Voice, App, & Remote Control
OLED TV: "OLED" means organic light-emitting diode, named
for the advanced material used in the TV's screen. The secret to OLED is this
unique light-emitting diode structure with its electroluminescent layer, a
special film made from an organic, carbon-based compound that emits its own
light when hit with an electric current. A thin-film transistor (TFT) backplane
switches each specific pixel on and off. This configuration enables a thinner,
lighter form factor, higher resolution and big, home theater-ready screen sizes.
Because OLED TVs do not require a backlight, pixels that are switched off are
truly black, so OLED achieves deeper black levels and a higher contrast ratio
when compared to LCD and LED-LCD TVs with conventional backlighting. OLED
technology also increases energy efficiency.
- Pixel Level Dimming w/ Infinite Contrast Ratio: LG OLED
TV's self-lighting pixels switch off completely for Pixel Level Dimming. As
the first display technology that allows self-lighting pixels to switch on
and off individually, OLED offers the first "Infinite" contrast ratio. With
no light bleed, LG OLED achieves absolute black levels, for Infinite
Contrast. Contrast ratio measures the range from the brightest whites on the
screen to the darkest blacks. The deep blacks will offer a greater sense of
realism and depth on all content.
- 10-Bit Panel (Billion Colors) w/ Wide Viewing Angle: Thanks to its 10-bit panel, the LG OLED TV is
capable of displaying billions of rich colors with fine steps of gradation. With so
many more colors to express, you'll see a picture that is more detailed and
natural when compared to conventional 8-bit panels. The 10-bit panel even holds
up from wide viewing angles, so now everyone in the room will have an ideal view
of the action.
- True Color Accuracy Pro w/ Intense Color: The LG OLED
TV's True Color Accuracy Pro & Intense Color Technologies deliver a color palette that
virtually matches those seen in today's high-end digital cinemas, thanks to
its 4 Color Pixel Technology. LG's 4 Color Pixel technology adds a white
sub-pixel to the conventional 3 color red, green, and blue that enhances
both color range and accuracy. This considerably improves the OLED pixels'
ability to express the realistic colors and represents a giant step ahead of
conventional flat-panel displays.
- Ultra Luminance Pro w/ High Brightness: Ultra-HD picture quality becomes even more
dynamic with an extended range of brightness, thanks to LG's Ultra Luminance Pro
technology. By enabling higher peak brightness and an enhanced
contrast ratio, Ultra Luminance Pro makes 4K & HDR images even more striking.
α (Alpha) 9 Intelligent Processor: LG, the industry leaders of OLED TVs,
made their OLED televisions even better by developing the α (Alpha) 9 Intelligent
Processor. LG's most powerful processor ever provides true-to-life images with
incredibly rich colors, sharpness and depth to deliver the ultimate picture
quality with more realism. As a result of the new image processor, 2018 LG OLED
TVs can display any content at maximum quality for a truly spectacular viewing
- 4-Step Noise Reduction: A core innovative element of the α
(Alpha) 9 is the four-step process of noise reduction, which boasts twice as
many steps compared to conventional techniques. This algorithm allows for
greater finesse in noise reduction, improving the clarity of images affected
by distracting artifacts and enabling more effective rendering of smooth
- Advanced Color Mapping: The processor also improves color
performance, thanks to the advanced mapping capabilities making colors look
closer than ever to the original content. The improved color correction
algorithm allows for more natural colors by expanding the reference color
coordinates seven-fold compared to before.
- 120 Hz Frame Rate: The α (Alpha) 9 processor is designed to support high frame
rate (HFR) for producing smoother and clearer motion images at 120
frames-per-second (fps) for better rendering of fast-action content such as
sports and action movies. As a result, you get even the fastest action to be
dependably crystal clear and virtually blur-free.
4K Cinema HDR w/ Enhanced Dynamic Tone Mapping: LG's 4K Cinema HDR
supports a variety of HDR formats - including Dolby Vision, Advanced HDR by
Technicolor, as well as Active HDR10 & HLG. Thanks to the TV's Active HDR technology with Enhanced Dynamic Tone Mapping and
SDR-to-HDR Effect, both HDR and SDR video content is optimized with the correct
amount of brightness and contrast, so all types of HDR & SDR content can be
displayed beautifully. HDR (High Dynamic
Range video) reproduces a greater dynamic range of luminosity or brightness
levels, bringing greater contrast & wider color spectrum to the screen. This
increased contrast reveals the subtle nuances of the image, from detailed blacks
and shadows to the brightest whites and colors, plus greater depth. Previously
hidden areas of dark shadow and sunlight are now full of clarity and detail.
