Kenwood KDC-MP925

Features
CD Changer Controls
Note

Features

3D MASK Pro: The KDC-MP925 features the 3D MASK Pro 2-piece control and display system. It has a motorized fold-out control panel, and an extra-large high-resolution color display with dot-matrix graphics. The angle of the display panel and the control panel can be adjusted for maximum visibility and convenience. The display panel also includes Soft-Key controls for several menu functions. When accessory power to the unit is turned off, the control panel folds up to reveal a plain black panel. For additional security, the back part of the control panel is detachable. Note: When a disc is being loaded/ejected, the control panel protrudes 3-1/4". Please make sure you provide enough clearance in front of the receiver for loading and unloading discs.

Multi-Function Key System: The radio preset keys (2-5) double as multi-function "soft key" controls. The lower portion of the display shows the function of the soft key directly below it. The main soft key functions include Audio, Display and Panel controls. Once the main function is chosen, other sub-menus are revealed. Preset 6 also doubles as a "return" key, allowing you to go back to the main soft key menu. In addition, the rotary volume knob can be programmed for use with the menu system, audio control and setup, display control, station/disc naming and folder search functions.

3-D High Resolution Display: The unit features a 3-D high resolution display with 8 tone gradations and fluorescent backlighting. The front panel features a full dot matrix display featuring 6912 total pixels (192 dots wide x 36 dots high). This fine pitch dot matrix display is easy to read and offers large motion graphics.

Selectable Display Modes: The unit's large display features a fine-pitch dot matrix readout with 4 display modes to choose from, each with numerous graphics, fonts, wallpapers, and text displays. Text displays can include all CD Text and ID3 Tag info, station names and frequencies, disc/track titles, track/file number, and track/file elapsed time, and can be displayed along with the graphic display.

MP3/WMA Playback: This unit can play MP3 and WMA files recorded on CD-ROM, CD-R, and CD-RW discs in ISO9660 Level 1/Level 2, Joliet, and Romeo formats. Each disc should have a maximum of 8 directory levels, 50 folders, and 255 files per folder. A total of up to 512 MP3/WMA files and folders can be played back by this unit. During MP3/WMA playback, the unit displays any recorded ID3 Tag information.

Sirius Satellite Radio Controls: This unit can control the optional Kenwood Sirius Satellite tuner (item #113SR903). In addition to the Sirius tuner, you will need an antenna and subscription in order to receive Sirius Satellite Radio programming. The Kenwood Sirius radio tuner has a CD-changer pass-through, allowing the connection of an optional Kenwood CD changer in addition to the Sirius tuner with only one connection to the head unit.

Quad 1-Bit D-A Converters: The KDC-MP925 features Integrated Quad 1-Bit Digital-to-Analog converters for superb CD sound. Four D-A converters, two for each channel, improve playback sound quality, including musical detail and resolution. Using 2 converters for each channel reduces distortion by half.

Zero-Bit Mute: This unit features independent left and right channel zero-bit mute circuits. During silent passages, the digital-to-analog converter is shut off, yielding absolute silence between songs.

Built-in Amplifier Mute: If this unit's internal amplifier is not being used, it can be switched off to enhance the quality of the preamp output signal quality.

System Q Sound Control: Seven EQ curves are preset into memory, allowing you to recall the best preset EQ curve for different types of music. The preset curves are named "Natural", "Rock", "Pops", "Easy", "Top 40", "Jazz", and "SRS Wow" (see below). In addition, you may store your own settings under the "User Memory" EQ curve. Each preset has its own bass, middle, and treble level settings.

SRS WOW: The KDC-MP925 is equipped with SRS WOW, a technology developed by SRS (Sound Retrieval Systems) Labs, which restores the loss that occurs to compressed audio delivered over the Internet and broadcast mediums, and reduces the hollow-sounding effects caused by smaller speakers. SRS WOW incorporates other SRS technologies such as TruBass, Focus, and SRS for improving the sound of CDs and radio:

• TruBass: uses harmonics to enhance the bass frequencies (settings: on/off)
• Focus: adjusts the sound image by changing the vertical position of the speakers virtually (settings: low/high/off)
• SRS 3D: creates a natural 3-dimensional sound field (settings: on/off)

SRS WOW can be accessed through the Audio menu or the System Q EX menu. There are three settings for SRS WOW: low, high and off. TruBass, Focus, and SRS can be independently set, or are set according to preset values of SRS WOW.

