About the Kicker 52CVTDF122

Product highlights:
- sealed downward-firing enclosure with one 12" CompVT subwoofer
- 3/4" medium-density fiberboard construction covered with carpet
- 2-ohm total impedance
- frequency response: 25-500 Hz
- power handling: 450 watts RMS (900 watts peak)
- sensitivity: 93.6 dB
- dimensions: 21.5"W x 7.5"H1 x 5.63"H2 x 14.75"D
- warranty: 1 year
- MFR # 52CVTDF122
- Item # 20652CF122
What's in the box:
Kicker 52CVTDF122 owner's manual
If you need assistance accessing this owner's manual, please give us a call.- Down-firing enclosure loaded with one 12" CompVT 2-ohm subwoofer
- 4 Mounting brackets
- Four 1" screws
- Eight 3/4" screws
- Owner's manual
More details on the Kicker 52CVTDF122

Features & specs
General | ||
---|---|---|
Woofer Size (inches) | 12 | |
Speakers Per Box | 1 | |
Woofer Material | Polypropylene | |
Enclosure Type | Sealed | |
Color | Black | |
Pieces in System | 1 | |
Width (inches) | 21-1/2 | |
Height (inches) | 7-1/2 | |
Depth (inches) | 14-3/4 | |
Connector Type | Spring post | |
Frequency Response | 25-500 Hz Hz | |
Power Handling (Watts RMS) | 450 | |
Power Handling (Watts Peak) | 900 | |
Sensitivity | 93.6 dB | |
Impedance | 2 ohms | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year |
Product Research
Features
Comp Woofer: The Kicker 52CVTDF122 enclosure is loaded with one 12" CompVT series subwoofer. The Kicker subwoofer features a stiff injection-molded polypropylene cone with 360-degree back bracing. The ribbed, UV-treated surround and cone are attached using Kicker's signature red stitching, providing an outstanding bond. Full perimeter venting allows air to move freely around the motor for excellent heat management, while a UniPlate backplate and pole piece provide outstanding thermal management for the voice coil.
Down-Firing Enclosure: The sealed down-firing enclosure is made of heavy-duty MDF (Medium Density Fiberboard) with extensive internal bracing, providing exceptional acoustic efficiency and deep powerful bass. The enclosure is covered in sleek black carpeting for added protection and a refined look. Its compact, down-firing form allows it to be mounted in cargo areas, or under seats, while its heavy-duty construction lets you stack cargo on top of it without affecting the bass quality.
Speaker Terminals: A single pair of spring-posts are mounted on the underside of the enclosure in a recessed terminal cup, and will accept pin connectors, single banana plugs, or bare wire up to 8-gauge.
Power: The single 2-ohm CompVT subwoofer can handle 225W-450W RMS (900W peak).
Break-in Period: Due to the complex nature of Kicker CompVT speakers, they require a break-in period in order to produce optimum low-bass response. The suspension system is very stiff out-of-the-box. Approximately two weeks of daily playing will allow the suspension to break-in and reach its optimum equilibrium. Once broken-in, the subwoofer will exhibit stronger bass performance, smoother response, and greater low-bass extension.
The Kicker 52CVTDF122 replaces these items:
- 3/4" medium-density fiberboard construction covered with carpet
- 2-ohm total impedance
- power handling: 400 watts RMS (800 watts peak)