- Dolby Vision: Dolby Vision Content has dynamic metadata that is
produced during content creation, capturing the dynamic properties of each scene.
This dynamic metadata is used to optimize the picture brightness curve
on a frame-by-frame basis. Dolby Vision is the preferred HDR format by major
Hollywood Studios and delivers the cinematic experience the creator intended
by optimizing the picture frame-by-frame.
- Active HDR10 & HLG Pro: HDR10 Pro and HLG Pro is LG's own proprietary HDR solution which processes
a HDR10 or HLG video
signal dynamically frame-by-frame using Enhanced Dynamic Tone Mapping. HDR10 uses static metadata at the start
of a movie to tell the TV that the video content is encoded using HDR; it is
currently the most popular HDR format on the market. HLG (Hybrid-Log Gamma)
uses no pre-encoded metadata and is primarily designed for live video and
over-the-air broadcasts. Enhanced Dynamic Tone Mapping allows the TV to
offer the best picture possible, even when playing HDR10 content which only
contains static metadata, or HLG content which uses no metadata at all.
- Advanced HDR by Technicolor: The same renowned Technicolor
technology that helps perfect premium Hollywood movies and TV shows can now
be found in LG OLED TVs. Advanced HDR by Technicolor optimizes the color
performance, which allows for content to be displayed as intended by
cinematographers. *Advanced HDR by Technicolor is supported via USB only.
- SDR-to-HDR Effect: The TV's HDR Effect feature raises image quality
for SDR content to near HDR quality Enhanced Dynamic Tone Mapping technology. With the HDR Effect feature, SDR images
are processed frame-by-frame to improve brightness in specific areas,
enhance contrast ratios and render more precise images.
Ultra HD 4K Resolution w/ Upscaler: The LG OLED TV has a
display resolution of 3,840 x 2,160 (4K) and will display all video at that
resolution through its built-in upscaler, regardless of input signal. 4K
provides four times higher resolution than current 1080p high-definition TVs
with a total of 8.3 million pixels. Its detail is so vivid and crisp, even when
viewed from close distances; it's nearly impossible to discern a single pixel,
even from inches away. Enjoy incredibly flawless images, vivid colors, and
picture details as never before. More benefits of Ultra-HD 4K include:
- Greater Sense Of Depth: At 4K, distant objects in a
scene can be rendered with greater clarity than at 2K, with more nuances of
light and shadow and focus for a greater sense of perceived depth.
- Better Color: Because pixels are units of colored
light, their greater quantity in 4K enables more layered transitions and
subtler gradations of tones, so the hues we see up on screen will be truer
to what we see in nature.
- Sit Even Closer: 2K HD TVs carry a recommended viewing
distance of three times (3X) the TV screen height, but with a 4K display you
can move in to one-and-a-half times (1.5X) screen height without exposing
individual pixels. Sitting closer better fills your field of vision,
assuring total immersion in whatever you're watching.
Video Inputs: The LG OLED television features
HDMI 2.0b and Composite video inputs. All of the television's video
inputs are displayed at 3,840 x 2,160 (4K).
- HDMI 2.0b: The four HDMI 2.0b inputs will accept 4K
(60/30Hz), 1080p (60/24Hz), 1080i, 720p, and 480p video signals. The HDMI inputs
not only allow you to connect your Blu-ray/DVD player or Satellite/Cable
receiver to the TV, but also a laptop or computer. The television's HDMI inputs
do not accept 480i video signals.
- HDCP 2.2: HDCP 2.2 is supported by all of the TV's HDMI
inputs. HDCP 2.2 is short for "High bandwidth Digital Content Protection"
and is used for 4K video copyright protection for compatibility with 4K
Blu-ray players and 4K Satellite/Cable providers.
- 4:4:4 Color Subsampling: All of the HDMI inputs
will support up to 4:4:4 chroma subsampling for full color data
rendering of 4K video (30/60fps). With 4:4:4 color, luminance
(brightness) and chroma (color) are sampled at the same rate, resulting
in an RGB color palette as big as the video sampling rate for a video
image with more total colors, plus greater color accuracy and detail.
You will need to enable this feature in the menu. 4:2:2 (30/60fps) and
4:2:0 (60fps) are also supported by any of the HDMI
inputs, by default.
- Composite Video: The composite video input will accept
480i only. The composite audio/video terminal consists of an AV 3.5mm
connector and a 6" mini-to-composite video/stereo RCA adapter.
Picture Settings: The LG OLED TV provides preset, user, and
expert adjustment of the television's picture settings.
