About the Fusion SG-F882W
Signature style and innovation
Signature style and innovation
You can count on FUSION's SG-F882W marine speakers to deliver impactful sound, thanks to power handling up to 130 watts RMS and innovative acoustic design elements. Designed to handle the extremes of a marine environment, FUSION's Signature Series makes the perfect captain's companion.
CURV cone technology and more
The boat life is unkind to speakers. Heat, humidity, salt, spray, and high-pressure hose-downs at the dock can shorten the life of any speaker that's not built for life on the water. Fusion's Signature Series 3 marine marine speakers meet the toughest standards for UV stability and salt/fog resistance. But just because they're tough doesn't mean they're not sensitive. Fusion's CURV cone design, a woven composite fiber that's heat-pressed into a light yet super-strong shape, delivers awesome sound. Plus, treated silk dome tweeters, brawny voice coils, and sealed componentry ensure impressive performance for your favorite songs of the sea.
What a warranty
The water-resistant design complies with high standards for UV stability and salt/fog resistance, so these speakers will perform at their peak even after prolonged exposure to the elements. As part of FUSION's True Marine™ line, these Signature Series 3 marine speakers are even backed by a 3-year warranty.
Product highlights:
- 8.8" 2-way marine speakers (pair)
- specially formed CURV woven fiber cone
- treated silk dome tweeter
- UV-resistant grilles
- sealed, water-resistant construction
- complies with ISO12216 and IP65 standards for water and weather resistance
Specs:
- handles up to 130 watts RMS (330 watts peak power)
- frequency response: 50-22,000 Hz
- sensitivity: 91 dB
- impedance: 4 ohms
- cutout diameter: 7.286"
- frame diameter: 9.085"
- mounting depth: 4.075"
- warranty: 3 years
- Our 60-day money-back guarantee
- MFR # 010-02434-00
What's in the box:
Fusion SG-F882W owner's manual
- Two 2-way Marine speakers
- 2 White grilles
- Twelve 1-1/2" Stainless steel screws
- Installation instructions (English/ French/ Italian/ German/ Spanish/ Portuguese/ Danish/ Dutch/ Finnish/ Norwegian/ Swedish/ Chinese)
- Safety and Product information
- Template
Reviews
Customer reviews
Loading reviews...
Thanks for submitting your review
Customer photos
This review was collected as part of a promotion
Pros:
Cons:
More details on the Fusion SG-F882W
Features & specs
| General | ||
|---|---|---|
| Speaker Size | 8.8 | |
| Design | 2-way | |
| Tweeter Design | Dome | |
| Tweeter Composition | Silk | |
| Woofer Composition | Woven Fiber Composite | |
| Woofer Surround | Rubber | |
| Parts Warranty | 3 Years | |
| Labor Warranty | 3 Years | |
| Specifications | ||
| Sensitivity |
91 dB at 1 watt | |
| Frequency Response | 50 - 20k Hz | |
| Max RMS Power Handling | 130 | |
| Peak Power Handling (Watts) | 330 | |
| Impedance (Ohms) | 4 | |
| Top-mount Depth (Inches) | 4 1/8 | |
| Bottom-mount Depth (Inches) | N/A | |
| Cutout Diameter or Length (inches) | 7 5/16 | |
| Bolt Circle | 7.943 | |
Product Research
Features
True Marine: Fusion describes these speakers as True Marine Accredited, meaning they are designed specifically for the marine environment and backed by Fusion's three year warranty. The speakers are tested to ensure they meet or surpass IP65 standards (waterproof and dustproof on the front of the speakers) and comply with ISO12216 standards for watertightness in areas II, III and IV of the vessel.
Curv Woofer Cone: CURV technology incorporates a woven fiber composite, heat pressed to form a lighter and stronger cone. This improves sound definition and increases output, along with creating better resistance to the marine environment.
Sealed Crossover: The crossover is sealed to provide full protection from the harsh marine environment.
Compass Safe Distance: The minimum distance the speakers should be mounted from a compass to avoid any interference is listed in the manual as 13½ feet.
Speaker Terminals: Each speaker has a six inch length of speaker wire attached, terminated with male quick slides (0.25" positive and 0.187" negative).
Stainless Steel Hardware: The provided mounting screws are stainless steel.
Enclosure: Enclosure recommendations are given in the installation manual (an enclosure is not necessary, the speakers will operate in free-air):
- Sealed: 0.78 ft³
- Ported: 1.23 ft³ (with a 3" diameter 6.7" long port tube)
The Fusion SG-F882W replaces these items
- specially formed CURV woven fiber cone
- treated silk dome tweeter
- handles up to 130 watts RMS (330 watts peak power)
