Canon EOS 77D Kit

24.2-megapixel DSLR camera with 18-55mm zoom lens, Wi-Fi®, and Bluetooth®

Overview

Our take on the Canon EOS 77D Kit

The Canon EOS 77D combines a 24.2-megapixel image sensor with a powerful DIGIC 7 processor to give you outstanding EOS performance. It has all the speed and versatility you need to create dynamic, high-resolution photos and HD movies. Check and change settings without missing a beat using the top-mounted LCD screen and rear Quick Control dial.

Canon EOS 77D

The Canon EOS 77D has a rotating touchscreen for creative composition from different angles.

Creative control for stunning results

The Canon EOS 77D combines a 24.2-megapixel image sensor with a powerful DIGIC 7 processor to give you outstanding EOS performance. It has all the speed and versatility you need to create dynamic, high-resolution photos and HD movies. Check and change settings without missing a beat using the top-mounted LCD screen and rear Quick Control dial.

Intuitive framing and focusing

The EOS 77D's optical viewfinder lets you keep your eye on your subject at all times. A rotating touchscreen monitor makes it easy to compose from different angles and allows for intuitive operation — just select the subject you want to focus on with a quick tap.

Keep up with the action

The 77D's Dual Pixel CMOS autofocus system enables fast, smooth focusing in Live View mode and during movie shooting, where quick focus is essential. Movie focus is natural and precise, even when switching between subjects.

The 77D's 45-point autofocus system for viewfinder shooting excels in challenging light and allows four types of AF area selection modes for different situations. This agile camera can capture sharply focused action sequences at up to six frames per second.

A lens you can use every day

The included 18-55mm lens zoom lens is great for all kinds of shooting situations. It's lightweight, quick to focus, and super quiet — perfect for still photography and video. Built-in Image Stabilization helps you capture blur-free photos and shake-free videos, while specialized lens elements contribute to high-resolution image quality.

Put your vision in motion with Full HD video recording

If you're new to videography, the 77D is a great camera to learn on, plus it's fun to use. It records Full HD movies in MP4 format for easy sharing. Touch-activated autofocus and manual controls make it easy to adjust settings on the fly. An external microphone jack lets you connect an outboard mic for superb sound quality.

The included 18-55mm STM (Stepping Motor) lens gives you near-silent movie focus. Five-axis digital image stabilization minimizes camera shake, so you can capture video on foot and get results that won't make you seasick. The kit lens's on-board Image Stabilization lets you max out the effects of the camera's digital Image Stabilization.

Wireless convenience and control

The 77D's Wi-Fi lets you upload and share photos and videos in a matter of moments. You can exchange data with other Canon cameras, play back images and movies on a smart TV, and print directly to a Wi-Fi printer.

Canon's free Camera Connect app lets you manage photos and videos taken with the 77D on your phone or tablet. Use your device to see what the camera sees, trigger the shutter remotely, and even change settings on the 77D.

Product Highlights:

  • 24.2-megapixel effective recording
  • APS-C-size CMOS image sensor (22.5 x 15 mm)
  • includes EF-S 18-55mm f/4-5.6 IS STM lens (35mm equivalent focal length: 29-88mm)
  • compatible with all Canon EF and EF-S lenses
  • Dual Pixel CMOS autofocus provides exceptionally fast and accurate autofocus performance while using live view or shooting video
  • high-def movie mode with sound (up to 1080p at 60 frames per second)
  • 3.0", 1.04-million-dot vari-angle tilt-and-swivel LCD touchscreen with brightness control
  • pentaprism optical viewfinder
  • built-in Wi-Fi and NFC touch pairing for easy sharing and control from smart devices
    • Bluetooth® low energy provides a constant connection to your compatible device with Canon Connect app
  • top-mounted LCD panel with backlighting displays camera and exposure settings
  • Canon's latest DIGIC 7 image processor with improved AF tracking for speedy operation and reduced noise at high ISO settings
  • 45-point autofocus system with all cross-type sensors for rapid, precise focusing
    • 4 AF area selection modes for different shooting situations (user-selectable Single-point AF, Zone AF, Large Zone AF, and 45-point AF auto selection)
  • built-in flash with flash exposure compensation
  • Quick Control dial lets you change settings during viewfinder shooting
  • self-cleaning sensor activates when the camera powers on or off to remove dust for spot-free images
Exposure Modes and Controls:
  • continuous shooting mode: up to 6 frames per second
  • shutter speed range: 30-1/4,000 seconds, bulb
  • sensitivity or ISO (film speed equivalent) range: 100-25,600, expandable to 51,200
  • shooting modes: auto (stills and movie), creative auto, program auto, shutter-priority, aperture-priority, manual (stills and movie), bulb, custom setting
File Formats and Storage:
  • still image storage modes: RAW, JPEG, or RAW+JPEG
  • top JPEG resolutions (pixels): 6,000 x 4,000
  • movie file formats: MOV (Video: H.264, Sound: Linear PCM)
  • movie image size: up to 1,920 x 1,080 resolution (up to 60 frames per second)
  • accepts optional SD, SDHC, and SDXC memory cards
Connections and Dimensions:
  • high-speed USB interface (cable not included)
  • mini HDMI (Type C) output (cable not included)
  • 3.5mm external stereo microphone input jack (microphone not included)
  • 5-3/16"W x 3-15/16"H x 3"D (without lens)
  • weight (with battery and memory card): 19.05 oz.
Supplied Accessories:

What's in the Box:

  • Digital camera body (with body cap installed)
  • EF-S 18-55mm f/3.5-5.6 IS STM lens (with E-58II front lens cap and rear lens cap installed)
  • LP-E17 Lithium-Ion rechargeable battery with plastic terminal cover installed (7.2V 1040mAh 7.5Wh)
  • LC-E17 Battery charger (8.4V / 0.7A)
  • EW-400D Adjustable cloth neck strap (with attached eyepiece cover)
  • Basic Instruction Manual (English)
  • Warranty Card
  • Online registration card
Reviews
Details

Hands-on research

Features and Specs

General
LCD Screen Size 3"
Adjustable-angle LCD Yes
Wi-Fi Built-in
GPS-enabled Optional
Lens 35mm Equivalent 29-88mm
Optical Zoom 3x
Digital Zoom N/A
Filter Diameter 58mm
Manual Focusing Yes
Manual Exposure Yes
Built-in Flash Yes
HDMI Output Mini
Memory
Internal Memory None
Memory Media SD/SDHC/SDXC
Sensor Size APS-C
Megapixels 24.2
Image Stabilization With optional lens
Highest Resolution 6000 x 4000
4K Video No
Video Resolution 1920 x 1080
Dimensions
Width (inches) 5-5/16
Height (inches) 4
Depth (inches) 3-5/16
Weight With Battery (ounces) 19.05
Warranty
Parts Warranty 1 Year
Labor Warranty 1 Year

Product Research

Features
Connections
Power Options
Wireless Functions
Lens Features
Software

Features

Overview: This Canon EOS 77D EF-S 18-55 IS STM kit includes the 77D DSLR camera body and the EF-S 18-55mm f/3.5-5.6 IS STM zoom lens. The camera has a standard Canon EF mount, and is compatible with Canon EF lenses, including EF-S lenses.

Viewfinder: The Canon EOS 77D uses an eye-level SLR viewfinder with pentamirror with 0.82x magnification (w/50mm lens at infinity) for approximately 95% vertical and horizontal coverage. It has a -3.0 to +1.0 diopter adjustment so you can focus the viewfinder to suit your eyesight (with or without eyeglasses). When using the self-timer or remote control, when your eye does not cover the viewfinder eyepiece, stray light may enter the eyepiece and affect the exposure when the image is captured. To prevent this, you can use the supplied eyepiece cover, attached to the neck strap, to cover the eyepiece.