- Picture Size: You can select a different aspect ratio
depending on input source (analog broadcasting, digital broadcasting, video
- Original: changes the aspect ratio to 4:3 or 16:9
depending upon the input video signal
- 16:9: displays an aspect ratio of 16:9
- 4:3: displays an aspect ratio of 4:3
- Just Scan: displays the picture in the original
size without cutting off the edges
- Vertical Zoom: adjusts the vertical dimension of
the screen and aligns the screen vertically
- All-Direction Zoom: adjusts the
horizontal/vertical/diagonal dimensions of the screen and aligns the
- Picture Modes: You can select the picture mode that is
best suited to your viewing environment, preferences or video type.
- APS (Auto Power Save): this Energy Saver mode
changes the TV's picture brightness to reduce power consumption
- Standard: provides optimum viewing for general use
- Vivid: maximizes the effect of the video by
strengthening the contrast, brightness, color, and sharpness
- Cinema: optimizes video for watching movies
- Sports: provides fast response speed for sports
- Game: provides even faster response speeds (21ms) for fast
- HDR Effect: enjoy a more dynamic, clearer image by
correcting the light and dark areas of the display
- User: manually adjust the TV's OLED Light, Contrast,
Brightness, Sharpness, Color, Tint, and Color Temperature (these
settings can be applied to an individual input or all inputs)
- Expert: the TV is ISFccc Ready and contains the
detailed standards necessary for professional calibration of brightness,
contrast, tint, sharpness, color levels and much more to meet local
lighting conditions for both day and nighttime viewing; the EXPERT/ISFccc
mode allows an expert to fine-tune the picture quality using a specific
- Technicolor: users will benefit from Technicolor's
renowned color science, applied to the majority of Hollywood's premium
content, through the Technicolor Expert Mode that is designed to deliver
the most accurate colors
- Advanced Picture Control: The TV also offers more
advanced picture settings.
- Dynamic Contrast: adjusts the contrast to keep it
at the best level according to the brightness of the screen; the picture
is improved by making bright parts brighter and dark parts darker
- Dynamic Tone Mapping: suitable contrast settings based on
image brightness of HDR content
- Dynamic Color: adjusts screen colors so that they
look livelier, richer and clearer; this feature enhances hue, saturation
and luminance so that red, blue and green look more vivid
- Preferred Color: fine tune Skin, Sky, and Grass
- Super Resolution: provides a crystal-clear picture
by improving the details in areas where the picture is blurry or unclear
- Gamma: you can adjust the brightness of dark areas
and middle gray level areas of the picture
- Color Gamut: maximizes the utilization of colors to
increase color quality
- Color Filter: filters a specific color spectrum in
RGB Colors to fine-tune color saturation and hue accurately
- Expert Pattern: patterns used for expert adjustment
- White Balance: adjusts the overall tone of the
screen as desired
- Color Management: this is a function used by
experts when they adjust colors using a test pattern of six colors
(Red/Green/Blue/Cyan/Magenta/Yellow) without affecting other color areas
- Picture Options: Additional picture options are
available to enhance your viewing experience.
- Real Cinema: makes video clips recorded in a film
look more natural by eliminating judder effect
- Black Level: sets the black level of the screen to
the proper level
- Noise Reduction: reduces screen noise without
compromising video quality
- MPEG Noise Reduction: removes noise caused by
- Motion Eye Care: automatically adjusts brightness
and reduces image blur based on image data to reduce eye strain
- Eye Comfort Mode: color temperature will be
automatically adjusted to reduce eye strain
- Panel Settings: With Panel Settings, you can improve
image retention issues (like "burn-in") related to images sticking when the screen has been on
for a certain amount of time.
- Pixel Refresher: this improves the quality of the
image displayed on the screen by removing image sticking on the display
- Screen Shift: this moves the screen slightly at
regular intervals to prevent image sticking on the display panel
- Logo Luminance Adjustment: automatically adjusts
the luminance (by 20%) of static images that are on-screen for two
minutes or more, such as logos within a program, to help prevent image
Live Zoom: LG's Live Zoom allows you to zoom in or zoom out on a portion of a video while it's
being played to make the desired section appear larger or smaller. Live Zoom is
only available on the TV's over-the-air tuner and HDMI inputs.
Built-in OTA Tuner: The LG TV features a built-in
over-the-air HDTV (ATSC) and Clear QAM tuner, so you don't need a separate
set-top box to receive and decode over-the-air HDTV/SDTV or unencrypted Digital
Cable signals (up to 1080i); subscription still required to receive cable
channels. A single RF-type coaxial input is use to connect an external
indoor/outdoor antenna (sold separately).
Dolby Atmos Support: This LG OLED TV currently supports
Dolby Atmos playback via Dolby Digital Plus through Internet streaming apps
(like Netflix & Vudu), over-the-air/cable broadcast, and USB. Dolby Atmos
playback delivered via Dolby TrueHD through Blu-ray & Ultra HD Blu-ray is also
supported over a non-ARC HDMI input.
