Network, Bluetooth, & USB Functions
Multiroom Audio Playback
Remote & App Control
Full Disclosure Power (FDP): NAD uses Full Disclosure Power (FDP), the most
demanding criterion for performance measurement. FDP specifies distortion under
the most extreme conditions of low impedance loads and frequency extremes,
rather than the simple and easy 1kHz @ 8 ohms test quoted by many of other
manufacturers. NAD uses this stricter performance criterion because it more
closely matches the demands of real music and real loudspeakers. Maintaining
specified distortion at 4/8Ω and at 20-20kHz is a much more difficult
achievement. The benefit of NAD's Full Disclosure Power is the total elimination
of audible distortion at any listening level. This provides pinpoint imaging and
realism with music and movies alike.
Assignable 7-Channel Amplifier: The T 758 is rated using
NAD's Full Disclosure Power; 60 watts continuous output x 7 channels with all
channels running simultaneously from 20-20,000 Hz into 8Ω loads with no more
than 0.08% THD. The stereo output is 110 watts continuous x 2 channels under the
same conditions. The seven amplifier channels built into the receiver are
typically used for 7.2 channel surround in the main room, but there are various
amplifier configurations to accommodate your home theater setup.
- 7.1ch: The AV receiver's amplifier channels can be
configured as Front Left/Right, Center, Surround Left/Right, and Surround
Back Left/Right for Dolby TrueHD & DTS-HD 7.1ch playback.
- 5.1.2ch: This amplifier configuration provides Dolby Atmos
5.1.2ch playback with Front Left/Right, Center, Surround Left/Right, and
Overhead Left/Right speakers.
Bi-Amp: You can configure the amplifier for front bi-amp operation
to achieve a higher-quality 2-channel sound by connecting the receiver's
front and surround back channels to your main front speakers (if
compatible). Receiver will be limited to 5.1ch surround.
- Zone 2: The receiver's amplifier channels can be
configured as Front Left/Right, Center, Surround Left/Right, and Zone 2 for
Dolby Digital & DTS 5.1ch playback in the main zone and 2ch PCM playback in
the second zone.
Compatible Digital Audio Formats: The NAD T 758 V3 AV receiver supports
the following stereo & multichannel digital audio formats through its HDMI jacks
and optical/coax digital inputs.
| Digital Audio Connector ||Audio
Signal Type || Audio Signal Format |
| HDMI ||2Ch Linear PCM ||2ch, 32-192kHz,
|Multichannel Linear PCM ||8ch, 32-192kHz,
Dolby Digital, Dolby Digital EX,
DTS, DTS ES,
DTS 96/24 |
|High Definition Audio Bitstream || Dolby Atmos,
Dolby Digital Plus, Dolby TrueHD,
DTS:X (firmware update),
DTS-HD Master Audio,
DTS-HD High Resolution,
DTS Express |
| Optical/Coaxial ||2Ch Linear PCM ||2ch, 32-96kHz,
|Multichannel Linear PCM ||6ch, 32-96Hz,
Dolby Digital, Dolby Digital EX,
DTS, DTS ES,
DTS 96/24 |
Immersive Surround Sound: The NAD T 758 V3 AV receiver goes
beyond regular surround with the latest immersive surround sound formats - like
Dolby Atmos & DTS:X (future firmware update).
- Dolby Atmos:
Dolby Atmos surround sound technology
dispenses with channel-based coding in favor of more advanced object-based
coding, giving the soundtrack designer the ability to precisely place sounds
anywhere in the 3-dimensional space. Now you can enjoy this same
award-winning technology at home with the T 758 V3 that lets you to
connect a 5.1 surround sound speaker system and 2 additional overhead
speakers or 2 Dolby Atmos elevation speakers for the ultimate home theater
- DTS:X (future firmware update required): The latest immersive surround sound system,
DTS:X features object-based audio
coding that lets the soundtrack designer place sonic elements anywhere in
the 3D acoustic soundspace, and provides for overhead speakers to deliver a
stunning surround sound experience. Along with DTS:X decoding, the
T 758 V3 features DTS-HD Master Audio decoding and other DTS audio
Post Decoding Formats: The NAD T 758 V3 supports Dolby
Surround & DTS Neo:6 (Music/Cinema) to enhance 2-channel and multichannel
- Dolby Surround:
Dolby Surround offers an enhanced cinema experience to your 2ch and
multichannel movie soundtracks using your existing 5.1ch, 7.1ch or Dolby
Atmos speaker setup. Dolby Surround enhances audio definition by improving
the spatial dimension and overall audio definition of movie soundtracks. It
does this by using four distinct surround zones that provide greater control
over the exact placement of each detail in a movie sound track, so audio can
be matched more accurately to the video on screen; this means more depth and
greater realism for your movies. As a result, individual sounds are clearer
and more distinct. It also improves the surround sound experience across the
entire theater by widening the listening "sweet spot".
