Ring Alarm Keypad (2nd Generation) Control pad for Ring Alarm system

Item # 1694AK1SZ

Your Ring Alarm kit came with a keypad, but you can expand your system with additional keypads for added convenience.

Your Ring Alarm kit came with a keypad, but you can expand your system with additional keypads for added convenience.

Item # 1694AK1SZ

Every order includes

  • Free lifetime tech support
  • 60-day price-drop protection
  • 60-day returns
In stock
$49.00

Get questions answered fast & free

Expert help 400+ hours training Virginia-based

About the Ring Alarm Keypad (2nd Generation)

Emily S.

Product highlights:

  • additional keypad for Ring 5-piece and 8-piece Alarm systems
  • arm and disarm the system, bypass certain sensors, or trigger the alarm
  • three security modes:
    • "Disarmed" deactivates your sensors and allows you to move freely throughout the house
    • "Away" activates all your sensors to protect your home while you're away
    • "Home" only activates select sensors to give you flexibility
  • acts as a second siren when Ring Alarm is triggered
  • emergency buttons for police, fire, and medical response (with optional Ring Home plan)
  • includes quick-release bracket for wall mounting
  • "duress code" option appears to disarm the system but triggers police emergency response (with optional Ring Home plan)
  • can also be used as a portable keypad
  • add a second keypad at the back door, garage, or second floor for convenient control
  • 250-foot range to base station
  • dual power
    • AC adapter and rechargeable battery included
  • 4-3/16"W x 4-7/16"H x 3/4"D
  • warranty: 1 year
  • MFR # B07ZB2DFMB
  • Item # 1694AK1SZ

What's in the box:

Ring Alarm Keypad (2nd Generation) owner's manual

If you need assistance accessing this owner's manual, please give us a call.
  • Ring Alarm keypad
  • Mounting bracket / tabletop stand (attached)
  • AC adapter with USB Type A port (Output: 5V 1A)
  • 79" USB cable (Type A USB on one end and a Micro-B USB on other end)
  • Two M3 x 20mm flat head screws
  • 2 Plastic wall anchors
  • Pinhole tool
  • Quick Start Guide
  • Important Product Information
  • Ring Keypad Z-Wave Device Specific Key (DSK)

More details on the Ring Alarm Keypad (2nd Generation)

Mark G.
The Ring Alarm Keypad (2nd Generation) replaces these items:

Product Research

Features

Overview: The Ring Alarm Keypad (2nd generation) lets you arm or disarm your Ring system when you don't have access to your smartphone or the Ring App. It connects to the alarm Base Station via Z-Wave, which gives you a 250-foot range. This allows you to place additional keypads in your garage, bedroom, upstairs, basement, or other convenient locations. The Keypad features numeric keys 0 through 9, "X" and "checkmark" buttons, and LED indicators. The Ring Alarm is protected by a unique 4-digit Owner's Access Code, which is entered on the keypad or the Ring App.

Alarm Mode Buttons: The three mode buttons at the top of the keypad are backlit in blue to indicate the current connection status of the device:

  • Away: All of the connected sensors are activated.
  • Disarmed: No sensors are activated, allowing you to freely move about your house.
  • Home: Select sensors can activated, while leaving others turned off. For example, you can turn off the Motion Detectors while you're at home, but keep the Contact Sensors activated to protect your doors and windows.

Panic Mode: You can trigger the Panic Mode by simultaneously pressing the "X" and "checkmark" buttons on the keypad.

Emergency Responses: The Ring Alarm Keypad has three Emergency Response buttons (for fire, police, and rescue) that allow you to request emergency services via the optional Ring Protect Plus paid subscription. Protect Plus features a professional monitoring service which will call your local emergency services when you press one of the Emergency Response buttons.

Keypad Placement: The Keypad comes with a reversable quick-release bracket. The bracket has three keyhole slots for wall-mounting the device using the two provided screws and wall anchors. Flipping the bracket and attaching the Keypad to the other side creates an angled, tabletop base.

Power Requirements: The Keypad comes with a 79" USB cord and an AC adapter that plugs into to any standard power outlet. The built-in rechargeable battery keeps the keypad operating during power outages, or when used as a portable keypad.

The Ring Alarm Keypad (2nd Generation) replaces these items:


Adding...
  • use to arm and disarm the system, bypass certain sensors, or trigger the alarm
  • 250-foot range to base station
  • three security modes: home, away, and disarmed