Magic Sound Tuning: With the Magic Sound Tuning feature, you
can detect the space where your TV is installed using your Magic Remote's
microphone to optimize the audio of your TV for your environment. When the
initial detection is complete, you can select your desired audio mode.
- Standard: Selecting this option outputs Magic Sound
Tuning-adjusted audio in Standard mode. This mode provides a clean and
- Bass Mode: Selecting this option outputs Magic Sound
Tuning-adjusted audio with an emphasis on bass.
- Treble Mode: Selecting this option outputs Magic Sound
Tuning-adjusted audio with an emphasis on treble.
- Off: This option disables the use of Magic Sound
Tuning-adjusted audio. Selecting this option outputs your TV's default sound
without making any adjustments to it.
Ultra-Surround Sound + Equalizer: Ultra Surround delivers an immersive audio
experience from seven virtual channels, requiring only the two built-in speakers of
the TV. The TV also provides preset EQ modes. Choose
from Smart Sound, Standard, Clear Voice III, Cinema, Sports, Music, or Game.
In addition, you can adjust the TV's sound manually by using
the 5-band EQ (100Hz, 300Hz, 1khz, 3khz, 10kHz). Clear Voice III automatically
detects human voices in movies and TV shows, then increases their volume
to ensure that the dialog doesn't get lost in the soundtrack. You can
make the voice clearer by adjusting to one of the three clarity levels.
Sound Controls: Adaptive Sound Control automatically optimizes sound
based on the type of content. You can also set the TV's volume to automatically
adjust for different broadcasting stations, so you can always listen to channels
at the desired volume, even after switching the channels. In addition, if the video and sound of the television are not
synced, you can adjust the delay of the audio output to match the video. All
three of these features are only available when using the TV's internal
ARC (Audio Return Channel): The Audio Return Channel of the
TV's HDMI 2 input enables the television, via a single HDMI cable, to send audio
data "upstream" to your AV receiver; increasing user flexibility and eliminating
the need for any separate S/PDIF audio connection. This feature allows audio to
be sent from the television to your AV receiver through the same HDMI cable
already being used to send audio/video to the television. This eliminates the
need for extra cables connected to the TV. ARC allows audio from the TV tuner,
Network connection, inserted USB device, HDMI inputs, or any analog connected
device to be heard through your ARC compatible AV receiver via the television's
HDMI ARC input.
- The audio from the TV's tuner, HDMI inputs, and USB
ports can pass as DTS-HD, DTS, Dolby Digital Plus, Dolby Digital, or 2ch PCM.
- LG Store apps (like Netflix or Vudu) can be output as Dolby Atmos, Dolby
Digital Plus, Dolby Digital, or 2ch PCM.
- Analog connected & DLNA compliant devices will be output audio at 2ch
Note: Both the television and the receiver must support ARC
for this function to work properly. When connecting an AV receiver that is
compatible with Audio Return Channel (ARC), connect it to the TV's HDMI 2
input. If connecting a system that is incompatible with Audio Return Channel
(ARC), an additional audio connection via Digital Audio Out (Optical) is
Digital Audio Output: The optical digital output terminal
will output Dolby Digital/DTS (when available) or 2 channel PCM. The digital
optical output terminal only sends an audio signal in Dolby Digital/DTS when
receiving Dolby Digital/DTS surround sound from a digital broadcast channel
through the tuner, network apps, HDMI inputs, and USB ports on the TV. The
optical digital audio output will only output in 2ch stereo from sources
connected to the TV via stereo RCA.
Note: You can choose to turn the television speakers off or
leave them on with the TV's optical digital output active.
Bluetooth Audio Streaming (LG Sound Sync): Thanks to the TV's LG Sound Sync
and built-in Bluetooth 4.2, you can pair a single set of Bluetooth headphones, one
Bluetooth speaker, or a pair of Bluetooth speakers with the LG OLED TV. You are able
to stream audio from any of the TV's built-in sources or connected sources.
The TV's built-in speakers and audio outputs will be deactivated when streaming
audio to Bluetooth headphones or speaker. The Bluetooth audio output's volume is
variable, so volume of your Bluetooth speaker will need to be controlled by both
the TV and the Bluetooth speaker for adequate volume level. You can also
wirelessly connect a Bluetooth source device (such as your smartphone or tablet)
to play audio from your Bluetooth source device through the TV's speakers.
