a great product, does everything i need and more. The people at Crutchfield are great to deal with.
5 of 5 found this helpful
Works great! Couldn't be happier. For a post that I read earlier.... with newer Samsung TV's (2016 to present) when using ARC, I turn off the tv and receiver using the tv remote. The receiver does come back on, but then, turns itself off after 2 min. I have an Onkyo RZ820 that will do the same thing. It's nothing to panic about. It turns itself off! This is my sixth Onkyo. 2 yrs ago, I jumped ship and bought a Yamaha 481.The sound on this Onkyo 686 is much better than my older Yamaha 481.
2 of 5 found this helpful
I'm not an audio geek but had need to replace an older Sony AVR for my 5.1 Channel TV system. The Onkyo 686 had everything I was looking for and more. Its a bit beefier than my older unit (7" high) so I had to eliminate a shelf from my rack to ensure it had airflow above it. The installation was easy. The back panel is very well organized and easy to comprehend even for a novice. I eliminated several component cables and optical audio cables that I needed in my older system and replaced them with HDMI. My biggest challenge was re-configuring my Logitech universal remote but even that was not too time consuming. My TV room immediately took on a whole new level of sound enjoyment with this system. And because its UDMI instead of component cable connections, my HDTV picture also sharpened up. My only complaint is that the User Manual is not provided. Must download a PDF. I much prefer leafing through a printed document.
Pros: Plenty of HDMI Input Easy to setup and configure
Cons: Radio Tuning not intuitive
7 of 8 found this helpful
This receiver all that it claims to be and more. I had a Onkyo receiver that was like the TX-NR686 it before and the sound was better than good. But not like this. The Onkyo TX-NR686 reproduction is much better Listening to Beethoven's ninth (9th) symphony on my old unit was great but now I have the Onkyo TX-NR686 it is much, much like being at symphony hall with a living orchestra right in front of you. I would without any hesitation suggest the Onkyo TX-NR686 to anyone who is interested in great sound reproduction.
8 of 8 found this helpful
Probably would have given it 5-stars except day after I ordered it Crutchfield had a better model with a deep discount that cost only $50 more, so I bought that one and returned this one. Service at Crutchfield is super-amazing!
5 of 7 found this helpful
This is my 3rd Onkyo receiver and in this one I'm disappointed. I chose the 686 because of the Chromecast Built-in feature to enable multi-room music in my home only to discover that Chromecast Built-In doesn't work in Zone 2. No where in the literature or promo materials was this made evident. And this limitation makes no sense for a variety of reasons, including the fact that the previous model works in both zones, I'm told. I'll likely be returning it. On the bright side, Crutchfield Tech support has been very helpful in attempting to resolve this issue as they are equally surprised by this limitation.
9 of 16 found this helpful
Fantastic receiver, I had an old model, huge difference.
8 of 8 found this helpful
love crutchfield great people and service thanks
4 of 8 found this helpful
Very nice setup. Crutchfield helps you all the way.
5 of 10 found this helpful
I got this because my older Onkyo didn't pass 4K HDR video signals. Works well with Vizio P75-F1 and Sony UBP-X700.
15 of 16 found this helpful
Wow----from the first phone call to the last what a great experience. The sales force was knowledgeable in all respects of the equipment I ordered. Once I received the receiver I had some questions on set-up and called four different times during the set-up process, never was put on hold and all questions answered in a quick professional manner. I would absolutely recommend this company to anyone wanting to purchase any type of electronic gear. So far I have recommended Crutchfield to my twin brother and three others and all have been more than satisfied and we are all now loyal Crutchfield fans.
Pros: EVERYTHING ABOUT THE COMPANY IS A+
11 of 18 found this helpful
More details on the Onkyo TX-NR686
Features & specs
Dynamic Audio Amplification: The TX-NR686 AV receiver features Onkyo's Dynamic Audio Amplification with a 7-channel amplifier rated at 100 watts (into 8-ohms, at 20Hz-20kHz, with 0.08%, driving 2 channels). Onkyo's new Dynamic Audio Amplification technology incorporates a Hi-Current, non-phase shift amplifier design with discrete output stage circuitry capable of driving 4-16Ω speakers with dynamic control, while producing clear, detailed sound.
- Hi-Current Amp Design: The unique elements of Onkyo's Dynamic Audio Amplification system comprise high-current, low-impedance architecture with discrete output stage circuitry & custom audio capacitors for instantaneous high-current power and precisely control of your loudspeakers for dynamic, accurate sound.
- Non-Phase-Shift: Onkyo's Wide Range Amp Technology (WRAT) circuit layout prevents phase shifting by pushing the roll-off point higher than the listening-level frequency. Amplifying sound without phase shift creates an uncommonly well-focused and realistic audio image.
- H.C.P.S. (High Current Power Supply): The H.C.P.S. (High Current Power Supply) allows the receiver to deliver large amounts of power necessary for reproducing the wide dynamics of movie soundtracks, plus the detail and clarity of your music.
Amplifier Assignment: The 7-channel amplifier can be configured in a variety of ways to match your type of speaker setup.
- Dolby Atmos (5.1.2ch): The Surround-Back/Front-High speaker terminals are assigned to power a pair of Front-Height, Rear-Height, Overhead Ceiling, or Dolby Atmos-enabled speakers to create 5.1.2ch Dolby Atmos surround sound. Zone 2 speaker can still be powered by the receiver in the configuration. When Zone 2 is off, all seven channels will be used in the Main Zone for Dolby Atmos. However, when Zone 2 is on, power to the Dolby Atmos channels will be directed to the two speakers in Zone 2 and the Main Zone will receive only five channels of power without Dolby Atmos.
