Klipsch Bar 40

Powered sound bar with wireless subwoofer and Bluetooth®

Item # 714BAR40

This bar/sub combo is an affordable and attractive way to achieve better TV sound.

This bar/sub combo is an affordable and attractive way to achieve better TV sound.

California customers:
Please click here for your Proposition 65 warning.

Need help?
Contact our Virginia-based experts.
Discontinued item
4 questions - 13 answers

Item # 714BAR40

Need help?
Contact our Virginia-based experts.

About the Klipsch Bar 40

Genuine Klipsch sound at a great price

With wraparound grille cloth and wooden endcaps, the Bar 40 has an attractive, low-profile design that will fit easily into your home's décor. But this sound bar has more going for it than just good looks — it's a Klipsch, after all. And proudly so — they've exposed their signature Tractrix® horn-loaded tweeters at each end to hint at what's under the hood.

Genuine Klipsch sound at a great price

With wraparound grille cloth and wooden endcaps, the Bar 40 has an attractive, low-profile design that will fit easily into your home's décor. But this sound bar has more going for it than just good looks — it's a Klipsch, after all. And proudly so — they've exposed their signature Tractrix® horn-loaded tweeters at each end to hint at what's under the hood.

Klipsch Bar 40

The Bar 40 also comes with a wireless subwoofer in an attractive wooden enclosure. The sub's 6-1/2" down-firing driver will add that extra bit of low-end oomph to music and movie effects. And the included remote offers independent control of the sub, so you can dial in the level that's exactly right for you.

There are also some sound-optimizing EQ presets for enhanced dialogue and virtual surround sound. Try night mode if you are worried about disturbing the neighbors — it reduces bass and tailors overall output so you can follow what's going on, even at lower volumes.

Easy, flexible setup

This sleek sound bar connects to your TV with one cable and looks great whether it's wall-mounted or sitting on a stand. And that included wireless sub can be placed pretty much anywhere in the room. It just needs to be within about 30 feet of the sound bar and in the general vicinity of a power outlet.

Bluetooth streaming

Whether you want to stream your favorite Spotify® playlist, shuffle all your Pandora® stations, or listen to your downloaded podcasts and audiobooks, this sound bar has you covered with Bluetooth built in.

Download the latest firmware update to improve your Bar 40's performance and connectivity.


Product highlights:

  • 2.1-channel sound bar and subwoofer system with premium wooden enclosures
Sound bar:
  • two-channel sound bar with 4 built-in speakers
    • two 3/4" textile dome tweeters mated to Tractrix Horns for wide dispersion
    • two 3" oval fiber-composite midrange drivers
  • wood acoustic suspension (sealed) enclosure
  • ideal for wall-mounting beneath a flat-panel TV or placing on a TV stand
  • built-in Bluetooth for wireless music streaming from compatible smartphones, tablets, and computers
  • Dolby® Digital decoding
  • virtual surround sound mode for a more immersive listening experience
  • dialogue mode for enhanced vocal clarity
  • 40-1/8"W x 3"H x 3-7/16"D
  • 6-1/2" fiber-composite cone woofer in wood enclosure
  • syncs wirelessly with sound bar
  • 9-1/2"W x 13-3/16"H x 10-7/16"D
Connections and general info:
  • HDMI ARC connection
  • optical digital audio input
  • 1 minijack analog audio input
  • 1 subwoofer output for adding second sub or replacing included wireless sub with a wired sub
  • keyhole brackets for wall-mounting (wall template included)
  • remote control with independent subwoofer volume adjustment
  • warranty: 3 years for drivers and cabinets, 1 year for electronics
  • Our 60-day money-back guarantee
  • MFR # 1064247

No A/V receiver required.

What's in the box:

  • Active soundbar speaker
  • Wireless powered sub
  • Two 6.5' AC power cords
  • Remote control
  • 2 "AA" batteries
  • 58" HDMI cable
  • 2 Wall-mount brackets
  • 2 Screws
  • 2 Self-adhesive cork pads
  • Wall-mount template
  • Instruction Booklet
  • Warranty Information

Customer reviews

Loading reviews...

Klipsch Bar 40 reviews

Average review:

20 reviews

Thanks for submitting your review

Filter by rating

Customer photos

Sort reviews

Sort by:
Items per page:
View page:

Verified customer (What's this?)
Verified employee purchase (What's this?)



Crutchfield response

<< >>

More details on the Klipsch Bar 40

Stacey B.