Note: Not guaranteed to be compatible with all Bluetooth
Network & USB Functions
Wired or Wireless Network Connection: The LG OLED TV
supports a wired or wireless network connection via its Ethernet jack or
built-in WiFi. Via the TV's network connection and your internet provider, you can enjoy select online entertainment services. You can also
access music, video, and still-image files stored on your computer, smartphone,
or tablet. It even supports WiFi Direct, so you link wirelessly to a WiFi device
without a router.
- Ethernet Jack: The LG OLED TV is equipped with an
Ethernet (LAN) RJ-45 jack for connecting the television to your home network
- Built-in WiFi: The LG TV offers built-in
dual-band (2.4/5GHz) WiFi (802.11ac) that allows you to wirelessly access
the Internet and your home network. The TV's built-in WiFi provides a
wireless network connection for the television with easy and quick setup.
With this feature, you can easily connect to a wireless LAN and enjoy the
benefits of networking in a cable-free environment. A wireless connection
requires a home network with an 802.11 access point and internet connection.
Supports WPS, WEP, and WPA security; a dual-band Gigabit wireless-N or
better router is recommended for 4K streaming.
- WiFi Direct: When using
WiFi Direct, you can
connect directly with other WiFi-enabled devices without using a
wireless router. You'll be able to wirelessly transfer personal content
(such as photos & videos) to the LG TV from your device without
connecting to your home network. WiFi Direct completely bypasses your
WiFi access point/router, so it's easy to set up. Streaming of
copy-protected content and other certain formats are not supported.
Note: LG recommends a home network connection speed of at
least 2.5 Mbps recommended for standard definition, 10 Mbps for high
definition, and 20 Mbps for ultra-high definition.
LG Content Store: LG Content Store allows you to access a
variety of online entertainment services and content directly on the LG TV
through its network connection and your internet provider. You can quickly and conveniently
browse for TV Shows, Movies, and more. You can also
download and use apps from various categories such as entertainment,
lifestyle, news, education, sports, and games. Click
for the latest compatible apps (subscriptions & fees may apply for some online
services and content). Below is a list of some of the most popular apps
from LG Smart TV Apps.
- TV Shows, Movies, & Videos: The LG TV offers access
to select online services that let you enjoy your favorite TV shows, new
blockbuster movies, and other video content. Depending on the online
service, video content is available in different video formats - including
Standard Definition (SD), High Definition (HD), Ultra High Definition (UHD
or 4K), and HDR (High Dynamic Range).
- Netflix: Netflix is a
streaming service that allows you to watch a wide variety of TV shows,
movies, documentaries, and more (including Netflix Originals). Some content
is available in 4K and HDR. With Netflix, you can enjoy unlimited viewing
without having to watch a single commercial. Subscription and membership
fees will apply.
- Amazon Video: With an Amazon Prime membership, you gain
access to thousands of popular movies and TV shows from
Amazon Video, including exclusive Prime Originals. You have the option
to rent or buy from a huge selection of movies and TV shows. Many Amazon
Video movies and shows are available in 4K and HDR.
- Vudu: With
Vudu you can watch the
latest movies & TV shows with no subscription or contract. You can rent or
own from over 100,000 titles, or watch thousands of movies free with Vudu
Movies On Us. You'll be able to enjoy movies and TV shows in up to 4K UHD
video quality (some shows and movies are also available in HDR).
- Google Movies & TV: Google
Play Movies & TV makes finding and watching movies & TV shows easier
than ever. Buy or rent the newest movies and shows from the comfort of your
home. You can watch select movies & TV shows in 4K Ultra High Definition
(UHD) quality. You can even watch some movies & TV shows in HDR with a wider
range of brightness and color.
Hulu is a leading premium streaming service that offers instant access
to live and on demand channels, original series and films, and a premium
library of TV and movies; starting at just $7.99 per month. Hulu offers
480p, 720p, and 1080p video quality.
- Other Video Apps: Other online video services with 4K
and HDR support, include YouTube
Additional standard and high definition video apps include
Crackle, & YuppTV.
- Live TV Services: Stream Live TV using Channel Plus,
SlingTV or YouTube TV (subscription fees may apply).
- Channel Plus: The
app (powered by XUMO) offers 100 free
streaming channels sports, news, entertainment, and lifestyle programming
(including NBC and CBS News, PBS Digital Studios, Sports Illustrated, Fox
Sports, and more). The Channel Plus app features a handy on-screen guide
which is integrated into the TV's over-the-air TV channel guide for easy,
Sling TV is the new way to watch live television. It's an app-based TV
service that lets you stream your favorite live TV channels over the
internet. With Sling TV, you get to customize your channels by subscribing
to the best service to match your needs (subscriptions starting at $20 per
month). It is all about your TV watching experience, making it simple once
- YouTube TV:
YouTube TV is a TV streaming service that lets you watch live TV from
50+ major broadcast and popular cable networks, as well as record your
favorite shows to cloud with no storage space limits. Enjoy local and
national live sports, and must-see shows the moment they air. YouTube TV
costs $40/month for 1 membership with up to 6 accounts. Memberships include
your local ABC, CBS, FOX, and NBC streams, ESPN, regional sports networks,
and more. Add on sports and premium networks like SHOWTIME and Fox Soccer
Plus for an additional monthly charge.