- Dolby Atmos (5.1.2ch) + Zone 2: In this configuration, you can connect a Dolby Atmos 5.1.2ch speaker system in the Main Zone and a pair of speakers in Zone 2. When Zone 2 is off, all 5.1.2 channels will be used in the Main Zone. When Zone 2 is on, power to the two height speakers will be turned off and re-directed to the two speakers in Zone 2 and the Main Zone will receive only five channels of power for 5.1ch in the Main Zone.
- Surround Back (7.1ch): The Onkyo TX-NR686 provides 7.1ch surround in your main listening area with dedicated Surround Back speakers.
- Surround Back (7.1ch ) + Zone 2: In this configuration, you can connect Front, Center, Surround, Surround Back, and Zone 2 speakers to the AV receiver. When Zone 2 is off, all seven channels will be used in the Main Zone. When Zone 2 is on, power to the two surround back (or front height) channels will be re-directed to the two speakers in Zone 2 and the Main Zone will receive only five channels of power for 5.1ch playback.
- Front Bi-Amp (5.1ch): The Surround-Back/Height speaker terminals can be reassigned and used along with the Front terminals to bi-amp the front speakers, providing improved bass & treble performance. When bi-amping the front speakers the receiver is limited to a 5.1ch speaker system in the main room (no Surround Back or Front Height speakers)
32-Bit Architecture: The Onkyo TX-NR686 AV receiver utilizes 32-Bit architecture with Dual 32-Bit DSP Engines and a 384kHz/32-Bit Hi-Grade DAC for exceptional sound quality.
- Dual 32-Bit DSP Engines: The Onkyo TX-NR686 employs powerful and highly accurate 32-bit DSP (Digital Signal Processor) engines for better surround sound reproduction.
- 384kHz/32-Bit Hi-Grade DAC: The AV receiver utilizes one premium-quality AK4458 digital-to-analog converter from Asahi Kasei for all channels. This 384kHz/32-bit DAC implements unique low-distortion filtering technologies for clear sound, and unlocks the full potential of practically any audio format; including compressed, lossless, and hi-res audio (MP3, WMA, AAC, Apple Lossless, FLAC, WAV, DSD, LPCM, and Dolby TrueHD).
Advanced Circuitry: The Onkyo TX-NR686 incorporates a variety of advanced circuitry to eliminate jitter & distortion for cleaner, clearer sound reproduction.
- Vector Linear Shaping Circuitry (Front Channels Only): Onkyo developed Vector Linear Shaping Circuitry (VLSC) to reassemble the signal in its original form following processing. Unlike conventional filters, VLSC removes pulse noise generated in D/A conversion, allowing the sound wave to be reproduced with extremely high fidelity for a smooth analog signal. The signal's data is converted between sampling points and joined with analog vectors in real time to produce a smooth output wave form. The result is a virtually noiseless, smooth, analog signal that brings out even the most subtle of nuances in music sources.
- PLL Jitter-Cleaning Circuit Technology: PLL (Phase Locked Loop) jitter-cleaning circuit technology reduces jitter by comparing the input and output phases of the digital signal and creating an accurate clock waveform. This enhances the precision of digital signal processing and noticeably improves audio quality. Jitter-cleaning technology works for S/PDIF audio signals only.
AccuEQ Calibration w/ AccuReflex: The TX-NR686 incorporates AccuEQ calibration technology and comes with an auto calibration microphone. AccuEQ calibration technology reveals the true potential of your speakers by eliminating standing waves from your listening space. These acoustic peaks distort the audio image and prevent your loudspeakers from voicing the sound as their designers intended. AccuEQ utilizes Partial Band Equalization and only corrects frequency response below a certain point, leaving high-order harmonics untouched - so your speakers are free to reproduce the emotion in the recording faithfully and naturally. AccuEQ also includes three memory presets you can use to save your own customized EQ settings, perhaps tailored to suit different content such as movies, music, or games.
- Speaker Measurement: The first-round of AccuEQ measurements set the distance, sound pressure level, and crossover of your speakers. Distance and level calibration ensure all channels are treated equally. Crossover measurement selects the correct point to roll off low-frequency sound to the subwoofer for seamless speaker integration.
- Room Measurements: In the second round of AccuEQ measurements, your room's sonic characteristics are evaluated. Using this information, AccuEQ is able to prevent standing waves from forming by adjusting frequency response.
- AccuReflex Measurements: AccuEQ also incorporates AccuReflex technology to align the phase of up-firing "height" speakers with the sound coming directly from your other speakers. Any delay is resolved so that everything arrives at your ears at the same time. The result is cohesive reproduction of object-based soundtracks.
Note: You can choose to bypass the AccuEQ for your front speakers or all speakers, and manually set the distance, crossover, EQ, and level of each speaker.
THX Certified Select: THX Certified Select guarantees the same high-volume sound you experience at a commercial theater in your home. To gain certification, amplifiers must pass the industry's most severe bench-tests covering every aspect of audio performance to satisfy THX requirements. THX spends 40-60 hours testing over 2000 data points ensuring that the receiver is capable of meeting rigorous audio and video performance standards for reference level, distortion-free playback. THX delivers superior sound quality for movie, music, and gaming soundtracks through the use of the following advanced technologies and listening modes.
- ASA (Advanced Speaker Array): ASA is a technology patented by THX to provide a broad surround sound experience by adjusting the side and back surround speaker sounds respectively. When installing the surround back speakers, first select the distance between the two surround back speakers in the THX Audio settings. This setting optimizes the surround sound environment.
- Adaptive Decorrelation: In a movie theater, a large number of surround speakers help create an enveloping surround sound experience. If a home theater only has two sidewall surround speakers, the surround speakers may sound similar to headphones lacking spaciousness and envelopment. Surround sounds will also collapse toward the closet speaker as you move away from the middle seating position. Adaptive Decorrelation slightly changes one surround channel's time and phase relationship with respect to the other surround experience as in a movie theater using only two rear speakers.
