iDatalink KIT-C200 Dash and Wiring Kit

Install an iDatalink-ready stereo and retain the steering wheel audio controls and factory amp in select 2015-17 Chrysler 200 models

4 Reviews

Find what fits your vehicle






Can't find your exact vehicle?

Item # 794KC200

In Stock

Add to Cart

Earn up to 130 Rewards points

Ask an expert

Our VA-based experts can help.

1.888.955.6000

Chat

Overview

Your Chrysler 200 is a great car, but the factory radio leaves something to be desired. The KIT-C200 dash and wiring kit allows you to install an iDatalink-ready car stereo in the dash panel, while maintaining your climate controls, USB port, backup camera, parking assist, and other features. You'll also need iDatalink's Maestro ADS-MRR module (not included) for this installation.

iDatalink KIT-C200

Your Chrysler 200 is a great car, but the factory radio leaves something to be desired. The KIT-C200 dash and wiring kit allows you to install an iDatalink-ready car stereo in the dash panel, while maintaining your climate controls, USB port, backup camera, parking assist, and other features. You'll also need iDatalink's Maestro ADS-MRR module (not included) for this installation.

Your Chrysler features

The included wiring harness lets you keep your factory amplifier's Premium Audio functions (if equipped), as well as your secondary display's functions including audio information, hands-free info display, and navigation information. Your new radio will also display gauge information, parking assist distance, and other vehicle information.

The harness allows you to keep your steering wheel audio controls. The kit includes metal brackets for radio installation, and includes a button bar panel to fill the gap left when you remove the Chrysler radio without the button bar.

Note: Most vehicles will require additional installation parts — please identify your vehicle if you haven’t done so. You can also call an Advisor for more information.

Product Highlights:

  • allows installation of new iDatalink-ready receiver in select Chrysler 200 vehicles
  • requires the Maestro ADS-MRR module (not included)
  • retains the use of your steering wheel audio controls, factory amp, backup cam, and USB port
  • retains your secondary display (with phone call, audio, and navigation information)
  • includes metal brackets for radio installation and blank button panel for use in vehicles without the factory button bar
  • displays engine performance and other data on new car stereo's touchscreen
  • warranty: 1 year
  • Our 60-day money-back guarantee

What's in the Box:

  • Dash-panel
  • Radio bracket
  • 2 ISO-brackets
  • Vehicle harness
  • USB adapter cable
  • OBDII harness
  • 4 Screws
  • Quick Start Guide

Everything works great! Love this product and its easy to assemble. The idatalink offers some cool features as well!!

Terrelle Moss, Modesto, CA

Reviews

iDatalink KIT-C200 Dash and Wiring Kit Reviews

Average Customer Review(s):

(4 Reviews)

iDatalink KIT-C200 Dash and Wiring Kit

Crutchfield customer from Pensacola, FL on 1/8/2019

2015 Chrysler 200
Crutchfield Customer Review (What's this?)

Works and looks perfect

Pros:

Cons:

Great product

Terrelle Moss from Modesto, CA on 12/18/2018

2015 Chrysler 200
Crutchfield Customer Review (What's this?)

Everything works great! Love this product and its easy to assemble. The idatalink offers some cool features as well!!

Pros: Everything

Cons: None

iDatalink KIT-C200 Dash and Wiring Kit

marcus from Woodbridge, VA on 12/6/2018

2015 Chrysler 200
Crutchfield Customer Review (What's this?)

Great look...easy install

Pros:

Cons:

2015 chrysler 200 dash kit for double din

nick from Fresno, CA on 9/16/2018

2015 Chrysler 200
Crutchfield Customer Review (What's this?)

hey my recent purchase from crutchfeild was awesome choice for my ride i got a 2015 chrysler 200 sport and bought a idatalink c200 dash kit for my pioneer head unit and it came out perfect very clean with new bezel kit had everything i needed for install all my friends like my new stereo thanks again crutchfeild

Pros: good no flaws

Cons: good no flaws

Details

Hands-on research

Product Research

Features

Vehicle Compatibility: The iDatalink Maestro KIT-C200 consists of an OEM integration dash kit and vehicle harness designed specifically for 2015-2017 Chrysler 200(s) with or without a factory amplified audio system. The KIT-C200 lets you replace the factory radio of your 2015-2017 Chrysler 200 with an iDatalink Serial Port compatible head unit using the Maestro RR Car Radio Replacement Interface module (794ADSMRR, sold separately).

Make Model Year
Chrysler 200 (with factory amplifier 2015-2017
200 (without factory amplifier) 2015-2017
Note: The iDatalink Maestro KIT-C200 requires the purchase of the iDatalink Maestro RR (794ADSMRR) and the download of a vehicle specific firmware from iDatalink's Weblink site using a Windows PC (not compatible with Mac).

OEM Grade Fit & Finish Kit: The KIT-C200 OEM integration kit features a factory grade fit & finish to match the contour and color of your vehicle's dash. It will fit a double-DIN (4") size aftermarket head unit.

Vehicle Harness: The iDatalink Maestro KIT-C200 includes a vehicle harness which inserts into the iDatalink Maestro RR interface module (sold separately), plugs into your vehicle's factory radio harness, and hardwires to the harness of your new aftermarket double-DIN receiver. The installation harness contains one large Molex connector which plugs into your vehicle's factory radio harness. On the other end of the harness are four multi-pin connectors which plug into the Maestro RR interface module (sold separately). The harness also includes a composite video connector which plugs into your aftermarket head unit's rear-panel camera input in order to retain your vehicle's factory backup camera. In addition, a USB adapter harness retains your vehicle's factory USB port through your aftermarket receiver's rear-panel USB port.

Retained Features: The follow factory features (if applicable) are retained when replacing your aftermarket head unit with a compatible iDatalink Serial Port head unit from Kenwood, JVC, Alpine, or Pioneer using the Maestro RR Car Radio Replacement Interface module and KIT-C200 installation kit.

  • Steering Wheel Controls (with two function capability)
  • Factory Amplifier (with fader control, DSP settings, and gain adjustment)
  • Backup Camera
  • Secondary Vehicle Display (with Hands-Free, Audio, and Navigation Info)

Extra Features: The follow extra features are retained when replacing your aftermarket head unit with a compatible iDatalink Serial Port head unit from Kenwood, JVC, Pioneer, or Alpine using the Maestro RR Car Radio Replacement Interface module and KIT-C200 installation kit.

  • Selectable Performance Gauges
  • Park Assist (with distant display on-screen & warning chimes)
  • Tire Pressure Display
  • Battery Voltage Display
  • Read/Reset Check Engine Codes
  • Door Open Status and Warning

Navigation Outputs: To make installing an aftermarket navigation receiver easier; the KIT-C200 provides Parking Brake, Foot Brake, Reverse Gear, & VSS (Vehicle Speed Sense) output wires.