- DTS Neo:6: DTS Neo:6 is an advanced matrix decoder that
takes any two-channel source (including television broadcasts, CDs and DVDs)
and expands it into five or six channels. It also provides separate,
optimized modes for stereo music materials and matrix surround motion
picture soundtracks. DTS Neo:6 brings you a more revealing sound from
ordinary stereo and a more expansive home cinema experience.
Speaker & Room Calibration: The T 758 V3 utilizes NAD's SpeakerIQ
speaker setup & the Dirac Live Room Correction Suite to calibrate the receiver
to your loudspeakers and room. Future firmware update via a wireless network
connection is required (available summer of 2017).
- NAD SpeakerIQ: NAD SpeakerIQ is an easy way for you to set up
your home theatre within minutes. Using the supplied microphone, and with
the push of a button on the included remote control, NAD SpeakerIQ sends
test signals to the various speakers in the room and makes any necessary
adjustments to the AV receiver based on measurements of the distance between
speaker and listening position, loudness, and frequency response of audio
signals from each speaker.
- Dirac Live: With Dirac Live, a state-of-the-art digital room
correction technology, you can build the perfect listening environment that
corrects for both the timing and colorations in sound using the supplied
microphone and its powerful software.
EARS: Two-channel recordings, whether stereo or
surround-encoded, are reproduced with proprietary NAD surround processing with
signals output to the front left/right, center and discrete left/right surround
channels, plus subwoofer. EARS extracts the natural ambience present in nearly
all well-produced stereo recordings. It does not synthesize any ambience or
other sonic elements and thus remains truer to the sound of the original musical
performance than most other music-surround options. EARS offers realistic,
stable "front-stage" sonic imaging and spacious but unexaggerated ambient
"virtual acoustics" that remain faithful to the original recording. Select EARS
for listening to stereo music recordings and broadcasts. EARS produces a subtle
but highly natural and believable ambience from nearly all "natural-acoustic"
stereo recordings. Typically, these include classical, jazz, and folk genre.
Stereo Modes: The NAD T 758 also provides two-channel stereo
and multi-channel stereo playback, as well as an analog bypass stereo mode.
- Stereo: All output is directed to the front left/right
channels. Low frequencies are directed to the subwoofer if one is present in
the Speaker settings. Select 'Stereo' when you wish to listen to a stereo
(or monaural) production, such as music CD or FM broadcast, without surround
enhancement. Stereo recordings whether in PCM/digital or analog form and
whether surround-encoded or not encoded, are reproduced as recorded.
Multi-channel digital recordings (Dolby Digital and DTS) are reproduced in
"Stereo Downmix" mode via the front left/right channels.
- Enhanced Stereo: All recordings are reproduced in
stereo via the maximum speaker complement. Enhanced stereo can be useful for
maximum volume from all channels or for multi-speaker background music
(cocktail party) listening. For this mode, Front, Center, Surround and Back
speakers can be turned ON/OFF as desired.
- Analog Bypass: All analog signals remain in the analog
domain without analog-to-digital conversions. At Analog Bypass, the DSP
circuitry is bypassed but full tone control functions remain. 'Bass
management' or Speaker settings are also not in effect as these are DSP
7.1Ch Input & 7.1ch Preout: The T 758 V3 features a 7.1
Channel input (Front left, Front right, Center, Surround left, Surround right,
Surround Back left, Surround Back right, and Subwoofer) for connecting an
outboard processor or multi-channel analog source. The T 758 V3 also features
Front left, Front right, Center, Surround left, Surround right, Surround Back
left, Surround Back right and Subwoofer pre-outs to connect the receiver to
external power amplifiers.
Binding Post Speaker Terminals: The AV receiver has binding
post speaker terminals for the front, center, surround, and surround back
channels. The surround back speaker channels can also be used for Zone 2
speakers. The binding posts can accept bare wire, pin connectors, and single
banana plugs. The terminals are spaced too far apart for dual banana plugs and a
collar surrounding the terminals prevents the use of spade connectors.