- RE-EQ & Timbre Matching: Many movie soundtracks are mixed in studios for playback in large cinema auditoriums with an array of speakers. When played on home systems, they may appear abrasive and edgy. Re-EQ establishes a more accurate tonal balance when enjoying movies in your home. Your ears hear different tonal qualities in sounds coming from different directions. Timbre Matching restores the frequency balance between your front and surround speakers ensuring seamless and smooth panning between the front to back of the room.
- Boundary Gain Compensation (BGC) & THX Loudness Plus: Sitting near a wall may result in distorted bass response. BGC corrects the way low frequency sound is perceived when seated near a wall. This results in a more accurate bass response. THX Loudness Plus is a volume control technology that automatically adjusts the front-to-back speaker level relationship as you turn the volume down. With THX Loudness Plus home theater audiences can now experience surround sound at any volume level.
- Listening Modes: Choose between 4 THX Listening Modes - THX Cinema, THX Game, THX Music, and THX Surround EX. THX Cinema recreates the ambiance of the movie theater by positioning the 5.1, 7.1and immersive mixes to submerse you in the movie's soundtrack. THX Game distributes the sound effects and dialogue generated by the game engine by placing the audio from a 5.1, 7.1 or immersive mix to the appropriate "action" location - creating 360-degree gaming experience. THX Music emulates the original studio environment for the 5.1, 7.1 or immersive mix for an accurate and increased sense of spaciousness and localization - placing you directly in the recording session. THX Surround EX decodes the third surround channel from the traditional two surround channels to create a more immersive entertainment experience.
Note: THX Certified Select is suitable for medium sized rooms, up to 2,000 cubic feet in size, with a 10-12 foot viewing distance from the screen.
Compatible Digital Audio Formats: The AV receiver supports the following stereo & multichannel digital audio formats through its HDMI jacks and optical/coax digital inputs.
|Digital Audio Connector||Audio Signal Type||Audio Signal Format|
|HDMI (7 Inputs/2 Outputs)||High Definition Audio Bitstream|| Dolby Atmos, Dolby Digital Plus, Dolby TrueHD |
DTS:X, DTS-HD Master Audio, DTS-HD High Resolution, DTS Express
|Bitstream||Dolby Digital, DTS, DTS-ES, DTS 96/24|
|PCM||2ch to 8ch (32-192kHz, 16/20/24-bit)|
|DSD||2ch (2.8/5.6MHz, 1-bit)|
|Optical (2 Inputs)/Coaxial (1 Input)||Bitstream||Dolby Digital, DTS, DTS ES, DTS 96/24|
|PCM||2ch to 6ch, (32-96kHz, 16/20/24-bit)|
Immersive Surround Sound: The Onkyo TX-NR686 AV receiver goes beyond regular surround with the latest immersive surround sound formats, including Dolby Atmos, & DTS:X. The TX-NR686 also supports Dolby Surround & DTS Neural:X that enhances two-channel and multichannel content and decoding formats with immersive surround sound.
- Dolby Atmos: With Dolby Atmos, sound comes alive from all directions, including overhead, to fill your home theater with astonishing clarity, power, detail, and depth. The TX-NR686 has the processing power to run a more enveloping 5.1.2ch Dolby Atmos layout utilizing ceiling mounted or Dolby Atmos-enabled speakers (sold separately). A 5.1.2ch speaker configuration is based upon a traditional 5.1 speaker layout complemented by 2 overhead or Dolby Atmos-enabled speakers.
- DTS:X: DTS:X will be enabled through an online firmware update coming later this year. DTS:X is the next generation object-based, multi-dimensional audio technology from DTS. Unbound from channels, DTS:X conveys the fluid movement of sound to create an incredibly rich, realistic and immersive soundscape - in front of, behind, beside and above the audience - more accurately than ever before. DTS:X offers the ability to automatically adapt the audio to the speaker layout that best fits your space.
- Dolby Surround: Dolby Surround offers an enhanced cinema experience to your 2ch or multichannel movie soundtracks using your existing 5.1ch, 7.1ch or Dolby Atmos speaker setup. Dolby Surround enhances audio definition by improving the spatial dimension and overall audio definition of movie soundtracks. It does this by using four distinct surround zones that provide greater control over the exact placement of each detail in a movie sound track, so audio can be matched more accurately to the video on screen; this means more depth and greater realism for your movies. As a result, individual sounds are clearer and more distinct. It also improves the surround sound experience across the entire theater by widening the listening "sweet spot".
- DTS Neural:X: DTS Neural:X will be enabled through an online firmware update coming later this year. DTS:X incorporates Neural:X, the latest spatial remapping technology from DTS, which provides a fully immersive output for all types of source content; this includes DTS bitstreams and non-encoded (PCM) data. Neural:X delivers a thrilling sense of immersive sound to your speaker layout regardless of the original source format.
Onkyo Original DSP Modes: Onkyo's Original DSP Modes, combined with Dolby Digital & DTS processing, produce more realistic, powerful sound effects for your movie and music sound tracks based on the type of content and your home theater setup. You can choose from the following:
- Orchestra: Suitable for classical or operatic music. This mode emphasizes the surround channels in order to widen the sound image, and simulates the natural reverberation of a large hall.
- Studio-Mix: Suitable for rock or pop music. Listening to music in this mode creates a lively sound field with a powerful acoustic image, like being at a club or rock concert.
- TV Logic: Suitable for TV shows produced in a TV studio. This mode enhances the surround effects to the entire sound to give clarity to voices and create a realistic acoustic image.
- Unplugged: Suitable for acoustic instruments, vocals and jazz. This mode emphasizes the front stereo image, giving the impression of being right in front of the stage.
- Multichannel (Multich)/Game: Multichannel mode is suitable for playing sources recorded in multichannel PCM. The receiver also offers four different Gaming modes - RPG, Action, Rock, and Sports.