Speaker Settings: The Speaker Setting function tailors the System Q Sound Control settings according to the type of speakers in your vehicle. You may select a Speaker Setting of "SP OFF" (flat), "SP O.E.M." (for OEM factory speaker systems), "SP 6*9/6" (for systems with 6" and 6"x9" speakers), or "SP 5/4inch" (for systems with 4" and 5" speakers).

Dual Zone Audio Control: When an external audio source is connected (CD changer, Sirius Radio, or Auxiliary Input source), the KDC-MP925, with its Dual Zone Audio Control, allows you to play the external audio source in one zone, while at the same time play an internal audio source (CD or tuner) in another zone. When Zone 2 is switched on, the output of the front channels becomes different than the rear channel output. You can choose whether you want the external audio source to play through the front channels (sending the internal source to the rear channels), or through the rear channels (sending the internal source to the front channels). When operating in Dual Zone mode, audio adjustments can only be made to the internal source. Note: If the rear preamp outputs are set to "non-fading", there will be no audio from that output in the dual zone mode.

High-pass Filter: The KDC-MP925 has an adjustable 12dB/octave high-pass filter for the front and rear channels. You can independently choose the cutoff frequency for the front and rear channels from 40Hz, 60Hz, 80Hz, 100Hz, 120Hz, 150Hz, 180Hz, 220Hz or Thru (no filter).

Subwoofer Output: This unit has a preamp level subwoofer output with an adjustable low-pass filter, phase and level control. You can choose the LPF cutoff frequency from 50Hz, 80Hz, 120Hz or Thru (no filter). You can select between normal (0°) and reverse (180°) phase, and adjust the subwoofer output level from -15 to +15 in increments of 2.

3-Band Equalizer: You can independently adjust the level of three audio bands from -8dB to +8dB: Bass (100Hz), Midrange (1kHz) and Treble (12.5kHz).

Source Tone Memory: This feature allows you to store bass, middle and treble tone settings for each source (CD, FM, AM, Changer, Aux).

CR-2 Tuner: This unit uses Kenwood's CR-2 tuner provides high signal strength for clear radio reception. The tuner incorporates an Automatic Noise Reduction Circuit (ANRC), along with the Clean Reception System Circuit (CRSC), for improved rejection of distortion due to multi-path. You can choose one of three tuning modes: Auto 1 (seek tuning), Auto 2 (cycles through and tunes the selected band's preset stations only with each button press), or Manual.

HD Radio Ready: The KDC-MP925 is HD Radio ready. With an optional Kenwood HD Radio tuner (item # 113KTCHR10), you will be able to receive digital AM/FM broadcasts from local stations where available. This new technology will significantly improve audio quality and reception, as well as include information such as artist name and song titles or traffic news, viewable on the receiver's display.

Radio Data System (RDS): The unit's tuner features RDS (Radio Data System). RDS is a service used by some radio stations to transmit data outside of normal radio broadcast signals. When an RDS station is received, you can immediately find out what kind of data is being transmitted by looking at the program service name which appears in the display after the frequency. RDS features an emergency transmission function which interrupts regular programming to broadcast an emergency announcement (such as a tornado or severe storm). There is also a switchable Traffic Information function, which will automatically tune a traffic bulletin when it is broadcast, even when you're not listening to the radio.

Clock/Calendar: The built-in clock can be manually set or, through a tuned RDS station, automatically synchronized with the station's time data. In addition to the clock, this unit can also display the current date in one of seven modes.

Clean Reception System Circuit (CRSC): This circuit controls multi-path distortion by reducing stereo separation. As stereo separation is reduced, multi-path has less effect on the radio signal, improving reception in areas with tall buildings and mountains. The CRSC feature can be turned on or off.

Direct Access Tuning: When using the remote, you can directly access any radio station by entering the frequency on the numeric keypad.

