About the JBL Concert Edition Premium Audio Upgrade
Crank up your F-150's sound
Crank up your F-150's sound
JBL designed their Concert Edition audio upgrade package so you can put high-fidelity, concert-worthy sound inside your Ford F-150 SuperCrew without having to cut a single wire or change anything about your interior's appearance. This upgrade replaces the factory front and rear speakers with high-quality JBL models, and adds two 8-inch JBL subwoofers as well. An 8-channel amplifier with digital signal processing provides your music with the power and tone customized for your F-150's interior.
The dual 8" enclosure under your rear seat punches out some powerful bass.
JBL's illustrated instructions clearly show how to "drop in" and plug up the new speakers and wiring harnesses that integrate the Concert Edition upgrade into your vehicle's factory system. The sub enclosure and amplifier assembly fit out of the way under the rear seat, perfectly positioned to provide power and bass for your music.
Note: For the Extended Cab application, the subwoofer will extend beyond the seat by about 2".
Pre-tuned for your Ford's interior space
JBL engineers measured the physical and acoustical properties of the SuperCrew cab's interior and modeled the Concert Edition's sound equalization curves and speaker time alignments so everyone inside will hear premium sound, wherever they sit. All the components — speakers, amp, sub, and wiring harnesses — fit perfectly in position and simply plug into the factory system. The only installation tools required are a 7 mm wrench, a panel tool, and a wire worm or large tie wrap.
Important Notes: This upgrade package will only work with the 2015-up Ford F-150 SuperCrew and Extended Cab trucks with the non-amplified system (4, 6, or 7 speaker systems). It will not work in a F-150 with the premium (Sony) sound system.
Satellite Radio Note: When you install this JBL system in a 2017-up Ford F-150 with the factory 7-speaker/8" LCD radio package, the factory SiriusXM tuner won't work anymore.
- audio upgrade system
- fits select 2015-up Ford F-150 SuperCrew with basic (non-Sony) factory system
- package includes:
- two 6" x 8" 2-way speakers for front doors
- two 6-1/2" 2-way speakers for rear doors
- subwoofer enclosure with two 8" subwoofers for under rear seat
- 8-channel 360-watt amplifier with digital signal processing
- customized power and signal harnesses
- four small JBL door badges and one large JBL Concert Edition tailgate badge
- illustrated installation instructions available only via link provided below
- required installation tools: 7 mm wrench, panel tool, and wire worm or large tie wrap
- warranty: 3 years
- Our 60-day money-back guarantee
- MFR # JBL F-150 Concert
What's in the box:
- Subwoofer enclosure loaded with two 8" subwoofers
- Amplifier (mounted to subwoofer enclosure)
- 2 JBL GT7-86 Speakers mounted in custom Ford brackets
- 2 JBL GT7-6 Speakers mounted in custom Ford brackets
- 11' Power harness
- 20-amp ATM fuse (installed in power harness fuseholder)
- 17' Factory integration harness
- 4 M6x16mm Machine screws
- 4 M6 Nuts
- 4 JBL Grille badges
- 1 JBL Tailgate badge
JBL Concert Edition Premium Audio Upgrade reviews
Thanks for submitting your review
More details on the JBL Concert Edition Premium Audio Upgrade
Features & specs
|Sensitivity (1W at 1 meter)||N/A|
|Sensitivity at 2.83 volts||N/A|
|Minimum RMS Wattage||---|
|Maximum RMS Wattage||---|
|Peak Power Handling (Watts)||---|
|Top-mount Depth (Inches)||N/A|
|Bottom-mount Depth (Inches)||N/A|
|Cutout Diameter or Length (inches)||---|
Overview: JBL's VSSF150 replaces the front and rear factory speakers, adds two subwoofers in a custom enclosure, adds an amplifier to power the entire system, and includes all the necessary wiring for installation in select 2015-2019 full size Ford Super Crew and SuperCab pickups. (The subwoofer enclosure extends approximately 2" beyond the rear seat in the SuperCab.) Please enter your truck information to confirm fit.
Front Speakers: Two JBL GT7-86 speakers are mounted in custom Ford brackets and have Ford wiring harnesses attached, so they mount without any modification and the factory wiring plugs in.
Rear Speakers: Two JBL GT7-6 speakers are mounted in custom Ford brackets and have Ford wiring harnesses attached, so they mount without any modification and the factory wiring plugs in.
Subwoofer Enclosure: The custom enclosure is loaded with two 8" subwoofers and mounts under the back seat.
Amplifier: The amp is mounted to subwoofer enclosure, thus hidden under the rear seat. Three plugs on the end of the factory integration harness connect directly the amp; no other wiring is needed.
Wiring: Two custom wiring harnesses are included, an 11' power harness and a 17' factory integration harness. The power harness is routed from the battery (in the engine bay) to the center console, where it connects to the factory integration harness. The factory integration harness is routed from the radio location to the JBL amplifier, mounted on the subwoofer enclosure. The factory integration harness has custom plugs on both ends, so no factory wires need to be cut or spliced.