- Stereo/All Channel Stereo (AllCh Stereo): In Stereo mode, sound is output from the front left and right speakers and subwoofer. In All Channel Stereo Mode, stereo sound is output from all speakers - ideal for background music.
- Mono/Full Mono: In Mono mode, when the input signal is analog or PCM, the left and right front speakers output the sound in monaural. In Full Mono mode, all speakers output the same sound in mono, so the sound you hear is the same regardless of where you are within the listening room.
- Theater-Dimensional (T-D): In this mode, you can enjoy a virtual playback of multichannel surround sound even with only two or three speakers. This works by controlling how sounds reach the listener's left and right ears
Direct Mode: In Direct mode, audio from the input source is output without surround-sound processing. This mode delivers pure sound with minimum sound quality adjustment and filtration.
Audio Enhancements: The Onkyo TX-NR686 receiver provides various audio enhancements to deliver a high-quality listening experience every time.
- CinemaFilter: The CinemaFilter softens overly bright movie soundtracks. Movie soundtracks are typically mixed for a large theater (relative to your home theater) with lots of soft seats and thick curtains on the walls. Home theater settings often lack these high frequency absorbing wall treatments, making the soundtrack sound too bright. CinemaFilter accounts for this and for many movies sounds more natural at home.
- Music Optimizer: The Music Optimizer function enhances the sound quality of compressed music files. The Music Optimizer function only works with PCM digital audio input signals with a sampling rate below 48kHz, analog input signals, and Bluetooth audio.
- Late Night Feature: The Late Night feature limits the dynamic range of Dolby Digital recordings. Limiting the dynamic range makes it easier to find a volume that ensures the quiet sounds are not too quiet and the loud sounds are not too loud for night time listening. This allows you to comfortably listen to without the need to constantly adjust the volume to keep from waking family/neighbors. The choices are: Off, Low, and High. This feature only works with Dolby Digital Encoded software and the depth of the feature will vary based on the individual software package.
Bass Management: The Onkyo AV receiver offers Tone Control and Double Bass feature to get the most bass impact out of your system. You can independently adjust the Bass (20Hz) and Treble (20kHz) of the receiver's Front L/R channels from -10 to +10 dB. You can also activate the Double Bass function in order to boost bass output even more by feeding bass sounds to the front left/right speakers, center-channel, and powered subwoofer.
Volume & Level Setup: The Onkyo AV receiver provides the following volume & level settings.
- IntelliVolume: With IntelliVolume, you can set the input level for each input (+/-12dB) selector individually. This is useful if one of your source components is louder or quieter than the others. This function does not work in Zone 2.
- Maximum Volume: Use this feature to set the receiver's maximum volume level for the Main Zone and Zone 2. This feature is useful to avoid turning the volume too loud by mistake. You can set the Max Volume from 50-99 (max), or Off (disabled).
- Power On Volume: Use this feature to set the volume level when the power is turned on in the Mainz Zone and Zone 2. You can choose between Last (same as the volume when the unit was turned off), Min (0), or 1-99.
- Mute Level: Set the volume lowered from the listening volume when "Mute" is selected. Choose from 0, -40dB, or -20 dB.
- Headphone Level: With this setting, you can specify the headphone volume (+/-12dB) relative to the main volume. This is useful if there's a volume difference between your speakers and your headphones.
Analog Audio Outputs: The Onkyo TX-NR686 is outfitted with the following analog audio outputs.
- Binding-Post Speaker Terminals: There are binding-post terminals for all speaker connections - Front, Center, Surround, Surround Back/Height, and Zone 2. The binding post terminals will accept bare-wire, pin-connectors, and banana plugs (single only). Use 4- to 16-ohm speakers.
- Dual Subwoofer Outputs: The receiver is fitted with two subwoofer outputs to connect dual powered subs for extra bass. The dual outputs are wired in parallel and share the same input signal (they are not discrete).
- Headphones: When headphones are plugged into the full-size 1/4" jack on the front panel, all the speakers are automatically muted.
Phono Input: The TX-NR686 has a discrete low-noise phono pre-amp and is outfitted with Phono (MM) input for connection of a turntable with a moving magnet cartridge so you can enjoy listening to your vinyl records. There is also a ground screw terminal.
Front-Panel Aux Input: The TX-NR686 is fitted with a front-panel 3.5mm Aux input for connecting a portable audio player.
HDMI 2.0b: The Onkyo TX-NR686 has seven HDMI 2.0b inputs (6 rear/1 front) and dual HDMI 2.0b outputs. The dual HDMI outputs can simultaneously output the same HDMI audio/video signal to two TVs (video is output at the resolution supported by both TVs). Thanks to the latest HDMI 2.0b specification, the receiver can support 4K/60 Hz Ultra-HD video, HDCP 2.2 compatibility, 4:4:4 color sub-sampling, High Dynamic Range (HDR), and BT.2020 Wide Color Gamut.
- 4K/60Hz: The TX-NR686 supports up to 4K (3840x2160 pixels) video @ 60 frames per second on all of its HDMI inputs and outputs. It will also pass a 480p, 720p, 1080i, or 1080p video signals via HDMI (not compatible with 480i video signals).
- HDCP 2.2: The receivers HDMI inputs and HDMI monitor output support HDCP 2.2, which fully complies with the latest copyright protection standard for 4K video transmission.
- 4:4:4 Color Subsampling: The receiver's HDMI inputs and HDMI monitor output support RGB, YCbCr 4:4:4, YCbCr 4:2:2, and YCbCr 4:2:0 color subsampling (@ 60Hz or 50Hz). With 4:4:4 color subsampling, luminance (brightness) and chroma (color) are sampled at the same rate; resulting in an RGB color palette as big as the video sampling rate for a video image with more colors, plus greater color accuracy and detail.