- Music & Radio: Listen to your favorite Internet Radio
stations and online music from
Spotify (requires premium account),
iHeartRadio, and more.
- News, Weather, & Sports: Catch up on the news at
USA Today, get
weather forecasts from
AccuWeather, and receive sports updates from
- Games: The LG Content Store contains a variety of
online games; you will need to connect a compatible game-pad to the TV's USB
Note: 4K & HDR
network streaming requires a network speed of 20Mbps or greater. A wired
Ethernet connection is recommended over a wireless WiFi connection for
better performance. If you desire a WiFi connection, then use a dual-band
Gigabit wireless-N router or better for 4K/HDR streaming.
DLNA + Plex Content Sharing: DLNA &
compatibility lets you stream select video, photo, and audio files stored on
your computer to the LG TV over your home's WiFi network. DLNA is supported
by Windows (7, 8, 8.1, or 10) and other DLNA network devices and servers. You
will also need to download the
SmartShare software on your compatible Windows PC. Plex Media Server
software is supported by Windows (7, 8, 8.1, or 10) and Mac (OSX 10.9 or newer).
Screen Sharing via Miracast: Miracast is a "screen mirroring" function
which lets you wirelessly send the display from your compatible Windows
8.1+ or Android 4.2+ device (with support for Miracast) to the LG TV.
This allows you to view practically any content that is playing on your
compatible Windows or Android device on your TV screen; no wireless
router or access point required.
Triple USB Ports: The television features three USB (type-A)
2.0 ports for playback of video, still image, and music files stored on a
connected USB memory device. The television can support USB external hard
disc drives (up to 2TB) and USB mass storage class devices (up to 32GB). The
USB storage devices must be formatted as FAT 32 or NTFS file system. In
addition, the TV will charge USB devices that can be charged via USB (max.
5V/0.5A). The LG television even lets you watch a slideshow of your photos (JPEG)
while listening to background music (MP3) from an inserted USB device.
- Compatible Video Files: AVI/Xvid, MPEG 1/2/4, MKV, MOV, WMV, & Vob.
- Compatible Photo Files: JPEG, PNG, & BMP
- Compatible Audio Files: MP3, WMA, FLAC, & OGG
Web Browser: The LG Smart TV features a built-in web browser
that lets you search the Internet for a particular website by URL or keyword
searches. The web browser supports only HTML5 media and not Flash Plug-in. The
web browser only replays the following media file formats - JPEG/PNG/GIF. Not
all websites will be available for download, because of size and content.
Voice, App, & Remote Control
Magic Remote: LG's Magic Remote acts as a remote controller, mouse
pointer, and voice commander. The Magic Remote automatically pairs with the TV
via Bluetooth and has a wireless operating range up to 32.8'.
- Remote Controller/Mouse Pointer: The Magic Remote
operates the TV as if it were a wireless mouse pointer. It allows you to
point the remote at the TV and move through menu options with the movement
of the remote. With simple gesture control, LG'S exclusive Magic Remote
enables you to move the on-screen cursor, navigate menus, drag & drop apps,
and select icons.
- Voice Command Functions: The Magic Remote's built-in
microphone enables voice command for live TV, internet apps, web browser,
input selection, and volume control. Simply press-&-hold the "Mic" button on
the remote to activate the Voice Command function. When the microphone image
appears on the screen, speak your desired search request into the remote.
You can tune TV stations, browse TV shows & movies from online apps, search
the web, and raise the volume up/down.
AI (Artificial Intelligence) ThinQ w/ Voice Control: The LG
TV goes a step further than basic voice control commands with the
integration of AI (Artificial Intelligence) ThinQ. AI ThinQ is able to achieve
intelligent voice-activated control by employing Natural Language Processing
(NLP) and LG's exclusive deep learning platform (Deep ThinQ). The LG TV with
AI ThinQ can process hundreds of voice commands. You are able speak directly
into the Magic Remote's mic to enjoy the ultra-convenient features of the latest
advanced voice assistant technology with deep learning capability. AI ThinQ lets
you use your voice to control television functions, search for content, and even
manage your connected smart home devices.