Station Name Preset (SNPS): This feature allows you to assign names to radio stations. Up to 32 FM stations and 16 AM stations can be named. Each name can be up to 8 characters in length.

Disc Name Preset (DNPS): You may assign names to discs played in the internal CD player. Each disc name can be up to 8 characters long, and the receiver has a memory capacity for up to 30 discs. (See below for further DNPS features with CD changers.)

Volume Offset Control: The level of each source may be independently adjusted to prevent radical leaps in output volume when switching from one source to another. The available settings range from -8 to 0.

Attenuator With Smooth Volume Return: The attenuator immediately lowers the volume by a preset level. Smooth Volume Return gradually increases the volume to the original level when the ATT button is pressed a second time, eliminating a jarring change in volume.

CD Read Setting: If there is a problem with the CD player reading a disc with a special format, you can switch to a second CD Read setting which "forces" the player to read the disc. CD Read setting 1 is for normal CDs and MP3 discs, while CD Read setting 2 cannot read MP3 discs.

Disabled System Indicator: A red indicator will blink on the unit after the control panel is removed, warning potential thieves. This feature can be turned On or Off.

Security Code: You may program the unit with a 4-digit security code. Once the unit has been programmed with a security code, the code must be entered to use the unit after it has been disconnected from power.

Display Dimming: This unit is equipped with an orange/white wire that Kenwood calls an illumination lead, however, it acts as a dimmer lead. When the illumination wire of this unit is connected to the headlamp circuit of your vehicle, and you turn your lights on, the display will dim to a preset level. The display brightness is not affected by the vehicle's dimmer control.

Faceplate Finish: The faceplate and trim ring feature a flat black finish. The control panel, when in the open position, reveals a silver and black finish.

Remote Control: The KDC-MP925 comes with the RC-505 wireless remote control, a 22-button full-function remote with a 10-key number pad. It is powered by 2 "AA" batteries (supplied). The dimensions of the remote are: L=5.488", W=1.75", D=1.115".

CD Changer Controls

Compatibility: This unit is directly compatible with Kenwood changers manufactured in 1998 or later. If the changer has an O-N switch, the switch will need to be set to the "N" position. If you have a Kenwood changer manufactured before 1998, you will need the KCA-S210A switching adapter. Changers manufactured before 1994 require the CA-DS100 converter cord (113CADS100) and the KCA-S210A switching adapter.

Changer Controls: In addition to basic disc navigation features, this unit has the following changer controls: direct disc access (using the remote), direct track access (using the remote), track intro scan, track repeat, disc repeat, disc random, and all disc random.

Disc Name Preset (DNPS): When used with a compatible CD changer, this feature allows you to assign names to discs in the changer. Each name can be up to 8 characters in length. The number of names you can store depends on the CD changer that is connected to the head unit.

Disc Name Preset Play (DNPP): Once a disc has been named, you may press the DNPP button on the remote to display the name of each disc for 5 seconds. When the name of the desired disc appears, you can press the OK button on the remote to select the disc for playback.

Music Keg Compatible: This unit is fully compatible with the Kenwood Music Keg Digital Music System (models KHD-C710 and KHD-CX910).

Auxiliary Input: The KDC-MP925 is equipped with a built-in auxiliary input. There is a set of stereo RCA jacks on a 12-inch pigtail on the back of the receiver for connecting an external audio source. The Auxiliary input can be activated/deactivated through the menu. When it's activated, you can select one of six names for the source: Aux, TV, Video, Game, Portable or DVD. When deactivated, Auxiliary does not appear as a source. With an optional adapter (item 113CAC1AX or 113KCAS210), you can also turn the unit's CD changer input into a second auxiliary input.

Note

Display Illumination/Clock Display: When the unit is in Standby mode, the face/button illumination is "keyed". In addition, while the unit is in Standby mode, the Clock Display can be turned on or off using the display control button (clock must be selected for the text display). When the Clock Display is turned on and the unit is in Standby mode, the Clock Display is also "keyed". Pressing and holding the Source (SRC) button turns the unit off completely.