Headphone Output: The NAD AV receiver features a 1/4" stereo
headphone jack on the front-panel for connecting an optional pair of headphones.
The unit's speaker outputs are automatically muted when a set of headphones is
Front-Panel Inputs: The NAD T 758 V3 is outfitted with an optical
(toslink) digital connector and stereo analog RCA jacks on the front-panel for
easy connection of external analog & digital audio devices.
HDMI 2.0a: The NAD T 758 V3 is equipped with three HDMI 2.0a inputs
and one HDMI 2.0a output with supports for UltraHD 4K video, HDCP 2.2, 4:4:4
color gamut, and High Dynamic Range (HDR) support.
- 4K/60Hz: The T 758 V3 supports up to 4K (3840x2160
pixels) video @ 60 frames per second on
all of its HDMI inputs and output (pass-through only - no upscaling). It
will also pass a 480i, 480p, 720p, 1080i, or 1080p video signals via HDMI.
- HDCP 2.2: All of the receiver's HDMI jacks support HDCP
2.2, which fully complies with the latest copyright protection standard for
4K video transmission.
- 4:4:4 Color Subsampling: All of the receiver's HDMI
jacks support RGB, YCbCr 4:4:4, YCbCr 4:2:2, and YCbCr 4:2:0 color
subsampling (@ 60Hz or 50Hz). With 4:4:4 color subsampling, luminance
(brightness) and chroma (color) are sampled at the same rate; resulting in
an RGB color palette as big as the video sampling rate for a video image
with more colors, plus greater color accuracy and detail.
- High Dynamic Range (HDR): High Dynamic Range (HDR)
provides enhanced picture quality by simultaneously enabling greater detail
for both the dark and bright parts of an image. HDR reproduces a greater
dynamic range of luminosity or brightness levels, creating greater contrast.
This increased contrast reveals the subtle nuances of the image, from
detailed blacks and shadows to the brightest whites and colors, plus greater
depth. The receiver supports HDR 10 (no support for Dolby Vision or HLG).
Audio Return Channel (ARC): This feature of the AV receiver's HDMI
monitor output allows audio to be sent from your compatible TV to the receiver
through the same HDMI cable already being used to send audio and video to your
TV. This eliminates the need for extra cables connected to your television.
HDMI Pass-through: When the T 758 V3 is in standby mode
(power off), the HDMI source signals will continuously pass through the receiver
to the TV. The HDMI Control (CEC) feature must be enabled in order for HDMI
Pass-through to work.
3D-Ready: With the advent of 3D media, it is important to
own a receiver that passes 3D video signals. The T 758 V3 is able to pass 3D
signals from your Blu-ray player to your TV via the HDMI connection.
Lip Sync Delay: Video signals may take longer to process
than audio signals, depending on the connected video equipment. The audio signal
can be delayed up to 120ms to synchronize with the video signal.
Network, Bluetooth, & USB
BluOS Kit: The included BluOS Kit adds wireless network audio,
Bluetooth audio streaming, dual USB ports, and wireless multiroom audio playback
to the NAD T 758 V3 receiver. The BluOS kit plugs into the AV receiver's
rear-panel USB port.
- WiFi Dongle: A WiFi (802.11 b/g/n) dongle is pre-installed in the
BluOS Kit. If you experience poor WiFi reception, unplug the WiFi dongle and
plug in the included 23" USB extension along with the WiFi dongle to extend
the BluOS Kit's WiFi range.
- Bluetooth Dongle: A Bluetooth dongle is pre-installed in the
- Dual USB Ports: The BluOS kits provides two USB MSC (mass storage
class) device compatible ports.
Note: The T 758 V3 and the included BluOS Kit do not include a wired Ethernet connection.
BluOS Network Audio Streaming: With the BluOS Kit installed,
the T 758 V3 offers
wireless network audio playback, letting you stream lossless music to your home
theater system from local libraries, tune into Internet Radio stations, and
access popular online music streaming services. You can control the music from
anywhere in the house using the
Controller App for Apple (iOS 7.0+) & Android (OS 4.0+) devices, plus
Windows (Vista-up) & Mac computers (OS X 10.7-up).