Features & specs

Design Bar
Amplification Self-powered
Separate Subwoofer Yes
Wireless Surrounds No
Number Of Channels 2.1
Surround Formats
Dolby Digital Yes
Dolby Atmos No
Audio Enhancements
Dialogue Enhancement Yes
Auto Volume Night
Virtual Surround Virtual Surround
Audio Connections
Optical Digital Inputs 1
Coaxial Digital Inputs None
HDMI ARC Input Yes
HDMI eARC Input No
3.5mm Stereo Analog Inputs 1
RCA Stereo Analog Inputs None
USB Type-A Input No
Subwoofer Output Mono RCA
Audio Specs
Tweeter 0.75" Tractrix Horn (2)
Midrange None
Woofer 3" Cone (2)
Subwoofer Driver 6.5"
Enclosure Sealed(bar)/Ported(sub)
System Frequency Response Not Given
Sound Bar RMS Power Not given
Subwoofer RMS Power Not given
Video Connections
HDMI Inputs None
HDMI Outputs 1
Video Specs
HDMI Video Pass-through Resolution N/A
HDR Video Compatible No
Includes Remote Yes
Voice Control No
Control by App No
Remote IR Passthrough No
Learns TV Remote Yes
Audio Streaming
Bluetooth Connectivity Built-in
Apple AirPlay No
Chromecast built-in No
Files on Your Network No
Wi-Fi Networking
Built-in Wi-Fi Version None
Bands N/A
Other Info
Wall-mountable Yes
Mounting Bracket Included Yes
Sound Bar Size (inches) 3H x 40-1/8W x 3-7/16D
Sound Bar Weight Not Given
Subwoofer Size (inches) 13-3/16H x 9-1/2W x 10-7/16D
Subwoofer Weight Not Given
Speaker Parts Warranty 3 Years
Speaker Labor Warranty 3 Years
Amplifier Parts Warranty 1 Year
Amplifier Labor Warranty 1 Year

Product Research


Active Soundbar Speaker: The Klipsch BAR 40 includes a high performance 2-channel active soundbar speaker with dedicated left and right channels for true stereo imaging. The left and right front channels each consist of a 3" fiber composite woofer and a 0.75" LTS aluminum dome tweeter paired with 90° x 90° Tractrix horn. The tweeters and woofers are bi-amplified and utilize a DSP-controlled crossover network.

  • LTS Aluminum Tweeter w/ Tractrix Horns: The two 0.75" LTS soft-dome tweeters with 90° x 90° Tractrix horns deliver crisp highs. The Linear Travel Suspension (LTS) soft-dome tweeters minimize distortion for enhanced, detailed performances; while the 90° x 90° Tractrix horn technology offers controlled dispersion that directs the sound more effectively at the listening area.
  • Fiber Composite Woofers: The two 3" fiber composite woofers deliver clear midrange, detailed vocals, and a dynamic range to complete the soundbar's enhanced audio performance.

Wireless Powered Subwoofer: The Klipsch BAR 40 includes a wireless powered subwoofer you can place practically anywhere in the room for deep, room-filling bass response. The wireless powered sub houses a down-firing 6.5" fiber composite woofer with rubber surround inside a bass reflex enclosure with a down-firing power and driven by a built-in amplifier. Wireless 2.4 GHz technology automatically connects the soundbar and the subwoofer together and has a wireless range up to 50'. You can control the output level of the sub from the included IR remote. There is also a mono-RCA subwoofer output meaning you can add a second powered subwoofer to your setup or simply replace the included wireless powered sub with a powered subwoofer of your choice.

Dolby Digital Decoding + Surround Modes: Built-in Dolby Digital (up to 5.1ch) decoding with four selectable Sound modes (Surround, Dialog, Night, or Off) enables a powerful cinema experience. The Surround mode gives you an immersive virtual surround sound effect without the additional rear speakers and wires. When the Sound mode is set to Off, the soundbar will playback in 2ch stereo. Dialog mode increases dialogue volume for enhanced vocal clarity without increasing ambient sounds. Night mode adjusts the dynamic range for quieter listening environments.

HDMI ARC Output: The Klipsch BAR 40 features one HDMI ARC output to connect the soundbar to your TV's HDMI ARC input. The BAR 40's HDMI ARC output allows audio from your TV to be sent through the soundbar system. The HDMI ARC output supports Dolby Digital (5.1ch) and PCM (2ch).

  • Some televisions will only pass 2ch PCM through the ARC-enabled HDMI input from devices connected to the TV via HDMI or analog, and will only pass Dolby Digital via the TV's built-in tuner, network apps, or USB.
  • The HDMI ARC Output only supports audio transmission and does not support any type of video signals.

Digital & Analog Inputs: In addition to HDMI ARC connectivity, the Klipsch BAR 40 is outfitted with both digital and analog audio inputs. The optical (toslink) digital input supports Dolby Digital (5.1ch) and PCM (2ch). The BAR 40 is also equipped with an analog Aux (3.5mm) input for connecting legacy source devices.

Note: The optical digital output terminals of many flat-panel TVs only send an audio signal in 5.1ch when receiving Dolby Digital surround sound from the TV's built-in tuner, network connection, or connected USB device; and will output only 2ch stereo from sources connected to the TV via HDMI, or RCA (like your Blue-ray player or satellite/cable box).

