About the Anthem MCA 525
Multichannel muscle for your home theater
Multichannel muscle for your home theater
The Anthem MCA 525 is 61 pounds' worth of multichannel muscle. When Anthem visited Crutchfield to demo their line, I casually attempted to lift the MCA 525 — and was humbled by its heft. It will drive even power-hungry speakers to movie theater volume levels without breaking a sweat. And this well-engineered amp excels at controlling the stop-start motion of your speakers' drivers, enhancing virtually every aspect of sound quality from deep bass, to dynamics, to soundstaging.
Usually, 5-channel amps like the MCA 525 are paired with A/V preamp/processors like Anthem's superb AVM 60. But if your home theater receiver has preamp outputs — and many do, like Anthem's MRX Series models — you can easily connect the MCA 525 and use it to drive your main and surround channels. That surge of added power adds startling impact to movie soundtracks.
Inside the Anthem sound
The MCA 525 is constructed like 5 mono amps, with dual toroidal power supplies for plenty of stable power.
The MCA 525's rated power output provides a clue to this amp's unshakeable grip on the music. It produces 225 watts per channel at 8 ohms, 400 watts into 4 ohms and an incredible 600 watts into 2 ohms!
Anthem's previous 5-channel amp used a single power supply for the front left and right channels, and another supply for the center and surrounds. The MCA 525 employs a new design, sharing its two power supplies among all channels. The result is full bursts of power — instantly — without ever compromising channel separation.
When designing their latest MCA Series amplifiers, Anthem upgraded nearly every part in the signal path in order to reduce noise and distortion. From the custom high-power toroidal transformers inside, to the re-designed speaker binding posts in back, every feature was optimized so that you'll hear clean, transparent sound emerging from an eerily quiet background.
Made in Canada, respected around the world
For more than two decades, Anthem has been making award-winning high-performance audio/video equipment for music and home theater. Anthem power amplifiers are designed, engineered, and built in Canada.
- 225 watts per channel into 8 ohms, 400 watts per channel into 4 ohms, or 600 watts per channel into 2 ohms, for compatibility with even difficult-to-drive speakers
- Class AB design with 8 high-current bipolar output transistors per channel for lower distortion
- dual custom low-noise, high-power toroidal transformers for stable, noise-free operation
- high-quality filter capacitors and advanced power supply regulators
- Advanced Load Monitoring™ technology monitors internal temperature, current, and voltage to ensure safe, uninterrupted operation
- 3-way on/off operation: manual, triggered, or signal-sensing auto on/off
- balanced XLR and unbalanced RCA inputs for all five channels
- custom-designed binding post terminals accept bare wire, banana plugs, and spade lugs
- 3.5mm trigger in/out jacks allow the amplifier to be turned on or off remotely
- detachable power cord
- designed, engineered, and manufactured in Canada
- total harmonic distortion: 0.015%
- signal-to-noise ratio: 120 dB
- 17-1/4"W x 6-5/8"H x 18-1/8"D
- weight: 61 lbs.
- warranty: 5 years
- Our 60-day money-back guarantee
- MFR # 1412000005
What's in the box:
- 5-Channel power amplifier
- AC power cord
- Operating Manual
Anthem MCA 525 reviews
Its simply the cleanest most powerful 5 channel amp available without getting a 2nd mortgage. 5.1 and 2.1 theatre amp perfect. Next step is Bryston at over 10k. This one is a no brainer. John Stoker
Pros: Best affordable 5 channel amp made
Cons: For looks, its a wolf in sheep's clothing
2 of 2 found this helpful
First off this amplifier is HEAVY. It was everything I could muster to get it into the house. WOW, but once unboxed and put into service it is an amazing power amp. It humiliated two very nice older Krell amplifiers. You will hear nuances in your music that you didn't even know were there. Sound wise everything is better, more defined and extended bass, I'm in the audience midrange and treble that is just crystal clear and ultrasonic. When paired with the Anthem AVM 60 pre amp it is a match made in heaven. As it breaks in it gets better with every listening session. My only suggestion is to replace the amps two plain Jane glass fuses with two Synergistic Research Blue Quantum fuses. There expensive, but just like this amp worth every penny. Thank you Crutchfield
Pros: Sounds wonderful at low volume and when you want to shake the house it will deliver major sound pressure levels. So clear you will think you are there. Runs cool too which is really nice in the Summer.
Cons: Nothing, plan your lift when you put it in your cabinet. It is very hefty.
7 of 8 found this helpful
We're extremely happy with our purchase of this amp. Music dynamics are incredible and were noticed immediately. We can hear nuances in the music that were not heard prior. Simple hookup and away you go. Next step....new speakers (not sure which yet) to compliment it. I'm not an audiophile yet, but I'm getting there. Sales was a pleasure to deal with and the shipment was quick. We would do it over again anytime. One side note; In our opinion Crutchfield has the best sales team available. When your looking for info/help/suggestions/support, they're right there. Tough to find today.
Pros: Audio is ridiculously good.
9 of 9 found this helpful
My music and movie collection never sounded this good ever!
Pros: Wow this amp is a beast! if you want some power this is it. Drives my Martin Logan 40s ml 50 Center Channel speaker and a pair of Ml16s without cracking a sweat. It runs cool and is super quiet. Can't wait to buy another anthem amp for my Atmos speakers that I'm currently running with a vintage Marantz amp from 1975 4-channel no less! Thanks Crutchfield for helping me put together a system I've dreamed about for 40 years!
Cons: None except had to have help carrying it upstairs!