- TV Control: By utilizing the TV's built-in Electronic
Program Guide (EPG), AI ThinQ delivers real-time information and locates
channels with desired content. You can even say "search for this movie's
soundtrack" or "turn off the TV when this program is over" without repeating
the program's title or specifying a time. You can also ask the TV to play
your favorite show, search for a new movie, check information about a cast
member or director, and more. Additional voice commands include - Turn Off,
Volume Up/Down, Channel Selection, Switch Input, Control Playback, Content
Search & Recommendations, Launch Apps, Change Settings, and more.
- Smart Home Control: Beyond controls for the TV, LG's AI
ThinQ uses intelligent voice control to create a hub for your smart home and
IoT devices. By functioning as a smart home hub, the LG TV can access LG
SmartThinQ compatible smart home products on your network - such as
refrigerators, washers/dryers, robotic vacuum cleaners, air
conditioners/purifiers, smart lights and outlets, as well as many other
devices that connect to the TV via your home's WiFi network.
- Digital Assistants: Via a firmware update
(now available), AI ThinQ will support the
Google Assistant from the included Magic Remote's mic or an external
Google Home device (sold separately) to not only control the TV, but also
operate smart home devices, manage tasks, and find answers to your
questions. In addition, AI ThinQ supports
Alexa Skills & Commands from an external Alexa enabled device (sold
separately), so you can control the TV's primary functions from your Alexa
Echo, Dot, Show, etc. (all sold separately).
Note: The TV will need to be connected to your home's network and internet
provider for the AI (Artificial Intelligence) ThinQ feature to work.
LG TV Plus App: You can download the LG TV Plus
Android OS 4.2+ &
your compatible Apple iOS or Android OS device in order to control the television from
your smartphone or tablet, share content from your mobile device to the TV, and other
convenient features. The LG TV and your Android or Apple iOS device must
be connected to the same WiFi network.
- Remote Control: With the LG TV Plus app installed, your
compatible mobile device will act as a wireless remote control for the TV. You'll be able to change channels and adjust
volume from the app on your smartphone or tablet. You can even select the
television's LG Smart TV apps and switch between inputs
- Content Sharing: You can enjoy your pictures, videos,
and music stored on your Apple iOS or Android device through the LG TV using
the LG TV Plus app.
- My Starter: The My Starter feature of the LG TV Plus
app lets you view current time, weather, and calendars from your Apple iOS
or Android device on the TV screen when it is turned on.
HDMI-CEC: HDMI-CEC (or SIMPLINK) allows you to control other
HDMI-CEC compatible components connected to the TV via HDMI from the
television's Magic Remote. HDMI-CEC (or SIMPLINK) provides the following remote
- Instant Play: When you start a HDMI-CEC compatible device
which is connected to the TV via HDMI, you
can immediately watch content from the device on the TV without having to
control anything else.
- Device Control: HDMI-CEC also enables you to control
compatible devices connected to the television via HDMI with the TV's remote
- Main Power On/Off: Via HDMI-CEC, turning off the TV
will turn off all of your HDMI-CEC connected devices. In addition, turning on a
HDMI-CEC connected device will turn the TV on.
Control4 Simple Device Discovery Protocol (SDDP) Technology: The LG OLED TV features
Control4 Simple Device Discovery Protocol (SDDP)
Corporation is a leading provider of automation and control solutions for
the connected home. Products like flat-panel TVs, projectors, audio/video
receivers, security cameras, alarm panels, and other network-aware products can
be easily integrated into a consumer's smart and connected home via Control4
technology. With SDDP, the Control4 home automation system automatically finds,
identifies, authenticates, adds and connects the SDDP-enabled devices nearly
instantaneously during initial installation and set-up; dramatically reducing
the complexity and configuration time for Control4 installers, and reducing
potential incompatibility with other devices.
Keyboard Compatible: The LG OLED TV supports the use of a
keyboard & mouse through its USB ports or via Bluetooth. You can enter text with
the keyboard when using the Search function and the built-in Web Browser.
Serial Port: You can connect the 3.5mm serial port to an
external control device (such as a computer or AV control system) to control the
TV's functions externally.
WebOS 4.0: LG's latest WebOS 4.0 on-screen menu system is easy to
learn and use. Initial setup is smooth and simple, while connecting to other
devices and searching for content is extremely convenient. The intuitive WebOS
4.0 pulls together all your content choices and serves up entertainment options
that neatly organize your recent viewing history, what's on Live TV, what you
might like to watch next, and the latest movies, TV shows, apps and games from
the LG Content Store. Now you can spend less time navigating and more time enjoying
the premium content that you and your family want, accessed right through the
television, thanks to LG's intuitive WebOS 4.0 user interface.