3" Clear View II LCD Touch Screen Monitor: The EOS 77D features a flip-out, Vari-angle Touch Panel 3" Clear View II LCD monitor that allows you to shoot at a variety of angles. It has a 3:2 aspect ratio and approximately 1,040,000 dots for Live View composition and viewing recorded images. The screen has the same capacitive touch technology as today's popular mobile devices, and delivers intuitive touch panel operation. Two-finger gestures (multi-touch) can be used for zooming or changing images, menu and quick control settings can be accessed, and focus point and shutter release can be activated with the touch of a fingertip. The LCD monitor offers 100% viewing coverage and 7 brightness levels to choose from.

Live View: The Live View Function enables viewing your subjects directly on the camera's 3" LCD monitor. The camera allows you to magnify any part of the scene 5x or 10x for precise manual focusing. You can choose one of two grid overlay options for the LCD screen to help you line up vertical and horizontal lines. The camera can be controlled remotely via a computer through a USB connection, or wirelessly with the optional RC-6 remote controller.

24.2 Megapixel CMOS Sensor: Canon's large-area CMOS (Complementary Metal Oxide Semiconductor) sensor captures images with exceptional clarity and tonal range, and offers approximately 25.8 million total pixels and 24.2 million effective pixels. This APS-C-sized sensor (22.3mm x 14.9mm) has the same 3:2 ratio as film cameras, enabling an effective angle of view that is 1.6x the normal EF Lens focal length.

DIGIC 7 Image Processor: The 77D is equipped with Canon's DIGIC 7 Image Processor. The DIGIC 7 works with the CMOS sensor to deliver images with great detail. Improved light sensitivity allows you to shoot at higher resolution with less noise in dark conditions. The camera can achieve higher ISO sensitivity (up to ISO 25600), and can shoot continuously at up to 6 frames per second.

Image Recording: The camera records still images in JPEG and RAW formats. You can choose from the following image sizes: Large, Medium, Small 1, and Small 2. For each resolution (except Small 2), you can set the compression to Fine or Normal. For RAW images, you can record only at 6000 x 4000 resolution. You can set the camera to RAW + JPEG and record a RAW image and a Large Fine JPEG image simultaneously.

Aspect Ratio: The camera's image sensor has an aspect ratio of 3:2. You can choose to record still images in 3:2, 4:3, 16:9, and 1:1 aspect ratios. This gives you the option of selecting any of the following image sizes:

Quality Aspect Ratio and Pixel Count
3:2 4:3 16:9 1:1
Large/RAW 6000 x 4000
(24 MP)
5328 x 4000
(21.3 MP)
6000 x 3368
(20.2 MP)
4000 x 4000
(16.0 MP)
Medium 3984 x 2656
(10.6 MP)
3552 x 2664
(9.5 MP)
3984 x 2240
(8.9 MP)
2656 x 2656
(7.1 MP)
Small 1 2976 x 1884
(5.9 MP)
2656 x 1992
(5.3 MP)
2976 x 1680
(5.0 MP)
1984 x 1984
(3.9 MP)
Small 2 2400 x 1600
(3.8 MP)
2112 x 1600
(3.4 MP)
2400 x 1344
(3.2 MP)
1600 x 1600
(2.6 MP)

RAW File Format: The RAW file format records the image data as captured by the camera's CMOS sensor without further processing and converts it to digital data and records it onto the card as is. RAW images can be adjusted, then developed and produced into JPEG images using the downloadable Digital Photo Professional software.

Recording Media: The EOS 77D records images on an SD, SDHC, and SDXC memory cards, including UHS-I (Ultra High Speed) memory cards. It is also compatible with some brands of Eye-Fi cards that feature wireless transfer of images, although their performance is not guaranteed. No recording media is supplied with the camera.

Self Cleaning Sensor: Dust that settles on the sensor surface of the camera is removed using ultrasonic vibration. This Self Cleaning Sensor Unit routine is automatically activated whenever the camera is powered on or off. (It can also be manually activated.) In case visible dust still remains, you can delete the effect of the dust particles from the image via the downloadable Digital Photo Professional software.

