About the SVS SB-2000
A sub that music lovers and movie enthusiasts can agree on
A sub that music lovers and movie enthusiasts can agree on
I've always found it interesting how often subwoofers get typecast as being right for one application, but not another. "Ported-box subwoofers play really loud and are unbeatable for adding boom to action movies," some people say. Others claim, "Only a sealed-box sub gives me that tight, controlled bass I need for my music." Is it too much to ask to have one sub that can easily plumb the depths of bombastic Hollywood soundtracks, yet also provide pitch-perfect, lightning-quick low frequencies that bring out the best in our music?
SVS doesn't think so. Say hello to the SVS SB-2000 — a subwoofer that gives you the best of both worlds. Its high-output 12" aluminum-cone woofer and cool-running 500-watt Class D amplifier combine to deliver stunningly accurate bass at prodigious levels all the way down to 19 Hz. And that's something any music or movie buff can really get behind.
The SB-2000 delivers tight, powerful bass that will thrill home theater enthusiasts and music lovers alike. (Shown in Piano Gloss Black.)
Deep, powerful, and precise bass for all occasions
The SB-2000 has a built-in Digital Signal Processor (DSP) that dynamically controls amplifier power to ensure you hear deep, low-distortion bass no matter how loud your music and movies get. It also uses an acoustic suspension (sealed) cabinet design with no hole or port to interact with your room, so you'll experience tight, accurate response from this sub for added depth and dimension with all of your entertainment sources.
And since the driver creates some serious pressure inside the closed cabinet, SVS builds the SB-2000 strong and rigid to eliminate any cabinet flex and keep the bass clean.
Easy system integration
Line-level inputs and outputs let you easily connect this sub to most audio systems. A Low Frequency Effects (LFE) input accepts the subwoofer connection from your A/V receiver. Its back-panel volume, crossover, and phase controls help you fine-tune the bass to ensure a perfect sonic match with your main speakers and your room.
The sub includes four conical rubber feet that reduce surface contact area to decrease the amount of vibrations transmitted to the floor. The SB-2000 makes an excellent addition to just about any stereo music or home theater setup.
"When we started carrying SVS subwoofers a few years back, I wanted to get a feel for their sonic capabilities, so I took home an SB-2000 for an audition in my home theater/music system. What I thought would be a brief visit turned into permanent residence. The SB-2000 replaced an ACI Titan subwoofer, which had anchored the sound of my system for nearly 20 years. In its day, the Titan was considered one of the best under-$1000 subs available.
I was immediately impressed by the SB-2000's extension and power with movie soundtracks. Despite its compact size, it really gets a grip on my 16' x 19' room. But what I really love about this sub is its taut, tuneful finesse with music. The SB-2000's low frequencies pair beautifully with my Dynaudio Excite X18s. It can be hard to find music with well recorded bass, but the polished Afro-pop of Fatoumata Diawara's Fenfo gives this sub a workout.”
— Steve Kindig, Crutchfield's senior home A/V editor
Who is SVS?
SVS was founded in 1998 by a group of audio enthusiasts seeking to develop a better alternative to the under-performing and over-priced subwoofers popular at the time. By leveraging advanced technology, using the highest quality components, and applying rigorous engineering and design principles, the SVS team has developed a line of high-performance, high-value audio products that bring music and movies to life with stunning realism.
- frequency response: 19-220 Hz (±3 dB)
- built-in Class D amplifier delivers 500 watts RMS of continuous power (1100 watts peak dynamic power)
- advanced DSP processor maintains control over the subwoofer at all drive levels for refined, low-distortion sound
- lightweight 12" aluminum woofer cone with powder-coated cast aluminum basket for high efficiency and low distortion
- acoustic suspension (sealed) cabinet design
- rear-mounted volume, crossover, phase, and power controls
- digital actuator control knobs for precise and noise-free adjustment
- continuously variable low-pass 50-160 Hz crossover with a disable (LFE) setting for connecting an A/V receiver
- continuously variable phase control (0-180°)
- main power on/off switch plus auto standby/on mode
- line-level/LFE RCA inputs
- filtered RCA line outputs (fixed 80 Hz, 12dB/octave high-pass)
- remote trigger input
- protective non-resonant steel mesh grille
- detachable 8-ft. power cord
- 14-1/4"W x 14-5/8"H x 17-1/8"D
- weight: 34.8 lbs.
