About the Memphis Audio PRX50C
Powerful components
Powerful components
The time has come to take a stand against disappointing sound, and Memphis Audio's Power Reference Series PRX50C 5-1/4" component speaker system is your ally in the quest to bring fun back to your drive. These speakers handle up to 50 watts RMS, and they'll deliver excellent performance, whether you're driving them with a factory stereo or an aftermarket amp.
Memphis supplies logo-stamped grilles if you have plans for a custom installation.
Superior sound staging
Experience the superior sound staging of component polypropylene dome tweeters, which handle detailed delivery of the high frequencies. A polypropylene woofer cone handles the low frequencies, and an external crossover optimizes each driver's performance.
Product highlights:
- component speaker system includes two 5-1/4" woofers, 2 tweeters, 2 external crossovers
- polypropylene woofer with polyurethane surround
- polypropylene dome tweeter
- 2-way external crossover
- handles up to 50 watts RMS (100 watts peak power)
- frequency response: 94-20,000 Hz
- sensitivity: 88 dB
- woofer top-mount depth: 2-1/16"
- woofer grilles included
- warranty: 1 year
- MFR # PRX50C
What's in the box:
Memphis Audio PRX50C owner's manual
- 2 Woofers
- 2 Tweeters (with attached 16" wire terminated with quick-slide connectors)
- 2 Crossovers
- 2 Adhesive backed Memphis Audio logos (packaged with the crossovers)
- 2 Woofer grilles
- 2 Flush mount housings (with tweeters installed)
- 2 Flush mount retaining rings
- 2 Angled surface mount housings
- Two 6' Crossover input wires (tinned bare wire on both ends)
- Two 12' Tweeter wires (quick slides on one end and tinned bare wire on the other)
- Two 12' Woofer wires (quick slides on one end and tinned bare wire on the other)
- Eight 1-3/8" Pan head screws
- 8 Speed clips
- Four 3/4" Flat-head screws
- Tweeter installation instructions
- Warranty information
- Template
Customer reviews for Memphis Audio PRX50C
Loading...
Loading reviews...
Average review:
4.5 out of 5 starsThanks for submitting your review
Customer photos
This review was collected as part of a promotion
Pros:
Cons:
More details on the Memphis Audio PRX50C
Features & specs
General | ||
---|---|---|
Speaker Size | 5 1/4 | |
Design | 2-way | |
Tweeter Design | 1" Dome | |
Impedance (Ohms) | 4 | |
Tweeter Composition | Polypropylene | |
Woofer Composition | Polypropylene | |
Woofer Surround | Polyurethane | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year | |
Specifications | ||
Sensitivity (1W at 1 meter) | 88 | |
Sensitivity at 2.83 volts | N/A | |
Frequency Response | 94 - 20k Hz | |
Minimum RMS Wattage | --- | |
Maximum RMS Wattage | 50 | |
Peak Power Handling (Watts) | 100 | |
Top-mount Depth (Inches) | 2 1/8 | |
Bottom-mount Depth (Inches) | 2 5/16 | |
Cutout Diameter or Length (inches) | 4 3/4 | |
Mounting Height (Inches) | 0.226 | |
Frame Width | 5.098 | |
Frame Length | 5.098 |
Product Research
Features
Tweeter Mounting: The tweeters offer multiple mounting options; choose a flush mount, surface mount, or angled surface mount. The tweeters are shipped in the flush mount housings and the angled surface mount housings are included. The back of the flush mount housing and the top of the angled surface mount housing combine to create the (non-angled) surface mount housing. Once installed in any of the housings, the tweeter will pivot slightly to optimize imaging.
Crossover: The crossover's inputs and outputs are screw terminals that will accept bare wire or spade connectors up to 0.315" wide.
Tweeter Dimensions:
Flush Mount | Surface Mount | Angled Surface Mount | |
---|---|---|---|
Mounting Height | 0.207" | 1.044" | 1.605" |
Mounting Depth | 0.855" | screw depth | screw depth |
Frame Diameter | 2.135" | 1.833" | N/A |
Cutout Diameter | 1.839" | N/A | N/A |
Frame Width | N/A | N/A | 1.808" |
Frame Depth | N/A | N/A | 1.838" |
Crossover Dimensions:
- Width: 2-3/4"
- Height: 1-1/2"
- Depth: 4-3/4"
The Memphis Audio PRX50C replaces these items
Memphis Audio 15-PRX5C
- polypropylene woofer with polyurethane surround
- 1" polypropylene dome tweeter
- handles up to 50 watts RMS (100 watts peak power)
Loading...
Loading accessories...
Customer Q&A
7 questions already asked
Loading...
Loading articles...
These sound absolutely amazing compared to the Bose that came in my trailblazer. I have them paired to a 4channel, 70w/channel amp and was blown away by the sound these speakers produce! Easy installation for someone who has dealt with car audio
Philip from Lee, MA
