About the Sound Ordnance™ B-17

Sound Ordnance designed the B-17 bandpass subwoofer to be the bass fortress in your vehicle's sound system. Its 12" polypropylene woofer is mounted inside a sturdy enclosure, between an airtight sealed chamber and a second chamber that boasts a generous slot port for massive air movement. This bandpass design increases speaker efficiency, for impressive bass firepower from a relatively small box. Best of all, you can watch the woofer swing into action behind the clear acrylic front window.
The heavy-duty speaker terminals provide excellent connections, and the rugged black carpet cover with the Sound Ordnance logo lets your competition know you mean business. And you'll have extra peace of mind with Sound Ordnance's 3-year warranty behind your investment. Add a suitable amplifier, mount the system safely in your trunk or cargo area, and get ready for a bass barrage.
Need an amp for this sub? Check out this Crutchfield-approved bass package.
Product highlights:
- bandpass enclosure with 12" polypropylene woofer
- 5/8" medium-density fiberboard construction
- black carpet covering
- clear acrylic front window
- 4-ohm impedance
- recommended power: 50-250 watts RMS (500 watts peak power)
- frequency response: 45-150 Hz
- sensitivity: 89 dB
- 15-5/8"W x 15-1/8"H x 15-1/4"D1 x 10-1/4"D2
- warranty: 3 years
- Our 60-day money-back guarantee
- MFR # B-17
What's in the box:
Sound Ordnance™ B-17 owner's manual
- Bandpass enclosure loaded with one 12" subwoofer
- Owner's manual
- Warranty information
Reviews
Customer reviews
Loading reviews...
Sound Ordnance™ B-17 reviews
Average review:
Thanks for submitting your review
Customer photos
This review was collected as part of a promotion
Pros:
Cons:
More details on the Sound Ordnance™ B-17

Features & specs
General | ||
---|---|---|
Woofer Size (inches) | 12 | |
Speakers Per Box | 1 | |
Woofer Material | Polypropylene | |
Enclosure Type | Bandpass | |
Color | Black | |
Pieces in System | 1 | |
Width (inches) | 15-5/8 | |
Height (inches) | 15-1/8 | |
Depth (inches) | 15-1/4 | |
Connector Type | Spring post | |
Frequency Response | 45-150 Hz | |
Power Range (Watts RMS) | 250 | |
Maximum Wattage | 500 | |
Sensitivity | 89 dB | |
Impedance | 4 ohms | |
Parts Warranty | 3 Years | |
Labor Warranty | 3 Years |
Product Research
Features
Materials: The Sound Ordnance B-17 is a pre-loaded bandpass style enclosure with a single 12" subwoofer. It is constructed of 5/8" MDF (medium-density fiberboard), covered in black carpet. It also features a clear acrylic front window for viewing the subwoofer. The subwoofer features a polypropylene cone with rubber surround, a 2" voice coil, and a heavy-gauge stamped steel basket.
Box Design: The enclosure has a sealed chamber in front of the subwoofer, and a vented chamber behind. The front-firing slot port to the right of the sub is 1-1/4" wide and 14" high. The box has a total of 1.46 cubic feet of airspace.
Terminals: The B-17 is equipped with a single set of spring-post speaker terminals, mounted in the rear panel. The spring terminals will accept bare wire up to 10 gauge, pin connectors, and single banana plugs, but are spaced too far apart for dual banana plugs.
Brackets: Brackets for securing the enclosure to your vehicle are recommended.
Specifications:
- Frequency Response: 45-150 Hz
- Power Handling: Up to 250 watts RMS, 500 watts peak
- Sensitivity: 89 dB
- Dimensions:
- Width: 15-5/8"
- Height: 15-1/8"
- Depth (bottom): 18-1/4"
- Depth (top): 10-1/4"
Loading accessories...
Customer Q&A
5 questions already asked
Loading articles...
Great sound big bass. Only had it for a few days and extremely happy so far. Far exceeded my expectations. If you want a subwoofer that can really perform and looks great doing it this is the one.