- Wide Color Gamut (BT.2020): The BT.2020 color standard delivers a much wider color gamut and represents about 75% of the total visual color spectrum, while the current Rec. 709 color standard selected as the color space for HDTVs and early generation 4K Ultra HDTVs covers only 35% of the total visual color spectrum.
Note: Use a premium high-speed 18Gbps HDMI cable for the best 4K/HDR performance.
HDR (High Dynamic Range): HDR (High Dynamic Range) video provides enhanced picture quality by simultaneously enabling greater detail for both the dark and bright parts of an image. HDR reproduces a greater dynamic range of luminosity or brightness levels, creating greater contrast. This increased contrast reveals the subtle nuances of the image, from detailed blacks and shadows to the brightest whites and colors, plus greater depth. This receiver supports two HDR formats - HDR 10, Hybrid Log-Gamma (HLG), & Dolby Vision.
- HDR 10: HDR 10 is an open standard and currently the most popular HDR format on the market. It uses static metadata at the start of a movie to tell the receiver and your TV that the video content is encoded using HDR.
- Hybrid-Log Gamma: HLG (Hybrid-Log Gamma) is primarily designed for live video feed and over-the-air broadcasts. It uses no pre-encoded metadata and is backwards compatible with SDR. HLG's native compatibility allows much of today's existing SDR infrastructure to be re-used for HDR in the future.
- Dolby Vision: Unlike HDR 10 which contains static metadata and HLG which uses no metadata, Dolby Vision uses dynamic metadata technology which sets individual color and brightness levels for each and every scene. Dolby works directly with filmmakers at major Hollywood studios to create superior HDR video masters of blockbuster movies.
Analog Video-to-HDMI Conversion: Analog composite and component video signals (480i only) input to the receiver will be converted to HDMI signals and then output from the receiver via its main HDMI monitor output to your TV. The resolution remains the same and is not upscaled.
Other HDMI Features: The TX-NR686 AV receiver's HDMI connectivity also offers 3D video pass-through, ARC (Audio Return Channel), Deep Color & x.v. Color support, as well as an auto LipSync function.
- ARC (Audio Return Channel): The receiver's main HDMI monitor output features ARC (Audio Return Channel). This feature allows audio to be sent from your compatible HDTV to your receiver through the same HDMI cable already being used to send audio and video to your HDTV. This eliminates the need for extra cables connected to your television.
- Deep Color & x.v.Color Support: The AV receiver supports Deep Color and x.v.Color content, which can display a larger color range than standard-definition schemes. The result is a more lifelike, vibrant picture
- 3D-Ready: All HDMI jacks will accept 3D video from your 3D-ready Blu-ray player and output the video signal in 3D to your 3D-ready flat-panel television.
- AV Sync: The AV Sync feature can automatically synchronize HDMI audio and video (for any HDMI jack) that has gotten out of sync due to the complex digital video processing being performed by your HDMI-compatible TV. With AV Sync, the audio delay required to synchronize the audio and video is calculated and applied automatically by the AV receiver. You can also manually correct the audio delay from 0 (no delay) to 400 milliseconds; in 10 millisecond steps.
HDMI Through: When enabling the HDMI Through function, regardless of whether the AV receiver is "O" or in "Standby", both audio/video streams from an HDMI input will be output to your television, via the receiver HDMI monitor output. You can select between three HDMI Through modes.
- Auto: Detects the signal and automatically selects the input sources.
- Source: Selects the HDMI input source for which the HDMI Through function in enabled.
- Last: The HDMI Through function is activated on the input source selected at the time of setting the AV receiver to the "standby" mode.
Analog Video Inputs: The receiver features two composite video inputs and two component video inputs which support 480i video signals only. All analog video input signals are converted to digital and sent via HDMI to your TV at 480i (no upscaling). The component video inputs are not capable of high-definition video.
Video Select: It is possible to play audio and video from different sources. For example, you can play audio via Bluetooth and video from your BD/DVD player. This function is only effective when an input with audio only (Network, Bluetooth, or Tuner) has been selected initially.
Wired or Wireless Network Connection: The Onkyo TX-NR686 AV receiver supports a wired Ethernet (RJ-45) or wireless WiFi (802.11 a/b/g/n; 2.4/5GHz) network connection. Via the AV receiver's network connection, you can enjoy music files stored on your computer and listen to internet radio through a variety of online music services.
- Ethernet (LAN) Jack: The Onkyo AV receiver is equipped with an Ethernet (RJ-45) jack for connecting the player to your home network and computer. Connecting the A/V receiver's Ethernet port to a 100Base-TX switched Ethernet network is recommended for best results. Use a shielded CAT-5 Ethernet cable to connect the receiver to your home network.
- Built-in Wireless LAN: The AV receiver also features built-in WiFi that allows you to wirelessly connect to your home network, so you can enjoy the benefits of a cable-free network environment. A wireless connection requires a home network with a WiFi-enabled access point (IEEE 802.11 b/g/n; 2.4/5GHz). Supports WPS, WEP, and WPA security.
- Network setup requires that the receiver be connected to your TV via HDMI for display of the on-screen menu. The receiver's network setup cannot be accessed through its front-panel display.
- You can "Accept" or "Not Accept" for Onkyo to collect information about product usage when connected to the network and internet. However, if you do not accept the agreement you will get a "Onkyo Group Privacy Statement" each time the receiver is turned on.
