About the Memphis Audio BRX1044
Memphis Audio designed their Bass Reference Series subwoofers with one thing in mind: giving you the deep, rich, soulful bass you've been looking for. These durable subs combine proven technology and materials with rugged design to create subwoofers that will handle high power and keep on kicking.
The BRX1044 10" subwoofer sports a reinforced high-density paper cone that lays down warm, "old school" bass that'll have your vehicle rocking. The double-stitched surround helps this sub handle up to 400 watts RMS, so you can feed it plenty of power. The sub's dual 4-ohm voice coils allow you to draw maximum power from your mono amp. Just add an amp and an enclosure, and you've got the makings of a real bass party.
- dual 4-ohm voice coil subwoofer
- coated high-density paper cone
- double-stitched foam surround
- power handling: 400 watts RMS (800 watts peak)
- sensitivity: 85 dB
- top-mount depth: 5-1/8"
- grille not included
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # BRX1044
What's in the box:
- One 10" Dual 4-ohm voice coil woofer
- Removable rubber mounting ring (installed)
- Warranty information
Memphis Audio BRX1044 reviews
Thanks for submitting your review
More details on the Memphis Audio BRX1044
Features & specs
|Impedance||2 ohms or 8 ohms|
|Cone Material||Reinforced Paper|
|Ideal Sealed Box Volume (cubic feet)||1|
|Ideal Ported Box Volume (cubic feet)||1.5|
|Port diameter (inches)||N/A|
|Port length (inches)||N/A|
|Dual Voice Coil||Yes|
85 dB at 1 watt |
|Max RMS Power Handling||400|
|Peak Power Handling (Watts)||800|
|Top Mount Depth (inches)||5 3/16|
|Bottom Mount Depth (inches)||N/A|
|Cutout Diameter or Length (inches)||9 1/8|
|Parts Warranty||1 Year|
|Labor Warranty||1 Year|
Woofer Terminals: The woofer has spring post wire terminals. They will accommodate bare speaker wire up to 10 gauge.
Dual Voice Coils: For increased system flexibility, the woofer has two 4Ω voice coils. When the voice coils are wired in parallel, the woofer presents a 2Ω load; when wired in series, the woofer presents an 8Ω load.
Sealed Enclosures: Sealed enclosures provide the most control over a woofer and provide accurate sonic reproduction, making them suitable to all types of music. Memphis Audio recommends a sealed enclosure of 1.0 ft.
Vented Enclosures: Vented (or ported) enclosures typically provide better overall efficiency than sealed so they are suitable for use with smaller amplifiers, giving you more bass output from less power. Memphis Audio recommends a ported enclosure of 1.5 ft³ with a 10-1/2" x 1-1/4" x 17-3/4" slot port, yielding a tuning frequency of 38 Hz.
The Memphis Audio BRX1044 replaces these items
1 question already asked