- warranty: 5 years
- Our 60-day money-back guarantee
- MFR # SB-2000 BK Ash
What's in the box:
- Powered subwoofer
- 8' AC power cord
- Owner's Manual
- Quick Start Guide
SVS SB-2000 reviews
Thanks for submitting your review
More details on the SVS SB-2000
Features & specs
|Woofer Size (inches)||12|
|Low-Pass Crossover Freq||50-160 Hz|
|High-Pass Crossover Freq||80 Hz|
|Amplifier Output (watts)||500|
|Frequency Response||19-220 Hz|
|Speaker Parts Warranty||5 Years|
|Speaker Labor Warranty||5 Years|
|Amplifier Parts Warranty||5 Years|
|Amplifier Labor Warranty||5 Years|
12" High Output Woofer: The front-firing 12" high output woofer of the SVS SB-2000 powered subwoofer pumps out deep and powerful bass with low distortion, for smooth and accurate performance on music and movies soundtracks. The woofer features a lightweight 12" aluminum cone for enhanced sensitivity and transient response, an upgraded suspension for improved linearity and control, plus a long-excursion rubber surround for durability and long-life. It also incorporates FEA-optimized motor technology for low distortion, heavy-duty 2" voice coil for extreme power handling, and an extended pole piece that improves heat sink and thermal management properties.
STA-500D Sledge Amplifier: The SB-2000 powered subwoofer employs a Sledge STA-500D amplifier with efficient and cool-running Class D topology. The amplifier is conservatively rated at 500 watts RMS and 1000 watts Peak. This amp features a highly advanced DSP processor offering unmatched control over the subwoofer at all volume levels, for distortion free bass.
MDF Sealed Enclosure: The SVS SB-2000 powered subwoofer features a rigid MDF (Medium Density Fiberboard) cabinet with screw-in rubber feet and a non-resonant steel mesh grille to resist unwanted distortion caused by vibration. The enclosure is an acoustic suspension (sealed) design for tight, accurate bass response. The cabinet is elegantly finished in a premium black ash wood-grain vinyl or gloss piano-black lacquer, and fits with practically any décor.
Variable Controls: The SB-2000 subwoofer has simple and straightforward control options that make integrating the subwoofer into your listening environment an easy task. The control knobs are actually digital actuators for precise and noise-free adjustment.
- Volume Control: The Volume Control (Min/Max) affects how loud the subwoofer plays. It should be adjusted to match the output level of your loudspeakers.
- Low Pass Crossover: This Low Pass Crossover affects the
upper frequency limit of the powered sub. The control
range is 50-160 Hz, along with a "LFE" (disabled) setting. The slope of the low pass crossover is 12 dB/octave. For connection to a home theater receiver, the low pass should be set to "LFE" (disabled). For stereo receiver, it should be adjusted to blend with the natural roll-off frequency of your loudspeakers.
- Phase Control: The Phase Control (0-180°) delays the signal being processed through the amplifier. It should be adjusted to obtain the most coherent and stable soundstage and transition between your loudspeakers and the powered subwoofer.
Inputs & Outputs: Comprehensive and flexible connectivity options allow for easy set-up and integration into your home theater or stereo system.
- LFE/RCA Inputs: These unbalanced RCA inputs are used for line-level connection between your receiver and the powered sub. For a single mono connection to a home theater receiver, use the R/LFE input. For stereo receivers, use both the L/R inputs.
- RCA Outputs: These unbalanced RCA outputs are used in stereo applications to high pass the signal being sent to the loudspeaker amplifier. The line level outputs feature a fixed 80Hz, 12 dB/octave high-pass filter.
Placement Options: If possible, place the subwoofer near the front stage, for best blending with the front and center loudspeaker channels.
- Corner Placement: Corner placement will accommodate most rooms and will reduce the chances for encountering a null (an acoustic cancellation in the bass response) at the listening position. If your AV receiver equalizes the subwoofer channel during auto-set-up, corner placement will often provide the best overall performance.
- Other Placement Options: If corner placement sound excessively boomy, then try moving the subwoofer to other available locations along the front stage, listening for the best balance of output and a smooth accurate response. Always redo the auto-set-up of your AV receiver after moving the subwoofer to a different location to ensure the acoustic distance and calibration level are set correctly.
- Dual Subs: To maximize the bass output and impact of your home theater, two SB-2000s can be paired; one on either side of your room.
Auto/Standby & On Switch: If this switch is set to "Auto/Standby", it will automatically turn-on the powered subwoofer in the presence of an audio signal. If no signal is present for approximately 30 minutes, the powered subwoofer will enter "Standby" mode, where power consumption will be less than 0.5 watts. If this switch is set to "On", the amplifier will remain on continuously and will not enter "Standby" mode.
Power Status Light: The power status light is located on the front-panel of the powered subwoofer in the upper left corner. The light will illuminate blue when the amplifier is on. The light will illuminate red when the amplifier is in standby mode.
3V-12V Trigger Input: When in standby mode, the powered sub's trigger input (3.5mm) can be used to automatically turn on the powered subwoofer if a signal is sent to this input from another component in the system (like your AV receiver) that features a trigger output.