DLNA Certified: Because the TX-NR686 is DLNA (ver.15) certified, you can play back music files stored on your Windows PC (w/ Windows Media Player 11 or 12) or a DLNA compliant media server through the stereo receiver. You can control basic playback functions of your music library from the included remote control and receiver's on-screen menu; such as Folder/File Select, Play/Pause, Stop, Fast Forward/Rewind, Previous/Next Track, and Repeat/Random. Compatible music files include -
- Hi-Res Music Files: FLAC (8/16/24-bit; 44.1-192kHz), WAV (8/16/24-bit; 44.1-192kHz), AIFF (8/16/24-bit; 44.1-192kHz), ALAC (16/24-bit; 44.1-96kHz), DSD (1-bit; 2.8/5.6MHz)
- Low-Res Music Files: MP3 (8-320kbps; 44.1-48kHz), WMA (5-320kbps; 44.1-48kHz), AAC (8-320kbps; 44.1-96kHz)
Built-in Online Music Services: The Onkyo TX-NR686 offers several built-in internet radio & online music services through its wired or wireless network connection.
- TuneIn: With more than 100,000 radio stations and 2 million on-demand programs registered, TuneIn is a service where you can enjoy music, sports and news from all over the world.
- Amazon Music (available firmware update): Amazon Music is an on-demand music streaming service that offers access to tens of millions of songs. The Amazon Music service requires that you have an Amazon Prime account or Amazon Music Unlimited account.
- Pandora: Pandora is a personalized Internet radio service that plays the music you know and helps you discover music you'll love. You can select Internet radio stations by Artist, Song, or Genre.
- Tidal: Tidal is a global streaming service that offers over 30 million songs in high-fidelity CD sound quality. Tidal has two pricing tiers; either $9.99 or $19.99 a month. Both pricing levels allow you to access Tidal's entire music library. The $19.99 tier has the added benefit of high-fidelity sound at CD-level quality.
- Deezer: Deezer is an online music service offering over 43 million tracks starting at $9.99 a month. Discover the perfect playlist or make your own, as well as browse curated collections by genre.
Spotify Connect: The integration of Spotify Connect will enable Spotify Premium users to instantly select and wirelessly stream music to the Onkyo AV receiver from within the Spotify app (Apple iOS or Android). Spotify is a digital music service that gives you on-demand access to one of the largest music libraries in the world (over 15 million tracks and counting). Spotify makes it easier than ever to discover, manage, and share music with your friends. You can browse music by artist, album, track, or most popular; and create your own music library with customized playlists.
Chromecast Built-In: Chromecast built-in lets you instantly stream a variety of music apps from your Apple (iOS 7.0+) or Android (OS 2.3+) mobile device to the Onkyo stereo receiver. Chromecast built-in works over WiFi and allows you to connect more than one device at a time to the receiver, as well as control what's playing from anywhere in the house with your compatible mobile device.
- Supported Content: Chromecast built-in offers Internet Radio apps like TuneIn & iHeart Radio; plus online music service apps like Pandora, Spotify (requires Premium subscription), Tidal, Google Play Music, and more. Click here for a complete list of compatible apps. You can even wirelessly stream exactly what's playing on your Android phone or tablet through the Onkyo receiver. Or, if you're on your laptop or computer, you can also cast any music streaming website through the Chrome browser.
- Simple-to-Use: Simply tap the Cast button from a Chromecast Built-in compatible music app to start streaming to the Onkyo receiver. You can search, browse, play, skip, and turn up the volume directly from the music apps you know and love on your compatible phone, tablet or laptop. While you cast your music, you can still use your phone to answer a phone call, play a game, send a text, and even leave the room, all without interrupting what's playing on the receiver's speaker system.
Note: To use Chromecast built-in, you must agree to Google's Privacy Statement.
AM/FM Tuner: With the built-in tuner you can enjoy AM and FM radio stations. You can store your favorite stations as presets for quick selection. You can store a combination of up to 40 of your favorite FM/AM radio stations as presets.
Built-in Bluetooth: The Onkyo TX-NR686 features built-in Bluetooth (version 4.1+LE) with support for profiles A2DP 1.2 and AVRCP 1.3. You'll be able to wirelessly stream stored music and music apps from your Bluetooth-enabled Apple iPod/iPhone/iPad, Android smartphone/tablet, Windows Phone/PC, & Mac laptop/computer, as well as other Bluetooth compatible devices to the Onkyo receiver. The receiver has a 48' wireless Bluetooth range. You can even set the receiver to automatically turn on when a Bluetooth source device is paired and connected.
- SBC + AAC Codecs: In addition to support for the standard SBC Bluetooth audio codec, the TX-NR686 offers support of AAC. By supporting AAC, the receiver offers better audio performance of the music streamed from your Apple iPod, iPhone, or iPad.
- Playback Control: You can use the receiver's IR remote control to operate basic playback functions, like Play/Pause & Previous/Next Track. Advanced music browsing will still need to be handled from your Bluetooth-enable device.
- Song/Artist Information: The receiver will display song/artist information on its front-panel LCD and through its on-screen on your HDMI-connected TV. Album Art is not supported.
Note: Due to the differences in Bluetooth technology, some Bluetooth enabled devices may be incompatible, function improperly, or may not support all features when used with the Onkyo receiver.
AirPlay 2 (via available firmware update): Through an available firmware update, the Onkyo TX-NR686 will support AirPlay 2. AirPlay 2 is an advanced and easy-to-use wireless multiroom audio platform for iTunes, Apple Music, and other compatible Apple iOS apps. With AirPlay 2 you can play any sound from your Apple iOS device (running iOS 11.4 or later) or Mac computer (running OS X 10.13.2) on the TX-NR686 and other compatible AirPlay 2 components throughout your home. You will also be able to ask Siri-enabled devices (like your Apple iPhone, iPad, or Watch) to control playback of your Apple Music on the Onkyo TX-NR686. With AirPlay 2, also get to see song/artist information and album art via the unit's on-screen menu (via HDMI). You can choose to play audio in one room, play the same audio in grouped rooms, or play the same audio in every room (you can control and group directly from Apple's Music App and Home app on your Apple iOS device). You can even watch videos and movies from YouTube and Netflix on your compatible Apple iOS device or Mac computer with perfectly synced audio on the Onkyo TX-NR686.
