3-Channel Passive LCR Soundbar Speaker: The Klipsch Reference Premiere
RP-440D SB is a 3-channel passive LCR soundbar speaker. It combines the three
front channels (Left/Center/Right) into a single speaker cabinet - featuring
three horn-loaded 1" titanium dome Linear Travel Suspension (LTS) tweeters and
four 3.5" copper-spun Cerametallic woofers.
- The center-channel section features a single horn-loaded 1" titanium
dome Linear Travel Suspension (LTS) tweeter and two 3.5" copper-spun
- The left & right channels each feature a single horn-loaded 1" titanium
dome Linear Travel Suspension (LTS) tweeter and one 3.5" copper-spun
Horn-Loaded Tweeter: The Klipsch Reference Premiere RP-440D SB
features proprietary Tractrix Horn technology coupled with a Linear Travel
Suspension (LTS) titanium tweeter to produce clean, natural high frequencies.
- 90° x 90° Tractrix Horn: The Tractrix Horn's
geometry helps to improve high-frequency response and extension, while
enhancing imaging and dynamics. The 90°
x 90° Tractrix Horn also focuses the high
frequency sounds towards the listening area, for the cleanest, most natural
- LTS Tweeter: Behind the Tractrix Horn lies a 1"
titanium tweeter with a Linear Travel Suspension (LTS) for open, natural,
sound. The Linear Travel Suspension (LTS) minimizes distortion for enhanced,
Spun-Copper Cerametallic Woofers: The four 3.5" woofers of
the RP-440D SB passive soundbar speaker features Klipsch's distinctive,
spun-copper Cerametallic material. Made with an anodized aluminum, this cone is
strong and dent resistant. The anodizing process converts its inner and outer
surfaces to ceramic. The outcome is a rigid cone with superb damping
characteristics that will not flex or resonate at frequencies within the
woofer's operating range. The woofers also employ a rubber surround for added
Bass Reflex Enclosure: The horn-loaded tweeters and
spun-copper Cerametallic woofers are housed in a bass reflex enclosure with
three down-firing ports for greater efficiency and better bass performance. The
speaker enclosure is made of ABS and features a matte black painted finish.
Wrap-Around Magnetic Grille: The Klipsch Reference Premiere
series RP-440D SB passive soundbar speaker comes with a removable, wrap-around
cloth magnetic grille which easily snaps into place over the ABS enclosure.
Spring-Post Terminals: The RP-440D SB is equipped with
a set of spring-post terminals for each channel to connect to your AV receiver's
Front Left, Front Right, and Center speaker output terminals. These spring-post
terminals will accept bare speaker wire from 16AWG to 12AWG. Due to
the position of the spring-post terminals they will not accept banana plugs or
Mounting Options: The RP-440D SB passive soundbar speaker can be
mounted horizontally on a wall or table-top. The included wall-bracket and dual
four-way keyhole slots allow for easy, tight-to-the-wall mounting (mounting
screws not included). The included glass base provides a
table-top solution for placing the speaker on a stand, table, or shelf (the base
attaches to the speaker using the two included screws).
- Wall-Mount Dimensions:
- Speaker: 42.0" (w) x 6.0" (h) x 2.5" (d)
- Bracket: 38.0625" (w) x 2.0" (h) x 0.5" (d)
- Table-Top Dimensions:
- Speaker: 42.0" (w) x 0" (h) x 5.0625" (d)
- Footprint: 12.0625" (w) x 5.0625" (d)