- Compatible Audio Files: The T 758 V3 with BluOS
Kit supports both low-res and high-res audio files - including AIFF/ALAC/FLAC/MQA/WAV
(24-bit/192kHz), WMA-Lossless (24-bit/96kHz), and MP3/WMA/AAC/OGG
(320kbps/48kHz). BluOS has been designed to
work with today's larger music collections, and has indexed libraries up to
100,000 songs in demonstrated practice (this will depend on the music's metadata
& artwork). BluOS also offers gapless playback by default for all supported
file music types.
- Online Music Services: The T 758 V3 with BluOS Kit lets you access select online music services &
internet radio - including
Slacker. The BluOS Controller app on your Apple iOS or Android device
will serve as the controller for these apps and provide song/artist information
with Album Art.
- Music Library From Your Mobile Device: From the BluOS
Controller App, you can stream music directly over WiFi from your Apple iOS or
Android device to the NAD AV receiver and the rest of your BluOS components
around your home. The app gives you complete control of your compatible mobile
device's music library with song/artist information and album art.
- Computer Audio: Thanks to BluOS, the T 758 V3 will pull
music from an existing digital music library across the network on your Windows
PC (Vista-up) or Mac computer (OS X 10.8-up) using Windows or SMB File Sharing
(SAMBA) and the BluOS Controller App for Windows & Mac.
Note: The T 758 V3 does not offer a built-in AM/FM tuner. The only way to
access AM/FM stations is through the
TuneIn internet radio
service using the BluOS
Bluetooth Music Streaming: Thanks to the included BluOS Kit,
you can wirelessly pair and
connect instantly to the T 758 V3, allowing you to stream stored
music and music apps wirelessly from your Bluetooth-enabled source device; like
your smartphone, tablet, laptop or desktop computer. The high performance
Bluetooth aptX codec is fully supported for true CD-quality sound from aptX-compatible
Bluetooth devices (like Android OS 4.0+ smartphones & tablets). There is no
control or song/artist info display from the NAD AV receiver.
Dual USB-A Ports: The included BluOS Kit gives the T 758 V3
two USB (type-A) ports to directly connect your USB mass storage class (MSC)
device; such as a thumbdrive or external hard-drive. The unit's USB ports
supports high resolution audio and compressed music playback from these
compatible USB devices formatted in FAT 32.
| Compression || File Type || Sampling Frequency || Bit Rate or Bit Depth |
| Compressed || Lossy ||MP3 ||16-48kHz ||192-320
| Lossless ||WMA-Lossless ||up to 96 kHz ||up to 24-bit |
|FLAC ||192 kHz ||up to
| Uncompressed ||AIFF ||up 192 kHz ||up to
Note: The USB port is not compatible with the direct connection of an
Apple iPod/iPhone/iPad or Android devices.
Multiroom Audio Playback
BluOS Wireless Multiroom Audio: The included BluOS Kit enables the
NAD T 758 V3 to become part of the
BluOS by Bluesound wireless multiroom audio
eco-system, allowing you to stream and control your local and online music
effortlessly from anywhere in your home with the BluOS App on your compatible
Apple iOS or Android mobile device, as well as Windows PC or Mac computer over a
wireless WiFi network connection. BluOS offers the ability to group other BluOS compatible wireless speakers and music players (sold
separately) with the T 758 V3 for multiroom audio throughout your home. You can
play the same audio source in every room or any combination of rooms you choose,
including a different song in every room.
- High Res Synchronization: BluOS automatically synchronizes
audio playback between multiple BluOS devices so that your music (up to
24-bit/192kHz Hi-Res audio) coming from different rooms is perfectly in sync
and always sounds amazing.
- Compatible Sources: The following sources can be distributed through the BluOS multiroom audio system -
All of the receivers analog & digital inputs (excluding HDMI); TuneIn Internet Radio, BluOS music apps & Spotify Connect; Windows PC & MAC computer audio files;
Bluetooth & USB audio; plus music libraries stored on your Apple iOS or
Android mobile device.
- Rooms/Grouping: Up to 16 BluOS devices can be connected in a
strictly wireless environment. If you want to connect more than 16 BluOS
devices, you will need to connect the other BluOS devices to your network
using a wired connection. BluOS can then control up to 64 devices in a
strictly wired environment.
Note: The NAD T 758 V3 only supports a single BluOS music
stream. If you desire a second BluOS music stream through the receiver's
multizone output, you will need to connect the
Bluesound Node 2 (sold separately) to one of the AV receiver's analog inputs.