USB Mass Storage Class: This AV receiver is equipped with a rear-panel USB (type-A) port that allows you to enjoy a variety of music files from a USB mass storage class memory device, such as USB thumbdrive or portable digital audio player. The unit will recognize USB MSC devices formatted in FAT16 or FAT32 with up to 20,000 music files. You can control basic playback functions of your music library from the included remote control and receiver's on-screen menu; such as Folder/File Select, Play/Pause, Stop, Fast Forward/Rewind, Previous/Next Track, and Repeat/Random. USB portable audio players that can be charged via USB will be charged when plugged into the AV receiver's USB port (5V/1A); even in standby mode. Compatible music files include -
- Hi-Res Music Files: FLAC (8/16/24-bit; 44.1-192kHz), WAV (8/16/24-bit; 44.1-192kHz), AIFF (8/16/24-bit; 44.1-192kHz), ALAC (16/24-bit; 44.1-192kHz), DSD (1-bit; 2.8/5.6MHz)
- Low-Res Music Files: MP3 (8-320kbps; 44.1-48kHz), WMA (5-320kbps; 44.1-48kHz), AAC (8-320kbps; 44.1-96kHz)
Notes: The receiver's USB port does not support Apple iOS and Android devices, USB hubs and card-readers, computers and laptops, or any MP3 player containing music files that are managed with special hardware.
Zone 2 (Line & Speaker Level): In addition to the main listening room, you can also enjoy audio playback from a different source in another room of your home using the receiver's Zone 2 function. The receiver features Zone 2 line-outputs, as well as Zone 2 speaker terminals. The volume of Zone 2 is controlled from the receiver when using the speaker outputs and from your add-on integrated amp when using the line-level outputs.
- Line-Level Outputs: By using the line-level outputs on the TX-NR686 you can connect an external receiver or integrated amplifier in a second room, allowing you to listen to 7.1ch surround in the main room and play a different audio source in another room of your home.
- Speaker Level Outputs: By using the speaker-level outputs on the TX-NR686, you can directly connect a secondary pair of speakers in another room of your home, allowing you to listen to 5.1ch surround sound in your main room and play a different audio source in the other room
Zone 2 Sources: You can play the same audio source in both Zones (Main & Zone 2) or play a different audio source in each zone. Zone 2 is compatible with analog, digital, and wireless audio sources - see below for details.
- Compatible Sources: AM/FM tuner, Analog & Optical/Coax Digital (2ch PCM only) inputs, USB & Bluetooth Audio, Network (including DLNA, AirPlay, and built-in music apps) can be played back in Zone 2.
- Incompatible Sources: HDMI audio/video and analog video sources cannot be output to Zone 2. Chromecast built-in apps and DSD audio files cannot be played back in Zone 2.
- As for Network, USB, and Bluetooth sources; you cannot select different inputs for the main room and Zone 2. For example, if a Network source has been selected in the main room and then Bluetooth is selected as a playback source in Zone 2, the input in the main room will also change to the Bluetooth source.
- When listening to AM/FM or Internet radio, you cannot select different stations for the main room and Zone 2.
Dual HDMI Outputs: The AV receiver's dual HDMI outputs can simultaneously output the same HDMI audio/video signal to two TVs (video is output at the resolution supported by both TVs). The sub HDMI output only supports HDMI audio/video inputs (not compatible with composite or component video). This is not the same as a true HDMI Zone 2 function.
Google Home Multiroom: Using the Google Home app for Apple iOS 8.0+ and Android OS 4.0.3+, you can sync multiple speakers with Chromecast built-in in multiple rooms of your home to play the same song from a Chromecast built-in music app throughout your house at the same time. Friends and family can even use their own Chromecast compatible phone or tablet to cast music to your system by connecting to your home's WiFi network.
DTS Play-Fi (Firmware Update Available): DTS Play-Fi combines DTS and WiFi to wirelessly stream high quality audio through out your home using the Play-Fi app for Apple iOS 8.0+, Android OS 4.0+, & Windows 7 PC or later. Supported music formats up to 24-bit/192kHz (including MP3, AAC, FLAC, WAV) are wirelessly streamed to the receiver or to multiple DTS Play-Fi players at up to 16-bit/48kHz (CD quality sound). You can connect multiple DTS Play-Fi products together from different brands and manufacturers on the same home network to create a whole-home streaming experience. Play the same source in every room or a different song in each room. Due to the bandwidth limitations of most wireless networks, no more than 16 wireless DTS Play-Fi products on a single WiFi network at one given time is recommended. DTS Play-Fi has a range of up to 100' from your wireless router. Compatible sources include -
- Source Devices: DTS Play-Fi provides you with the ability to stream your music wirelessly in high-quality lossless audio from Apple iOS & Android devices, Windows laptops & desktop computers, as well as DLNA-servers on your existing home WiFi network to the Onkyo receiver. Up to eight separate wireless source devices, each with its own source, are supported simultaneously and any wireless source device can stream to eight DTS Play-Fi playback devices.
- Online Music Services: DTS Play-Fi enables wireless audio streaming from the world's most popular music services, including - Pandora, SiriusXM, TIDAL, Amazon Music, iHeartRadio, Napster, & more.
- DTS Play-Fi Compatible Products: All DTS Play-Fi enabled products work seamlessly together, so there's no hassle adding more components, or choosing more than one audio brand (like Onkyo, Integra, Klipsch, MartinLogan, McIntosh, Paradigm, Phorus, Polk Audio, SVS, Wren, and more) in your home.
Note: This unit does not support the following DTS Play-Fi functions - Spotify Connect, Wireless Surround Sound, Line-In Rebroadcast, Interent Radio, Criticaly Listening Mode, and L/R Stero Speaker Pairing.
