Features

Woofer Size Classification Note: Some manufacturers, including Morel, call this size woofer a 6½". Because it requires a larger cutout than a standard 6½" speaker, Crutchfield has traditionally referred to this size woofer as 6¾". Please enter your vehicle information to confirm fit.

Controlled Acoustic Resistance: Car speakers are typically installed in free-air applications, providing minimal acoustic loading. Morel uses Controlled Acoustic Resistance (C.A.R. Filter) in both the woofers and midrange to improve the acoustic loading by controlling airflow within the driver, mimicking the effects of an enclosure. This provides greater control over the diaphragm movement for improved bass dynamics.

Midrange Size: The midrange drivers are not a standard size, approximately 3½" diameter. They can be top or bottom mounted, and have these dimensions:

• Top mount depth: 0.83"
• Mounting height: 0.55" (0.625" including the grille)
• Flange height: 0.287"
• Bottom mount depth: 1.117"
• Tweeter Protrusion: 0.263"
• Cutout diameter: 2.985"
• Frame diameter: 3.521"

Factory Midrange Replacement: If the midrange drivers are mounted in a factory 3½" location, four of the included mounting clips should be used. Because the dome is very delicate, I also recommend using the included grilles.

Tweeter Mounting Options: The tweeter can be surface or flush mounted using the included adapters. The surface mount housing angles the tweeters at approximately 45°.

Tweeter Dimensions:

Crossover: The outboard crossovers have screw terminal inputs and outputs (0.3" wide). A jumper inside each crossover allows you to adjust the tweeter output level; choose -2 dB, 0 dB, or +2 dB. The woofers' low pass crossover is 12 dB/octave at 500 Hz. The midrange's high pass crossover is 18 dB/octave at 500 Hz and low pass is 12 dB/octave at 2.2 kHz. The tweeters' high pass crossover is 6 dB/octave at 2.2 kHz.

Crossover Dimensions:

• Width: 5.54"
• Height: 1.46"
• Depth: 4.17"