- Program Guide & My Channels: While watching TV, you can easily
other channels using the Program Guide or My Channels. The television's built-in
Program Guide gives you a weekly outlook of what's on TV and detailed
information about each program (when applicable). You can select a current
program to watch or schedule a future program to watch later. You can also
add channels you frequently watch to "My Channels" to easily check which
programs are airing on those channels.
- Application & Content Search: You can narrow down your online content
search by selecting which category you would like to search - All Apps,
My Apps, Premium Apps, Movies, TV Shows, and Games. You can also enter a
keyword search for content across multiple applications.
- Recents & Recommendations: The TV remembers and display
the most recent apps you've used for easier access. The TV also provides
instant recommendations for finding your favorite content and accessing
information about actors and characters on-screen, based on your viewing
- Input Selection: A dedicated Input button on the remote pulls up
an on-screen menu of your connected devices and gives you a live feed of
what's playing on each input as you scroll through them. Simply click on an
input to go directly to that source.
- Quick Settings: The Quick Settings Menu provides
quicker access to commonly used functions - such as Picture Mode, Aspect
Ratio, Sound Mode, Sound Out, Sleep Timer, and Network.
Netflix Recommended TV: Netflix Recommended TV is an
evaluation program recognizing TVs that offer better performance, easier app
access, and new features that make for a better smart TV. When you see the
Netflix Recommended TV logo, it means the TV has passed a rigorous evaluation
process based on criteria that Netflix members care about the most. The TV comes
with the latest version of Netflix with newest features. It offers easier and
faster access to Netflix (including a dedicated button on the remote), quicker playback and start times, and allows you to
resume the Netflix app from where you left it.
Gallery Mode: The Gallery mode turns the TV into a digital
picture frame, displaying pre-downloaded artwork and even your own USB
downloaded picture files (JPEG format only). You choose one piece of artwork or
begin a slide-show.
Closed Captions & Audio Guidance: The LG OLED TV offers Close Captions
and Voice Guidance for the hearing and visually impaired. The TV provides Analog
Closed Captions and Digital Closed Captions for the hearing impaired. You can
also activate Voice Guidance, which describes when you change channels or
inputs, adjust the volume up or down, and make changes in the menu settings.
Parental Control: Parental Control can be used to block
specific channels, ratings, and other viewing sources (external input and
The Parental Control Function is used to block program viewing based on the
ratings sent by the broadcasting station. The default setting is to allow all
programs to be viewed. Viewing can be blocked by choosing the type of the
program and the categories. It is also possible block a specific channel. The
Parental Control function is protected by a 4-digit user password.
Energy Saving Feature: The Energy Saving feature helps to
save electric power by adjusting the screen brightness; you can select from six
modes - Auto, Minimum, Medium, Maximum, Screen Off, or Off.
On/Off & Sleep Timers: You can program the television to
turn On and turn Off at a certain time. You can set the On and Off timer to
Daily, Mon-Fri, Mon-Sat, Sat-Sun, or Once. You can also set the input, channel,
and volume level for the On Timer. If you do not press any button within 2 hours
after the TV turns on with the On Timer, the TV will automatically revert back
to standby mode. The Sleep Timer turns the TV off at the preset time (10, 20,
30, 60, 90, 120, 180, or 240 minutes).
Built-in Customer Support: The LG Smart TV offers
built-in customer support to help your learn functions and diagnose problems.
- On-Screen User Guide: The TV offers a built-in,
on-screen User Guide to help you learn how to use your new TV.
- Picture/Sound Tests: This customer support function
executes picture and sound tests to make sure you have the TV properly
- LG Remote TV Service: LG Remote TV Service can allow LG
Customer Service to help you perform menu actions and resolve many problems
remotely. To use this feature make sure your TV is connected to the
Software Update: You can update the TV with the latest
software to enhance the product operation and/or add new features via the TV's
network connection. Visit LG's
Support Site for the
latest firmware/software updates.
Pedestal Stand: The TV is shipped with the pedestal stand
unattached; assembly is required using the supplied hardware. The television
weighs 55.9 lbs with the stand. The TV does not swivel.
Wall Mounting: The TV has four threaded inserts on the back
for use with an optional wall-mount bracket. The spacing of the mounting holes
is 300mm (h) x 200mm (v). The threaded inserts require 6mm machine screws (not
supplied). The television weighs 46.2 lbs without the stand.
Ventilation Requirements: When mounting the TV on the stand
or a wall (with optional bracket) leave 4" of clearance on each side of the
television and 4" above/below the television for adequate ventilation.
Attached AC Power Cord: The television features an attached
5' AC power cord. The power cord is fitted with a right-angle AC plug that sits
0.9375" from the wall.
