About the Infinity Reference 6022i
Install Infinity Reference 6022i 6-1/2" speakers in your car and change the way you think about long road trips and traffic jams. Reference speakers play your music boldly and cleanly, making your listening time more enjoyable.
Reference speakers feature low impedance so they extract maximum power from any amplifier or car stereo. Infinity makes their Plus One+ woofers 30% larger than other speakers in the same size category. As a result, you'll enjoy deeper bass and higher efficiency for an impressive performance.
The textile dome tweeters feature oversized voice coils that match the tweeters' diameter, a design that provides more surface area for heat dissipation and allows higher power handling. You can adjust the sound to your liking with the tweeter level control. In addition, you can swivel the tweeters up to 350 degrees, aiming them directly at you for a more focused soundstage. You'll hear smoother, more accurate response, with more sparkle and detail in your music.
Infinity makes sure that your installation stays stress-free by including Intermount III, a proprietary mounting system that allows you to install these 6-1/2" speakers in a variety of 6" to 6-3/4" factory locations. You'll also find adapters that fit many domestic and imported cars.
Important Note: These Infinity speakers use a low impedance design to pull more power safely from your car stereo or amplifier. This design is compatible with virtually all factory and aftermarket stereos.
Priced per pair
Product highlights:
- 2-way car speakers for 6-1/2" and 6-3/4" locations (pair)
- Plus One+ injection-molded polypropylene (IMPP) woofer cone with hi-roll rubber surround
- 1" rotating UniPivot textile dome tweeter
- Intermount III mounting system for fit in 6-3/4" openings
- True Four Ohm Impedance technology: speaker's 2-ohm impedance combines with speaker wire impedance for a 4-ohm load
- compatible with virtually all factory or aftermarket car stereos
- power range: 2-60 watts RMS (180 watts peak power)
- frequency response: 53-21,000 Hz
- sensitivity: 93.4 dB
- top-mount depth: 1-7/8"
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # REF6022I
What's in the box:
Infinity Reference 6022i owner's manual
- Two 2-way speakers
- 2 Grilles
- 2 Grille frames
- 2 Metal mounting rings
- 2 Plastic mounting rings (includes GM/Chrysler 6-3/4G)
- Eight 1" Self-tapping screws
- 8 Machine screws
- 8 Speed clips
- 2 Strips of self-adhesive foam
- Instructions
- Warranty card
Featured video:
Featured review
Excellent sound quality, reasonable price, easy to install. What more could you want. Matched them up with the factory Infinity Gold stereo in my wife's 96 Grand Cherokee. I put these in the front doors, we'll see how durable they are. The factory speakers lasted about 9 years.
Basil from Stafford, VA
12 reasons to shop with us
#2
Free 2-day shipping
Plus most orders go out the same day.
REVIEWS
Customer reviews
Loading reviews...
Infinity Reference 6022i reviews
Average review:
Thanks for submitting your review
Customer photos
More details on the Infinity Reference 6022i
Features & specs
| General | ||
|---|---|---|
| Speaker Size | ||
| Design | 2-way | |
| Tweeter Design | 1" Dome | |
| Impedance (Ohms) | 2.65 | |
| Tweeter Composition | Textile | |
| Woofer Composition | IMPP | |
| Woofer Surround | Hi-roll rubber | |
| Parts Warranty | 1 Year | |
| Labor Warranty | 1 Year | |
| Specifications | ||
| Sensitivity (1W at 1 meter) | 87.5 | |
| Sensitivity at 2.83 volts | 93.4 | |
| Frequency Response | 53 - 21k Hz | |
| Minimum RMS Wattage | 2 | |
| Maximum RMS Wattage | 60 | |
| Peak Power Handling (Watts) | 180 | |
| Top-mount Depth (Inches) | 1 7/8 | |
| Bottom-mount Depth (Inches) | N/A | |
| Cutout Diameter or Length (inches) | 5 | |
| Mounting Height (Inches) | 0.967 | |
Product Research
Features
Plus One+ Woofer Cones: Each speaker uses a cone significantly larger than other speakers of the same size. This is accomplished by using a unique basket design and hi-roll surround. The Plus One+ design offers greater bass output and a significant increase in efficiency.
Woofer Materials: Each woofer is constructed from Injection-Molded Polypropylene. This process of cone molding assures a uniform cone thickness for superior linearity and clarity. It is also lighter weight and more rigid for decreased distortion and improved bass response.
Hi-roll Rubber Surrounds: The hi-roll rubber surrounds allow the woofers a greater range of movement, resulting in longer X-max and more bass output.
Textile Dome Tweeters (UniPivot Design): Each speaker uses an edge-driven textile dome tweeter for smooth, accurate highs. The UniPivot design allows the tweeter to be pointed at the listeners location even when the speaker is mounted off axis. This optimizes the stereo image and ensures a more uniform response. The tweeter housing can be turned approximately 315 degrees.
Note: The tweeters are not made to turn 360 degrees. If they are turned 360 degrees or more, they will be damaged.
Tweeter Level Control: A switch on the front of the tweeter allows you to boost the tweeter output 3dB, useful if the speakers are mounted low in a door where high frequencies are easily absorbed.
True Four Ohm Impedance Technology: The speaker's 2.65-ohm impedance combined with the impedance of your speaker wire provides a true 4-ohm load to your connected head unit or amplifier.
Mounting: Infinity's mounting system allows the 6022i speakers to fit in 6-1/2" and 6-3/4" applications. Metal and plastic adapter rings are included for each speaker.
