About the Infinity Reference REF607F

Product highlights:
- 6-1/2" 2-way speakers (pair)
- Plus One+ polypropylene woofer cone with hi-roll rubber surround
- 1" textile, edge-driven dome tweeter with 3.0 dB level adjustment
- True Four Ohm Impedance technology
- speaker's 3-ohm impedance combines with speaker wire impedance for a 4-ohm load compatible with virtually all factory or aftermarket car stereos
- compatible with virtually all factory or aftermarket car stereos
- handles up to 60 watts RMS (180 watts peak power)
- frequency response: 53-21,000 Hz
- sensitivity: 93 dB at 2.83V
- top-mount depth: 2.063"
- grilles not included
- warranty: 1 year
- MFR # INFSPKRF607FUS
- Item # 108R607F
- California customers: Please click here for your Proposition 65 WARNING.
What's in the box:
Infinity Reference REF607F owner's manual
If you need assistance accessing this owner's manual, please give us a call.- Two 2-way speakers
- 2 Plastic mounting rings
- Eight 1" Screws
- Eight 1/2" Screws
- 8 Speed clips
- 2 Adhesive backed foam gaskets
- Instruction manual
- Template on box
Featured video:
More details on the Infinity Reference REF607F

Features & specs
General | ||
---|---|---|
Speaker Size | 6 1/2 | |
Driver Design | 2-way | |
Woofer Design | Plus One Cone | |
Woofer Material | Polypropylene | |
Woofer Surround | Rubber | |
Midrange Design | --- | |
Midrange Material | --- | |
Tweeter Design | Edge-Driven Dome | |
Tweeter Material | Silk | |
Super Tweeter Design | --- | |
Super Tweeter Material | --- | |
Impedance (Ohms) | 3 | |
Weather-resistant | No | |
Grilles Included | No | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year | |
Specifications | ||
Sensitivity (1W at 1 meter) | N/A | |
Sensitivity at 2.83 volts | 93 | |
Frequency Response | 53 - 21k Hz | |
Maximum RMS Wattage | 60 | |
Peak Power Handling (Watts) | 180 | |
Top-mount Depth (Inches) | 2 1/8 | |
Bottom-mount Depth (Inches) | N/A | |
Cutout Diameter or Length (inches) | 5 | |
Mounting Height (Inches) | 0.7 | |
Frame Width | 6.215 | |
Frame Length | 6.215 |
Product Research
Features
Plus One+ Woofer Cones: Each speaker uses a cone larger than other speakers of the same size. This is accomplished by using a unique basket design and hi-roll surround. The Plus One+ design offers greater bass output and an increase in efficiency.
Angled Tweeter: The tweeters are mounted at an angle (fixed), so they can be directed toward the listeners to improve imaging.
Tweeter Level Control: A switch on the front of the tweeter allows you to boost the tweeter output to +3dB, useful if the speakers are mounted low in a door where high frequencies are easily absorbed.
High-Output Design: The 3Ω voice coil design compensates for the high in-line resistance of small gauge factory wiring, extracting more power from factory (or aftermarket) receivers.
Mounting: Without an adapter, the 607FSL speakers fit standard 6¾" applications. Given their required cutout, they will also fit 6½" applications without an adapter, but often require drilling new screw holes. Using the included adapter brackets they can be mounted in a variety of 6½" and 6¾" applications, without any modification. Please enter your vehicle information to confirm fit.
The Infinity Reference REF607F replaces these items:
- Plus One+ polypropylene woofer with rubber surround
- 1" edge-driven textile dome tweeter
- handles up to 60 watts RMS