Shooting Modes: The EOS 77D offers 12 different shooting modes arranged on the Mode Dial in the following zones:

  • Creative Zone:
    • Program AE: This is a general-purpose shooting mode, the camera automatically sets the shutter speed and aperture value to suit the scene's brightness.
    • Shutter-priority AE: In this mode, you set the shutter speed and the camera automatically sets the aperture value to suit the brightness of the subject.
    • Aperture-priority AE: In this mode, you set the desired aperture value and the camera sets the shutter speed automatically to suit the subject brightness.
    • Manual Exposure: You set both the shutter speed and aperture value as desired.
  • Basic Zone:
    • Scene Intelligent Auto: The camera analyses the scene, and automatically selects the settings.
    • Flash Off: Disables the flash.
    • Creative Auto: In this auto mode, you can still set the brightness, flash mode, sharpness, image recording quality, and picture style settings.
    • Portrait: Blurs the background to make the human subject stand out.
    • Landscape: For wide scenic views, night scenes, etc.
    • Close-up: To take close-up shots of flowers, insects, etc.
    • Sports: For fast-moving subjects when you want to freeze the action.
    • Special Scene: Once you select the Special Scene Mode, you can choose from the following modes:
      • Group Photo: Use this mode to shoot a group of people, assuring persons in the front and back rows are in focus.
      • Kids: Continuous focusing allows you to photograph children running around. Skin tones look healthy. Default drive mode is Continuous Shooting.
      • Food: When photographing food, the images will look bright and vivid. You can change the color tone to warm or cool if needed.
      • Candlelight: The candlelight mode allows you to photograph a human subject in candlelight. You can change the color tone to warm or cool.
      • Night Portrait: For images of people at twilight or at night.
      • Handheld Night Scene: Allows you to take handheld photos at night by recording four photos that are combined into a single bright image.
      • HDR Backlight Control: Useful for taking photos with bright and dark areas. Three photos are taken and combined into a single image with restored detail in dark and light areas.
    • Creative Filters:
      • Grainy B/W: Creates a grainy black-and-white photo with adjustable contrast.
      • Soft Focus: Gives the image a soft look. You can change the degree of softness by adjusting the blur.
      • Fish-eye Effect: Gives the effect of a fish-eye lens with a barrel-type distortion.
      • Water Painting Effect: Makes the photo look like a watercolor painting with soft colors. The color density is adjustable.
      • Toy Camera Effect: This effect makes the photo look as if it was shot by a toy camera by darkening the photo's corners and applying a unique color tone.
      • Miniature Effect: Creates a diorama effect.
      • HDR Art Standard: Clipped highlights and shadows are reduced. The low contrast and flat gradation create a painting-like effect with bright (or dark) edges on the subject outlines.
      • HDR Art Vivid: Colors are more saturated than HDR Art Standard.
      • HDR Art Bold: Colors are most saturated, making the subject stand out. The picture looks like an oil painting.
      • HDR Art Embossed: Color saturation, brightness, contrast, and gradation are decreased to make the picture look flat.

Shooting Movies: The EOS 77D can record movies in High Definition or Standard Definition at different frame rates. Movies are recorded in MOV format with MPEG-4 AVC/H.264 compression, and Linear PCM audio, and MP4 with AAC audio. You can record audio using the built-in stereo microphone, or with an optional stereo microphone (such as the Canon DM-E1) with a 3.5mm plug. When shooting movies, a large-capacity SD card with a speed rating of Class 6 or 10 is recommended for MP4 movies. If recording in MOV format, a card with a UHS Speed Class 3 or faster should be used. Slower cards may not record your movies properly. You can select from the following recording sizes and frame rates:

  • 1920 x 1080: Full HD recording quality with a 16:9 aspect ratio for viewing on a widescreen HDTV; Available frame rates: 60 (59.94) fps 30 (29.97) fps, 24 (23.98) fps
  • 1280 x 720: HD recording quality with a 16:9 aspect ratio for viewing on a widescreen HDTV; Frame rate: 60 fps, 30 fps
  • 640 x 480: Standard definition recording quality with a 4:3 aspect ratio; Frame rate: 30 fps

Movie Servo AF: When Movie Servo AF is enabled, you can shoot a movie while focusing a moving subject continuously.

