About the Pioneer TS-Z10LS2

Product highlights:
- 10" subwoofer with 2-ohm voice coil
- injection-molded aramid fiber/cellulose fiber cone
- butyl rubber surround
- lightweight die-cast aluminum basket
- handles up to 400 watts RMS (1300 watts peak)
- frequency response: 20-3800 Hz
- sensitivity: 80 dB
- mounting depth: 3-3/16"
- grille not included
- warranty: 1 year
- MFR # TS-Z10LS2
- Item # 130TSZ10L2
What's in the box:
Pioneer TS-Z10LS2 owner's manual
If you need assistance accessing this owner's manual, please give us a call.- One 10" Shallow mount subwoofer
- Six 1-1/8" Self-tapping screws
- Rubber gasket (installed)
- Manual (English/ German/ French/ Spanish/ Portuguese/ Italian/ Russian)
- Warranty information
More details on the Pioneer TS-Z10LS2

Features & specs
Features and Specs | ||
---|---|---|
Size | 10-inch | |
Impedance (Ohms) | 2 | |
Cone Material | Woven Aramid Fiber/Cellulose Fiber | |
Surround Material | Butyl Rubber | |
Basket Material | Aluminum | |
Grille | None included | |
Free-Air | Yes | |
Dual Voice Coil | No | |
Sensitivity |
74 dB at 1 watt | |
Frequency Response | 20 - 3800 Hz | |
Max RMS Power Handling | 400 | |
Peak Power Handling (Watts) | 1300 | |
Top Mount Depth (inches) | 3 1/4 | |
Bottom Mount Depth (inches) | N/A | |
Cutout Diameter or Length (inches) | 9 1/16 | |
Frame Width | 11.184 | |
Frame Length | 11.184 | |
Vas (liters) | 23.1 | |
Fs (Hz) | 34 | |
Qts | 0.48 | |
Xmax (millimeters) | 9.4 | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year | |
Box Requirements | ||
Ideal Sealed Box Volume (cubic feet) | 0.6 | |
Minimum Sealed Box Volume (cubic feet) | 0.35 | |
Maximum Sealed Box Volume (cubic feet) | 0.7 | |
Ideal Ported Box Volume (cubic feet) | 0.6 | |
Minimum Ported Box Volume (cubic feet) | 0.5 | |
Maximum Ported Box Volume (cubic feet) | 0.7 | |
Port diameter (inches) | 3 | |
Port length (inches) | 7.5 |
Product Research
Features
Terminals: The spring post terminals will accept pin connectors, single banana plugs, or bare wire up to 10 gauge.
Sealed Box Volume: The sealed box sizes recommended by Pioneer range from 0.35 ft³ to 0.7 ft³; within this range the ideal size is 0.6 ft³.
Vented Box Volume: The vented box sizes recommended by Pioneer range from 0.5ft³ to 0.7 ft³; within this range the ideal size is 0.6 ft³ with a single 3" diameter x 7.5" long port.
Free-Air: The woofer can also be mounted in free air to a baffle board (infinite baffle, no enclosure). When mounted in free air, the power handling is reduced by 75% (to 100 watts).
