About the Pioneer GM-4300F
Upgrade your in-car listening experience with a Pioneer GM Series amplifier it'll provide the power and sound quality you're looking for, all in a reliable package you can count on.
The GM-4300F 4-channel amplifier produces plenty of juice, with 40 watts RMS per channel. Selectable frequency filters on each channel make this amp equally at home driving subwoofers or full-range speakers. High- and low-level inputs allow you to add the GM-4300F to almost any system, even a factory stereo, while preamp outputs simplify adding additional amps.
Product highlights:
- 4-channel car amplifier
- 40 watts RMS x 4 at 4 ohms (50 watts RMS x 4 at 2 ohms)
- 100 watts RMS x 2 in bridged mode (4-ohm stable in bridged mode)
- CEA-2006 compliant
- 4-channel selectable high- and low-pass filters (80 Hz, 12 dB per octave)
- MOSFET power supply
- speaker-level inputs
- preamp inputs and outputs
- fuse rating: 40A x 1
- 8-gauge power and ground leads recommended wiring and hardware not included with amplifier
- 11-13/16"W x 2-3/8"H x 11-13/16"D
- warranty: 1 year
- Our 60-day money-back guarantee
- MFR # GM-4300F
What's in the box:
Pioneer GM-4300F owner's manual
- 4-channel amplifier
- 40A fuse (installed)
- Two 4" Speaker-level input harnesses
- Four 3/4" Self-tapping screws
- Owner's Manual (English/French/Spanish)
- Warranty sheet
- Additional information sheet
REVIEWS
Customer reviews
Loading reviews...
Pioneer GM-4300F reviews
Average review:
Thanks for submitting your review
Customer photos
More details on the Pioneer GM-4300F
Features & specs
| Performance | ||
|---|---|---|
| RMS Power Output (Watts x Channels) |
40 x 4 | |
| Peak Power Output (Watts x Channels) | 80 x 4 | |
| Power at 2 Ohms (Watts x Channels) | 50 x 4 | |
| Bridged Power (Watts x Channels) | 100 x 2 | |
| Minimum Impedance Bridged | 4 | |
| Minimum Impedance Unbridged | 2 | |
| Minimum Impedance | 2 | |
| Best Frequency Response | 10-50k Hz | |
| THD at Rated RMS Power | 1% | |
| Signal to Noise Ratio | 80 dB | |
| Input Voltage | 14.4v | |
| Features | ||
| Amplifier Class | AB | |
| Low-Pass Crossover Frequency | 80 Hz | |
| Low-Pass Slope (dB/octave) | 12 dB/oct | |
| High-Pass Crossover Frequency | 80 Hz | |
| High-Pass Slope (dB/octave) | 12 dB/oct | |
| Bass Boost | No | |
| Bass Boost Frequency | N/A | |
| Fan Cooled | No | |
| Fuse Rating | 40 x 1 | |
| Speaker Level Inputs | Harness | |
| Preamp Outputs | 1 pair | |
| Width (inches) | 11-7/8 | |
| Height (inches) | 2-3/8 | |
| Depth (inches) | 11-7/8 | |
| Parts Warranty | 1 Year | |
| Labor Warranty | 1 Year | |
Product Research
Features
Inputs and Outputs Notes
Internal Crossovers: The amplifier's internal front and rear crossovers are 12dB/octave filters, independently selectable for high-pass, low-pass, or full-range operation. Each crossover is fixed at 80 Hz.
Preamp Outputs: The preamp output jacks provide a convenient source for daisy-chaining an additional amplifier without running an extra set of RCA cables from the front of the vehicle to the amplifier location. These outputs provide a full-range signal.
BFC (Beat Frequency Control) Switch: If you hear a beat while listening to an AM broadcast with your car stereo, change the BFC switch using a small standard tip screwdriver. The switch is located to the right of the speaker output terminals.
Power Connections: The power and ground connections are 0.531" wide screw terminals that will accommodate up to 4-gauge wire. The remote turn-on terminal is 0.325" wide and will accept up to 8-gauge wire. A Phillips-head or flat blade screw driver (not supplied) is required to tighten/loosen the terminals. Spade connectors are recommended for the power, ground, and remote wires.
Speaker Connections: The speaker terminals are also 0.325" wide and will accommodate up to 8-gauge wire. A Phillips-head or flat blade screw driver (not supplied) is required to tighten/loosen the terminals. Spade connectors are recommended for the speaker wires.
