Pioneer TS-W384C

Name: Pioneer TS-W384C
Brand: Pioneer
SKU: 130TSW384C
Rating: 5 (1 reviews)

15" 4-ohm Component Subwoofer

Item # 130TSW384C

Make sure the nuts and bolts on your vehicle are tightened before you crank up the TS-W384C from Pioneer.

Pioneer TS-W384C - Front

Make sure the nuts and bolts on your vehicle are tightened before you crank up the TS-W384C from Pioneer.

Need help?

Contact our Virginia-based experts.

1-844-221-4640

Discontinued item

Item # 130TSW384C

Shop all Pioneer Component Subwoofers

Need help?

Contact our Virginia-based experts.

1-844-221-4640

OVERVIEW

Make sure the nuts and bolts on your vehicle are tightened before you crank up the TS-W384C from Pioneer. Otherwise, this 15" monster will shake them loose in no time flat!

KEEP READING

Make sure the nuts and bolts on your vehicle are tightened before you crank up the TS-W384C from Pioneer. Otherwise, this 15" monster will shake them loose in no time flat!

The diamondplate foamed IMPP woofer cone is lightweight and rigid for excellent response and booming bass. The Voice Coil Cooling System works to dissipate heat and limit distortion, while a dual layer urethane surround will stand up to road and weather extremes. 1-year warranty.

Details:

frequency response 15-1,500 Hz
power range 50-350 watts RMS
peak power 700 watts
sensitivity 91 dB SPL
4-ohm impedance
top mount depth 6-11/16"
sealed box volume 2.0 cubic feet
ported box volume 2.2 cubic feet
single reflex bandpass box volume 1.5 cubic feet (sealed)/1.15 cubic feet (vented)

What's in the box:

Pioneer TS-W384C owner's manual

One 15" woofer
1 Strip of self-adhesive foam
8 Self-tapping screws
Instruction Manual
Warranty sheet

MFR #TS-W384C

REVIEWS

Loading reviews...

Pioneer TS-W384C reviews

Average review:

1 review

Thanks for submitting your review

Most reviews are processed and published within 5 business days. You will receive a confirmation email once your review has been published.

Filter by rating

Customer photos

Verified customer

Verified employee purchase

Pros:

Cons:

Have questions for

Crutchfield response

Helpful?

Yes

<< >>

DETAILS

Researched by Crutchfield's Pat M.

Features & specs


Size	15 -inch
Impedance	Other
Cone Material	Foamed IMPP Rigilite
Surround Material	Urethane
Ideal Sealed Box Volume (cubic feet)	2
Ideal Ported Box Volume (cubic feet)	2.2
Port diameter (inches)	4
Port length (inches)	8
Free-Air	No
Dual Voice Coil	No
Sensitivity	91 dB at 1 watt
Frequency Response	15 - 1500 Hz
Max RMS Power Handling	350
Peak Power Handling (Watts)	700
Top Mount Depth (inches)	6 11/16
Bottom Mount Depth (inches)	7 5/16
Cutout Diameter or Length (inches)	14 1/16
Vas (liters)	321.62
Fs (Hz)	20.7
Qts	0.308
Xmax (millimeters)	9.2
Parts Warranty	1 YEAR
Labor Warranty	1 YEAR

The Pioneer TS-W384C replaces these items:

Pioneer TS-W383C

Product Research

Features
Specifications

Features

Woofer: The TS-W384C has a Foamed IMPP (Injection Molded Polypropylene) Rigilite composite cone woofer. This process of cone molding assures a uniform cone thickness for superior linearity and clarity. The cone is lightweight and rigid for low distortion and superior bass response.

Dual-Layer Urethane Surround: The dual-layer urethane surround has very high internal loss, which reduces speaker cone distortion.

Voice Coil Cooling System: The Voice Coil Cooling System reduces voice coil heat, allowing for stable bass reproduction and reinforced power handling capability.

Long Voice Coil Design: The long voice coil design allows expanded piston motion for better linearity and improved power handling.

Extended Pole Yoke: The extended pole yoke extends the magnetic field, greatly improving linearity during large woofer excursions at high input levels.

Vented Pole Yoke: The vented pole yoke allows air circulation in the magnetic circuitry to ensure better heat dissipation.

Enclosure Compatibility: This woofer can provide extended bass in sealed, vented and bandpass enclosures (see the "Specifications" section for more information on enclosures).

Specifications

Recommended Sealed Box Volume: The sealed box sizes recommended by Pioneer range from 1.8 cu/ft to 2.2 cu/ft. Within this range, the ideal size recommended by Pioneer is 2.0 cu/ft, so this is the enclosure recommended by Crutchfield.

Vented Box Volume: The vented box sizes recommended by Pioneer range from 1.98 cu/ft to 2.42 cu/ft. Within this range, the ideal size recommended by Pioneer is 2.2 cu/ft, so this is the enclosure recommended by Crutchfield. One 4" diameter x 8" long port should be used with a 2.2 cu/ft enclosure.

Single Reflex Bandpass Volume: The bandpass box sizes recommended by Pioneer range from 2.385 cu/ft to 2.915 cu/ft. Within this range, the ideal size recommended by Pioneer is 2.65 cu/ft, so this is the enclosure recommended by Crutchfield. The 2.65 cu/ft enclosure should have a sealed chamber volume of 1.5 cu/ft and a vented chamber volume of 1.15 cu/ft. One 4" diameter x 5" long port should be used with a 2.65 cu/ft enclosure.