Sonos Connect Ready: Instantly upgrade the music streaming capability of your Onkyo receiver with Sonos Connect (sold separately) and a free over-the-network firmware update. With the Sonos Connect connected to the Onkyo receiver via a set of stereo RCA cable, the audio system you've built around the receiver can now be part of a Sonos Wireless Multiroom Audio System (components sold separately). After a simple set up, the Onkyo receiver will seamlessly tie into Sonos, instantly turning on from network standby, changing inputs and playing at the volume you command through the Sonos controller app on your compatible Apple iOS or Android device.
- Functionality: Once the Onkyo receiver is connected to the Sonos Connect you will be able to send any music or source on the Sonos app to the receiver. You will also be able to group the receiver to other Sonos devices on the network or use it independently. Whenever you start playing music back from your Sonos app and the Onkyo receiver is selected, the receiver will automatically turn on and switch to the correct input.
- Compatibility: The Onkyo receiver can be used with the Sonos One, Play:1, Play:3, Play:5 or any combination of these speakers (all sold separately). You can even use the Onkyo receiver with a Playbar or Playbase (sold separately) that is located in a different room. Just remember that you need to have a Sonos Connect to connect the Onkyo receiver to the Sonos multiroom audio system.
Note: Click here to learn even more about Onkyo and Sonos working together to give you the ultimate home theater and multiroom audio experience.
FlareConnect MultiRoom Audio: FlareConnect powered by Blackfire mirrors network audio sources and any external analog source playing through the receiver (from streaming audio to vinyl) on optional FlareConnect/Blackfire wireless speakers (such as the Onkyo NCP-302, sold separately). Sampling rates up to 48 kHz are supported. FlareConnect powered by Blackfire is stable, fast, and easy to control with Onkyo's Controller app for Apple iOS and Android.
Note: Onkyo cannot guarantee the compatibility with other devices featuring FlareConnect or Blackfire.
Onkyo Controller App: The Onkyo Controller app (for Apple iOS 8.0+ & Android OS 4.0.3) features an intuitive, user-friendly interface that allows you to conveniently operate the Onkyo receiver from your compatible Apple iOS or Android device. This app not only has the usual remote control functions, it also has a multiroom functionality for Zone 2 and wireless multiroom audio setups.
- Remote Control: You can operate general control functions (play/stop, control the volume, select the input source, etc.) from your compatible smartphone or tablet.
- Source Device Playback: Operation of connected products (like a Blu-Ray player or TV) that are connected to the receiver via HDMI.
- Streaming Audio: Lets you play audio from built-in music streaming services (such as Pandora, Spotify, TIDAL, etc), the music library on your Apple iOS or Android device, and your Windows PC or other DLNA-compatible server. You can also access music from Bluetooth and USB source devices.
- Multiroom Audio: Provides control over Zone 2 and wireless multiroom audio (such as FlareConnect by Blackfire).
Google Home Voice Commands: With a Google Home voice-activated speaker (sold separately - see Accessories Tab) and the Google Home App (for Apple iOS 8.0+ or Android OS 4.2+), you can use your voice to control select functions of the Onkyo AV receiver. With a simple voice command, you can play music from Chromecast compatible music services by artist, song, genre, album, playlist, mood or activity. You can also turn up the volume, skip to the next track, or stop the music - all without lifting a finger.
IR Remote: The receiver comes with an IR remote control for wireless operation of this receiver and other HDMI-connected sources (via HDMI CEC).
HDMI Control: This function allows HDMI-CEC compatible components or RIHD-compatible components connected via HDMI to be controlled with the TX-NR686. The AV receiver offers the following HDMI-CEC controls.
- The AV receiver will enter Standby mode when the power of the TV is turned to Standby.
- You can set on the menu screen of the TV to either output the audio from the speakers connected to the AV receiver, or from the speakers of the TV.
- It is possible to output the audio/video from the antenna or from the input jack of the TV from the speakers connected to the AV receiver.
- Input to the AV receiver can be selected with the remote controller of the TV.
- Operations such as volume adjustment or similar for the AV receiver can be performed from the remote controller of the TV.
Web Control: When connected to your home's wired or wireless network, you can setup the Onkyo AV receiver with the web control screen displayed in your PC's web browser.
On-Screen Menu w/ Setup Assistance (HDMI only): The Onkyo AV receiver offers an on-screen (GUI) menu system through its HDMI output. The simple on-screen display combines text and graphics that make setup and other operations extremely easy. The initial setup assistant takes you step-by-step through speaker configuration, source connection, remote programming, and network connection.
Note: Initial setup requires that the receiver be connected to your TV via HDMI for display of the on-screen menu. Many of the receiver's setup functions can only be found via the on-screen menu and not the front-panel display.
Gapless Playback: Many live and classical albums have no gaps in the music. Gapless playback ensures that there are no pauses between audio files. This provides playback with no interruptions, the way it was meant to be heard. Compatible with WAV, FLAC, and ALAC music files via USB.
Name Edit: You can enter a custom name for each individual input selector and radio preset for easy identification. When entered, the custom name will appear on the display. This function cannot be used for the AM/FM, Network, USB, and Bluetooth input selectors.
Display Dimmer: The front-panel display brightness has three settings - Dim, Dimmer, and Normal.
Timers: The receiver features a programmable Auto Standby function & programmable Sleep Timer.
- Auto Standby: The AV receiver will automatically go into Standby mode, if there is no operation for 20 minutes with no audio/video signal input.
- Sleep Timer: From the remote, you can set the unit to automatically turn off after 30, 60, or 90 minutes.
Firmware Updates: Future firmware updates are available from the Onkyo website through the receiver's Network or USB connection. Visit Onkyo's online Download Center for the latest firmware updates.
Q Crutchfield asked: Why did you buy this?
9 questions already asked