Video Snapshots: A video snapshot is a short movie clip lasting 2, 4, or 8 seconds. You can combine a series of video snapshots into an album, and save them as a single movie file. The compiled video is perfect for sharing online or displaying on an HDTV via the HDMI port.

45-Point Auto-Focus System: The EOS 77D features a high-precision 45-point wide area auto-focus that uses cross-type points for improved tracking of moving subjects. You can select one of four AF area selection modes: Single-point AF (Manual Selection), Zone AF (Manual selection of zone from 9 zones), Large Zone AF (Manual selection of zone from 3 large zones), or 45-point automatic selection AF.

AF Modes: The camera employs one of 3 AF systems to let you seize every photo opportunity with fast, accurate focus:

  • One-Shot AF: suited for still subjects, the camera focuses only once.
  • AI Servo AF: for moving subjects when the focusing distance keeps changing. The subject will be focused continuously while the shutter button is pressed halfway.
  • AI Focus AF: switches from One-Shot AF to AI Servo AF automatically if the subject starts moving.

Manual Focusing: If you choose to focus manually, you will need to set the focus mode switch on the lens from AF to MF, and turn the lens focusing ring until the subject looks sharp in the viewfinder. You can magnify the image 5x or 10x for better visibility when focusing.

ISO Speed: The Image Sensor's sensitivity to light, or the ISO Speed, can be set to suit the ambient light level. In Basic Zone modes, the ISO speed is set automatically. In other modes, you can set the ISO automatically or manually from 100 to 25600, with expansion to 51200. You can also set maximum ISO speeds of 400, 800, 1600, 3200, 6400, 12800, or 25600 for ISO Auto.

White Balance: You can choose from the following white balance settings:

  • Auto: the camera sets the white balance automatically according to shooting conditions. You can choose between Ambience Priority and White Priority
  • Daylight: for recording outdoors on a bright day
  • Shade: counters strong blue tones in open shade on sunny days
  • Cloudy: for cloudy days, dusk and dawn
  • Tungsten Light: for incandescent illumination
  • White Fluorescent Light: eliminates typical green color casts
  • Flash Use: a starting point for studio strobes and Canon Speedlites
  • Custom: enables you to manually set the white balance for a specific light source for better accuracy. By selecting this image, you import the white balance data for the setting

White Balance Correction: You can correct the standard color temperature for the white balance setting. It has the same effect as using a color temperature conversion filter or a color compensating filter. Each color can be corrected to one of nine levels.

Color Space: The color space refers to the range of reproducible colors. With this camera, you can set the color space for captured images to sRGB or Adobe RGB. For normal images, sRGB is recommended. In the Basic Zone modes, sRGB will be set automatically.

Shoot by Ambience: Except in the Scene Intelligent Auto and Flash Off Basic Zone modes, you can select the ambience for shooting. You can choose from Vivid, Soft, Warm, Intense, and Cool, each at Low, Standard, or Strong effects. You can also choose Brighter or Darker, with Low, Medium, and High settings, and a Monochrome setting, with Blue, B/W, or Sepia effects.

Picture Style: By selecting a picture style you can achieve various effects matching your photographic expression or the subject. Picture Style setting is not available in Basic Zone modes, except Creative Auto. Picture Style selections include: Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, and User Defined 1-3.

Exposure Compensation: Exposure compensation is used to alter the camera's standard exposure setting. You can make the image look lighter (increased exposure) or darker (decreased exposure). The exposure compensation amount can be set up to +/-5 stops in 1/3-stop increments, although the indicator in the viewfinder can only display the setting up to +/-2 stops.

Auto Exposure Bracketing: With auto exposure bracketing (AEB), the camera automatically changes the exposure level up to +/-2 stops in 1/3-stop increments for three successive shots. When in Single Shooting mode, the camera will change the exposure level on three single shots (requiring three presses of the shutter release). In Continuous Shooting mode, or when shooting with the self-timer or optional remote controller, you can take three shots with one press of the shutter release, and the exposure levels will change with each shot taken.