Built-In Bluetooth: The Klipsch BAR 40 features built-in Bluetooth with support for A2DP and AVRCP which allows you to wirelessly stream and control audio from your Bluetooth-enabled source device (such as your TV, smartphone, tablet, or computer) to the soundbar system. The BAR 40 supports Bluetooth's standard SBC audio codec (not compatible with Dolby Digital, AAC, or aptX). The soundbar's remote can control the Volume Up/Down and Play/Pause functions of your Bluetooth source device (in some cases you may need to still use your Bluetooth source device's volume control). You can pair multiple devices (up to 8) with the soundbar, but only one device can be used at a time.

  • The soundbar system does not support Fast Forward/Rewind, Previous/Next Track, Random/Repeat or Music Browsing functions. You'll still need to use your Bluetooth source device to control these playback and search functions.
  • The soundbar and your connected TV will not display song/artist/album info. This will still need to be done from your Bluetooth source device.
  • The BAR 40 does not support Bluetooth hands-free communication for making or answering phone calls.
  • Due to the differences in Bluetooth technology, some Bluetooth enabled devices may be incompatible, function improperly, or may not support all features when used with the soundbar system.

Remote Control: The included IR remote control provides full wireless operation of the soundbar speaker system. It features an automatically-activated LED backlight, so its easy to use in the dark when watching your favorite movie. You can also program the BAR 40's Volume Up/Down and Mute functions into your existing TV or satellite/cable box remote for further ease-of-operation.

  • Many newer TVs are coming with RF remotes and don't offer IR functionality. In this case, you would not be able to program the soundbar and TV or satellite/cable box remote to work together.
  • The BAR 40 does not support HDMI-CEC.

Mounting Options: Measuring at only 3" tall, the soundbar speaker easily fits below your TV regardless if you are placing it on a table-top or mounting it on a wall. The soundbar includes two wall-mount brackets and comes with a wall-mount template (wall-mount screws not provided). Because the powered sub is wireless, it can be positioned almost anywhere up to 50' from the soundbar speaker. It is recommended that the subwoofer be positioned on the same wall as the soundbar.

Power Requirements: Both, the active soundbar & wireless powered sub, will require AC power. Each one comes with a detachable 6.5' AC power cord that will need to be plugged into an AC power outlet or surge protector (sold separately - see Accessories Tab).

Loading accessories...

Customer Q&A

4 questions already asked

Can this setup be used in conjunction with a receiver and be added to an already existing klipsch wired surround sound set?
[ JAY  Oct 29, 2020 ]
2 answers
Hard to say without being there.
[ ROBERT  Oct 30, 2020 ]
I don't because i use it as it says, directly in my master bedroom only only with my TV.
[ Tommy  Oct 29, 2020 ]
Does the Soundbar accept power and volume commands from TV via HDMI-CEC?
[ Dave  Sep 10, 2020 ]
2 answers
I am no expert.. Hard to say.
[ ROBERT  Oct 30, 2020 ]
It does not connect to my VISIO 4k TV. It turns on automatically, but I have to use the Klipsch remote to adjust. The Optical Cable connection is the only way to go. All others generate a bad hummmm. Beware.
[ James  Sep 10, 2020 ]
the sub on occasion makes popping sounds..when I unplug the sub for a day or two its fine then it happens all over there a fix for this?
[ mikey  Apr 01, 2020 ]
2 answers
Yes, and on numerous occasions it will lock up and not do anything. I have to unplug it for 30 minutes, then power it up again.
[ Mark  Apr 05, 2020 ]
Your wall outlet may have dirty power or voltage fluctuations. Sometimes weird things happen with power inconsistencies. I would suggest a wall outlet tap with a minimum of 1700 joules.
[ Brett  Apr 02, 2020 ]
I have Klipsch bar 40 and when I watch TV the subwoofer doesn't work. Does it have the capability for the sub to work when watching TV?
[ kiki  Jan 03, 2020 ]
7 answers
I have the same problem and have worked with Crutchfield they are very good at helping you rectify your situationEnter an answer to this question.
[ vinny  Jan 03, 2020 ]
Night mode* make sure it's not in night mode.
[ Kasey St.  Jan 03, 2020 ]
Yes it does. Make sure it's not in. Ought mode, the sub is turned off on night mode. Also make sure the sub is turned up. You can manually adjust the subwoofers volume with the remote
[ Kasey St.  Jan 03, 2020 ]
Certainly, should function with TV. Follow Installation instructions.
[ CARY  Jan 03, 2020 ]
Yes it should work mine works with my Samsung, check to see if you have the blue lite on back of sub is on if not you have to connect it and turn off the tv speakers read the instructions to connect the sub.
[ Tommy  Jan 03, 2020 ]
It should. Did you make the connection between the sound bar and the subwoofer? I connect mine via optical cable directly from my cable box and it works just fine. Crutchfield support can help with set-up.
[ Daniel  Jan 03, 2020 ]
My sub works with TV. So I say yes. I had trouble hooking up FO cord( I have small TV, I am connected via Bluetooth. Check blue light on sub woofer back. It should be on when working. If all else fails. Hit reset or default on units and start again.) Enter
[ Lee  Jan 03, 2020 ]