9 of 9 found this helpful
I bought 2 MCA525s and paired them with Anthem AVM60. All I can say is wow. Talk about waking up your speakers. I replaced a Marantz AV8801 that was paired with Integra DTA 70.1 and Anthem MCA20. Never heard anything like Dolby Atmos before. It's amazing..... was a pricey setup but soooooo worth it.
Pros: Sound Runs cool
11 of 12 found this helpful
Clean, clear sound with plenty of power to drive my 5.2 surround system. The Martin Logan main speakers Motion 60XT and center Motion 50XT are easily handled by this power amp. Sound is almost as if you were there live.
Pros: Plenty of power Clean clear sound
17 of 20 found this helpful
More details on the Anthem MCA 525
Features & specs
|Number of Channels||5|
|Power Output per Channel (8 ohms)||225|
|Power Output per Channel (6 ohms)||---|
|Power Output per Channel (4 ohms)||400|
|Bridged Power per Channel||0 watts|
|Parts Warranty||5 Years|
|Labor Warranty||5 Years|
|Inputs & Outputs|
|Number of Inputs||5|
MCA Series Amplifier: Anthem's MCA series of amplifiers balance the complex dynamics of today's most demanding multi-channel media with the rare finesse required to satisfy the audiophile in you. MCA series amplifiers provide an abundance of conservatively rated power into demanding low-impedance loads with incredible reliability.
Note: The MCA series amplifiers are perfectly matched for Anthem's AVM 60 Pre-Amplifier (973AVM60, sold separately).
Superior Craftsmanship: The Anthem MCA series multi-channel amplifier's superior craftsmanship is reflected in its clean, clear, audiophile-quality sound from top-to-bottom of the frequency spectrum. MCA series multi-channel amplifiers utilize only the highest quality of parts - like custom low noise high-power toroidal transformers, high-current bipolar output transistors, high-quality filter capacitors, advanced power supply regulators, oversized aluminum heatsinks, custom-designed dual binding posts, and patented auto-on/off circuitry.
5-Channel Power Amp: The Anthem MCA 525 is a 5-channel power amplifier. This 5-channel power amp is incredibly stable into difficult, low-impedance speaker loads, making it a reliable performer in even the toughest circumstances. The MCA 525 utilizes 8 bipolar output devices per channel for greater high-current power with less stress on the amplifier.
- 8Ω: 225 watts per channel (continuous RMS, 20Hz to 20kHz, <1% THD)
- 4Ω: 400 watts per channel (continuous RMS, 20Hz to 20kHz, <1% THD)
- 2Ω: 600 watts per channel (continuous RMS, 20Hz to 20kHz, <1% THD)
Massive Toroidal Power Supplies: The MCA 525 shares its two power supplies between all channels; the result is full bursts of instantaneous power without affecting channel separation. The MCA series amplifier delivers incredible dynamics thanks to these massive, conservatively rated power supplies designed with high-rail voltages. Low flux toroidal power transformers ensure ultra quiet performance by minimizing stray magnetic field radiation. This provides the pure, clean, low-noise power that is needed to reproduce the full dynamics of home theater and the most complex and dynamic music recordings.
Direct Path Circuitry: The MCA series greatly reduces the use of internal cabling for a much smoother circuit path for pure, unobstructed audio performance. Both power supply impedance and internal cabling inductance have been minimized to deliver a direct, clear path for maximum power; even in the most demanding conditions. Consequently, Anthem removed output relays, so the signal path has absolutely no moving parts. All parts, including the eight bipolar output transistors per channel, are run conservatively so they remain within their safe operating range.
Advanced Load Monitoring (ALM) Technology: Anthem's exclusive ALM circuitry protects the amplifier's sensitive output devices by constantly monitoring temperature, current, and voltage to ensure optimum long-term performance. ALM is totally non-invasive; it is not in the signal path and only engages in the most extreme circumstances to protect the amplifier from damage by maintaining the safe operating area of the output devices.
120dB Signal-To-Noise Ratio: With a signal-to-noise ratio of 120dB, background noise is practically nonexistent, leaving you with just pure natural sound reproduction from the MCA series amplifier.
Balanced & Unbalanced Analog Inputs: The Anthem MCA 525 amplifier is equipped with five balanced XLR inputs and five unbalanced RCA inputs for Front Left, Front Right, Center, Surround Left, and Surround Right channels. Balanced XLR connections offer the highest transmission quality, particularly over long cable lengths, because they reject noise and hum pickup. If your preamplifier does not have XLR outputs, use the RCA inputs.
Custom-Designed Binding-Posts: Five pair of speaker terminals are provided for connecting a pair of front speakers, a center-channel speaker, and a pair of rear surround speaker. These custom-designed, oversized robust binding-posts ensure full power delivery at all times. They're easy to use and facilitate large speaker cable connectors, as well a banana plugs (single only).
Trigger Input/Output: The Anthem MCA 525 is equipped with a 12V trigger input (3.5mm) and 12V trigger output (3.5m) to synchronize power on/off with other components that also feature 12V trigger inputs and outputs.
3-Way On/Off: The MCA series amplifier can be powered on or off in three ways - manually with the On/Off switch on the front-panel, remotely via the rear-panel 5V-24V trigger input, or automatically with Anthem's patented Auto-On/Off circuit. Via the Auto-On/Off circuit, an incoming audio signal immediately switches it on; and approximately 20 minutes after the audio signal ends, it simply switches off.
Protection Circuitry: The Anthem MCA series amplifier utilizes a 3-way protection circuit to guard against Short Circuits (Short Circuit protection), Over-Heating (Thermal protection), and Ground Faults (DC protection).
Crafted In Canada: Anthem's MCA series multi-channel amplifiers are designed and crafted in Canada.
