MTX 3512-02 35 Series 12" 2-ohm subwoofer

Name: MTX 3512-02
Brand: MTX
SKU: 236351202
Price: 119.95 USD
Availability: InStock
Rating: 4.5 (6 reviews)

Item # 236351202

MTX's 35 Series subs prove once again that you can pack a lot of technology into an affordable subwoofer.

Front

1/6

Back

2/6

Only at Crutchfield

3/6

Only at Crutchfield. No pressure. And no commissions! Our experts help you get what you need and will never upsell you. No sweat. We do the research, so you get the best info, the best instruction, and the best tech support. All for free. No regret. With 60-day price protection and returns, you can feel good about your purchase – or send it back. Legendary Service. Since 1974.

MTX's 35 Series subs prove once again that you can pack a lot of technology into an affordable subwoofer.

Item # 236351202

Free 1-day shipping to Virginia

Every order includes

Free lifetime tech support
60-day price-drop protection
60-day returns

In stock

$119.95 each

Add to cart

Add to wishlist

Compare products

Get questions answered fast & free

Expert help 400+ hours training Virginia-based

1-888-955-6000

by Crutchfield's Dave Delamere

Another strong member of the family

MTX's 35 Series subs prove once again that you can pack a lot of technology into an affordable subwoofer. This 12” 2-ohm sub shows off many of the features that MTX originally developed for their top-of-the-line subs. That means you get a sub that performs the way you want, delivering great low-end bump with impressive accuracy. And MTX protects this sub with a 2-year warranty.

The heart of the matter

The Inverted Apex Surround increases the cone's surface area for better volume displacement and a higher SPL. This sub's sophisticated suspension system offers better control over cone movement for more refined bass. MTX's venting system keeps the voice coil cooler for optimum performance over the long haul. Put this 2-ohm model in a sealed or ported enclosure, power it with a mono amp, and you've just created a cost-effective recipe for adding a solid kick to your music.

Product highlights:

12" 2-ohm subwoofer
polypropylene cone with nitrile-butyl rubber surround
power range: 125-250 watts RMS (500 watts peak power)
frequency response: 28-130 Hz
sensitivity: 86.23 dB
top-mount depth: 5-1/4"
sealed box volume: 1.00 cubic feet
ported box volume: 2.32 cubic feet
warranty: 2 years
MFR # 3512-02
Item # 236351202
California customers: Please click here for your Proposition 65 WARNING.

What's in the box:

MTX 3512-02 owner's manual

One 12" Single voice coil subwoofer
Specifications

Researched by Crutchfield's Pat M.

Features & specs

Features and Specs
Size	12-inch
Impedance (Ohms)	2
Cone Material	Polypropylene
Surround Material	Rubber
Basket Material	---
Grille	None included
Free-Air	No
Dual Voice Coil	No
Sensitivity	92.6 dB at 2.83 volts 86.23 dB at 1 watt
Frequency Response	26 - 130 Hz
Max RMS Power Handling	250
Peak Power Handling (Watts)	500
Top Mount Depth (inches)	5 1/4
Bottom Mount Depth (inches)	N/A
Cutout Diameter or Length (inches)	11 1/16
Frame Width	12.324
Frame Length	12.324
Vas (liters)	73.1
Fs (Hz)	30.4
Qts	0.645
Xmax (millimeters)	8.128
Parts Warranty	2 Years
Labor Warranty	2 Years
Box Requirements
Ideal Sealed Box Volume (cubic feet)	1
Minimum Sealed Box Volume (cubic feet)	N/A
Maximum Sealed Box Volume (cubic feet)	N/A
Ideal Ported Box Volume (cubic feet)	2.32
Minimum Ported Box Volume (cubic feet)	1.83
Maximum Ported Box Volume (cubic feet)	2.785
Port diameter (inches)	N/A
Port length (inches)	N/A

Product Research

Features
Enclosure Compatibility

Features

Terminals: The woofer features heavy-duty spring post terminals which can accept single or dual (standard 3/4" width) banana plugs, pin connectors, or bare wire up to 10-gauge.

Inverted Apex Surround: The new Inverted Apex surround allows increased cone surface area, creating more air movement and higher SPL.

Progressive Suspension: The progressive suspension controls excursion at high power, thus reducing distortion and improving sound quality.

Spider Plateau Venting: Heat from the voice coil is vented through vents that surround the back of the spider. As the woofer travels back and forth, cool air is pulled in and heated air is pushed out.

Enclosure Compatibility

Sealed Box: For the best possible sound quality where space is a premium MTX recommends a sealed enclosure with an internal volume of 1.0 ft³. Sealed enclosures provide the most control over a woofer, will handle a lot of power, and provide accurate sonic reproduction, making them suitable to all types of music.

Vented Box: The recommended vented box has a net internal volume of 2.32 ft³ with a slot port 13-3/4" x 2-1/2" x 26-1/4". Vented (or ported) enclosures typically provide better overall efficiency than sealed so they are suitable for use with smaller amplifiers, giving you more bass output from less power.

Loading accessories...

2 questions already asked

I have the dual 12 MTX terminator box, can I swap these subs for the ones it comes with?

jeff Jul 24, 2022

1 answer

We haven't tested this swap, but based on the measurements, it should work. For additional help with this project, please give our advisors a call at 1-800-324-9695.

zachary Jul 24, 2022 (Staff)

What amp would you recommend to power two mtx 3512-02 subs?
