Technics SL-BD20D

Controls
Special Features
Specifications
Notes

Controls

On the front of the turntable (outside the dust cover) are a:

• Stop Button
• Cueing (tonearm up/down) switch
• Speed (33/45 RPM) switch

Under the dust cover, near the tone arm pivot point are two adjustment screws. One screw adjusts the automatic-return position and is located to the left of the tonearm pivot point; the screw is recessed and covered by a rubber cap. The other adjustment screw is used to set the stylus-to-disc clearance and is located in front of the pivot point; the screw is slightly recessed and is brass colored.

Special Features

This is a semi-automatic turntable. To begin playback, you must cue up the tonearm, move the tonearm to the playing position, then cue down the tone arm. At the end of a record (or if the "STOP" button is pressed), the tonearm will automatically return to the arm rest and the platter will stop rotating.

The turntable will play at 33 1/3 and 45 RPM speeds. An adapter is included for playing 45 rpm records. There is a stud located to the left of the tonearm pivot that the 45 rpm adapter slips onto when not in use.

There are provisions for adjusting the automatic return position and the stylus-to-disc clearance.Tracking force and anti-skating settings are done at the factory and are not user adjustable.

P Mount Cartridge: This turntable uses a P Mount cartridge (supplied). This type of cartridge requires very little setup (it simply plugs in to the end of the tonearm) and is easily user replaceable.

Specifications

Supplied Cartridge:

• frequency response: 20-30kHz
• channel separation: 22dB (@ 1kHz)
• tracking force: 1.25 grams (+/- 0.25 grams)
• type: moving magnet stereo
• mounting: standard mount style
• replacement stylus: EPS-34CS


Notes

When first unpacked the turntable cover, platter mat, and drive belt are not in their operational positions. Assembly and preparation involves:

1) Removing two packing spacers (transport keys) from the turntable platter.

2) Removing blue foam spacer from beneath the counterweight.

3) Removing small plastic tonearm retaining strap.

4) Pulling the drive belt over the capstan.

5) Placing the platter mat onto the platter.

6) Sliding the dust cover into hinges at the rear of the turntable.

7) Removing plastic stylus protector.

NOTE: Tracking force and anti-skating adjustments are set at the factory and should not require user modification. Since tracking force and anti-skating are not adjustable, only the supplied cartridge should be used. We do not stock this part, but the replacement stylus (Part number EPS-34CS) can be ordered from Panasonic/Technics. This cartridge is a standard P-Mount cartridge, so you could mount another P-Mount Cartridge, but unless it has the same weight, etc. it may not be a good match for this unit.
