About the JBL Stage Marine 6

Product highlights:
- 6-1/2" 2-way marine speakers (pair)
- durable, powerful polymer woofer cone
- grille-mounted balanced-dome tweeter
- one-piece cast polymer basket
- IPX5 rated for water resistance
- available in Gray or White
Specs:
- power handling: 60 watts RMS (180 peak)
- sensitivity: 90 dB at 2.83 volts
- frequency response: 60-20,000 Hz
- impedance: 4 ohms
- warranty: 1 year
- MFR # JBLMARSPKST6WHTAM
- Item # 109STAGM6W
- California customers: Please click here for your Proposition 65 WARNING.
What's in the box:
JBL Stage Marine 6 owner's manual
If you need assistance accessing this owner's manual, please give us a call.- Two 2-way marine speakers with fixed white polymer grilles
- Two 6" Wiring harnesses (quick slides on one end and tinned wire on the other)
- Ten 1-1/8" Stainless-steel screws (3mm Allen head)
- 3mm Allen head bit
- 10 Stainless-steel speed clips
- Adhesive backed foam gaskets
- Installation manual (English/ French/ Spanish/ Portuguese/ Russian)
- Template on box
More details on the JBL Stage Marine 6

Features & specs
General | ||
---|---|---|
Speaker Size | 6 1/2 | |
Design | 2-way | |
Tweeter Design | 1/2" Balanced Dome | |
Tweeter Composition | --- | |
Woofer Composition | Polypropylene | |
Woofer Surround | Rubber | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year | |
Specifications | ||
Sensitivity |
90 dB at 2.83 volts | |
Frequency Response | 60 - 20k Hz | |
Max RMS Power Handling | 60 | |
Peak Power Handling (Watts) | 180 | |
Impedance (Ohms) | 4 | |
Top-mount Depth (Inches) | 2 3/4 | |
Bottom-mount Depth (Inches) | N/A | |
Cutout Diameter or Length (inches) | 5 1/16 | |
Bolt Circle | --- |
Product Research
Features
Tweeters: The tweeters are bridge mounted to the grilles, rather than to a pole piece, thus there is no chance of water leaking through the woofer cone.
Size: With a required cutout diameter of approximately 5" and a frame diameter of approximately 7", these speakers fit into the openings for many standard 6½" and 6¾" car speakers, but the screw hole pattern is different. Because the grille is not designed to be removed, the mounting height is also greater than most car speakers. For these reasons, the speakers won't fit in most car applications.
Stainless Steel Hardware: The provided mounting screws are stainless steel.