AE Lock: AE lock enables you to lock the exposure at a different place from the point of focus. After locking the exposure, you can recompose the shot while maintaining the desired exposure level. This feature is useful for backlit and spotlighted subjects.

Bulb Exposures: When bulb is set, the shutter is open during the time you keep pressing the shutter button fully. Bulb is useful when a long exposure is necessary for capturing night scenes, fireworks, the night sky, etc. The optional RS-60E3 remote switch is also recommended for bulb exposures. It connects to the camera's 2.5mm sub-mini remote jack.

Flash: The camera's built-in retractable, auto pop-up flash with E-TTL II autoflash metering. The flash takes approximately 3 seconds to recycle for the next flash. The viewfinder has an icon to let you know the flash is ready. You can set the exposure compensation for the flash to +/- 2 stops in 1/3-stop increments. The flash range varies with the ISO speed. Other flash functions include:

  • AF-Assist: Under low-light conditions, the built-in flash fires a brief burst of flashes when you press the shutter button halfway. This is to illuminate the subject to enable easier auto-focusing. It is effective up to approximately 13.1 feet away.
  • FE Lock: FE (flash exposure) lock obtains and locks the correct flash exposure reading for any part of a subject.
  • Red-Eye Reduction: Using the camera's Red-Eye reduction lamp before taking a flash picture will reduce the common phenomenon of red-eye effect.

External Flash: In addition to the built-in flash, the EOS 77D has a hot shoe for adding optional external flash units. The camera is compatible with Canon's entire line of EX-series Speedlites, plus Macro Lites for close-ups. Canon EX-series Speedlites offer professional-quality illumination for virtually any subject. The built-in flash can work as a Master unit with Canon Speedlites with the wireless slave feature and trigger the Speedlite(s) to fire.

Optional GPS Receiver: The optional GP-E2 GPS Receiver can be mounted to the camera's hot shoe. The receiver records location information, such as longitude, latitude, elevation, direction, and time data, and attach it to your photos.

Metering Modes: The 77D has 63-zone TTL open-aperture metering, using 7,560-pixel RGB+IR metering sensor. You can select from the following metering modes:

  • Evaluative Metering: The camera's standard metering mode utilizes all AF points within the frame, and is suited for most subjects even under backlit conditions. After detecting the main subject's position, brightness, background, front and back lighting conditions, etc, the camera sets the proper exposure.
  • Partial Metering: Effective when the background is much brighter than the subject due to backlighting, etc; uses approximately 6% of the frame at the center.
  • Spot Metering: For metering a specific part of the subject; uses approximately 2.6% of the frame at the center.
  • Center-weighted Average Metering: Metering is weighted at the center and then averaged for the entire scene.

Continuous Shooting Mode: In Continuous Shooting mode, you can shoot up to about 6 full-resolution frames per second. The maximum number of shots in a single burst will vary with the image quality setting:

Image Quality Setting Maximum Burst
8 GB SDHC Card UHS-I Memory Card
JPEG (Large/Fine) 190 Full
RAW 21 27
RAW + JPEG (Large/Fine) 19 23

Self-Timer: The camera will record an image following a preset time delay after pressing the shutter release. The self-timer lamp and beeper will indicate a countdown before the picture is taken. You can choose from the following self-timer modes:

  • 10 Second: The camera takes a single image 10 seconds after pressing the shutter release button. You can also use the optional remote control in this mode.
  • 2 Second: The camera takes a single image 2 seconds after pressing the shutter release.
  • 10 Second Continuous Shots: The camera begins taking a series of images (2-10) ten seconds after the shutter release button is pressed.

Mirror Lockup: The Mirror Lockup feature helps prevent camera vibration when using a super telephoto lens or shooting close-ups.

Auto Rotation: Vertical shots can be rotated automatically so that they are displayed upright during playback.

Image Review: The image can be displayed on the LCD monitor immediately after you shoot. The review time can be set to off (not displayed), 2 seconds, 4 seconds, 8 seconds, or Hold, which keeps the image displayed on the LCD monitor until the camera is focused again.

