About the Morel Maximo Ultra Coax 502 MKII

Product highlights:
- 2-way 5-1/4" speakers (pair)
- treated paper composite woofer cone with butyl rubber surround
- soft dome textile tweeter
- built-in Morel Crossover Resolution (MXR) crossover
- handles up to 80 watts RMS (140 watts peak power)
- frequency response: 55-20,000 Hz
- sensitivity: 89.5 dB at 2.83 V
- mounting depth: 2-1/16"
- grilles included
- warranty: 1 year
- MFR # 350145-220
- Item # 210MU502X
What's in the box:
Morel Maximo Ultra Coax 502 MKII owner's manual
If you need assistance accessing this owner's manual, please give us a call.- Two 2-way speakers
- 2 Grilles
- 2 Grille frames
- Grille putty
- Eight 1" Screws
- 8 Speed clips
- Two 0.187" Crimp-on female quick slides
- Two 0.110" Crimp-on female quick slides
- Two 0.187" Quick slide insulating covers
- Two 0.110" Quick slide insulating covers
- Installation instructions
- Morel window sticker
Featured video:
More details on the Morel Maximo Ultra Coax 502 MKII

Features & specs
General | ||
---|---|---|
Speaker Size | 5 1/4 | |
Driver Design | 2-way | |
Woofer Design | Cone | |
Woofer Material | Treated Paper | |
Woofer Surround | Rubber | |
Midrange Design | --- | |
Midrange Material | --- | |
Tweeter Design | Dome | |
Tweeter Material | Textile | |
Super Tweeter Design | --- | |
Super Tweeter Material | --- | |
Impedance (Ohms) | 4 | |
Weather-resistant | No | |
Grilles Included | Black, Steel mesh, Plastic frame | |
Parts Warranty | 1 Year | |
Labor Warranty | 1 Year | |
Specifications | ||
Sensitivity (1W at 1 meter) | N/A | |
Sensitivity at 2.83 volts | 89.5 | |
Frequency Response | 55 - 20k Hz | |
Maximum RMS Wattage | 80 | |
Peak Power Handling (Watts) | 140 | |
Top-mount Depth (Inches) | 2 1/16 | |
Bottom-mount Depth (Inches) | N/A | |
Cutout Diameter or Length (inches) | 4 7/16 | |
Mounting Height (Inches) | 0.351 | |
Frame Width | 5.075 | |
Frame Length | 5.075 |
The Morel Maximo Ultra Coax 502 MKII replaces these items:
- treated paper composite woofer cone with butyl rubber surround
- soft dome textile tweeter
- handles up to 70 watts RMS (140 watts peak power)
- treated paper composite woofer cone with butyl rubber surround
- soft dome textile tweeter
- handles up to 70 watts RMS (140 watts peak power)
Loading...
Loading accessories...
Customer Q&A
Loading...
Loading articles...
I installed these in my 2004 911 Cab in the front door panels and fit right in with out mods. Sound much better than the stock Bose speakers from 2004. Great advise from Jody to buy these.
Steven from Hollister, CA