Zone 2 (Line-Level or Speaker-Level): Zone 2 allows stereo
audio playback of another source connected to the receiver in another room of
your home via RCA line-level output or speaker-level output. When using the T
758 V3 to power speakers in a second room of your home, the main zone is
restricted to 5.1-channels. When using the receiver's line output terminals for
the second room you need an additional amplifier to power your Zone 2 speakers;
the main Zone of the receiver remains 7.1-channel. The volume of Zone 2 can be
controlled by the NAD receiver using either configuration or from your add-on
amplifier when using the line-output.
- Compatible Sources:
Analog audio inputs only,
- Incompatible Sources: HDMI audio/video,
Optical/Coaxial digital audio, BluOS audio (including Network,
Bluetooth, and USB).
Remote & App Control
BluOS Controller App: The
Controller App turns your Apple iPod/iPhone/iPad (iOS 7.0+), Android smartphone/tablet
(OS 4.0+) Windows (Vista-up) PC or Mac (OS X 10.7-up) computer
into a full-featured remote control for the BluOS wireless music system. The
BluOS Controller App on your compatible device uses your home's WiFi network to
connect with BluOS devices, so you can play all the music you love anywhere in
your home for a wireless multiroom music experience. Get on-demand access to
your music libraries on your home network, stream live Internet radio from
almost any place in the world, or listen to one of the many music services
available on BluOS, all from the palm of your hand with the easy-to-use BluOS
NAD AV Remote App: Download the free
NAD AV Remote App from the Apple Apps Store to control the T 758 V3 from
your Apple iOS 6.0+ device (including iPod touch, iPhone, & iPad). Control,
adjust and select basic functions - including power, volume, source, and
listening mode for all zones with the touchscreen of your compatible iOS device.
Note: The NAD AV Remote App is currently not compatible with Android.
Dual IR Remotes: The T 758 V3 includes an IR remote (AVR 4)
for wireless operation of the AV receiver and other NAD AV components. The
included Zone 2 IR remote (ZR 7) controls the Zone 2 features of the T 758 V3;
it allows control of the Zone 2 volume and source selection, as well as other
applicable functions. The ZR 7 remote will work from a different room using an
IR sensor and hub, or the IR sensor of a compatible NAD component in the second
zone (either must be wired back to the location of the T 758 V3).
HDMI Consumer Electronic Control (CEC): The NAD T 758 V3 supports HDMI
Consumer Electronic Control (CEC), which allows you to operate external
components via HDMI with one remote. If your TV or other external components
support HDMI control, you can use the remote controls of those devices to
operate some of the AV receiver's functions, and to synchronize this unit with
the operation of those devices. You can use the following operations with the
remote control of any of the connected HDMI Control compatible devices.
- Power synchronization (On/Standby)
- Volume control, including Mute
- Changing the volume of the audio output signal device (either the TV or
Remote Connections: The NAD T 758 V3 is outfitted with the
following remote inputs and outputs for custom integration.
- DC Trigger: The +12 volt output trigger (3.5mm) is
programmable and can engage when the receiver is turned on, when Zone 2 is
turned on, or when a specific source is used. The output can also be delayed
up to 15 seconds.
- IR In/Out: One IR input (3.5mm) & Two Outputs (3.5mm)
allow you to connect the T 758 V3 to an infrared repeater and other
components with IR inputs.
- RS-232C: The RS-232C port is to be used in conjunction
with an external controller; AMX, Crestron or a compatible PC using NAD's
proprietary PC software.
Modular Design Construction (MDC): MDC ends the frustration of having
to replace your entire AV surround sound receiver just to keep pace with the
ever-changing world of AV electronics. NAD's most important recent innovation,
MDC battles technology obsolescence by allowing you to upgrade the T 758 V3 with
new connectivity and features as new technology becomes available. MDC places
all the input circuitry on easily removable plug-in cards; your investment is
protected because a single card, rather than the entire receiver, can be
replaced when a new format is introduced.
OSD (On-Screen Display): In addition to the unit's
front-panel display, the T 758 V3 employs a simple, self-explanatory on-screen
display menus system which will appear on your connected television. The OSD is
available through the unit's HDMI output only.
5 Custom AV Presets: Five AV presets can be stored with customized settings
for listening mode, DSP options (lip sync delay), tone control, speaker setup,
and front panel display.
Input Rename: Inputs can be renamed to match your particular connected
Switched AC: The maximum output on the 3-prong switched AC
outlet on the rear panel is 120 watts/1 amp.
Firmware/Software Updates: Firmware & software updates are performed
via the receiver's wireless network connection.