Slide Show: You can view all images on the memory card one after another with the Auto Playback function (slide show). You can set the time each image is displayed on the LCD monitor to 1, 2, 3, 5, 10, or 20 seconds. You can also select which images to display: all images, images by date, images by folder, movies only, stills only, or by rating.

Index Display: This feature allows you to view four (2 x 2), nine (3 x 3), 36 (6 x 6), or 100 (10 x 10) images at once on the LCD monitor so that you can search for an image quickly.

Image Magnification: When viewing a still picture in single image playback mode, you can magnify the image from 1.5x to 10x. While the image is magnified, you can scroll anywhere around the image.

Rotating Images: You can rotate an image by 90° or 270° clockwise in the LCD monitor.

PictBridge Printing: Using the supplied USB cable, you can connect this camera directly to a PictBridge compliant printer. PictBridge is a standard that allows you to connect a PictBridge compliant camera directly to a PictBridge compliant printer and make prints, regardless of brand.

DPOF Print Settings: On the memory card, you can select which image or images you want to print and how many copies you want. This is convenient for printing images all at once, on optional Canon direct print function compliant printers, on PictBridge compliant printers, or at participating photo labs.

Connections

HDMI Outputs: The camera is equipped with a mini-HDMI jack (Type C) which allows you to connect the camera to an HDTV. The HDMI output terminal is CEC-compatible.

Digital Terminal: The Digital Terminal is a Mini-B 2.0 USB port for connecting the camera to your computer via an optional USB cable (IFC-400PCU, IFC-200U, or IFC-500U) for downloading the recorded images and movies.

Microphone: The camera has a 3.5mm minijack input for connecting an external microphone.

Remote: A 2.5mm sub-minijack is provided for use with the optional RS-60E3 Remote Switch. The wired remote switch has a 2' cord, and is recommended for long exposures and bulb shooting.

Power Options

Battery: The EOS 77D operates on the supplied LP-E17 Lithium-Ion battery (7.2V, 1040 mAh, 7.5Wh). Battery performance decreases when used in temperatures below 32° F. The battery can be charged in the supplied LC-E17 battery charger in approximately 2 hours. Typical battery life for the LP-E17 battery is as follows:

Shooting Method Temperature Shooting Conditions
No Flash 50% Flash
Viewfinder At 73° F 820 shots 600 shots
At 32° F 770 shots 550 shots
Live View At 73° F 310 shots 270 shots
At 32° F 270 shots 230 shots
Movie Shooting At 73° F 1 hr 55 min N/A
At 32° F 1 hr 50 min N/A

Auto Power Off: To save battery power, the camera turns off automatically after a period of non-operation. The Auto Power Off time can be set to 30 seconds or 1, 2, 4, 8, or 15 minutes.

Note: The Auto Power Off function will not activate in Auto Playback Mode.

Optional AC Power: With the optional AC-E6N AC adapter and DR-E18 DC coupler, you can connect the camera to a household power outlet and not worry about the battery becoming exhausted.

Wireless Functions

Wireless Functions: The EOS 77D offers Bluetooth, Wi-Fi, and NFC wireless communications:

  • Bluetooth: You can connect the camera to your smartphone via Bluetooth to facilitate a Wi-Fi connection directly between the smartphone and the camera. You can also use a Bluetooth connection to pair the camera to the optional BR-E1 Wireless Remote Control for remote shooting.
  • Wi-Fi: When connected via Wi-Fi, you can perform a range of tasks wirelessly:
    • Connect to a Smartphone: Connecting to a smartphone lets you view images stored in the camera. You can also operate the camera remotely from a smartphone or camera. The Canon Camera Connect app, available from the App Store or Google Play, must be downloaded to the phone.
    • Transfer Images Between Cameras: You can transfer still images and movies shot with this camera to other Canon cameras with built-in Wi-Fi functions. The camera can be connected to only one camera at a time.
    • Print Images to a Wi-Fi Printer: You can directly print images by connecting the camera with a wireless LAN-compatible printer supporting PictBridge (Wireless LAN). Up to 3 printers can be registered to the camera.
    • Save Images to Connect Station: The optional CS100 Connect Station is a device that allows you to import captured still photos and movies for viewing your TV, tablet, or smartphone, or sharing them over a network. You can easily save still photos and movies to Connect Station by holding the camera close to the Connect Station.
    • Send Images to a Web Service: You can share images with family and friends or share images using a range of Web services via the Canon iMAGE Gateway, a free online photo service for Canon users.
  • NFC Function: The 77D supports NFC (Near-Field Communication) which enables you to connect the camera to a smartphone or Connect Station by touching them together. While playing back images, you can send images to the smartphone by touching an NFC-enabled smartphone to the camera. NFC-enabled smartphones operate on the Android platform running OS version 4.0 or later, and are labeled with the NFC "N-mark." The camera's "N-mark" is located on the bottom of the camera body.

App Compatibility: The Canon Camera Connect app, required for connecting the camera to a smartphone, is compatible with iOS version 8.0 or later and Android devices version 4.1 or later.

Lens Features

Lens: This EOS 77D kit comes with the EF-S 18-55mm f/3.5-5.6 IS STM lens.

Image Stabilizer (IS): The lens has a lens shift type Image Stabilizer. With the Image Stabilizer turned on, you can obtain sharp, natural-looking pictures in dim lighting without using flash or a tripod. The Image Stabilizer is turned on/off through a switch on the barrel of the lens.

Stepping Motor (STM): This new lens features a built-in stepping motor and focus mechanism which delivers smooth and quiet continuous auto-focusing. This is especially helpful when shooting movies in the Movie Servo AF mode, as very little focusing noise is recorded as you shoot.

Auto/Manual Focus Modes: To shoot in auto-focus mode, you must set the focus mode switch on the lens to "AF." To manually focus the camera, you must set the switch on the camera barrel to "MF," and focus by turning the focusing ring.

Optional Accessories: This lens can be used with an optional EW-63C hood and optional screw-on filters (58mm).

Specifications:

  • Focus Length/Aperture: 18-55mm f/3.5-5.6
  • Minimum Aperture: f/22-36
  • Construction: 13 elements in 11 groups
  • Angle of View:
    • Diagonal: 74º20' - 27º50'
    • Vertical: 45º30' - 15º40'
    • Horizontal: 64º30' - 23º20'
  • Maximum Magnification: 0.36x (at 55mm)
  • Minimum Focusing Distance: 0.82' (9.84")
  • Filter Diameter: 58 mm
  • Dimensions:
    • Diameter: 2.791"
    • Length: 3.36"
    • Weight: 7.2 ounces

Software

Software: The following software is available for download from the Canon website for use with the EOS 77D:

  • Digital Photo Professional (Windows/Mac): primarily used for browsing, selecting, and developing RAW images. It has various image adjustment functions in the Picture Style format, and allows you to make adjustments easily. Available for Windows 10, Windows 8.1, Windows 8, Windows 7, Mac OS X 10.10, 10.11, macOS 10.12.
  • EOS Utility (Windows/Mac): an application for making camera settings, transferring images, and remote shooting. Available for Windows 10 (desktop mode only), Windows 8.1, Windows 8, Windows 7, Mac OS X 10.10, 10.11, macOS 10.12.
  • Picture Style Editor (Windows/Mac): allows you to edit Picture Style to your unique image characteristics and save them as original Picture Style files. Available for Windows 8.1, Windows 8, Windows 7, Mac OS X 10.10, 10.11, macOS 10.12.
  • Camera User Guides: The Basic Instruction Manual, Full Instruction Manual and Wi-Fi Function Instruction Manual are available for download.

Our Product Research Team

At Crutchfield, you'll get detailed, accurate information that's hard to find elsewhere. That's because we have our own in-house Product Research team. They verify what’s in the box, check the owner's manual, and record dimensions, features and specs. We stay on top of new products and technologies to help people make informed choices.

Accessories
Q & A

Customer Q&A

Articles
